Osaki OS-3000 User manual

INSTRUCTION MANUAL
MODEL NO.: OS-3000

1
Table of Contents
Safety Instructions ................................................................. 2-3
Chair Specifications ............................................................... 4
Parts of the Chair ................................................................... 5-6
Chair Installation .................................................................... 7-8
Moving the Chair .................................................................... 9
Controller Diagram ................................................................. 10
Operation Guide .................................................................... 11-16
Features ................................................................................. 17
Troubleshooting ..................................................................... 18
Product Maintenance and Precautions .................................. 18

2
Safety Instructions
01
● Please ensure that you insert massage chair plug into a proper electrical outlet.
● Make sure the power plug is securely inserted into the proper electrical outlet to
reduce the risk of short-circuit and fire.
● Always unplug the massage chair from the electrical outlet immediately after use and
before cleaning.
● DO NOT use the massage chair in places where the humidity is high.
● DO NOT use the massage chair outdoors and avoid places with direct sunlight.
● If the power goes off during use, be sure to turn the power switch to the OFF position
and pull the power plug out from the socket to prevent any damage from occurring
when the power is restored.
● Never operate the massage chair if the power cord is wet or damaged.
● Never plug/unplug the power cord from the socket with wet hands.
● Close and continuous supervision is necessary when this appliance is used by, on, or
near children, invalid or disabled persons.
● Use this appliance only for its intended use as decribed in this user manual.
● DO NOT use any attachment other than those recommended by this manual.
● DO NOT stand, sit or jump in the calves rest when massage chair is in use. This may
result in injury to yourself.
● DO NOT attempt to stand on the backrest and armrest. This may result in injury.
● Be careful not to fall asleep during the massage.
● Always keep the massage chair clean and never insert any object into the gaps on and
around the massage chair.
The plug must be fully inserted into an appropriate outlet. Improper connection of the
equipment-grounding conductor can result in the risk of electric shock.
Check with a qualified electrician or service technician, if you are in doubt as to whether
the product is properly grounded. Do not modify the plug provided with the product. If the
outlet is not suitable, please ensure that a proper outlet is installed by a qualified
electrician.
When using the massage chair, basic precautions should always be followed to reduce
the risk of electric shock, burns, fire, or injury to the person.
Read the following details before usage:

3
● DO NOT move the massage chair by pulling the power supply cord.
● Ensure that there are no persons (children in particular), pets or obstacles underneath
the massage chair prior to lowering the leg rest/backrest.
● Always check whether the surface of the massage chair is torn or ripped before usage.
If you find any unfamiliar rips in any area of the cloth in the backrest do not use the
massage chair.
● This appliance is designed for household use only.
● For those suffering from illnessed, please consult your doctor on whether you can use
the massage chair before using it.
● The following persons are requested to consult a doctor prior to use in order to reduce
the risk of user feeling sick or suffering from injury:
» Those who have malignant tumor.
» Those who suffer from heart disease.
» Those who are experiencing pregnancy, menstruation and puerperal fever.
» Those who require complete rest.
» Those who are under medical treatment.
» Those who suffer from back problems or whose backbone is abnormal or bent.
● If you experience pain during usage, stop using the massage chair immediately. If any
injuries occur, consult a doctor immediately.
● Never massage swollen or inflamed parts of the body.
● This product is non-professional appliance designed to provide a comfortable massage.
Do not use this product as a substitute for medical treatment.
● DO NOT use this massage chair for more than 30 minutes at one time. Limit massage
on a concentrated area to a maximum of 15 minutes. Over-massaging can lead to the
massage chair overheating, thus giving it a shorter lifespan.
● DO NOT operate where aerosol (spray) products are used or where oxygen is being
administered.
● The massage chair is not suitable for children aged 12 years old and below.

