Orlaco RadarEye User guide

RadarEye®system
Sets with 7” and 12” Monitor
System manual
No. SM0974110 A 05
08/2013
English
Set with 12” Monitor
Set with 7” Monitor

2
RadarEye®System
SM0974110 A 05
Safety
is Warning sign that identies a specic
concern or instruction. Please make sure that all
are read, understood and followed.
In order to guarantee safe operation, read this
manual before using this equipment. Failure
to follow the safety instructions in this manual
can result in serious injury or death. Please
store this manual in a safe location.
• Do not open the equipment’s enclosure. This can cause
damage, short-circuiting or electrical shocks that could
lead to serious injury or death.
• Do not expose the equipment to extreme temperatures.
This can cause deformation of the enclosure or damage
to internal components.
• Repairs may only be undertaken by the manufacturer.
• The equipment must be assembled as shown in this
manual.
• The equipment is to be used with side view mirrors or
cameras to ensure safe operation.
• The equipment is not an alternative to safe driving
practices.
•If this equipment is used improperly on the vehicle it
could lead to serious injury or death.
This installation manual describes the functions of the
equipment, outlines the connection options and explains
how to put the equipment into operation. We recommend
that you keep this manual in a safe place for reference
purposes.
If you have any questions or issues concerning the
operation of this equipment, consult the relevant section
in the manual or contact the Orlaco Products BV Service
department.
All data subject to change without prior notice. The camera/
Monitor systems from Orlaco comply with the latest CE,
ADR and EMC-directive regulations. All products are manu-
factured in accordance with the ISO 9001 quality manage-
ment system, IATF 16949 quality automotive, ISO 14001
environmental management systems, where applicable.
System manual

3
SM0974110 A 05
Contents page
1. Introduction 3
2. RadarEye® sets 4
2.1. 7”/12” Monitor RLED/LEDD CAN SRD 6 4
2.2. Interface, Art. No. 0256010 4
2.3. Cables 5
2.4. SRD sensor CAN Horizontal 0004310 5
2.5. Terminator, Art. No 0350110 5
2.6. Mounting brackets Art. No. 0401330 and 0401320 5
3. Interface Box with Ext. speaker CAN/SRD/camera
Art No. 0504820 6
4. Explanation of the set types and available parts 7
4.1. Set Article No. 0403100 Set SRD Center Rear 7
4.2. Set Article No. 0403120 Set SRD Corner Rear 8
4.3. Available parts 9
5. Specifications and dimensions 10
5.1. Monitor 7” RLED CAN SRD R6 11
5.2. Monitor 7” RLED CAN SRD 4 CAM 7-4 12
5.3. Monitor 7” LEDD CAN SRD 6 13
5.4. Set monitor 12” RLED CAN SRD R6 14
5.5. Interface box CAN/SRD/camera 16
5.6. SRD sensor CAN Horizontal 18
5.7. Bracket SRD Sensor Center Rear 20
5.8. Bracket SRD Sensor Corner Rear 21
5.9. Interface Box with Ext. speaker CAN/SRD/camera 22
6. Guidelines for mounting the Sensors 24
7. Disposal 26
8. General terms and conditions 26
9. Release notes 26
1. Introduction
RadarEye® System
• May save lives.
• Prevent vehicle damage due to backing accidents.
• In-Cab Display Unit.
• Audible tones that increase in rate as objects become
closer.
• Rugged Design, shockproof and waterproof housing.
• Radar technology itself is very weather resistant
(compared to ultrasound).
• Speed of detection.
• Modern radar technology.
• Radar is more sensitive to approaching objects
than outgoing objects as a result of its intelligent
signal processing.

WARNING
The Equipment will not
identify objects if the
radar’s sensor is blocked.
As such, do not block the radar’s
sensor with objects
Please routinely clean the radar’s
sensor to prevent accumulation of
mud, dirt and other substances.
Please make sure the radar antenna
is aligned properly as this is critical
to the successful operation of the
system.
System manual

4SM0974110 A 05
The RadarEye® System is designed to detect objects in
zones obscured from the operator’s view. The pulsed-
timedomain radar systems detect stationary as well as
moving objects in a desired coverage area as long as the
vehicle is moving (engine on is enough movement to also
detect stationary objects). The system is ideal for on-road
and off-highway commercial vehicles, forklifts and other
industrial vehicles.

Utilizing the ability to network multiple sensors and Orlaco
cameras together with a single Orlaco Monitor, see figure
2, systems may be designed to provide necessary detection
around large vehicles.
The radar is plug-and-play and sends messages over the
CAN bus containing information of the targets.
The radar is providing distance information. Below 0,3
meter the distance information is less accurate.
2. RadarEye® sets
The Orlaco RadarEye® is always a complete system
consisting of a camera, monitor, Sensors, cables and
connection and mounting parts.

2.1. Monitor 7”/12” RLED/LEDD CAN SRD 6 and Monitor
7” RLED CAN SRD 4 CAM 7-4
The 7” monitor is supplied a with 6m powercable open
wired and a 6m video cable with 7p connector. The 7”
LEDD monitor is a build in monitor (in a Double DIN slot).
The 7” RLED and 12” RLED version are delivered with an
adjustable mounting bracket, see figure 1. The 7” RLED
CAN monitor is suitable to use with CAN protocols.

