Osaki TP-8500 User manual

OPERATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS
TP-8500 Massage Chair

Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our Company reserves the right to revise the design and description of this
product without any further notice. Please refer to the actual color of this product.
01
CONTENTS
02
06
07
08
19
Important Safety Instruction
Name and function of components
Function
Method of usage
Product specification

0302
When using an electrical appliance, basic precautions
should always be followed, including the following:
Read all instructionsbefore using (thisappliance)
DANGER-To reduce the risk of electric shock:
1) Alwaysunplug this appliancefrom the electricaloutlet immediately after
using and beforecleaning.
WARNING-To reduce the risk of burns, fire,
electric shock, or injury to Persons:
1) Anappliance should neverbe left unattendedwhen plugged in.Unplug
from outlet whennot in use,and before puttingon or takingoff parts.
2) Do notoperate under blanketor pillow.Excessive heating canoccur and
Cause fire, electricshock, or injuryto persons.
3) Close supervisionis necessary whenthis appliance isused by, on,or near
children, invalids, ordisabled persons.
4) Use theappliance only forits intended useas described inthis manual.
Do not useattachments not recommendedby the manufacturer.
5) Never operatethis appliance ifit has adamaged cord orplug, if itis not
working properly, if ithas been droppedor damaged, ordropped into
water. Returnthe appliance toa service centerfor examination andrepair.
6) Do notcarry this applianceby supply cordor use cordas a handle.
7) Keep thecord away fromheated surfaces.
8) Never operatethe appliance withthe air openingsblocked. Keep theair
openings free oflint, hair,and the like.
9) Never dropor insert anyobject into anyopening.
10) Do notuse outdoors.
11) Do not operatewhere aerosol (spray)products are beingused or where
oxygen is beingadministered.
12) To disconnect, turnall controls tothe off position, then remove plug from
outlet.
13) The appliance is intendedfor household andindoor use only.
14) Connect this applianceto a properlygrounded outlet only,see grounding
Safety And Maintenance
instructions .
15)Keep children awayfrom extended footsupport (or othersimilar parts
16)Do not usemassager in closeproximity to looseclothing or jewelry.
17)Keep long hairaway from massagerwhile in use.
GROUNDING INSTRUCTIONS
This product must be grounded ,if it should malfunction or breakdown ,grounding
provides a path of least resistance for electric current to reduce the risk of electric
shock ,this product is equipped with a cord having an equipment grounding
conductor and a grounding plug ,the plug must be plugged into an appropriate outlet
that is properly installed and grounded in accordance with all local codes and
ordinances
DANGER:Improper connection of the equipment grounding
conductor can result in a risk of electric shock ,check with a qualified electrician or
serviceman of you are in doubt as to whether the product is properly grounded ,do
not modify the plug provided with the product-if it will not fit the outlet,have a proper
outlet installed by a qualified electrician
1)This product is for use on nominal 120-volt circuit,and has a grounding plug that
looks like the plug illustrated in sketch on the page 13 ,A temporary adapter that
looks like the adapter illustrated in sketches B and C may be used to connect this
plug to a 2-pole receptacle as shown in sketch B if a properly grounded outlet is not
available the temporary adapter should be used only until a properly grounded
outlet (shetch A )can be installed by a qualified electrician ,the green colored rigid
ear ,lug ,or the like extending from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover ,Whenever the adapter is
used ,it must be held in place by a metal screw
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTION

0504

06 07
Function
Designed with a set of vertically movable,four wheel driven muted
intelligentmassage hands
Designed with emulation massage methods of shiatsu, kneading,
flapping,knocking, simultaneous kneading and flapping
Set with the shoulder automatic detection and location
Set with characterizedauto massage function: ache-improving, comfort, ease, fast
improving experience massage, upper body, lower body six kinds of automatic.
Set with memory set on function M1 and M2
Manual massage for the upper body with three options,fixed,partial and
overallmassage,with five levels of speed adjustable.in the state of flapping,shiatsu
and knocking,the width between the two kneading balls is adjustable with three
Levels:wide,medium and narrow.On partial and fixed point,the massage hands
can move up and down to adjust the massage point accurately.
Air pressure massage function with three modes:full body air pressure,arms
(upper arm set with 4 airbags, arm set with 8 airbags),leg set with 16 airbags,
three intensity optional.
Leg designed with roller massage function at the bottom of foot, two pairs of
papillae on toe root rotating massage; on the arch and heel mastoid skin scraping
massage.
Back heating function: carbon fiber far infrared heat source
Right arm is equipped with a USB charging function and lie-down function.
The footrest use double stepless extended to suit for different body heights.
Backrest frame down slides used technology to deviate from the wall by keeping
zero space, reach the maximum space saving
Leg lifting adjusting, the backrest frame lifting adjusting and automatic lay down
mode adjustment function
L shape back track fitting curves of the body, can realize the zero gravity when
back down
Name and function of components Function
1.Pillow pad
2.Upper arm air bag components
3.Arm air bag components
4.Armrest hotkey
5.Seat cushion
6.Leg rest frame
7.Foot rest frame
8.Calf stop sealing plate
9.Back rest pad
10.Armrest decoration
11.Manual controller pocket
12.Armrest
13.Side cover
14.Back cover
15.Manual controller
16.Drive box cover
17.Safety switch
18.Base caster
19.Power line and power plug
20.Power socket
21.Fuse box
22.Power switch
23.Manual controller socket
1
2
3
5
6
9
11
7
15
14
18
20
12
21 22 23
13
8
16
17
19
4
10

