Orion GST-795h User manual

Chapter 1. Install and Specification
1.1 Safety Cautions
1.2 Package
1) This camera may be damaged by electrical and physical shock.
Use regulated 12V DC, 1A power supply. Do not throw or drop it onto floor.
2) In case it is installed at high location, be sure to mount securely to prevent the
unit from falling below.
3) In case the unit fails, Do not try to disassemble the product.
Contact or consult the distributor or an authorized technician for after-sales
service.
Warranty void for the product disassembled without an authorization from the
distributor or an authorized technician.
4) All responsibility by using this unit is on the user.
5) This producthas 2 models according to IR LED.
① SK-NV30(w/o IR)
② SK-NV30IR(with IR)
※This manual is based on SK-NV30IR.
1.4 Specification
1.4.1 Camera Specification
1.4.2 Camera Function
1.4.3 Network Specification
2
1.3 How to Install
1.3.1 Camera installation
Fix the camera set with the supplied screws on ceiling or wall mount. If you
don't use supplied screws, the camera may fall off.
Put a sticker on the ceiling and make holes according to the spots marked on
a sticker.
<Ceiling mount>
<Wall mount>
1.3.2 Camera Angle Adjustment
1.3.3 Lens Adjustment
1.3.4 Dimension
1) Pan adjustment : Grasp the disk of camera and then adjust direction to the
right or left(-160 ~ 190 )
2) Tilt adjustment : Grasp the LED cover ofcamera and then adjustdirection to
the up or down(6 ~ 90 )
3) Roll adjustment : Grasp the camera holder and then rotate(-178 ~ 178 )
After opening the LED cover,
1) ① By turning the "Tele-Wide" knob, you can
Access a range of focal lengths within specified limits.
2) ② Since then, by turning the "Near-Far" knob,
you can set the focus toward the wanted object.
° °
° °
° °
<Caution> If you try to adjust the camera out of limited angle, it mightcause troubles
and damage to camera.
3 4
6
1.4.4 Electric Specification
7 85
Software & User Manual CD
Screw Tp1 3EA4x25
Camera Quick Guide
If the product is to beput out of operation definitively, take it to a
local recycling plant for a disposal which is not harmful to the
environment.
1.4.7 Basic Setting Table
[Reference] In case to reset hardware and network setting, ID and password of user
and Administrator will be automatically returned to the above default value.
*Frame rate can be affected by the externalvideo output option.
So factory default is off. When you install the camera, enable this option. Then
disable it after the installation.
Static IP
Enable
192.168.1.30
192.168.1.1
255.255.255.0
80
554
5000 ~ 5999
admin/admin
root/root, guest/guest
iplinker.net
H.264 30fps@(1920x1080)
None
None
OFF
rtsp://<ip address>:554/stream1
rtsp://<ip address>:554/stream2
rtsp://<ip address>:554/stream3
After installation, deactivate it.
Network
Static IP/Dynamic IP
IP Server Enable
IP Address
Gateway
Subnet Mask
RTSP Port
RTP Port Range
ID and Password
User ID/Password
Domain of Related Server
DDNS Server
Stream setting
Stream 1
Stream 2
Stream 3
Video out*
Administrator
ID/Password
Web Connection
Port
Resolution
Min.Illumination
Model No.
Type
Image Sensor
Effective Pixels
Scanning System
IR LED
Lens
Item Specification
Specifications
Item
Specification Classification Item
Summary
Function
OS
Network Interface
Setting
Security
PC OS
Web Browser
Compression
Resolution
Compression Rate
Frame Rate
Bit Rate
Simultaneous Access
Video Recording
Motion Detection
Privacy Zone
OSD
Dynamic IP
IP Router
DDNS
Network Support
Supported Protocol
Embedded Linux
RJ45 10/100BaseT, Ethernet
By web browser
User authentication
WINDOWS XP, WINDOWS VISTA,WINDOWS7
IE 7.0 or higher
H.264, MPEG-4,MJPEG
200 : 1(Typical)
Max. 30fps(@1920X1080)
64 ~ 9000kbps
Max. 10 users
Support
Support
Support
Support
Support
Support
Leased Line, Cable Modem, Support Dynamic
IP and Static IP, ADSL usable under Router
TCP/IP, UDP/IP, RTP, RTSP, RTCP, NTP,
HTTP, DHCP, FTP, SMTP, DNS, DDNS
Recording in client PC with CMS or FTP Server
Classification Specification
Power Supply
Current Consumption
Operation Temp.
