Orion SCR2 Manual

1
25,216&5N9$
2N-LINE 57UPS
User Manual and Instructions
Table of contents
1. Introduction................................................................................2
1.1 System Introduction ..........................................................2
1.2 Product Features ..............................................................3
1.3 Safety Precautions............................................................4
1.4 Switches and Panel Indicators..........................................6
2. Installation and Operation..........................................................7
2.1 Unpacking and Inspection.................................................7
2.2 RACK Installation..............................................................7
2.3 Wiring Method...................................................................8
2.4 ON and OFF operation of the unit.....................................8
2.5 Battery Maintenance.........................................................9
3. Troubleshooting.......................................................................10
3.1 Led and Diagnostic audio alarms....................................10
3.2 Troubleshooting ..............................................................10
3.3 Significance of alarm sounds..........................................12
4. Time Endurance of Batteries...................................................12
5. Communication Interface Port.................................................13
6. Electrical Specification............................................................14
6.1 Input ...............................................................................14
6.2 Output.............................................................................15
6.3 Internal Battery Pack .....................................................16
6.4 End of Discharge Voltages .............................................16
6.5 Mechanical Requirements ..............................................16
6.6 Audible Noise..................................................................17

2 3
1. Introduction
1.1 System Introduction
This rack-mounted UPS can be installed into a 19” rack, placed together with
all your networking equipment, Hub Switches and Remote Routers in a single
computer equipment room so that all devices are protected by the UPS; the setup
has a fashionable look, too.
Our rack-mounted UPS is a state-of-the-art, ideal, on-line and fully
uninterrupted power supply system. Sine-wave output accompanied with bypass
switching provides a reliable and high quality AC power source. The wide range of
application covers computer equipment, communication systems and industrial
automation facilities. Thanks to the On-line design, the device provides functions
such as voltage regulation, mains filtration and frequency drift prevention in
normal operation. During a power outage, the stand-by battery pack will switch-in
to maintain a sustained power supply. Under an overload or inverter failure, the
UPS device will automatically switch-over to bypass mode for the system to be
powered by the Power Mains; when the overload condition is eliminated, the
system will automatically switch back to inverter mode. All the switching over
takes place within 4ms, so that your equipment operates continuously without any
interruption.
Figure of Front Panel
Battery Pack
1.2 Product Features
1.2.1 Electrical properties
Input Output
Current
Loading and
Capacitance
(KVA/KW/PF)
Voltage
3-Wire
+
GND
Current
L1 or L2
PFC Input
Voltage
3-Wire
+
GND L1-N
&
L2-N
L1-L2 L1-L2
Phase
difference
5.4/3.78/.70 100/200 21.6 A 100/200 27.0 A 27.0 A 180°
6.0/4.2/.70 110/220 21.9 A 110/220 27.3 A 27.3 A 180°
6.0/4.2/.70 115/230 20.9 A 115/230 26.1 A 26.1 A 180°
5.2/4.2/.81 120/208 23.1 A 120/208 25.0 A 25.0 A 120°
6.0/4.2/.70 120/240 20.0 A 120/240 25.0 A 25.0 A 180°
Note 1: When overload capacity＞130% ±10%, trip to bypass after 10 seconds.
When overload capacity＞200% ±10%, trip to bypass after 8 cycles.
Note 2: In case the input is 100VAC L-N, the UPS can only be used up to 90%
capacity.
Figure of Rear Panel
Status
indication and
control
Input switch
Maintenance
SW.
Selection interface
Communication
Interface
Fan
Wiring duct
Plug for
external
Battery
Output Switch

4 5
1.2.2 Mechanical specifications
Weight (kg)
Model
NO. Dimensions (mm)
W×D×H Net weight 35
Online 6kva
RT 120v 176×615×430 31 35
1.3 Safety Precautions
Detailed safety regulations
All the safety regulations described in this manual shall be strictly observed during
the installation and maintenance of the UPS and battery assembly.
Note:
The UPS unit contains a battery pack which is very heavy; in order to prevent
the rack from falling over, the UPS unit shall be positioned as low as possible
in the rack.