4
02 Chair Specifications
Description
Product Name
Model number of the Product
Power source
Alternating current
Power consumption
Timer
Maximum operating period
Specification
Luxury Massage Chair
OS-3000
~120V
60Hz
220W
5/10/15/20/25/30 minutes
30 minutes
Shiping dimension
(Length/width/height)
Weight
Length of wire
Usage condition
Storage condition
Safety feature
Using benefits
Product carton: 1320 x 770 x 870(mm)
Side panel carton: 960*620*370(mm)
Product gross weight: 115kg
Product net weight: 97kg
Controller wire: 1.2m
Power supply wire: 2.1m
Environment temperature: 20-60 degree
Contrasting humidity: 30-85RH
Storage temperature: 20-60 degree
Storage humidity level: 30-85RH
Equipped with overheated and power surge
safety protection
Increasing blood circulation
Relieving muscular fatigue

5
03 Parts of the Chair
Wheel
Pillow Pad
Backrest
Backrest Pad
Armrest
Controller
Seat Pad
Calvesrest
Legrest
Footrest

6
Massaging Position

7
04 Chair Installation
Step 1:
When positioning the massage chair, please leave 80cm of space behind the backrest
to allow free reclining of the backrest, and 80cm of space in front of the footrest to allow
free lift of the footrest.
Step 2:
Insert and connect the backrest to the bottom seat, and fasten the backrest into the
allocted slot.

8
Step 3:
Connect the wire plugs to the corresponding place in the seat according to the
marks given.
Step 4:
Unfold the backrest until you hear it click into place as shown in the diagram below.

9
05 Moving the Chair
1. Lift up the calves rest.
2. Then recline the chair to approximately to 45 degrees, so that you can easily move
the chair around the house with a slight pull or push.
Caution:
1) Before you move the chair, please put the footrest back into the original position first. Otherwise, injuries
might occur in the process of moving.
2) Avoid moving the massage chair when there is someone seated on it.
3) Placing a mat underneath the massage chair is advisable, as the moving process might leave scratches
on the floor surface.

10
06 Controller Diagram
A.
Full Body Auto
Programme
B.
Localised Auto
Programme

11
07 Operation Guide
Connect to the power supply, and turn the switch to “I” position. The chair is now in idle
mode. During idle mode, there are only seven funtions: ON/OFF, Foot Extend, Pause,
Recline, Sit Up, Lift Leg or Recline Leg that can be operated.
CONTROL BUTTONS FOR THE MASSAGE CHAIR
1. ON/OFF
The Start/Stop Control Button
Press once on this button and the backlight of the Remote Control will start blinking: the
chair is in idle mode. Press any massage function button to begin massage functions on
the chair. This will also start the Timer.
Press this button again to stop all massage functions, the massage rollers will return to its
original position.
2/3. Recline/Sit Up
Angle Adjustment Control Button for Massage Chair
These two control buttons can adjust the Reclining and Sit Up angle respectively.
Press once on the Reclining or Sit Up control button to adjust the Backrest and Footrest
to a comfortable position. Press any of the control button again to adjust for Reclining, Sit
Up, Lift Leg or Recline Leg, to confirm the position.
4/5. Lift Leg/Recline Leg
Angle Adjustment Control Button for Calves
These two control buttons can adjust massage angle on the Legrest.
Press once on the Lift Leg or Recline Leg control button, and the Legrest will adjust itself
to a comfortable position. Press any of the control buttons again for Reclining, Sit Up, Lift
Leg or Recline Leg to confirm the position.
Note: The adjustment angle functions will be activated by sustained pressing of the button
for 2 seconds.
6/7. Length Adjustment Control Button for Legrest
These two control buttons can adjust the length on the legrest.
Press the button once to adjust the legrest to a comfortable length. Press the button again
to confirm the length.