Connections to the monitor:
Red wire = Power input: 18...30V/DC
White wire = Power input: 0V

2.2. Interface 0256010
CAN (Controller Area Network) is a two-wire differential
serial communication protocol for real-time control. The
“bus” must be composed of a Twisted Pair cable having a
standard 120Ω characteristic impedance.

From the monitor the 7p video cable enters the interface
which separates the CAN wires from the video wires.

The interface has two outputs: 5p to the Sensor (Primary)
and a 4p to the camera, see figure 2.
Figure 1
Figure 2
System manual

5
SM0974110 A 05
2.3. Cables
The connection between the Interface and the Sensors is
done with cables with twisted pair and power wires for the
Sensors. These cables with molded M12 connectors are
available in different lengths, see figure 3.
Connection between the Interface and first Sensor is done
with the cable with a green color marking (cable type D).
The connection between a Primary Sensor and a Secondary
Sensor is done with the cable with red color marking (cable
type K).
The difference between the green and the red cable is the
number of connections. In the green marked cable 4 wires
are connected and in the red marked cable 5 wires are con-
nected, the extra connection is for communication between
Primary and Secondary Sensor.
For the camera connection the Orlaco (Uni or Dynamic) 4p
cables are used.
2.4 SRD sensor CAN Horizontal 0004310 and SRD sensor
CAN Vertical 0004320
The SRD sensor CAN Horizontal is one Sensor, article No.
0004310 (freq.=24 GHz) with a theoretical detection angle of
70° horizontal. The SRD sensor CAN Vertical is one Sensor,
article No. 0004320 (freq.=24 GHz) with a theoretical detec-
tion angle of 11° vertical.
Sensitivity is less outside 70 degrees, but signal level is still
high enough for accurate detection until 90 degrees.
The vertical detection zone is 11°.
When installing the Sensor CAN Horizontal; the orientation
of the antenna must be horizontal. The milling lines at the
surface of the Sensor indicate the antenna position and need
to be in line with the horizon. When installing the Sensor
CAN Vertical; the orientation of the antenna must be vertical.
For mounting four M4 Vibration dampers are included, see
figure 4.
2.5 Terminator 0350110
The CAN bus must be terminated at both ends by a 120-ohm
resistor placed across CAN_H and CAN_L so that reflections
of signals are avoided.
Therefore the terminator is supplied in the sets and the main
terminator activated in the monitor (Default via OSD set-
tings), see figure 5.
2.6. Mounting brackets 0401330 and 0401320
To mount the Sensors there are two mounting brackets avail-
able. Article No. 0401330 is a bracket to be used to mount
one Sensor and is applied for corner rear mounting. Article
No. 0401320 is the bracket used to mount two Sensors (Pri-
mary/Secondary) for center rear mounting, see figure 6.
Figure 3
Figure 4
Figure 5
Figure 6
System manual

6SM0974110 A 05
3. Interface Box with Ext. speaker CAN/SRD/camera
0504820
The monitor has an internal buzzer for the audible warning.
Optional the 0504820 is available which features an external
speaker.
From the monitor the 7p video cable enters the interface
which separates the CAN wires from the video wires.

The 0504820 interface has three outputs: 5p to the Sensor
(Primary), 4p to the camera and a 6p connection for the
external speaker, which is included.

The 0504820 interface also features external outputs:
These signals are RS232 en RS485 stop indications output
and an possibility to connect an external indicator (for
example tower light). This external device is switched via a
relays in the 0504820, see figure 7.
ORLACO PRESENTS THE
RADAR SIGNAL AVAILABLE,
BUT WILL NOT BE LIABLE IF
IT IS USED TO INTERVENE IN
THE MACHINE.
Figure 7
System manual

7
SM0974110 A 05
4. Explanation of the Set types and available parts:

4.1. Set Article No. 0403100 Set SRD Center Rear.
which consists of 2 wide beam Sensors (70° beam width, 11° beam height) that work together to guard a
wide area, see figure 8.
range = 2m...20m
Zones
14
32 5
RadarEye set center rear, system overview
Monitor A
Camera C
E
Interface
Power
Terminator
DK
Primary Secondary
B
M(red)
M(green)
(green)F(red)F
Set SRD Center Rear, Art. No. 0403100
consisting of:
2 x Art. No. 0004320 SRD sensor CAN vertical
1 x Art. No. 0401320 Bracket SRD Sensor center rear
1 x Art. No. 0301080 0,25m M12 M-S Red
1 x Art. No. 0350110 M12 Terminator 120 Ohm
Set Art. No. 0403100
Explanation
A- Monitor
B- Camera Cable
C- Camera
D- Radar Cable
E- Radar Set, center rear
K- Radar connecting cable
Cables D Cables K
Other Sensors Primary/Secondary Sensors
Male/Female Connectors Male/Female Connectors
M12 Green 5p Connectors M12 Red 5p Connectors
4wires in use 5wires in use
Figure 8
System manual