Connect the UPS to a socket furnished with a circuit breaker or fuse
protection and capable of sustaining a current of at least 30A.
To ensure normal operation, this device shall not be used to power electric
drills, vacuum cleaners or laser printers, for which transient starting current is
high.
The UPS contains high voltage; in case of any problem, please consult a
professional or contact the service center for assistance to prevent any injury.
The UPS carries the power of the battery pack; the output may carry an
output voltage even if the UPS is disconnected from the power mains.
The rated voltage of the internal battery pack is 144VDC.
Grounding wire – a non-loading PVC wire that is green or green with narrow
yellow strips.
The grounding wire depicted above denotes the connection wire that
connects the metal casing of the device to the ground.
The maintenance and replacement of the battery pack shall be carried out by
a trained UPS professional. No other personnel shall be allowed to
manipulate the UPS.
When replacing the battery, observe the principle of consistency in the
quantity, brand and model number. In case of any problem resulting from the
customer using batteries other than that approved, the customer shall be held
responsible.
It is strictly forbidden to expose the battery or battery pack to fire, or
explosion and injury may occur.
Never dismantle or damage the battery arbitrarily, or else the battery fluid
may spill out. The battery fluid is highly corrosive; it may cause severe injury
to the skin and eyes if touched.
Shorting electrodes of the battery will cause risks of high voltage and high
electric current.
Placing magnetic objects upon the UPS may cause data loss or damage.
In order to secure safe and continued operation, the
user must observe the regulations for using the UPS
correctly and the following precautions:
Do NOT open the outer cover of the UPS.
Avoid placing the UPS in an environment of high temperature and humidity.
Do NOT pour any liquid or poke any object into the UPS.
Do keep the venting slots in the front, rear and sides unclogged.
Avoid exposing the UPS to direct sunshine and avoid placing it near a heat
source.
High-voltage Risks:
Note: High-voltage will be present between a battery electrode and the
ground if the battery circuitry and input voltage are not isolated. Check any
electrode for high-voltage before touching it.
Note: Even if the UPS is disconnected from the power mains, internal parts of
the UPS are still connected to the battery pack. Therefore a potential risk
exists. Make sure the battery jumpers are disconnected before performing
any maintenance or repair.
Warning: Batteries will age with the time. When aging occurs, consult
professionals for regular replacement or treatment, or the battery fluid may
leak, causing fire or other hazards. We suggest regular maintenance to
check the batteries once a year.
Note: Batteries tend to age and gradually lose their capacity when used at the
normal temperature (approx. 25°C).A normal lifespan is 2-3 years. If batteries are
used with frequent cycles of charging and discharging, the lifespan will be further
shortened.

6 7
1.4 Switches and Panel Indicators
(1) Power switch: Press the “On/Mute” button on the front panel to
switch the UPS on. Press the “Off” button on the front panel to
switch the UPS off.
(2) AC INPUT indicator (Green): When this indicator lights up, the power
mains input is normal.
(3) BATTERY indicator (Yellow): When this indicator lights up, the UPS is
powered by the battery pack.
(4) BYPASS indicator (Yellow): When this indicator lights up, the UPS unit is
supplying power of the Power Mains to the output via bypass.
(5) UPS ON indicator (Green): When this indicator lights up, the UPS is
supplying power to the output through the inverter.
(6) Fault indicator (Red): In case of any anomaly of the UPS, this indicator
lights up and a continuous audio alarm sounds.
(7) Load capacity indicators (4 green lamps and 1 yellow lamp) or battery
capacity indicators (5 green lamps): Number of lit lamps indicates the
percentage of load or battery capacity. Designation of indicators is as
follows: (from left to right as in the following diagram of indicators on the
panel.)
2. Installation and Operation
2.1 Unpacking and Inspection
In case of any damage of the carton package, please contact the shipper
immediately. For the purpose of further shipment or storage, please place
the packaging material in the carton and store them properly.