Dimension
Weight
Max. 1A(DC 12V) IR LED ON
-45~50℃
Ø150.5 x 95.6(H)mm
Approx. 4 00g
Regulated 12V DC, PoE(Power over Ethernet) - IEEE802.3af
Item Default(Basic setting) Remarks
Megapixel network vandal-proof dome camera
1/2.8" SONY PROGRESSIVE SCAN EXMOR CMOS
1984(H) x 1225(V)
Progressive Scan
Vari-focal auto iris megapixellens
24PCS
LED OFF : 0.01Lux
LED ON : 0Lux(25M Range)
1920x1080 / 1280x1024 /
1280x960 / 1280x720 / 1024x768 / 640x480 / 320x240
1920x1080 /
1280x1024 / 1280x960 / 1280x720 /
1024x768 / 640x480 / 320x240
Privacy Zone
Day&Night
WDR
Sense Up
White Balance
Function
ON / OFF(6 Programmable Zones)
Auto / Night / Day
WDR(1 ~ 5), (Back Light, Front Light)
Auto(1 ~ 14)
Auto / Indoor / Outdoor / Fluorescent / User
Auto : 1/25 ~ 1/5,000(NTSC), 1/12.5 ~ 1/8,000(PAL)
Suppress Rolling, Manual
Electronic Shutter
G4S-795
2 MEGA PIXEL
NETWORK VANDAL-PROOF
DOME CAMERA
GST-795h
QUICK GUIDE
SCREW Tp1 4X25 3EA
MOUNT HOLE PLATE(STICKER) Ø3.5
Ø30
SCREW Tp1 4X25 3EA
MOUNT HOLE PLATE(STICKER)
Ø3.5 Ø30
Put a sticker on the ceiling and make holes
according to the spots marked on a sticker
Put a sticker on the wall and make holes
according to the spots marked on a sticker
SCREW Tp1 4X25 3EA
MOUNT HOLE PLATE(STICKER) Ø3.5
Ø30
SCREW Tp1 4X25 3EA
MOUNT HOLE PLATE(STICKER)
Ø3.5 Ø30
Put a sticker on the ceiling and make holes
according to the spots marked on a sticker
Put a sticker on the wall and make holes
according to the spots marked on a sticker
LED COVER
DISK
ROTATION
U
D
R
L
CAMERA HOLDER
Ø100
Ø150.5
45
95.6
Ø129
1.3.2. Camera angle adjustment :
 (1)Pan adjustment : Grasp the
diskofcameraandthenadjust
direction to the right or left(-
160°~190°)
 (2)Tilt adjustment : Grasp the
LEDcoverofcameraandthen
adjust direction to the up or
down(6°~90°)
 (3)Roll adjustment : Grasp the
cameraholder andthen rotate
(-178°~178°)
 <Caution>If you try to adjust the camera out of limited angle, it might cause
troublesanddamagetocamera.
1.3.3 Lens Adjustment
 AfteropeningtheLEDcover,
  ①Byturningthe"Tele-Wide"knob,youcanaccessa
rangeoffocallengthswithinspecifiedlimits.
  ②Sincethen,byturningthe"Near-Far"knob,youcan
setthefocustowardthewantedobject.
1.3.4 Sllica gel
 When installed in high humidity area, take out silica gel
from polythene bag then put silica gel into the dome
camera.
 *Mustusesilicagelfromsealedpolythenebag.