8SM0974110 A 05
4.2. Set Article No. 0403120 Set SRD Corner Rear.
which consists of 2 wide beam Sensors (70° beam width, 11° beam height) that work together to guard a
rectangular area, see figure 9.
Terminator
M(green)
M(red) F(red)
(green)F
Interface
Power
RadarEye set corner rear, system overview
Set Art. No. 0403120
Primary Secondary
Monitor A
D
K
Camera C
B
H
Set SRD Corner Rear, Art. No. 0403120
consisting of:
2 x Art. No. 0004310 SRD Sensor CAN Horizontal
2 x Art. No. 0401330 Bracket SRD Sensor Corner Rear
1 x Art. No. 0350110 M12 Terminator 120 Ohm
Zones 2 3 4 5
range = 2m...20m
1
Separation
distance
Separation
distance
+ 0,5m
Explanation
A- Monitor
B- Camera Cable
C- Camera
D- Radar Cable
H- Radar Set, corner rear
K- Radar connecting cable
Cables D Cables K
Other Sensors Primary/Secondary Sensors
Male/Female Connectors Male/Female Connectors
M12 Green 5p Connectors M12 Red 5p Connectors
4wires in use 5wires in use
Figure 9
System manual

9
SM0974110 A 05
0208871 Monitor 7’’ RLED CAN SRD R6
0209110 Monitor 7” RLED CAN SRD 4 CAM 7-4
0208371 Monitor 7’’ LEDD CAN SRD 6
0411300 Set Monitor 12” RLED CAN SRD R6
0004310 SRD sensor CAN Horizontal
0004320 SRD sensor CAN Vertical
Pick one of the below Interfaces
0256010 Interface box CAN/SRD/camera
0504820 Interface Box with Ext. speaker CAN/SRD/camera
 
0401330 Bracket SRD sensor Corner rear
0401320 Bracket SRD sensor Center rear
0350110 M12 terminator 120 Ohm
 
Pick one of the below cables type D
0301151 Cable 2m M12 Green
0301051 Cable 5m M12 Green
0301061 Cable 10m M12 Green
0301071 Cable 15m M12 Green
0301121 Cable 20m M12 Green
0301131 Cable 25m M12 Green
0301141 Cable 30m M12 Green
Pick one of the below cables type K
0301081 Cable 0,25m M12 Red
0301021 Cable 1m M12 Red
0301031 Cable 4m M12 Red
0301041 Cable 8m M12 Red
0301091 Cable 16m M12 Red

4.3. Available parts
For cameras and cable between interface and camera: See catalog HE, OT and FA on www.orlaco.com
System manual

10 SM0974110 A 05
5. Specifications and dimensions
Type Automotive 7inch TFT liquid crystal display module LED backlight.
Resolution
WVGA 800xRGBx480 pixels.
Viewing
70° horizontal and 60° vertical (@ CR≥10).
LED Life Time
30000 Hrs.
Typical performance
Center luminance of white: 600cd/m2, Contrast ratio 650:1, Response time 5 ms (Tr).
Softwaremenu
Full On-Screen-Display (OSD) functionality in 15 languages: English, Dutch, German, French, Chech, Hungarian, Italian, Polish,
Portuguese, Spanish, Turkish, Swedish, Finnish, Danish, Norwegian.
ABC mode
Improved Auto Brightness Control (ABC) including one-touch day/night setting and adjustable minimum and maximum levels
for automatic control.
Operating temperature
-40°C ..+85°C.
Storage temperature
-40°C ..+105°C.
Electrical
Input voltage range
12...60V
+/-10%.
Power consumption
Max 12W (only for the monitor, total power consumption depending on cameras and other peripherals).
Protection
>70V overvoltageprotection, <10V undervoltageprotection, protected against loaddumps, spikes and surges, reverse polarity
on all wiring.
Power-output
Nominal 2A +/-10% for powering cameras and other peripherals.
Video input
1Vtt, 75Ω, Pal 50 Hz, 4,43MHz color sub carr. NTSC 60 Hz, 3,58MHz color sub carr.
Mechanical
Surface
Hard coating (3H), with AG LR (Low Reflection) polarizer.
Housing
Color Black, material: aluminium & high impact automotive synthetic thermoplastic polymer.
Shock constancy
Shock and vibration resistant for usage on trucks, cranes, fork-lifts, maritime applications, machinery. Random vibration test
9,73G
rms at frequency: 5 to 2000, PSD (g²/Hz) 0,015 to 0,10.
Ingress protection
IP67 according IEC 60529 (dust tight, immersion in water up to 1m for 30 min).
Truck use
Withstand all fluids and materials used in and around trucks like: ammonia solution 5%, ethanol 80-100%, isopropanol
5-10%, soapy water (min. 50% soap per volume), alkaline degreasing compounds(used in high pressure washing equipment).
Certification
Quality & environment
Units are manufactured by Orlaco in the Netherlands; ISO 9001, ISO14001, ISO-TS16949.
Approvals
Approvals in compliance with all relevant EMC- and Automotive directives. Certificates available upon request.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Green Passport
All materials are compliant to Green Passport requirements according IMO resolution MEPC.197(62) as adopted on 15 July
2011 (Maritime sector: International Maritime Organization concerning the functions of the Marine Environment Protection
Committee).
Electrical
Input voltage range 18...30V
+/-10%.
Power consumption Max 12W (only for the monitor, total power consumption depending on cameras and other peripherals)
Protection >70V overvoltageprotection, <10V undervoltageprotection, protected against loaddumps, spikes and surges, reverse polarity
on all wiring.
Power-output For powering cameras and other peripherals. Power-output = input voltage. Output current 2A max.
Video input 1Vtt, 75Ω, Pal 50 Hz, 4,43MHz color sub carr. NTSC 60 Hz, 3,58MHz color sub carr.
System manual
English, Dutch, German, French, Italian, Polish, Spanish,
Swedish.
8