2.2 RACK Installation
2.2.1 Slide Rail Accessories include:
Item Quantity
Front rail 2
Rear rail 2
Inner rail 2
M4 * 8mm screw 16+16
M4nut 8
M5 * 16mmscrew 12
Handle 2
Fig. 1
Fig. 2
2.2.2 Device box bracket
assembly process:
(1) Adjust the front and rear sliding
rails to the same length as the
RACK, fix the front and rear ends
of the slide rails to the RACK
using 8 M5 bolts, as shown in
Fig.1.
(2) Lock the front rails and the rear
rails using 8 M4 bolts and 8 M4
nuts as shown in Fig.2.
(3) Fix the handle and inner rails to
both sides of the RACK using 16
M4 bolts, with the lock latch on
the inner rail facing the rear of
the RACK, as shown in Fig.3.
RACK
front rail
bracket Front
rail
Rear
rail
M5 bolt
M5 bolt RACK rear
rail bracket
UPS Rack
M4 bolt
M4 Nut M4 Bolt
M4 Nut
Front panel
Handle
Inner rail
M4 bolt
Latch
Fig. 3

8 9
(4) Check and tighten all bolts, then
insert the UPS cabinet into the
rails on the RACK with the rear
side of the cabinet slanting up,
then lift the front side of the
cabinet to a horizontal position as
shown in Fig.4 and push the
cabinet into position inside the
RACK.
(5) Finally fix the cabinet front panel
handles to the front brackets of
the RACK using 4 M5 bolts so
that the UPS unit does not fall
out of the RACK.
Fig. 4
(
2.3 Wiring Method
(1) At least 10AWG (soft) or 22mm² (hard) wires shall be used for the input
and output wires.
(2) Wiring the input: In case of 3-phase 4-wire 208/120V power system (with
R, S, T, N, and G wires) taking any 2 phases as the power input, the
Neutral wire (N) must be connected too.
2.4 ON and OFF Operation of the Unit
(1) After verifying correct wiring to the Power Mains, press the “On/Mute”
button and the load indicator on the panel lights up. Check indicators one
by one. A few minutes later, the inverter indicator “UPS ON” will light up
and the “BYPASS” indicator will go out. At this point, the UPS unit has
entered into normal operation.
In case the bar-type indicator indicates a load exceeding 100%, the
buzzer will beep every half second, alerting the user that excessive load
has been connected to the system. You may disconnect loads of
secondary devices such as printers. If the “Power Mains” indicator lights
up, the AC power source is correctly connected. If both the “Power Mains”
and “Battery” indicators light up at the same time, it indicates that the
voltage or frequency of theAC source has exceeded its range.
(2) UPS I/P breaker off: Checks and confirms that the standby function of the
battery is normal.
The UPS unit will beep every 4 seconds. The Power Mains indicator goes
out.
(3) Press the “OFF” button (**Note**)
Pressing the “OFF” button once will switch the load devices over to the
bypass circuit for standby power supply. Pressing the “OFF” button a
second time within 4 seconds will disengage the output socket(s)
and the connected load device(s) from power. Please turn off all the
connected loads according to all necessary procedures before pressing
the “OFF” button twice.
(4) The UPS unit has “DC (battery) start up” and “alarm mute” functions.
When the Power Mains fails, the load indicator will function as a “Battery
Capacity Indicator” during standby. Direct start up in Battery Mode: When
there is no Power Mains input, press the “ON/Mute” button to start the
UPS unit for a Battery Mode start up. The first-time use of “DC (battery)
start up” is only available when the unit has been started with the Power
Mains.
Alarm Mute: Pressing the “ON/Mute” button will stop the alarm. Pressing
the button again will re-activate the alarm. Please note every button needs
to be pressed for more than 1 second for activation.
2.5 Battery Maintenance
1. When the UPS unit is not in use, the battery shall be re-charged every
three months for at least 12 hours. In warm areas, charge the battery
every two months for at least 12 hours.
2. Batteries tend to age when in operation. In general, batteries have a
lifespan of 3-5 years.An aged battery must be replaced, or the battery
may leak battery fluid and create a fire hazard.
UPS
output Input of
power

10 11
3. Troubleshooting
When you call for service, please provide the following information:
Date and time of the problem, product model and serial number.
Detailed description of the event and the status of panel indicators at the time
of event.