0908
Menory
Menory
Method of usage Method of usage
Note: The specific displays referto
the actual object of this product!
1.Switch power supply on
Diagram of plug in Diagram of the switch position of power supply
2.Start to massage
1). Press power button, massage chair automatically reclining, and start massage.
2). Automatic shoulder position and massage acupressure point detection, waiting
for the completion of testing.
3). If there is difference with the massage balls and the actual shoulder position,
youcan adjust the up and down button to a suitable position. Shoulder position
has 10 grades adjustable.It will run automatic massage if there is noadjustment
on shoulder position within 10 seconds
Button Description Display
Move the massage balls upward to a suitable position
Move the massage balls downward to a suitable position
Shoulder
adjust
High shoulder position
suitable shoulder position
Low shoulder position
4) Choose massage function to massage
Memory function massage
Function Button Display
Memory
massage
Press button Upper body / M1 or Lower body /M2 for 3 seconds, then
enter into memory massage function M1 or M2 , it will revert to the
previous memory massage mode.

1110
Characterized auto massage
Air pressure functionmassage
Auto F1
Auto F2
Auto F3
Auto F0
Auto F4
Auto F5
Massage point adjust (in fixed
point, partial modes you can
adjust the massage position)
Other manual function
Method of usage Method of usage
Function Button Feature Display
Characterized
auto
massage
Deeply massage on acupressure points,
effectively alleviate pain
Loosen body physique
Promote blood circulation
Fast to experience all the massage effect (press
for 2S, switch to speed press)
Massage focus on upper body
Massage focus on lower body
Upper body manual massage, lower body manual massage
1)Upper body manual massage
Function Button Adjust Massage Ball Display
Technique
Speed
Width
Shiatsu
Flap
Knead&flap
Knock
Knead
Speed And Width
Speed
Speed And Width
Speed
Speed And Width
Three Grades Speed Adjustable
Three Grades Widths Adjustable
Speed
Width
Function Button Description Display
Back
Stretch
Back Stretch
Back Stretch
Back Stretch
Massage hand
move up
Massage hand
move down
Function Button Description Display
Air pressure
mode
Intensity
Three air pressure modes(full body, arm and leg )
for Lower body
With three grades adjustable
Function Button Description Display
Roller
Heating
Sole roller: sole roller switch, with 3 speed levels
available
Far infrared back heating, has warm feeling when
it start to work 3 minutes later
Back Stretch
Back Stretch
H0
H1
H2
H3
H4
Fixed position (fixed point) massage back and forth
Small area (partial area) massage back and forth
Overall massage back and forth
Upper body massage back and forth
Lower body massage back and forth
Other manual function
Function Button Description
Calf rise
and drop
Backrest rise
and drop
Auto lay
down mode
Calf rest lifting button, press this button, calf restlifting slowly,
stop when release it
Calf rest decline button, press this button, calf rest decline
slowly, stop when release it
Backrest lifting button, press this button, backrest lifting slowly,
stop when release it
Backrest decline button, press this button, backrest decline
slowly, stop when release it
with three modes circulation function, when press the button,
turn into auto lay downmode.

13
12
Set with safety switch in a power supply
box, if there is heavy pressure on power
supply box, then forced stop back lying
function, prevent hurts peoplewhen lying.
Method of usage Method of usage
4.Turn off power, stop massage
3) Cut off the power of the whole machine.
Figure (Switch power off)
Diagram of the switch position of power supply Power switch method map
WARNING
1)Press power button during massage progress, all massage function will be stop
immediately, the backrest and footrest will return to original position automatically,
meanwhile you can set up memory function. After rated working time, all massage
functions will be finished, meanwhile you can set up memory function, but
backrest and footrest won't return to original position.
2)Memory store function: After rated working time or switch off, the hand controller
displays "Memory" and glitter, remind the users whether need to store the
massage mode before turn off, you can press the memory function buttons
M1 or M2 as you like, store the massage mode.
Open the master carton, take down the calf rest. (figure 1)
Remove the back cushion (note: please ensure the heat wire in the cushion was
unplugged before remove). (figure 2)
Figure 1 Figure 2
Zip the backrest kneading cloth open completely, put the cloth on the top of chair
(note: please remember to prevent the kneading cloth from dirty or damage).
( figure 3)
The calf rest decoration cover is card slot design, make an effort to pull it when
disassembly. (figure 4)
Figure 3 Figure 4
Pull
Unscrew the 8 screws of front dam-board (NEED NOT unscrew the 4 screws on
the bottom). (figure 5)
Open the front dam-board, unplug the joint of air pipe and power cord
corresponding to armrest. (figure 6)
Figure 5 Figure 6
5.Armrest disassembly method
Note: this method is only use for cannot easy move into small space, such as too
small room door, please do not arbitrarily disassemble.
Function Button Description
Calf rise
and drop
Backrest rise
and drop
Calf rest lifting button, press this button, calf restlifting slowly,
stop when release it
Calf rest decline button, press this button, calf rest decline
slowly, stop when release it
Backrest lifting button, press this button, backrest lifting slowly,
stop when release it
Backrest decline button, press this button, backrest decline
slowly, stop when release it
USB
3.USB recharging function and lie-down function.
ON/OFF
Switch Press to open and close the massage function.
USB recharging port, recharge smart devices (such as mobile
phone).