11
SM0974110 A 05
Type Automotive 7inch TFT liquid crystal display module LED backlight.
Resolution WVGA 800xRGBx480 pixels.
Viewing 70° horizontal and 60° vertical (@ CR≥10).
LED Life Time 30000 Hrs.
Typical performance Center luminance of white: 600cd/m2, Contrast ratio 650:1, Response time 5 ms (Tr).
Softwaremenu Full On-Screen-Display (OSD) functionality in 15 languages: English, Dutch, German, French, Chech, Hungarian, Italian, Polish,
Portuguese, Spanish, Turkish, Swedish, Finnish, Danish, Norwegian.
ABC mode Improved Auto Brightness Control (ABC) including one-touch day/night setting and adjustable minimum and maximum levels
for automatic control.
Operating temperature -40°C ..+85°C.
Storage temperature -40°C ..+105°C.
Electrical
Input voltage range 12...60V
+/-10%.
Power consumption Max 12W (only for the monitor, total power consumption depending on cameras and other peripherals).
Protection >70V overvoltageprotection, <10V undervoltageprotection, protected against loaddumps, spikes and surges, reverse polarity
on all wiring.
Power-output Nominal 2A +/-10% for powering cameras and other peripherals.
Video input 1Vtt, 75Ω, Pal 50 Hz, 4,43MHz color sub carr. NTSC 60 Hz, 3,58MHz color sub carr.
Mechanical
Surface Hard coating (3H), with AG LR (Low Reflection) polarizer.
Housing Color Black, material: aluminium & high impact automotive synthetic thermoplastic polymer.
Shock constancy Shock and vibration resistant for usage on trucks, cranes, fork-lifts, maritime applications, machinery. Random vibration test
9,73Grms at frequency: 5 to 2000, PSD (g²/Hz) 0,015 to 0,10.
Ingress protection IP67 according IEC 60529 (dust tight, immersion in water up to 1m for 30 min).
Truck use Withstand all fluids and materials used in and around trucks like: ammonia solution 5%, ethanol 80-100%, isopropanol
5-10%, soapy water (min. 50% soap per volume), alkaline degreasing compounds(used in high pressure washing equipment).
Certification
Quality & environment Units are manufactured by Orlaco in the Netherlands; ISO 9001, ISO14001, ISO-TS16949.
Approvals Approvals in compliance with all relevant EMC- and Automotive directives. Certificates available upon request.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Green Passport All materials are compliant to Green Passport requirements according IMO resolution MEPC.197(62) as adopted on 15 July
2011 (Maritime sector: International Maritime Organization concerning the functions of the Marine Environment Protection
Committee).
Electrical
Input voltage range 18...30V
+/-10%.
Power consumption Max 12W (only for the monitor, total power consumption depending on cameras and other peripherals)
Protection >70V overvoltageprotection, <10V undervoltageprotection, protected against loaddumps, spikes and surges, reverse polarity
on all wiring.
Power-output For powering cameras and other peripherals. Power-output = input voltage. Output current 2A max.
Video input 1Vtt, 75Ω, Pal 50 Hz, 4,43MHz color sub carr. NTSC 60 Hz, 3,58MHz color sub carr.
Cables / Connectors 6m power cable open wired, 6m video cable with 7p molded M16 female connector;
Art. no.:8976331.
Bracket
A clamping user-adjustable mounting bracket is supplied. Art. No. : 2015500.
Weight 1,9kg (Monitor, bracket, cables and connectors).
back side
cable connection
downwards
cable connection
upwards
remove cap
Note by reassembly: Make
sure to tighten the screws
according torque 0.25 Nm / 35.4 in.ozf
Connections to the monitor: (Secure the power input with a 5A fuse)
1 = Red = Power input: 12...60V/DC
2 = White = Power input: 0V
3 = Blue = Cam No. 1 activated at 7...60V/DC*
+ Activation Radar on sensor direction 5,6 and 7
4 = Brown = Cam No. 2 activated at 7...60V/DC*
+ Activation Radar on sensor direction 1,11 and 12
5 = White/Yellow = Cam No. 3 activated at 7...60V/DC*
6 = Grey = Cam No. 4 activated at 7...60V/DC*
+ Blocking sensor directions 2,3,4 and 8,9,10
7 = Yellow = Quad view, Parking Brake (only Front Cam)/Zoom out
*Triggers camera >7V/DC and returns to non triggered <5V/DC.
If multiple cameras are triggered the highest camera number has the highest priority.
Front side 7p molded female connector:
1 = Coax core = Video in
2 = Coax shielding = Video GND
3 = Red = Power output: equal to “Power input”
4 = Black = Power output: 0V
5 = Orange = CAN-L
6 = Yellow = CAN-H
7= Grey = N.C.
1
2
3
7
456
2
5
7
43
61
units in mm
6000
120,0
98,3
49,1
89,6
30,0
∅64,5
40,5 ∅7,0 (4x)
64,0
188,0
Min. bend radius= 50mm
R = 50
97,6
Controller Area Network (CAN)
Pair of signal wires (CAN_H and CAN_L)
5.1. Monitor 7” RLED CAN SRD R6
Article number: 0208871
Electrical connections
Dimensions
System manual