3.1 LED and diagnostic audio alarms
3.2 Troubleshooting
Problem Possible cause Remedy
UPS does not start
when ON button
pressed
UPS output short circuit
or overload Make sure the power supply to the UPS is switched off. Remove all the load devices.
Make sure no load device is connected to the
output socket. Verify that none of the load
devices has an internal failure or short.
AC input LED
blinks Frequency of power mains exceeds UPS
rating by ±5% range.
UPS output frequency not synchronized with
Power Mains. Please check UPS input for
normal frequency. May be that the power
source is a generator.
UPS has no input
power UPS is operating in Battery Mode; please check that the input socket of the UPS is in
normal condition.
UPS input protecting
fuse broke up or Input
NFB tripped.
UPS is operating in Battery Mode; please save
data and close application programs. Replace
input fuse of UPS, then restart UPS. Switch
ON input NFB again.
Battery LED lights
up
Voltage of Power
Mains exceeds input
range of the UPS.
UPS is operating in Battery Mode; please save
data and close application programs. Make
sure Power Mains is within the voltage range
acceptable to the UPS.
Battery not fully
charged. Keep UPS plugged in for at least 24 hours to fully charge the battery.
UPS overload. Check load level display and reduce loads
from UPS.
UPS battery
operation time
shortens
Aged battery unable to
reach full charge. Replace the battery. Please call your local dealer or service personnel; purchase
batteries as specified.
Fault and Bypass
LEDs and all load-
level LEDs light up
UPS overload or failure
of loaded devices. Check load level display and remove unnecessary loads from the UPS. Re-calculate
and reduce loads connected to the UPS.
Check load devices for failure.
Fault & Bypass
LEDs light up and
LED A lights up
UPS internal fan
failure, or UPS shuts
down due to excessive
temperature.
Make sure the UPS is not overloaded. Check if
vents are clogged and the surrounding
temperature is maintained within a proper
range. Waite for 30 minutes to cool down the
UPS. If the UPS cannot be restarted, call your
local dealer or service personnel.
When the UPS is
in fault and any of
LEDs A through E
light up
UPS internal failure. The UPS needs to be serviced. Please call
your local dealer or service personnel.
Power Mains LED
lights up and
Battery LED blinks
Battery cable detached/
not connected. Check the battery circuit; restart UPS after fully switching off the unit. Remark: If the battery
circuit is disconnected during the UPS
operation, the next battery test will detect this
condition.
Status of Anomaly LEDs
and Load LEDs Diagnoses/ Audio Alarms
All LEDs light up Tripped to Bypass due to output overload; beeps every half a
second
LED A lights up Tripped to Bypass due to output overload; beeps (1s or 2s)
every 4 seconds
LED B lights up Tripped to Bypass due to Bus overvoltage; beeps (1s or 2s)
every 4 seconds
LED C lights up Tripped to Bypass due to failure of control power; beeps (1s or
2s) every 4 seconds
LED D lights up Tripped to Bypass due to PFC failure; beeps (1s or 2s) every 4
seconds
LED E lights up Tripped to Bypass due to INV failure; beeps (1s or 2s) every 4
seconds
LEDs A&B light up INV-to INV communication anomaly; beeps every half a second
LEDs A&C light up Battery test anomaly; beeps (2s) every 60 seconds.
LEDs A&D light up L1 & L2 phase failure
LEDs B&C light up REPO activation
LEDs C&E light up Command given from interface for UPS shutdown; no alarm
activation
LEDs D&E light up Charger overvoltage: Beeps (1s) every 4 seconds
Power Mains LED lights
up; Battery LED blinks Battery not installed or battery low voltage; constant beeping
Bypass LED blinks Bypass voltage or frequency exceeds range

12 13
3.3 Significance of alarm sounds
Significance Alarm Sounds
Battery mode (Power Mains failure) One beep every 10s
Battery voltage low Two short beeps every 5s
Output overload (Bypass) One short beep every 0.5s
Overheat (Bypass) One beep (1s or 2s) every 4s
Inverter (INV) failure (Bypass) One beep (1s or 2s) every 4s
Bus overvoltage (Bypass) One beep (1s or 2s) every 4s
Battery test failure One beep (2s) every 60s
INV-to-INV communication failure One short beep every 0.5s
4. Time Endurance of Batteries
Load proportion
(linear load) Internal battery
10% 75
20% 38
30% 25
40% 18
50% 14
60% 11
70% 9
80% 7
90% 6
100% 5
Remark: At 25°C environment temperature, in minutes. Discharge time will
shorten as the battery ages; it is recommended that the battery be
replaced every 3-5 years.