1.3.5 Dimension
1.3 How to Install
1. Camera installation
 (1)Fixthecameraset with thesuppliedscrewsonceilingorwallmount.Ifyou
don'tusesuppliedscrews,thecameramayfalloff.
 (2)Putastickeronthecellingandmakeholesaccordingtothespotsmarkedon
asticker.
<Ceilingmount>
<Wallmount>
SCREW Tp1 4X25 3EA
MOUNT HOLE PLATE(STICKER) Ø3.5
Ø30
SCREW Tp1 4X25 3EA
MOUNT HOLE PLATE(STICKER)
Ø3.5 Ø30
Put a sticker on the ceiling and make holes
according to the spots marked on a sticker
Put a sticker on the wall and make holes
according to the spots marked on a sticker
SCREW Tp1 4X25 3EA
MOUNT HOLE PLATE(STICKER) Ø3.5
Ø30
SCREW Tp1 4X25 3EA
MOUNT HOLE PLATE(STICKER)
Ø3.5 Ø30
Put a sticker on the ceiling and make holes
according to the spots marked on a sticker
Put a sticker on the wall and make holes
according to the spots marked on a sticker
1
2w
NFT
LED COVER
DISK
ROTATION
U
D
R
L
CAMERA HOLDER
Ø100
Ø150.5
45
95.6
Ø129
Ifthe productistobeput outofoperationdefinitively,takeittoalocal
recyclingplantforadisposalwhichisnotharmfultotheenvironment.
1.2 Packge
Camera
2MEGA PIXEL
NETWORK VANDAL-PROOF
DOME CAMERA
GST-795h
QUICK GUIDE
QuickGuide
Wrench ASealed
silicagel
Mounthole
plate(sticker)
Software&UserManualCD
Screw4x25
Tp13EA
Item Specification
ModelNo. GST-795h
Type 2MPnetworkvandal-proofdomecamera
ImageSensor 1/2.8”SONYIMX291STARVIS
Numberofeffectivepixels 1945(H)×1097(V)approx
Stream MultipleStream
Resolution
Main Stream 1
1920×1080,1280x1024,1280x960,1280x720
Sub-stream2
1280x720,800x600,704x576,640×360,
640x480,352x288,352x288,
320x288,320x176
Sub-stream 3
704x576,640x480,640×360,352x288,320x288,320x176
EncodeType H.264Baseline/H.264MainProfile/H.264HighProfile/
H.265MainProfile
Min.llumination IRLEDOFF:0.01Lux
IRLEDON:0Lux(25MRang)
IRLED 24PCS
AlarmInput/Output Input:1,Output:1
Lens Vari-focalirismegapixellens
1.4.2 Image Function
Imagesettings Rotatemode,saturation,brightness,contrast,
adjustablethrough
Day&Night Auto/Day/Night
WDR WDR(Disable,Low,High)
ElectronicShutter 1/5sto1/50,000s
PrivacyMask On/Off(4ProgrammableZones)
WhiteBalance Auto,Cloudy,Sunny,Fluorescent,Tungsten
ROI Upto4configurableareas.
1.4.3 Interface
Interface
Audioinput 1-chRCAaudiointerface
Audiooutput 1-chRCAaudiointerface
Communicationinterface RJ4510M/100Methernetport
AlarmI/O Alarminput:1,Alrmoutput:1
Videooutput 1Vp-pcompositeoutput(75Ω/BNC)
1.4.4 Electric Specification
1.4.5 Alarm input/Output
1.4.6 Audio input/Output
MIC(Red)
LINE OUT(Black)
1.4.7 Basic setting Table.
Item Default setting Remarks
Network
Static IP/
DHCP StaticIP
IP address 192.168.1.30
Subnet mask 255.255.255.0
Gateway 192.168.1.1
Web Port 80
RTSP port 554
Upnp Disable
Date&Time GMT+01:00
Resolution 1920x1080,640x360 Mainstream:1920x1080,25fps,
Substream:640x360,25fps
ID/Password admin/admin
Stream setting
Stream1 H.2641920x1080,25fps rtsp://[ipaddress]:554/media/live/1/1
Stream2 H.264640x360,25fps rtsp://[ipaddress]:554/media/live/1/2
Stream3 H.264,352x288,25fps rtsp://[ipaddress]:554/media/live/1/3
Chapter 1. Install and Specification
1.1 Safety Cautions
1.2 Package
1) This camera may be damaged by electrical and physical shock.