12 SM0974110 A 05
5.2. Monitor 7” RLED CAN SRD 4 CAM 7-4
Article number: 0209110
Electrical connections
Dimensions
Cables / Connectors 2m multicable (power) open wired, 2m Y-cable (video) with molded 7p female connector and
molded 4p female connector. Art. no.: 8976751.
Bracket A clamping user-adjustable mounting bracket is supplied. Art. No. : 2015510.
Weight 1,9kg (LCD, bracket, cables and connectors).
1
2
3
7
4564
1
23
Front side molded 4p female connector:
1 = Coax core = Video input
2 = Coax shielding = Video 0V
3 = Red = Power output: 12...30V
4 = Black = Power output: 0V
Shielding = To housing
2
5
7
43
61
Connections to the monitor: (Secure the power input with a 5A fuse)
1 = Red = Power input: 12...60V/DC
2 = White = Power input: 0V
3 = Blue = Cam No. 1 activated at 3...60V/DC*
+ Activation Radar on sensor direction 5,6 and 7
4 = Brown = Cam No. 2 activated at 3...60V/DC*
+ Activation Radar on sensor direction 1,11 and 12
5 = White/Yellow = Cam No. 3 activated at 3...60V/DC*
6 = Grey = Cam No. 4 activated at 3...60V/DC*
+ Blocking sensor directions 2,3,4 and 8,9,10
7 = Yellow = Quad view, Parking Brake (only Front Cam)/Zoom out
*Triggers camera >7V/DC and returns to non triggered <5V/DC.
If multiple cameras are triggered the highest camera number has the highest priority.
Solder side 7p female connector:
1 = Coax core = Video in
2 = Coax shielding = Video GND
3 = Red = Power output: equal to “Power input”
4 = Black = Power output: 0V
5 = Orange = CAN-L
6 = Yellow = CAN-H
7= Grey = N.C
back side
cable connection
downwards
cable connection upwards
remove cap
Note by reassembly: Make
sure to tighten the screws
according torque 0.25 Nm / 35.4 in.ozf
2000
1000
Cable length
2000mm
units in mm
120
98,3
49,1
89,6
30,0
∅64,5
40,5 ∅7 (4x)
64
188,0
Min. bend radius= 50mm
R = 50
97,6
Controller Area Network (CAN)
Pair of signal wires (CAN_H and CAN_L)
System manual

13
SM0974110 A 05
5.3. Monitor 7” LEDD CAN SRD 6
Article number: 0208371
Cables / Connectors Cable LEDD 6m serial (power) open wired, 6m multicable (video) with 7p female M16 OEM
molded connector. Art. No.: 8975180
Weight
1,2kg (monitor, cables and connector)
objec ts in
monitor are
closer than
they appear
Connections to the monitor:(Secure the power input with a 5A fuse)
1 = Red = Power input: 12...60V/DC
2 = White = Power input: 0V
3 = Blue = Cam No. 1 activated at 3...60V/DC
+ Activation Radar on sensor direction 5,6 and 7
4 = Brown = Cam No. 2 activated at 3...60V/DC
+ Activation Radar on sensor direction 1,11 and 12
5 = White/Yellow = Cam No. 3 activated at 3...60V/DC
6 = Grey = Cam No. 4 activated at 3...60V/DC
+ Blocking sensor directions 2,3,4 and 8,9,10
7 = Yellow = Quad view, Parking Brake (only Front Cam)/Zoom out
Front side 7p female molded connector:
1 = Coax core = Video in
2 = Coax shielding = Video 0V
3 = Red = Power output: equal to “Power input”
4 = Black = Power output: 0V
5 = Orange = CAN-L
6 = Yellow = CAN-H
7= Grey = N.C.
1
2
3
7
456
2
5
7
43
61
120
units in mm
188
Min. bend radius= 50mm
R = 50
DDIN opening
(acc. to ISO 7736)
183
113,5
181
53,1 46,5
112,5
objects in
monitor are
closer than
they appear
6000
6000
Controller Area Network (CAN)
Pair of signal wires (CAN_H and CAN_L)
Dimensions
objects in
monitor are
closer than
they appear
objects in
monitor are
closer than
they appear
objects in
monitor are
closer than
they appear
objects in
monitor are
closer than
they appear
1
Disassembling of the LEDD monitor (from dashboard):
234
Remove the suncover by
sliding it upwards in the arrow
direction and then forwards.
Insert the U shaped demounting
tool into the holes as shown.
Tweak the dismounting tool in both
holes & pull the screen slightly out
of the dashboard. Pay attention to
step 4 before completely removing
the screen from the dashboard.
Do the same thing on the
other side.
Electrical connections
Disassembling of the LEDD monitor (from dashboard)
System manual