12
8. Length Auto Adjustment Control Button
It’s equipped with anAuto Function that length of footrest can be adjusted according to the
user’s leg length for a more effective massage. Every time the button is pressed, the auto
function will detect the best massage length.
9. Timer
The Timer’s Time Interval
After the masage process is activated, the chair will be automatically set on a 15-minute
Timer. Subsequently, every time the “TIMER” button is pressed, the Timer’s interval will be
changed in the sequence of “20>25>30>5>10>15” minutes.
When there is only 1 minute remaining in the set time, the Backlight of the Remote Control
will light up automatically, followed by 5 beeps to alert the user.
10. The Pause Button
When the chair is in massage mode and the user wants to temporarily pause it, press the
Pause button and all massage functions will stop. The “Pause” icon will be blinking on the
Liquid Crystal Display and the set time countdown will be paused as well. The chair is now
in idle mode. Only the “Pause, Sit Up, Lift Leg, Recline Leg” can be used. Press the Pause
button again to immediately cease the “Pause” function and resume the original massage
function. The countdown continues.
11. Zero-G
Press this button to active the Zero-G function. Press the button again to stop the Zero-G
massage function.
A. Full Body Auto Programme
If one of the five Auto Programmes is activated before the Auto Scan of the entire body,
the machine will automatically do a height scan for the back.At the same time the user can
manually adjust the massage height to the prefered level.
The following are the Auto Programmes available:
12. Healthcare
13. Relax
14. Therapy
15. Smart

13
16. Circulation
The Backrest and Footrest will resume original position when this Auto Programme is
about to end.
B. Localised Auto Programme
This programme gives precise massage at the exact part of the body for better
localized-massage effect.
17. Neck/Shoulder
Neck/Shoulder Auto Programme Start/Stop Control Button.
18. Back/Lumbar
Back/Lumbar Auto Programme Start/Stop Control Button.
19. Lower Body
Lower Body Start/Stop Control Button.
20. Demo
Press this button for a brief demonstration of the features of the massage chair.
21. Tapping
Tapping funtion Start/Stop Control Button- 3 sizes of width, 5 levels of speed to be
adjusted.
Press this button once to active the tapping function for a full back massage at medium
speed. Press the button again to stop the tapping massage function.
22. Clapping
Clapping function Start/Stop Control Button- 3 sizes of width, 5 levels of speed to be
adjusted.
Press this button once to active the clapping function for a full back massage at medium
speed. Press the button again to stop the clapping massage function.
23. Shiatsu
Shiatsu function Start/Stop Control Button- 3 sizes of width, 5 levels of speed to be
adjusted.

14
Press this button once to active the shiatse function for a full back massage at medium
intensity. Press the button again, to stop the shiatsu massage function.
24. Rolling
Rolling function Start/Stop Control Button- 3 sizes of width.
Press this button once and it will activate the Rolling function for full back massage. Press
again to stop the function.
This function cannot be used to perform “Spot” massage.
25. Swedish
Swedish function Start/Stop Control Button- 5 levels of speed to be adjusted.
Press this button once and it will activate the Swedish function for full back massage.
Press again to stop the function.
26. Speed
The Speed Adjustment button for Tapping, Clapping, Swedish and Shiatsu mode.
After activating the Tapping, Clapping, Swedish or Shiatsu function, every time the button
is pressed, the strength can be adjusted in the cycle.
27. Width
The Width Adjustment button for Tapping, Clapping, Shiatsu, Rolling mode.
After activating the Tapping, Clapping, Shiatsu or Rolling function, every time the button is
pressed, the width can be adjusted in the cycle.
28. Kneading
Kneading function Start/Stop Control Button- 5 strength levels to be adjusted
Press once on “Kneading” to activate full back-massage of Kneading mode, press again
to stop the Kneading function.
This function can be combined with Tapping/Clapping/Shiatsu to enjoy Kneading +
Tapping, Kneading + Clapping, Kneading + Shiatsu multi massage functions.
29. Strength
The Adjustment Button for Kneading Speed
After activating the Kneading function, every time the button is pressed, the speed can be
adjusted in the cycle.