Use regulated 12V DC, 1A power supply. Do not throw or drop it onto floor.
2) In case it is installed at high location, be sure to mount securely to prevent the
unit from falling below.
3) In case the unit fails, Do not try to disassemble the product.
Contact or consult the distributor or an authorized technician for after-sales
service.
Warranty void for the product disassembled without an authorization from the
distributor or an authorized technician.
4) All responsibility by using this unit is on the user.
5) This producthas 2 models according to IR LED.
① SK-NV30(w/o IR)
② SK-NV30IR(with IR)
※This manual is based on SK-NV30IR.
1.4 Specification
1.4.1 Camera Specification
1.4.2 Camera Function
1.4.3 Network Specification
2
1.3 How to Install
1.3.1 Camera installation
Fix the camera set with the supplied screws on ceiling or wall mount. If you
don't use supplied screws, the camera may fall off.
Put a sticker on the ceiling and make holes according to the spots marked on
a sticker.
<Ceiling mount>
<Wall mount>
1.3.2 Camera Angle Adjustment
1.3.3 Lens Adjustment
1.3.4 Dimension
1) Pan adjustment : Grasp the disk of camera and then adjust direction to the
right or left(-160 ~ 190 )
2) Tilt adjustment : Grasp the LED cover of camera and then adjustdirection to
the up or down(6 ~ 90 )
3) Roll adjustment : Grasp the camera holder and then rotate(-178 ~ 178 )
After opening the LED cover,
1) ① By turning the "Tele-Wide" knob, you can
Access a range of focal lengths within specified limits.
2) ② Since then,by turning the "Near-Far" knob,
you can set the focus toward the wanted object.
° °
° °
° °
<Caution> If you try to adjust the camera out of limited angle, it might cause troubles
and damage to camera.
3 4
6
1.4.4 Electric Specification
7 85
Software & User Manual CD
Screw Tp1 3EA4x25
Camera Quick Guide
If the product is to beput out of operation definitively, take it to a
local recycling plant for a disposal which is not harmful to the
environment.
1.4.7 Basic Setting Table
[Reference] In case to reset hardware and network setting, ID and password of user
and Administrator willbe automatically returned to the above default value.
*Frame rate can be affected by the external video outputoption.
So factory default is off. When you install the camera, enable this option. Then
disable it after the installation.
Static IP
Enable
192.168.1.30
192.168.1.1
255.255.255.0
80
554
5000 ~ 5999
admin/admin
root/root, guest/guest
iplinker.net
H.264 30fps@(1920x1080)
None
None
OFF
rtsp://<ip address>:554/stream1
rtsp://<ip address>:554/stream2
rtsp://<ip address>:554/stream3
After installation, deactivate it.
Network
Static IP/Dynamic IP
IP Server Enable
IP Address
Gateway
Subnet Mask
RTSP Port
RTP Port Range
ID and Password
User ID/Password
Domain of Related Server
DDNS Server
Stream setting
Stream 1
Stream 2
Stream 3
Video out*
Administrator
ID/Password
Web Connection
Port
Resolution
Min.Illumination
Model No.