14 SM0974110 A 05
5.4. Set Monitor 12” Set Monitor 12” RLED CAN SRD R6
Set Article number: 0411300
Monitor Article No. 0207930 Monitor 12” RLED CAN SRD
Cable Article No. 0304830 Cable monitor 6 ow b7
Bracket Article No. 2015600 Adjustable Bracket 190mm
Mounting material Article No. 0910310 Set Mounting Material Adjustable Bracket
General
Weight 2,81 kg, including cable and bracket.
Type Automotive 12,1inch TFT-LCD module with a white LED backlight.
Resolution XGA 1024 x R.G.B. x 768 pixels.
Viewing 80° horizontal and 70° vertical (@ CR≥10).
LED live time 30.000 Hrs.
Typical performance Center luminance of white: 500cd/m2, Contrast ratio 700:1, Response time 5ms (Tr).
Softwaremenu Full On-Screen-Display (OSD) functionality in 12 languages: English, Dutch, German, French, Italian, Polish, Portuguese,
Spanish, Swedish, Finnish, Danish and Norwegian.
ABC mode Improved Auto Brightness Control (ABC) including one-touch day/night setting and adjustable minimum and maximum levels
for automatic control.
Operating temperature -40°C...+85°C.
Electrical
Input voltage range 12...30V.
Power consumption 12W@24V.
Protection: >30V overvoltage protection, <10V undervoltage protection, protected against load dumps, spikes and surges, reverse polarity
on all wiring.
Power-output: 12V, for powering cameras and other peripherals. Output current 2A max.
Video input 1Vtt, 75Ω, Pal 50 Hz, 4,43MHz color sub carr. NTSC 60 Hz, 3,58MHz color sub carr.
Mechanical
Surface Hard coating (3H), with AG LR (Low Reflection) polarizer.
Housing Color Black, material: aluminium & high impact automotive synthetic thermoplastic polymer.
Protection IP67 according IEC60529. dust-tight and protected against the effects of temporary immersion in water up to 1 m under water
for 30 minutes.
Temperature/humidity test According IEC60068-2-1/2/3/14/30/38.
Certication
Quality & environment Units are manufactured by Orlaco in the Netherlands; ISO 9001: 2000, ISO14001: 2004.
Electrical
Input voltage range 18...30V.
Power consumption 12W@24V.
Protection: >30V overvoltageprotection, <10V undervoltageprotection, protected against load dumps, spikes and surges, reverse polarity
on all wiring.
Power-output: For powering cameras and other peripherals. Power-output = input Voltage. Output current 2A max.
Video input 1Vtt, 75Ω, Pal 50 Hz, 4,43MHz color sub carr. NTSC 60 Hz, 3,58MHz color sub carr.
Serial
General
Weight 2,81 kg, including cable and bracket.
Type Automotive 12,1inch TFT-LCD module with a white LED backlight.
Resolution XGA 1024 x R.G.B. x 768 pixels.
Viewing 80° horizontal and 70° vertical (@ CR≥10).
LED live time 30.000 Hrs.
Typical performance Center luminance of white: 500cd/m2, Contrast ratio 700:1, Response time 5ms (Tr).
Softwaremenu Full On-Screen-Display (OSD) functionality in 12 languages: English, Dutch, German, French, Italian, Polish, Portuguese,
Spanish, Swedish, Finnish, Danish and Norwegian.
ABC mode Improved Auto Brightness Control (ABC) including one-touch day/night setting and adjustable minimum and maximum levels
for automatic control.
Operating temperature -40°C...+85°C.
Electrical
Input voltage range 12...30V.
Power consumption 12W@24V.
Protection: >30V overvoltage protection, <10V undervoltage protection, protected against load dumps, spikes and surges, reverse polarity
on all wiring.
Power-output: 12V, for powering cameras and other peripherals. Output current 2A max.
Video input 1Vtt, 75Ω, Pal 50 Hz, 4,43MHz color sub carr. NTSC 60 Hz, 3,58MHz color sub carr.
Mechanical
Surface Hard coating (3H), with AG LR (Low Reflection) polarizer.
Housing Color Black, material: aluminium & high impact automotive synthetic thermoplastic polymer.
Protection IP67 according IEC60529. dust-tight and protected against the effects of temporary immersion in water up to 1 m under water
for 30 minutes.
Temperature/humidity test According IEC60068-2-1/2/3/14/30/38.
Certication
Quality & environment Units are manufactured by Orlaco in the Netherlands; ISO 9001: 2000, ISO14001: 2004.
Electrical
Input voltage range 18...30V.
Power consumption 12W@24V.
Protection: >30V overvoltageprotection, <10V undervoltageprotection, protected against load dumps, spikes and surges, reverse polarity
on all wiring.
Power-output: For powering cameras and other peripherals. Power-output = input Voltage. Output current 2A max.
Video input 1Vtt, 75Ω, Pal 50 Hz, 4,43MHz color sub carr. NTSC 60 Hz, 3,58MHz color sub carr.
Serial
General
Weight 2,81 kg, including cable and bracket.
Type Automotive 12,1inch TFT-LCD module with a white LED backlight.
Resolution XGA 1024 x R.G.B. x 768 pixels.
Viewing 80° horizontal and 70° vertical (@ CR≥10).
LED live time 30.000 Hrs.
Typical performance Center luminance of white: 500cd/m2, Contrast ratio 700:1, Response time 5ms (Tr).
Softwaremenu Full On-Screen-Display (OSD) functionality in 12 languages: English, Dutch, German, French, Italian, Polish, Portuguese,
Spanish, Swedish, Finnish, Danish and Norwegian.
ABC mode Improved Auto Brightness Control (ABC) including one-touch day/night setting and adjustable minimum and maximum levels
for automatic control.
Operating temperature -40°C...+85°C.
Electrical
Input voltage range 12...30V.
Power consumption 12W@24V.
Protection: >30V overvoltage protection, <10V undervoltage protection, protected against load dumps, spikes and surges, reverse polarity
on all wiring.
Power-output: 12V, for powering cameras and other peripherals. Output current 2A max.
Video input 1Vtt, 75Ω, Pal 50 Hz, 4,43MHz color sub carr. NTSC 60 Hz, 3,58MHz color sub carr.
Mechanical
Surface Hard coating (3H), with AG LR (Low Reflection) polarizer.
Housing Color Black, material: aluminium & high impact automotive synthetic thermoplastic polymer.
Protection IP67 according IEC60529. dust-tight and protected against the effects of temporary immersion in water up to 1 m under water
for 30 minutes.
Temperature/humidity test According IEC60068-2-1/2/3/14/30/38.
Certication
Quality & environment Units are manufactured by Orlaco in the Netherlands; ISO 9001: 2000, ISO14001: 2004.
Electrical
Input voltage range 18...30V.
Power consumption 12W@24V.
Protection: >30V overvoltageprotection, <10V undervoltageprotection, protected against load dumps, spikes and surges, reverse polarity
on all wiring.
Power-output: For powering cameras and other peripherals. Power-output = input Voltage. Output current 2A max.
Video input 1Vtt, 75Ω, Pal 50 Hz, 4,43MHz color sub carr. NTSC 60 Hz, 3,58MHz color sub carr.
Serial
System manual