15
Setting Spot or Localised Back Massage
30. Spot
The Spot or Localised Back massage
This button allows user to select Spot massage for any part on the back. Press this button
once to activate spot massage while the original massage mode continues to run at the
original position. Press again to cease Spot massage function and resume full back
massage function.
31. Partial
The Partial Back Massage
This button allows user to select Partial Massage for any part of the back. The position for
Partial Massage can be adjusted for a user friendly method of Localised Massage.
Press this button once to continue the original massage mode, while activating Partial
Massage, which takes the original position as the centre to perform Partial Massage with
the width of approx. 8cm. Press again to stop Partial Massage function and resume full
back massage function.
Setting Seat/Leg Vibration
32. Seat V
Seat Vibration function Start/Stop Control Button
Press the Vibration button once to activate the Vibration. Press this button again and it will
stop the Vibration function.
33. Back & Seat
Back and Seat Air-pressure Start/Stop Control Button- 5 levels of intensity to be adjusted.
Press once to activate Seat Air-pressure massage mode. Press again to stop the function.
34. Calves
Calves Air-pressure Control Button- 5 levels of intensity to be adjusted
Press once to activate Calves Air-pressure Massage Mode to enjoy rhythmic air-pressure
massage at the calves. Press again to stop the function.

16
35. Auto
Auto Air Squeeze function Start/Stop Button- 5 levels of intensity to be adjusted
Press once to activate pre-programmed Air-pressure Massage Mode to enjoy rhythmic
air-pressure massage. Press again to stop the function.
36. Intensity
The Intensity Adjustment Button for Air-pressure, Auto or Manual- 5 levels of intensity to
be chosen.
After activating the Air-pressure function, press this button to adjust the intensigy in the
cycle.
Finish Operating
Please press the “ON/OFF” button after use, the chair will stop operation. Massage
Rollers will resume to its original position; then switch the power supply button under the
chair to “O” and unplug the machine from the socket.

17
08
● Spring-styled massage that is specially structured for the back is designed according
to the curve of the human body to provide a more effective and thorough massage.
● The massage Rollers use an interlocking gear to provide in-depth massage to the
acupressure points on the back.
● Designed with double automatic adjustment, the chair’s backrest can be adjusted from
115 to 160, while the footrest, from 0 to 90 to suit you.
● The Timer function can be adjusted according to our desied duration of the massage
programme.
● Liquid Crystal Display and Glow-in-the-dark display for a user friendly operation even
in the dark.
● Designed with power surge and pressure detector as well as automatic temperature
sensor and auto shutdown mechanism for safety.
● The operation is controlled by intelligent microprocessor for excellent performance
and consistent quality.
Features
The operation of massage chair is controlled by a microcomputer that performs various
intelligent massage methods and combinations, like Kneading, Tapping, Clapping,
Shiatsu, Rolling, Vibration and Air Massage. All these methods massages acupressure
points accurately to effectively alleviate fatigue, promote metabolism and improve blood
circulation.
The chair is equipped with five sets of full body automatic programmes and three sets of
localised automatic programmes to thoroughly fulfill your various needs.
The combination of air pressure for the Seat Pad and Leg as well as the Calf and Vibration
functions can be set automatically for a more effective massage.

18
09
10
Troubleshooting
Product Maintenance And Precautions
This massage chair is controlled by microcomputer and is susceptible to power surge even
by +10% or -15%. The massage chair will show the following strange circumstances:
● Do not use water or other cleaning detergents to clean the massage chair.
● Do not stack, pull harshly, stab or slit the surface of the massage chair.
● Please press the buttons gently during operation, and avoid hitting with hard object.
● Please pull out the power supply plug after usage.
● The recommended duration of the operation is 30 minutes. It is not advisable for user
to exceed the suggested time frame.
The Massage Chair cannot operate even though
it has been connected to the power supply.
During operation, the Controller is working
but not the Massage Chair.
During operation, both the Controller and
Massage Chair are not working.
Situations Solution
1. Check whether the plug is well connected
and working well.
2. Check whether the switch on the Massage
Chair is turned to “I” position.
The Massage Chair could be overheated
after prolonged use. It will automatically
cool down to resume its normal condition.
Please turn OFF the power and allow the
Chair to cool off for 30 to 50 minutes.
1. If the set-time in the Timer is complete,
please press the timer function again
to resume operation.
2. Switch OFF power, and switch ON again
to activiate the Chair.
