OSP Designs FS18 User manual

FS18
BOOKCASE / DESK
OPERATING INSTRUCTIONS
LIMITED WarranTy
OSP Designs Warrants, to the original purchaser its products to be free from defects in material and workmanship for a period of 90 days. Defects
and damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other event beyond the control of OSP
Designs is not covered. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or consequential
damages is excluded. The user assumes all risk of injury resulting from use of this product. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state.
To make a warranty claim, contact Customer Service, provide model number, sales receipt and description of the problem. It is the customer’s
responsibility to prepay freight on any components returned to the factory. OSP Designs will pay return freight on components covered under
terms of warranty.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when hardware is missing.
Our Parts Department will do everything possible to promptly remedy the problem. Contact us via email parts@officestar.net, by Fax
1-909-930-5629, or toll free parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00 p.m. Pacific Time. OSP Designs P.O. Box
3520 Ontario, California 91761 USA
WarnInG
1. Do not use this product unless all screws and bolts are
securely tightened.
2. Check that all screws and bolts are tight every three months
or as needed.
3. Dispose of packing material properly. Do not use plastic
cover as head covering. It may cause suffocation.
4. Do not use this product as a stepladder.
5. Use this product for its intended purpose only.

IMPORTANT NOTE:
1. Use hand tools only for assembly as power tools
may cause damage
2. Carefully remove any staples used for packaging.
3. Phillips Screwdriver also needed for assembly
(not provided)
Remove all parts from carton, separate by part numbers indicated on parts list, and verify part quantities.
STEP 1 Insert three Cam Lock Studs (13) into each Support Rail (5). Insert two Cam Lock Studs (13) into bottom of Desk Top (1).
FULLY TIGHTEN ALL CAM LOCK STUDS (13).
STEP 2 Insert four Wooden Dowels (15) into Support Panel (3), attach both Support Rails (5) to Support Panel (3) and secure using six Cam Locks (14),
FULLY TIGHTEN ALL CAM LOCKS (14). Insert one Wooden Dowels (15) into each end of Trim Bars (9), attach two Angle Brackets (10) to both
Cross Panels (4) using one Short Screw (11) for each Angle Bracket (16). Secure one Trim Bar (9) to each Coross Panel (4) using two Short Screws (11) for
each Trim Bar (9). FULLY TIGHTEN ALL SHORT SCREWS (11).
STEP 3 Insert six Cam Lock Studs (13) into both Side Panels (2L & 2R), FULLY TIGHTEN ALL CAM LOCK STUDS (13).
STEP 4 Insert one Wooden Dowel (15) into Desk Top (1), attach Support Panel (3) to Desk Top (1) and secure using two Cam Locks (14).
Attach Support Brace (10) to Desk Top (1) and Support Panel (3) using four Short Bolts (12). FULLY TIGHTEN ALL CAM LOCKS (14)
AND ALL SHORT BOLTS (12).
FS18
BOOKCASE / DESK
ASSEMBLY INSTRUCTIONS
FS18
BOOKCASE / DESK
ASSEMBLY INSTRUCTIONS
STEP 5 Attach both Cross Panels (4) to Side Panel (2L) and secure using two Cam Locks (14) for each Cross Panel (4). Attach Desk Top (1) to
Side Panel (2L) and secure using two Cam Locks (14). FULLY TIGHTEN ALL CAM LOCKS (14).
STEP 6 Attach Side Panel (2R) to assembly and secure using six Cam Locks (14), FULLY TIGHTEN ALL CAM LOCKS (14).
STEP 7 Secure Top Back Panel (7) and Bottom Back Panel (8) to assembly using thirty four Short Screws (11),
FULLY TIGHTEN ALL SHORT SCREWS (11).
STEP 8 Insert Shelf Pins (14) into assembly, carefully place Shelves (2) onto Shelf Pins (14).
ATTENTION: MAKE SURE ALL SCREWS ARE FULLY TIGHTENED BEFORE BOOKCASE / DESK.