15
SM0974110 A 05
back side
cable connection
sidewards
25
7
4
3
6
1
1
2
3
7
456
Connections to the monitor: (Secure the power input with a 5A fuse)
1 = Red = Power input: 12…30V
2 = White = Power input: 0V
3 = Blue = Cam No. 1 activated at 12...30V
+ Activation Radar on sensor direction 5,6 and 7
4 = Brown = Cam No. 2 activated at 12...30V
+ Activation Radar on sensor direction 1,11 and 12
5 = White/Yellow = Cam No. 3 activated at 12...30V
6 = Grey = Aux 1 activated at 12...30V
+ Blocking sensor directions 2,3,4 and 8,9,10
7 = Yellow = Aux 2 activated at 12...30V
Shielding to GND
Solder side 7p female connector:
1 = Coax core = video 1 input
2 = Coax shielding = video 0V
3 = Red = Power output: 12V
4 = Black = Power output: 0V
5 = Orange = CAN-L
6 = Yellow = CAN-H
7 = Grey = Video 2 input
Shielding to housing
back side
cable connection
sidewards
25
7
4
3
6
1
1
2
3
7
456
Connections to the monitor: (Secure the power input with a 5A fuse)
1 = Red = Power input: 12…30V
2 = White = Power input: 0V
3 = Blue = Cam No. 1 activated at 12...30V
+ Activation Radar on sensor direction 5,6 and 7
4 = Brown = Cam No. 2 activated at 12...30V
+ Activation Radar on sensor direction 1,11 and 12
5 = White/Yellow = Cam No. 3 activated at 12...30V
6 = Grey = Aux 1 activated at 12...30V
+ Blocking sensor directions 2,3,4 and 8,9,10
7 = Yellow = Aux 2 activated at 12...30V
Shielding to GND
Solder side 7p female connector:
1 = Coax core = video 1 input
2 = Coax shielding = video 0V
3 = Red = Power output: 12V
4 = Black = Power output: 0V
5 = Orange = CAN-L
6 = Yellow = CAN-H
7 = Grey = Video 2 input
Shielding to housing
Article number: 0411300
Dimensions
Electrical connections
System manual

16 SM0974110 A 05
5.5. Interface box CAN/SRD/camera
Article number 0256010
General Interface is designed to connect the Orlaco RadarEye® sets to a Camera and a
Monitor.
Color Grey RAL7032.
Protection Water and Dustproof IP 66 according to IEC 60529.
Operating temperature -40°C to +75°C.
Weight 176gr.
Connectors 7P Male Socket to Monitor, 4p Female Socket to Camera,
5p Female Socket to RadarEye® set.
System manual