Type
Image Sensor
Effective Pixels
Scanning System
IR LED
Lens
Item Specification
Specifications
Item
Specification
Classification Item
Summary
Function
OS
Network Interface
Setting
Security
PC OS
Web Browser
Compression
Resolution
Compression Rate
Frame Rate
Bit Rate
Simultaneous Access
Video Recording
Motion Detection
Privacy Zone
OSD
Dynamic IP
IP Router
DDNS
Network Support
Supported Protocol
Embedded Linux
RJ45 10/100BaseT, Ethernet
By web browser
User authentication
WINDOWS XP, WINDOWS VISTA, WINDOWS 7
IE 7.0 or higher
H.264, MPEG-4, MJPEG
200 : 1(Typical)
Max. 30fps(@1920X1080)
64 ~ 9000kbps
Max. 10 users
Support
Support
Support
Support
Support
Support
Leased Line, Cable Modem, SupportDynamic
IP and Static IP, ADSL usable under Router
TCP/IP, UDP/IP, RTP, RTSP, RTCP, NTP,
HTTP, DHCP, FTP, SMTP, DNS, DDNS
Recording in client PC with CMS or FTP Server
Classification Specification
Power Supply
Current Consumption
Operation Temp.
Dimension
Weight
Max. 1A(DC 12V) IR LED ON
-45~50℃
Ø150.5 x 95.6(H)mm
Approx. 400g
Regulated 12V DC, PoE(Power over Ethernet) - IEEE802.3af
Item Default(Basic setting) Remarks
Megapixel network vandal-proof dome camera
1/2.8" SONY PROGRESSIVE SCAN EXMOR CMOS
1984(H) x 1225(V)
Progressive Scan
Vari-focal auto iris megapixellens
24PCS
LED OFF : 0.01Lux
LED ON : 0Lux(25M Range)
1920x1080 / 1280x1024 /
1280x960 / 1280x720 / 1024x768 / 640x480 / 320x240
1920x1080 /
1280x1024 / 1280x960 / 1280x720 /
1024x768 / 640x480 / 320x240
Privacy Zone
Day&Night
WDR
Sense Up
White Balance
Function
ON / OFF(6 ProgrammableZones)
Auto / Night / Day
WDR(1 ~ 5), (Back Light, Front Light)
Auto(1 ~ 14)
Auto / Indoor / Outdoor / Fluorescent / User
Auto : 1/25 ~ 1/5,000(NTSC), 1/12.5 ~ 1/8,000(PAL)
Suppress Rolling, Manual
Electronic Shutter
Approx. 750g

2.2.5 Complete the installation
Upon installation, Web Viewer appears and image of camera is to be seen.
2.2.3 Input ID/Password
2.2.4 Active-X auto installation
Shown the main page, input ID and Password and click on "Viewer" to see the
video feed.(Default administrator's ID &Password is 'admin'.)
Click"install" on the security certificate to load the Active-X control.
If you choose "Don't install", the web viewer would not work.
<Caution>
[Reference]
Please change default value of ID/Password into new ones after the
installation.
Please refer to 5.3 Administrator's ID and Password Change regarding
'Change Administrator'.
2.2.1 Change the setting value of PC network environment
2.2.2 Connect the camera with web browser
Set IP Address, Subnet Mask and Gate-way of user's PC with 192.168.1.50 /
255.255.255.0 / 192.168.1.1 as shown on below picture.
Run web browser and input the default IP address(192.168.1.30) in URL line
and press "Enter". Then, below picture is to be shown.
10
Chapter 2. Installation and Video Check
2.1 Installation
2.2 Network Setting and Video Check
On the assumption that User PC and the camera are used under static IP, and
the camera is to be directly connected with User PC or Local Network.
The installation procedure is to be;
1) Connect the camera and PC with LAN Cable.
2) Power on camera.
※Use regulated 1A (Built-in IR LED Model)
※Use PoE(Power Over Ethernet) : The cable includes data and power, so it's
easy to install the camera.So, you can save time to installand cost. When you
connect the camera withPoE and DCadaptor,Only PoE is used.
3) Wait about 2 minute after power on camera, the system willbe booted.
To connect the unit in user'sPC, change the setting valueof PC network environment.
on your PC.
Default network setting valueof the unit is to be;.
<Caution> Before changing the setting value, please memorize the previous setting
value
11 129
IP Address : 192.168.1.30
Subnet Mask : 255.255.255.0
Gateway : 192.168.1.1
※The specification is subject to change without anyprior notice to improve the quality.
01
02 03
04
3B26913A
