oticon Oticon Opn S 1 miniRITE R User manual

Instructions for use miniRITE R
Oticon Opn S™
Oticon Opn Play™

Model overview
This booklet is valid for the Oticon Opn S™ and Oticon Opn Play™
families in the following hearing aid models:
Oticon Opn S 1 miniRITE R Oticon Opn Play 1 miniRITE R
Oticon Opn S 2 miniRITE R Oticon Opn Play 2 miniRITE R
Oticon Opn S 3 miniRITE R
The following speakers are available for the above models:
Speaker 60
Speaker 85
Speaker 100 (Power Instrument)
Power flex mould speaker 100 (Power Instrument)
Power flex mould speaker 105 (Power Instrument)
Introduction to this booklet
This booklet gives you guidance on how to use and maintain your
new hearing aid. Please read the booklet carefully, including the
Warnings section. This will help you to get the most out of your new
hearing aid.
Your hearing care professional has adjusted the hearing aid to meet
your needs. If you have further questions, please contact your
hearing care professional.
About Start-up Handling Options Tinnitus Warnings More info
For your convenience, this booklet contains a navigation bar to help
you easily navigate through the different sections.

Intended use
The hearing aid is intended to amplify and transmit sound to the
ear, and thereby compensate for impaired hearing within mild to
severe-to-profound hearing loss. This hearing aid is intended for
use by adults and children older than 36 months.
In short
Charging
Charge the hearing aid every night.
The LED on the hearing aid will turn RED when the hearing aid is
charging and GREEN when fully charged.
It takes 3 hours to fully charge the hearing aid.
ON/OFF
The hearing aid turns ON when you remove it from the charger.
The hearing aid turns OFF when you place it in the charger.
Always leave the charger connected to a power source when the
hearing aid is seated in the charging port. Switching off the charger
will make the hearing aid turn on and start using battery.
IMPORTANT NOTICE
The hearing aid amplification is uniquely adjusted and optimised
to your personal hearing capabilities during the hearing aid fitting
performed by your hearing care professional.

Table of contents
About
Your hearing aid, speaker and earpiece 10
Hearing aid 12
Charger 13
Start-up
Prepare charger 14
Charge the hearing aids 15
Charging time 16
Battery performance 17
Turn hearing aid ON/OFF using charger 18
Turn hearing aid ON/OFF using push button 19
Battery low indication 20
Identify left and right hearing aid 21
Put on hearing aid 22
Continues on next page

Handling
Cleaning 24
Replace standard earpieces 26
ProWax miniFit filter 28
Clean customised earpieces 30
Replace ProWax filter 31
Storage of the hearing aid 32
Flight mode 34
Options
Optional features and accessories 36
Change volume 37
Change program 38
Mute 40
Use hearing aid with iPhone and iPad 41
Wireless accessories and other options 44
Sound and LED indications 46
Table of contents
Tinnitus
Tinnitus SoundSupport™ (optional) 50
Sound and volume adjustments 52
Limitation on use time 55
Warnings
Tinnitus SoundSupport warnings 58
General warnings 60
More info
Troubleshooting guide 66
Water & dust resistant (IP68) 70
Hearing aid: Conditions of use 71
Warranty 72
Technical information 74
Your individual hearing aid settings 80

10 11
About Start-up Handling Options Tinnitus Warnings More info
About
Your hearing aid, speaker and earpiece The standard speakers use one of the following earpieces:
Standard earpieces: Customised earpieces:
LiteTip
VarioTherm® LiteTip
Open dome Micro mould
VarioTherm® micro mould
60 85
Please see details for replacing the dome
in section “Replace dome or GripTip”
® VarioTherm is a registered trademark
of Dreve
100 100
105
Power dome
Grip Tip
Available in small and large, left and
right, with or without vent.
Bass dome, single vent
Bass dome, double vent
* only as open dome for speaker 60
** not for open dome
6 mm5 mm* 8 mm 10 mm 12 mm**
Ear grip
(optional)
Standard
speakers
The hearing aids uses one of the following speakers:
Power flex
mould
speakers Dome sizes

