Orlaco Camera EMOS Ethernet with Ex housing User manual

Camera EMOS Ethernet
with Ex housing
Installation manual
No. IM0973660 A 01
11/2015
English
Camera Emos Ethernet
Ex Specifications
ATEX 2014/34/EU
18 ATEX 12180 X
Ex II 2 G Ex db IIC T4 Gb, T-amb. -40°C to +70°C
Ex II 2 D Ex tb IIIC T 85°C Db

2 IM0973660 A 01
Before you start using this equipment, please read this manual carefully
and follow all instructions. We recommend that you keep this manual in a
safe place for reference purposes.
If you have any questions or issues concerning the operation of this equi-
pment, consult the relevant section in the manual or contact the Orlaco
Products BV Service department.
The camera/display systems from Orlaco comply with the latest CE, ADR,
EMC and mirror-directive regulations. All products are manufactured in
accordance with the ISO 9001 quality management, ISO/TS16949 quality
automotive and ISO 14001 environmental management.
Contents page
1. Mounting and connecting Camera 3
2. Pin connection 4
3. Specifications EMOS Ethernet Ex 4
4. Maintenance and cleaning 5
5. Disposal 5
6. General terms and conditions 5
7. User manual Ex Camera housing 6
8. IECEx Certificate of Conformity 11
9. ATEX Certificate 14
Release Notes
A 01. New edition, July 2018.
Available Documentation
Data sheet: DS0964250
ORLACO Camera EMOS Ethernet with Ex housing
Safety
In order to guarantee safe operation, these safety instructions
must be read before you start using this equipment.
• Do not open the enclosure. This can cause damage, short-circuiting
or electrical shocks.
• Do not expose the equipment to extreme temperatures. This can
cause deformation of the enclosure or damage to internal
components.
• Repairs may only be undertaken by the manufacturer.
• The equipment must be assembled as shown in this manual.
Installation Manual
Camera EMOS Ethernet
Ex enclosure for Camera EMOS Ethernet

IM0973660 A 01 3
1. Mounting and connecting Camera
Camera EMOS open wire
Figure 1
Installation Manual
46
58
175
103
4
6
6
6
120
105
108
Units in mm
Camera enclosure Camera EMOS
M5 Earth 4x ∅9
50

4 IM0973660 A 01
Open wires
1 = Orange/white = +Tx
2 = Green/white = +Rx
3 = Orange = -Tx
4 = Green = -Rx
Overall shielding connected to connector housing.
Open wires
1 = Red = Power
2 = White = 0V
2. Pin connection
See figure 2.
3. Specifications
Camera EMOS Ethernet 30°/60°/90°
Description
Lens specied Hor. lens angle Ver. lens angle
EMOS 90° Ethernet 90° 68°
EMOS 60° Ethernet 60° 45°
EMOS 30° Ethernet 30° 22°
Sensor
Sensor element: High resolution 1/3” CMOS rolling shutter, 1280H x
960V.
Video image:60fps at 720p SDR, 45fps at 960p SDR image processing
and 56fps at 720p HDR, 43fps at 960p HDR image processing.
Protocols: RTP (MJPEG RFC2435 and h.264 RFC6184) over UDP, PTP
and gPTP, ISO17215-2014, IEEE1722 (AVB).
IP address: DHCPv4 or static IPv4 (IPv6 possible).
Latency: <100ms depending on hardware processing platform (50ms
demonstrated on Orlaco hardware).
Light sensitivity: responsitivity 5,5V/lux-sec, Low light feature (<0,1Lux).
High dynamic range: >115dB.
Compression: MJPEG, H.264 (High 10 intra profile encoding).
Interface: 100Mb/s (Fast Ethernet).
Image processing: Color and gamma correction, 3D noise correction,
edge enhancement, digital WDR, advanced contrast enhancement, auto
white-balance, auto exposure control, mirroring, flipping, photometric
and geometric lens distortion correction.
Electrical
Power input: 12/24V/DC. Below 7V: camera is non-functional. Above 33V
the overvoltage protection is activated. This overvoltage protection is
deactivated below 30V. Powercircuit is protected up to 80V/DC. Outputs
are Short Circuit Protected.
In all these above mentioned values; a tolerance of +/-10% is applied.
Power consumption: <2W.
Transient protection: Camera may be powered directly from 12V or
24V battery without additional electrical protection since camera has an
integrated circuit that protects the camera against over- and undervoltage,
spikes, ripples and loaddumps.
Cable: 6 wire: 2x twisted pair for data and 2 wires for power supply.
Min. cable bend radius: 50mm.
Mechanical
Camera housing: Anodised aluminium, black, UV resistant, light fastness
>8, corrosion proof according IEC 60068-2-52 salt mist, cyclic.
EX housing: Description; see page 7.
Filling: Camera is potted with automotive potting resin
Ingress protection: IP66 / IP67
Shock constancy: Shock and vibration resistant for usage on trucks,
cranes, fork-lifts, maritime applications, machinery.
Truck use: Withstand all fluids and materials used in and around trucks
like: ammonia solution 5%, ethanol 80-100%, isopropanol 5-10%, soapy
water (min. 50% soap per volume), alkaline degreasing compounds(used
in high pressure washing equipment).
Operating temperature: -40°C to +70°C
Storage temperature: -40°C to +125°C
Certification
Camera
Approvals: In compliance with all relevant EMC- and Automotive
directives.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation. Certificates available upon request.
Compliant with RoHS and REACH.
Ex housing
IECEx see page 11.
ATEX see page 14.
Installation Manual
Figure 2