17
2
5
7
43
61
41
2
3
1
23
4
SM0974110 A 05
Dimensions
1 = Video
2 = Video-GND
3 = PWR
4 = 0V
5 = CAN L
6 = CAN H
1 = Video
2 = Video GND
3 = Power
4 = 0V
1 = PWR
2 = CAN L
3 = 0V
4 = CAN H
Solder side
7P Male socket
to Monitor
Solder side
4P Female socket
to Camera
Solder side
5P Female socket
to RadarEye® set
50
40
54
5p Female Socket to RadarEye set
4p Female Socket to Camera
7p Male Socket to MonitorUnits in mm
Electrical connections
System manual

18 SM0974110 A 05
5.6. SRD sensor CAN Horizontal
Article number: 0004310 0004320
Antenna position Horizontal Vertical
Connectors position Side Top or bottom
Electrical
Supply voltage 8 to 16V (protected against reverse polarity).
Supply current 120mA (typ.).
Frequency ISM Band 24.000 GHz … 24.250 GHz (USA, EU Member states and EFTA countries)
Please consult Orlaco before using this radar in other areas.
Max. transmit power 20dBm (EIRP) ETSI 300 / 440 compliant with 250MHz bandwidth.
Detection area 2m ... 20m, divided in 5 equally sized segments.
Separation distance 1m ... 4m (configurable), mounting distance between radar units in case of Corner Rear setup.
Sensitivity Ability to detect a person of average child size. Moving object sensitivity (0 – 100, 50 is the current sensitivity).
Non-moving object sensitivity (0 – 100, 50 is the current sensitivity).
Obstacle reaction delay 50ms.
Output hold time 500ms.
Mechanical
Mounting For mounting four M4 Vibration dampers are included.
Resolution +/- 20cm.
Housing Waterproof and vibration proof.
Weight 0,60kg.
Operating temperature -40°C...+85°C.
Communication Monitor and radar communicate with the data link layer to transmit and receive CAN messages.
Communication speed: 250kbps. Each radar unit will send 1 message each 50ms (20 times per second).
Fully Compliant with CAN Standard rev 2.0 A and rev 2.0 B. ISO16845 certified.
Certication
Appprovals Frequency Communication standards: ETSI(Europe) and FCC(USA).
Available documentation User manual UM0972110 and System Manual SM0974110.
Preset the unit to:
UK 24.150 GHz … 24.250 GHz (high band)
France 24.000 GHz … 24.150 GHz (Low band)
Japan 24.050 GHz … 24.250 GHz
1 = Red = Power
2 = Blue = Can-L
3 = Black = Power 0V
4 = Blue/White = Can-H
5 = Orange = N.C.
1 = Red = Power
2 = Blue = Can-L
3 = Black = Power 0V
4 = Blue/White = Can-H
5 = Orange = M/S Communication
Cable M12 Green Cable M12 Red
Front side
connector
molded
M12 5p
male
Front side
connector
molded
M12 5p
female
Electrical connections
4
12
3
5
Code A
Front side
Connector Molded
M12 5p male
green code A
Front side
Connector Molded
M12 5p male
red code A
Front side
Connector Molded
M12 5p female
green code A
Front side
Connector Molded
M12 5p female
red code A
5
3
2
4
1
Code A
4
12
3
5
Code A
Front side
Connector Molded
M12 5p male
green code A
Front side
Connector Molded
M12 5p male
red code A
Front side
Connector Molded
M12 5p female
green code A
Front side
Connector Molded
M12 5p female
red code A
5
3
2
4
1
Code A
System manual

19
SM0974110 A 05
Terminator
M(green)
M(red) F(red)
(green)F
Interface
Power
RadarEye set corner rear, system overview
Set Art. No. 0403120
Primary Secondary
Monitor A
D
K
Camera C
B
H
Set SRD Corner Rear, Art. No. 0403120
consisting of:
2 x Art. No. 0004310 SRD Sensor CAN Horizontal
2 x Art. No. 0401330 Bracket SRD Sensor Corner Rear
1 x Art. No. 0350110 M12 Terminator 120 Ohm
Zones 2 3 4 5
range = 2m...20m
1
Separation
distance
Separation
distance
+ 0,5m
range = 2m...20m
Zones
14
32 5
RadarEye set center rear, system overview
Monitor A
Camera C
E
Interface
Power
Terminator
DK
Primary Secondary
B
M(red)
M(green)
(green)F(red)F
Set SRD Center Rear, Art. No. 0403100
consisting of:
2 x Art. No. 0004320 SRD sensor CAN vertical
1 x Art. No. 0401320 Bracket SRD Sensor center rear
1 x Art. No. 0301080 0,25m M12 M-S Red
1 x Art. No. 0350110 M12 Terminator 120 Ohm
Set Art. No. 0403100
100 42
100
Units in mm
4x M4 tapped
holes depth
10mm
4x M4
Vibration
dampers
included
Back side
11°
11°
90°
Detection zone
11° or 90° beam width
11° beam height
2-20m range
2-20m
Example Sets installation
Dimensions
System manual

20 SM0974110 A 05
5.7. Bracket SRD Sensor Center Rear
Article number: 0401320
Stainless steel, fully adjustable with mounting position for camera.
Dimensions Bracket center rear.
Largest turning radius R137
50 258
130
25
102
200
150
∅ 9,0 12x
30
Side view Front view
Bottom view
Units in mm
Figure 10
System manual