12 13
About Start-up Handling Options Tinnitus Warnings More info
Hearing aid
What it is and does
Rechargeable battery
Only replaced by the
hearing care professional
Wax filter
Protects the
speaker from
wax
Speaker
Sound out
Ear grip
Holds the speaker
in place (optional)
Push button
Upper part:
Volume up,
program change
Lower part:
ON, OFF, Flight mode,
volume down,
program change
Microphones
Sound in
LED light
Charging, ON, OFF,
Flight mode status
Charger
What it is and does
Charging ports
For hearing aids when
charging
LED light
Status indicator for
charger ON/OFF
Power plug*
For power socket Power cable
Supply power
USB plug
Insert in power plug or
other power sources
* Power plug will vary from country to country

14 15
About Start-up Handling Options Tinnitus Warnings More info
Prepare charger
1. Insert the USB plug into the
power plug.
2. Insert the power plug into a
power socket.
The charger will turn on
automatically.
When the charger is connected to
power, the green LED turns on.
Connect to power source Charger is on
Charge the hearing aids
Place the hearing aids in the
charging ports as shown in the
picture.
The hearing aids LEDs will
turn on when the hearing aids are
correctly placed in the charger.
Hearing aid LED charging status:
Red light = Charging
Green light = Fully charged
Place hearing aids in charger Charging
Start-up
1 2

16 17
About Start-up Handling Options Tinnitus Warnings More info
Charging time
Fully charge your hearing aid before first time use.
Charge your hearing aid every night. That ensures you start your
day with a fully charged hearing aid.
Charging time may vary depending on the remaining capacity of
the battery. If your hearing aid is completely drained the normal
charging time is:
3 hours 1 hour 0.5 hour
Fully charged 50% charged 25 % charged
The charging process will automatically stop when the battery is
fully charged. Leave the hearing aid in the charger when you do not
use it. Remember to keep the charger connected to a power source.
Note charging time may vary between left and right hearing aid.
Battery performance
The daily battery performance varies depending on your individual
use and hearing aid settings.
Streaming sound from e.g. TV, mobile phone or ConnectClip can
influence daily battery performance.
If your hearing aid runs out of battery place it in the charger for a
re-charge. Additional usage time cannot be achieved by trying to
restart the hearing aid.
For best charging condition, the room temperature should be
between +5°C to +35°C.
If you experience that your hearing aid does not perform a full day,
it might be time to have the battery replaced. Contact your hearing
care professional.

18 19
About Start-up Handling Options Tinnitus Warnings More info
Turn hearing aid ON/OFF using charger
Your hearing aid automatically turns ON when removed from the
charger.
The hearing aid LED turns GREEN after 6 seconds, confirming that
it is ready for use. You may hear a start-up jingle.
Your hearing aid automatically turns OFF when placed in the
charger and starts charging. The LED turns RED.
IMPORTANT NOTICE
Always leave the charger connected to a power source when the
hearing aid is seated in the charging port. Switching off the charger will
make the hearing aid turn on and start using battery.
Turn hearing aid ON/OFF using push button
The hearing aid can be turned ON and OFF using the push button.
ON:
Press and hold the lower part of the push button for
approx. 2 seconds.
Release the button and wait until the hearing aid LED
turns GREEN.
The hearing aid is now turned ON. You may hear a short
start-up jingle.
OFF:
Press and hold the lower part of the button for approx.
3 seconds until the hearing aid LED turns RED and the
hearing aid plays 4 descending tones.
Release the push button and the hearing aid is turned OFF.
See overview “Sound and LED indications”.