. Unscrew the screw on the front-end of armrest (note: the screw is in the side of
steel frame). (figure 7)
. Unscrew the screw on the front-end of armrest (note: be careful not missing the
plastic block for fixed). (figure 8)
Figure 7 Figure 8
. Unscrew the screw on the back-end of armrest (note: zip the backrest kneading
cloth open completely, you may find it). (figure 9)
. Gently lift up the front-end of armrest, pull out the buckle. (figure 10)
Figure 9 Figure 10
Lift up gently
. Gently pull forward the back-end of armrest to pull out the decoration cover, then
lift up the back-end of armrest to pull out the buckle. (figure 11)
. Unplug the joint of upper armrest air pipe (figure 12), the armrest removed completely.
Pull forward gently
Figure 11 Figure 12
Connect the air pipe on the back-end of armrest to the upper arm's. (figure 1)
Put the air pipe and power cord into the steel frame (avoid the air pipe stuck). (figure 2)
Figure 1 Figure 2
Hook the back-end of armrest on the steel frame (please note there are two, place
it on the upper one). (figure 3)
Insert the back-end of armrest into the decoration cover of upper arm. (figure 4)
Figure 3 Figure 4
Hook the front-end of armrest on the steel frame and lock the buckle. (figure 5)
Gently push the armrest down, double check if the hook well locked. (figure 6)
Put the plastic block between the armrest and calf rest pothook, then tighten the
up & down screws. (figure 7)
Tighten the screws on the back-end of armrest. (figure 8)
Figure 5 Figure 6
Figure 7 Figure 8
PRESS IT
DOWNWARD GENTLY
6.Armrest installation method
Method of usage Method of usage
15
14

Connect the joint of air pipe and power cord (note: there's marks on the air pipe and
size of cable connectors is different, you won't miss it). (figure 9)
Pull the calf rest air pipe and power cord through the hole of front dam-board, then
tighten the screws of dam-board. (figure 10)
Figure 9 Figure 10
Zip the backrest kneading cloth up. figure 11
Plug the heat plug of the back cushion into the heat hole on the backrest, put the
back cushion tidily on the backrest. (figure 12)
Figure 11 Figure 12
The calf rest decoration cover is card slot design, make an effort to push it when
assembly (note: please keep the cover tight with the side), armrest installation is
completed. (figure 13)
Push
Figure 13
7.Calf installation
Install the rotating shaft incalf fixed axis first, noticed the hole should be aligned, so
that the R shape pin assembly (chart 1)
After calf is connected with the fixed axis aligned, then insert (chart 2)
chart 1 chart 2
Plug R pin, then moved to the other side of the calf, and the plug R pin (chart 3)
Finished (chart 4)
chart3 chart4
When the machine under the working state, with lying and calf rest lifting, you
could not apply gravity on the calf, to prevent the massage chair does harm to
peoplebefore dumping(chart1).
chart2).
Ensure the mechanism hands not in the seat part ,otherwise will cause
uncomfortable in the Buttock when you seating in the chair(
Note
chart1 chart2
Method of usage Method of usage
17
16

18 19
Note:During movementyou must turn off the power switch firstand then unplug the
power line and hand controller connecting line
Method of usage
Product specification
9.Floor Protection
Put the heavy massage chairs on the wood floor for a longtime may damage thefloor,
so please place a carpet or other object to avoid this damage.
10.Method of movement
Make sure that all wires are far above the ground, tilt the backrest backward to
acertain degree (with the gravity center resting on the wheels), push the chair
forwardor backward with your hands and finally resume the chair to the normal
position in aslow and gentle manner.
Model: TP-8500
Name: Massage Chair
Rated voltage: 110-120V~ 60Hz
220-240V~ 50Hz/60Hz
Rated power input:150W
Rated time: 20Min
Safety structure: Class
Material introduction: PVC, PA, steel parts and electric &ele
-ctron parts
MATERIAL PU LEATHER CLOTH WOOD
Caution: Do not move the chairs with its wheels on wood floor, rough ground or in
anarrow space. Two people are required to lift the chair.During the lifting period, the
windscreen and backrest cover grooves as the focal point(Please do not lift armrest
directly)
Method of usage
8.Pillow and backrest pad's dismounting and use manual
Using pillows can reduce the kneading massage intensity on shoulder
andneck,according to your needs to decide whether the pillow pad is
needed(recommend headcushions). Backrest cushion and backrest connected
byzipper (1), head cushion and backrest pad connected by thread gluing (2)
Zipper Thread gluing