5. Communication Interface Port
The RACK-installed UPS has a standard DB-9 female serial port. This port provides
several signals and their respective functions are given as follows:
Pin Function
1 Low battery power (transistor collector open, see the figure below).
2 UPS TxD (normal RS-232 transmission)
3 UPS RxD (normal RS-232 transmission)
4 Switched off by remote control (max. 5-12 VDC,10-24mA) during
the battery operation mode.
5 Common ground for pins 2, 3, and 4
6 Switched off by remote control (pin 5 shorted) during any operation
mode.
7 Low battery power (transistor collector open; see the figure below).
8 Abnormal Power Mains input (transistor emitter open; see the
figure below).
9 Abnormal Power Mains input (transistor collector open; see the
figure below).
Pin Assignment Collector to Emitter
Note: Maximum allowable voltage and current fed into pins 1, 7, 7 and 9 are
60VDC/10.0mA. If these values are exceeded, internal optical couples of
the UPS may get burnt.
Pin 4 – Explanations of remote control switch off of battery operation
1. This pin is only functional when the UPS is in battery mode. Pin 4 will ignore
any signal when the UPS is in the normal mode where the Power Mains is in
normal supply.
2. Pin 4 requires a 5-12 VDC signal to switch off the unit. A 5-12 VDC signal
sustained for more than 1.5s is required for switch off of the unit; any signal
shorter than 1.5s will be ignored. When Pin 4 receives a switch off signal
Open
collector
Open
emitter

14 15
longer than 1.5s, this signal can no longer be canceled.
3. The UPS is not switched off immediately after the receipt of a switch off signal
at Pin 4; instead, the unit starts a 2-minute timer and the switch off will only
take place after 2 minutes.
Note: the switch off timer cannot be stopped midway once it is activated.
4. In case the Power Mains resumes supply during the 2-minute countdown, the
timer still fulfills the countdown and switches off the UPS. The UPS will remain
OFF for at least 10s before automatically resuming the LINE MODE, even if
the AC input is resumed before the UPS is switched off.
6. Electrical Specification
6.1 Input
Model: 6kva 120v/240v
Acceptable L-N Input
Voltage without damage 0-150 VAC Note 3
Acceptable input frequency
without going to batteries 40-70Hz; 0.1
Low Line Transfer Voltage
Range With 110, 115, 120,
127 Nominal L-N
(based on % loading)
L1-N or L2-N voltage, whichever is less
100-90% / 90-70% / 70-30% / 30-0%
Low Line transfer 90 / 80 / 70 / 60 VAC; 3.1 VAC
High Line transfer 140 VAC; 3.1 VAC
Input power factor
0.97 at full resistive load, nominal input conditions
0.95 at half load
Input frequency 40 Hz to 70 Hz; ±0.1 Hz
Bypass Protection Limits
Disable Bypass operation If input voltage exceeds ±15% of the nominal voltage
Re-enable Bypass
operation If input voltage returns to within ±10% of nominal output voltage
Note - The intent of low and high line transfer and comeback voltages is to
establish about 7 VAC of hysteresis. The ±3.1 VAC tolerance is to mean that if the
transfer point is +2 VAC, then the retransfer point should also be about +2 VAC. If
the low line transfer point is +3.1 VAC and the retransfer point is –3.1VAC, the
hysteresis could be reduced to 0.8 VAC. To prevent this, the voltage error should
be in the same direction and about the same magnitude for each transfer point
voltage pair.
Note – At a nominal line voltage of 127 VAC, the maximum AC input will be
reached before 127 + 15% and the unit will go to battery mode before the bypass
reaches the disable voltage, so 127 +15% can be ignored.