20 21
About Start-up Handling Options Tinnitus Warnings More info
Battery low indication
When the battery is running low, you will hear three short beeps.
This will leave you approximately two hours before the hearing aid
stops working. The beeps will be repeated every 30 minutes. Just
before the battery runs out you will hear four descending tones.
If streaming audio to your hearing aid (from e.g. TV or mobile
phone) you have approximately one hour before the hearing aid
stops working, when you hear the three short beeps.
Stopping streaming will prolong the battery performance.
Three beeps
= The battery is running low
Four descending tones
= The battery has run out
Optional LED
Red blinks, continuously repeated, to indicate battery low.
Identify left and right hearing aid
It is important to distinguish between the left and the right hearing
aid, as they may be programmed differently.
You can find left/right colour indicators on the hearing aid itself
and on 60 and 85 speakers as shown. Indicators (either L or R) can
also be found on 100 speakers and some earpieces.
A RED indicator marks
the RIGHT hearing aid.
A BLUE indicator marks
the LEFT hearing aid.

22 About Start-up Handling Options Tinnitus Warnings More info
Put on hearing aid
Ear grip
(optional)
Place the hearing
aid behind your ear.
The speaker should
always be used
with an earpiece
attached. Use only
parts designed for
your hearing aid.
Hold the bend of
the speaker wire
between your
thumb and index
finger. The earpiece
should point toward
the opening of the
ear canal.
Gently push the
earpiece into your ear
canal until the
speaker wire sits
close to your head.
If the speaker has an
ear grip, place it in the
ear so it follows the
contour of the ear.
Step 1 Step 2 Step 3

24 25
About Start-up Handling Options Tinnitus Warnings More info
When handling your hearing aid, hold
it over a soft surface to avoid damage
if you drop it.
Clean the microphone openings
Carefully brush away any debris
from the openings. Gently brush the
surface. Make sure the brush is clean
and that it is not pressed into the
openings.
IMPORTANT NOTICE
Use a soft, dry cloth to clean the hearing aid. The hearing aid must
never be washed or immersed in water or other liquids.
Microphone
openings
Cleaning
The MultiTool contains a brush and wire loop for cleaning and
removing earwax. If you need a new MultiTool, please contact your
hearing care professional.
Brush
Wire loopMagnet
IMPORTANT NOTICE
The MultiTool has a built-in magnet. Keep the MultiTool 30 cm away
from credit cards and other magnetically sensitive devices.
Handling

26 27
About Start-up Handling Options Tinnitus Warnings More info
IMPORTANT NOTICE
If the earpiece is not on the speaker when removed from the ear,
the earpiece may still be in the ear canal. Consult your hearing care
professional for further instructions.
Replace standard earpieces
The standard earpiece (dome and Grip Tip) should not be cleaned.
If the earpiece is filled with wax, replace it with a new one. Grip Tip
needs to be replaced at least once a month.
Hold on to the
speaker and pull off
the earpiece.
Insert the speaker
exactly into the
middle of the
earpiece to obtain a
secure attachment.
Push firmly to ensure
that the earpiece is
fastened securely.
Step 1 Step 2 Step 3

28 29
About Start-up Handling Options Tinnitus Warnings More info
IMPORTANT NOTICE
Always use the same type of wax filter as was originally supplied with
the hearing aid. If you are in any doubt about the use or replacement of
wax filters, contact your hearing care professional.
Replace ProWax miniFit lter
2. Remove 3. Insert
Remove the tool
from the shell. The
tool has two pins,
one empty for re-
moval and one with
the new wax filter.
Push the empty pin
into the wax filter in
the speaker and pull
it out.
Insert the new wax
filter using the other
pin, remove the tool,
and throw it out.
1. Tool
New
filter
New
filter
Empty
pin
Old
filter
Final
Note:
If you use a mould or LiteTip, your hearing care professional must replace the wax filter in the speaker.
ProWax miniFit lter
The speaker has a white wax filter
attached to the end where the earpiece
is attached. The wax filter keeps wax
and debris from damaging the speaker.
Replace the filter when clogged, or if
the hearing aid does not sound normal.
Alternatively, contact your hearing care
professional.
Remove the earpiece from the speaker
before replacing the wax filter.
Wax filter

