Orion GST-412 User manual

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
their own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
CAUTION :To prevent electric shock and risk of fire hazards:
ōDo NOT use power sources other than those specified.
This installation should be made by a qualified service person and
should conform to all local codes.
2. Safety Instructions
s This camera should be installed by qualified personnel only
s There are no user serviceable parts inside
s Do not disassemble this camera other than to make initial adjustments
s Use a UL approved regulated 24 volt AC or 12 volt DC power supply
s Use appropriate low voltage power cable to prevent fire or electrical shock
s Please insure that your installation area can support the weight of the camera
s Do not use a strong or abrasive detergent when cleaning the camera
s Do not expose the camera to direct sun
s Do not install camera in places where humidity is high
s Do not install near cooling or heating device
s Do not expose camera to rain or moisture
Precautions for use
Please handle this camera carefully
1. Precautions
Do not install the camera in
extreme temperature conditions.
Do not touch the front lens of the
camera.
Do not expose the camera to rain
or spill liquids on it.
Do not install or use the camera in an
environment where the humidity is high.
%POPUJOTUBMMPSVTFUIFDBNFSBJOBO
FOWJSPONFOUXIFSFUIFIVNJEJUZJTIJHI
Never keep the camera pointed
directly at strong light.
Do not expose the camera to
radioactivity.
Do not install the camera under
unstable lighting conditions.
Do not drop the camera or subject
it to physical shocks.
Only use the camera under conditions
where temperatures are between
-10°C and +50°C. Be especially careful to
provide ventilation when operating under
high temperatures.
This is one of the most important parts of
the camera. Be careful not to leave
fingerprints on the lens cover.
If it gets wet, wipe dry immediately.
Liquids can contain minerals that
corrode the electronic components.
It can cause malfunctions to occur.
If exposed to radioactivity the CCD
will fail.
Severe lighting change or flicker can
cause the camera to work improperly.
Housing damage can compromise
weatherproof ratings.
NOTE
* If the camera is exposed to
spotlight or object reflecting
strong light, smear or
blooming
may occur.
* please check that the power
satisfies the normal
specification before
connecting the camera.
1| Digital Video Security Systems 2| Digital Video Security Systems
3| Digital Video Security Systems 4| Digital Video Security Systems
GST-412
DNR Dome True Day/Night
Weather-Proof Camera
3B050012465A

Digital Video Security Systems
6| Digital Video Security Systems
8| Digital Video Security Systems
5| Digital Video Security Systems
7| Digital Video Security Systems
VIDEO TEST CABLE
1EA
Instruction Manual
1EA
SCREW
3EA
TORX WRENCH
1EA
8. Package
4. Key Features
5. Specifications
6. Cable Connection
7. Camera Connection
s3ONY(##$ s(IGH2ESOLUTION46,
sTH'ENERATION$30#HIP
s-IN)LLUMINATION,UX
s0RIVACY-ASKING:ONES
s.O.OISE'HOSTING%FFECTWITH$.2
s(IGHEST2ESOLUTION6IVID3HARP0ICTUREINCOMPLETELYDARKNESS
s4RUE$AY.IGHTWITH)#2
s$UAL0OWER!#6$#6
Camera
%!
*DC Auto Iris Varifocal Lens(2.8mm-12mm)
3. Dimension
OSD Control Board
True Day & Night
(True Day/Night with ICR) OSD
,%.3
3(544%230%%$
7()4%"!,
",#
!'#
$.2
3%.350
30%#)!,
%8)4
DC
%,#
ATW
()'(
OFF
LOW
OFF
DC Auto Iris Varifocal Lens
(2.8mm-12mm)
9,'(2\HOORZ
%1&
32:(5UHG
'&9
32:(5
3RZHU 9LGHR6LJQDO
9LGHR*1'
3RZHU
9,'(2
WWW.ORION-TECHNOLOGY.EU
MAIL : [e-mail]
Sensor type
Effective pixels
Total pixels
Resolution
Scanning system
Min. illumination
Video Output
S/N Ratio
AGC
Sens-UP
Backlight Compensation
D-WDR
Privacy Masking
DIS(Digital Image Stabilizer)
Day & Night
White Balance
3DNR(2D or 3D)
Mirror
D-ZOOM
SMART DZOOM
DEFOG
Blemish Compensation
Poewr Source
Poewr Consumption
Lens
Storage Temperature
Operating Temperature
Dimension(W x H x D)
Weight
1/3" Sony 960H CCD
976 (H) X 494 (V) approx. 480K pixels (NTSC)
976 (H) X 582 (V) approx. 570K pixels (PAL)
1020 (H) X 508 (V) approx. 520K pixels (NTSC)
1020 (H) X 596 (V) approx. 610K pixels (PAL)
700TV Lines
2:1 Interlace
0.00001Lux(Sens-up*256)
1.0Vp-p Composite. 75 Ohms
52dB
Low / Middle / High
OFF/AUTO (X2 ~ X256)
OFF/BLC/HLC
OFF/INDOOR/OUTDOOR
8 Zone
OFF/ON
Auto(AGC)/Day/Night/Ext
ATW/AWB/AWC->SET/Manual(1,800K ~ 11,000K)
1 ~ 200 Level Selectable
H-Rev / V-Rev / ROTATE/PIP
X32
OFF/ON
OFF/MANUAL/AUTO
Auto(512POINT)
Dual Voltage
120mA
DC Auto Iris Varifocal Lens(2.8mm-12mm)
-20º ~ +60º(Humidity : 20%RH ~ 95%RH)
-10º ~ +50º(Humidity : 20%RH ~ 80%RH)
150mm(W) * 100mm(H) * 150mm(D)
1400g