IM0973660 A 01 5
4. Maintenance and cleaning
Fixing a blurry image:
If the camera image is blurry, it is advisable to clean the camera.
Cleaning the lens glass:
Use a soft cloth to clean the lens glass of the camera. Use clean water
or a high quality and safe foam cleaner. Rub the camera lens glass clean
with the cloth.
Do absolutely not use aggressive chemicals or abrasive cleaning agents.
5. Disposal
Disassembly, removal and disposal. Local regulations for dealing with
waste must be followed when disposing of disassembled components or
entire units.
6. General terms and conditions
Orlaco Products BV is not liable for damage resulting from inadequate
servicing, incorrect usage or alterations made to the equipment without
informing the manufacturer in writing.
This installation manual has been made available by Orlaco Products
BV. All rights reserved. No part of this manual may be reproduced and/
or made public in printed form, in photocopy form or on microfilm, or in
any other way, without the prior written permission of Orlaco. This also
applies to the associated drawings and figures.
Orlaco reserves the right to make changes to components at any time
without informing customers beforehand or directly. All dimensions given
are for commercial purposes.
For information regarding repairs that is not covered in this manual,
please contact the Orlaco Products BV service department.
This manual has been prepared with all due care and attention. However,
Orlaco Products BV cannot be held responsible for any errors in this
manual or any consequences thereof.
FCC compliance statement:
The camera comes under section for commodity codes for electronic
equipment. This is known as “Harmonize code: 8525.30.9060” and the
importer can check off Block 2 on FCC form which states: “An FCC grant
of equipment authorization and an FCC ID are not required, but the equip-
ment complies with FCC technical requirements.”
Caution: Any changes or modifications in the construction of this device
which are not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment. Camera/Display
sets are visual aids and objects visible in camera/Display systems are
smaller or bigger than they appear on screen.
Installation Manual

6 IM0973660 A 01
Installation Manual
Chapter 7

IM0973660 A 01 7
Installation Manual

8 IM0973660 A 01
Installation Manual

IM0973660 A 01 9
Installation Manual

10 IM0973660 A 01
Installation Manual

IM0973660 A 01 11
Installation Manual
Chapter 8

12 IM0973660 A 01
Installation Manual

IM0973660 A 01 13
Installation Manual

14 IM0973660 A 01
Installation Manual
Chapter 9

IM0973660 A 01 15
Installation Manual

16 IM0973660 A 01
Installation Manual