30 31
About Start-up Handling Options Tinnitus Warnings More info
Wax filter
Clean customised earpieces
The earpiece should be cleaned
regularly.
The earpiece has a white wax
filter*. The filter keeps wax
and debris from damaging the
speaker.
Replace the filter when
clogged, or if the hearing
aid does not sound normal.
Alternatively, contact your
hearing care professional.
Clean the vent by pressing
the brush through the hole,
twisting it slightly.
Vent
New
filter
Replace ProWax lter
2. Remove 3. Insert
Remove the tool
from the shell. The
tool has two pins,
one empty for
removal and one
with the new wax
filter.
Push the empty pin
into the wax filter
in the earpiece and
pull it out.
Insert the new wax
filter using the other
pin, remove the tool,
and throw it out.
1. Tool
New
filter
Old filter
* VarioTherm Micro mould and LiteTip do not have a wax filter

32 33
About Start-up Handling Options Tinnitus Warnings More info
Storage of the hearing aid
The charger is the best storage for the hearing aid. Anytime your
hearing aid is not in use, place it in the charger for charging. This
will ensure your hearing aid is always charged.
To ensure the longest life of the rechargeable battery in the
hearing aid do not expose to excessive heat. For example, do not
leave the hearing aid in the sun in a window or in a car, even if the
hearing aid is in the charger.
Long term storage (weeks, months)
Before storing the hearing aid for a longer period (more than 14
days) fully charge the hearing aid. Then turn the hearing aid off.
This way the battery can be charged again.
It is necessary to fully charge the hearing aid every 6 months to
protect the rechargeable battery. If a stored hearing aid is not
charged within a 6 months time frame, the rechargeable battery
will need to be replaced.
IMPORTANT NOTICE
Always leave the charger connected to a power source when the
hearing aid is seated in the charging port. Switching off the charger will
make the hearing aid turn on and start using power.

34 35
About Start-up Handling Options Tinnitus Warnings More info
Flight mode
To activate and deactivate flight mode press and hold the push
button (lower part) for 7 seconds.
Beep: The hearing aid plays 4 descending beeps
followed by 4 beeps. This indicates that flight mode is
activated or deactivated.
LED flight mode activated: A long red blink followed by
green, red, red. The LED will blink green, red, red a few
times. This confirms that flight mode is activated.
LED flight mode deactivated: A long red blink followed
by two long green blinks. This confirms that flight mode
is deactivated.
See overview “Sound and LED indications”.
Pressing the button on one hearing aid will activate flight mode on
both hearing aids.
When flight mode is activated, Bluetooth® is turned off. The
hearing aid will still be working.

36 37
About Start-up Handling Options Tinnitus Warnings More info
Optional features and accessories
The features and accessories described in the following pages are
optional. Please contact your hearing care professional to find out
how your hearing aid is programmed.
If you experience difficult listening situations, a special program
may be helpful. These are programmed by your hearing care
professional.
Write down hearing situations in which you may need help.
Options
You will hear
2 beeps at
start-up level
Change volume
The push button allows you to adjust the volume.
You will hear a beep when you turn the volume up or down.
MAXIMUM
START-UP
LEVEL
MINIMUM
Press button to
turn up volume
Press button to
turn down volume
To be filled out by the hearing care professional
Volume change LEFT RIGHT Short press

38 39
About Start-up Handling Options Tinnitus Warnings More info
Change program
Your hearing aid can have up to 4 different programs.
These are programmed by your hearing care professional.
To be filled out by the hearing care professional
Program Activation sound When to use
1“1 beep”
2“2 beeps”
3“3 beeps”
4“4 beeps”
Change program LEFT RIGHT Short press Long press
Press up or down
between programs.
Note that you can change continuously
between programs - both up and down
in the program order. For example, if you
want to go from program 1 to 4, you can
press the lower button once instead of
pressing the upper button 3 times.