Note - If the transfer points are specified using L-N voltages, the L-L voltage will
depend upon whether the inverters are 120 or 180 degrees apart. For reference,
this table shows the equivalent L-L voltages for the specified L-N voltages.
Angle Max VAC (120 +
25%)L-N / L-L High Line Transfer (120 + 17%)L-N / L-L Low Line Transfer (120 – 25%)L-N / L-L
180 150 / 300 140 / 280 90 / 180
120 150 / 260 140 / 242 90 / 156
6.2 Output
Model: 6kva 120v/240v
Power
Load may be all L-N, all L-L, or mixed
Power (kVA) max. 6.0 (110V derated to 5.4 kVA)
Power (kW) max. 4.2 (110V derated to 3.78kW)
Load Power Factor
Range 0.65 lagging to 1.0 (unity)
Output Voltage
Waveform Sinusodial
Nominal L1-N & L2-N
Voltages
120 VAC (Factory default setting)
Line Mode RMS Voltage L1-N, L2-N = 3 % of nominal, L1-L2 = 5 % of nominal;
no load to full load, resistive & RCD loads
Battery Mode RMS
Voltage L1-N, L2-N = 3 % of nominal, L1-L2 = 5 % of nominal;
no load to full load, resistive & RCD loads
Transfer Time 0 mS
Output Voltage Distortion
Linear Load 3% THD, R load
Non-Linear Load
(no load to full load) 5% THD, RCD load
Output Frequency 50 Hz nominal operation
Synchronization Range 46.5 Hz - 53.5 Hz; ±0.1 Hz
47 Hz - 53 Hz; ±0.1 HzCapture Range 60 Hz nominal operation
Synchronization Range 56.5 Hz – 63.5 Hz; ±0.1 Hz
Capture Range 57.0 Hz – 63.0 Hz; ±0.1 Hz
Free-Running Mode 0.1 Hz of nominal
AC Efficiency

16 17
Line Mode
88 % AC-AC, minimum
Overload Capability
Inverter overload
112 to 130 %, 10 %;
for 10 seconds minimum, then transfer to bypass
Inverter overload 131 to 200 %, 10 %;
for 2 seconds minimum, then transfer to bypass
Inverter overload > 201 %, 10 %;
for 96 msec minimum, then transfer to bypass
6.3 Internal Battery Pack (all parameters are defined
at 25 degC)
Model: 6kva 120v/240v and External Battery
Cabinets
Rating / Type 12V / 9AH
Voltage 144Vdc nominal, 12 x 12V
Back-up Time (at 25 degC) 5 minutes minimum at full rated load
Extended Battery Capability Yes, through safe connector on rear of UPS
Recharge Time (internal
battery) Six hours to 90% capacity after discharged into full load at nominal input voltage
6.4 End of Discharge Voltages
The end of discharge shutdown voltage will be based on the total runtime.
Discharging time 50 minutes, Batt Vcutoff = 9.6V/pcs
50minutes < Discharging time 4Hrs, Batt Vcutoff = 10V/pcs
4Hrs < Discharging time Batt Vcutoff = 10.5V/pcs
6.5 Mechanical Requirements (generally 4U UPS with
2U VBATT for 19 inch rack)
Model 6 KVA UPS 4U External Battery 2U
Width (tower) /Height (rack) 176 mm (6.93 in) 87 mm (6.93 in)
Depth (incl. handles) 592 mm (20.55 in) 592 mm (20.55 in)
Height (tower) /Width (rack) 430 mm (16.93 in) 430 mm (16.93 in)
The 4U UPS will use one UPS bezel and one battery bezel from the 2U UPS
models. The 2U battery cabinet will use one 2U battery bezels
6.6 Audible Noise
UPS Model Noise Level
6000 VA 55 dBA Max
Environmental Requirements
The UPS will be capable of withstanding the following environmental conditions:
** Ambient Temperature Range
Operating: 0 degC to +40 degC for altitude 0 to 1500 meter above sea level
Non-operating: -15 degC to +50 degC
** Humidity: 0% to 95% non-condensing
