Output Technology LaserMatrix Floor Model Stacker Instruction Manual

LaserMatrix®
Floor Model Stacker
(Full Capacity Models LM1000A115 & LM2400A100)
Replacement Parts Catalog

COPYRIGHT 1994, OUTPUT TECHNOLOGY CORPORATION
All rights reserved. This document may not, in whole or in part, be copied, photocopied,
reproduced, translated, reduced to any electronic medium or machine readable form without prior
consent, in writing, from Output Technology Corporation.
Tri-Flow is a trademark of Thompson & Formby, Inc.
Output Technology Corporation
3808 North Sullivan Road
Building 3
Spokane, WA 99216
USA
We suggest you use genuine Output Technology Corporation supplies and authorized service
centers. Contact us at —
[phone] (Voice) or [phone] (Fax)
For service, please have the serial numbers of your printer and LaserMatrix Stacker handy so that
we can serve you more quickly.
WWW: http://www.output.com
Part No: 066-00466-02
Rev. E
January 23, 1998
CTS 046-00887-00-3

GENERAL
This catalog contains itemized lists of all field replaceable parts for the LaserMatrix Models
LM1000A115 and LM2400A100 Refoldlng Stackers. Ordering information is provided for field
replaceable units (FRUs). FRUs are illustrated at the end of this publication.
ORDERING INFORMATION
To order a field replaceable unit (FRU), proceed as follows:
1. Find the appropriate FRU item number from the illustrations in this publication.
2. From the FRU table on Page 5, match the FRU item number to the FRU part number.
3. Obtain the serial number of your stacker (along rim of refolding deck).
4. If applicable, have your Visa or MasterCard number and expiration date ready, and then
contact Output Technology Corporation by phone, fax, or mail:
3808 North Sullivan Road
Building 3
Spokane, WA 99216
Phone: [phone]
Fax: [phone]
FIELD SERVICE TOOLS (Recommended)
 Screwdrivers
1/8" Straight slot
#1 Phillips
#2 Phillips
 Open end wrenches or sockets, 3/8"

3/8" nutdriver
 Diagonal cutters
 Needle-nose pliers
 Utility knife
 Cable ties
 Tri-Flow silicone spray lubricant (Output Technology Part No. 125-00332-00).
1

ACCESSORIES & MISCELLANEOUS
Part No. Description
Qty Per
Assembly
Standard Accessories (Figure 1)
001-00742-XX
001-00745-XX
001-00746-XX
001-00797-XX
001-00808-XX
001-00812-XX
020-00185-XX
020-00208-XX
021-00616-XX
046-00878-XX
066-00452-XX
082-00341-XX
LM1000CK100
Support, Wirefrom Paper Stack
Support, Radiused Paper Chute1
Chute, Wireform Paper2
Guide, Main Paper
Guide, Auxiliary Paper
Bracket, Paper Chute Support
Cable, Control, 16 PPM Printer
Cable, Control, 24 PPM Printer
Assembly, Paper Chute
Wedge, Paper (with flexible platform)
Manual, Operator’s Guide
Glide, Floor
Power Supply (120 vac, 60Hz)
1
1
1
1
1
1
1
1
1
1
1
6
1
TÜV Accessories (International)
LM1000CK200 Power Supply (230 vac, 50Hz), Figure 2
020-00016-XX Adapter Cable for LM1000CK2003, Figure 3
Miscellaneous
066-00466-XX Manual, Replacement Parts Catalog
047-00029-XX Ship Kit4
LM1000A126 Casters, Set of 6 (2 locking, 4 nonlocking)
1Part of paper chute assembly (021-00616-XX).
2Part of paper chute assembly (021-00616-XX).
3Included with LM1000CK200. 020-00016-XX is a standard TÜV detachable power cord for use with 220/230 vac, 50/60Hz power
sources.
4Original shipping container or its replacement is required for proper shipment of refolding stacker.
2

Figure 1. Standard Accessories LD0-E2
3

Figure 2. TÜV Power Supply (LM1000CK200) LD0-F
Figure 3. Adapter Cable (020-00016-XX) Included with LM1000CK200 LD0-I
4

FIELD REPLACEABLE UNITS (FRUs)
The following list of FRUs is illustrated in Figures 4 through 6.
Item FRU Part No. Description
Qty Per
Assembly
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
21
22
23
23.5
24
25
26
27
28
29
31
001-00738-XX
001-00742-XX
001-00780-XX
001-00782-XX
001-00783-XX
001-00794-XX
001-00795-XX
001-00796-XX
001-00797-XX
001-00800-XX
001-00808-XX
002-00548-XX
002-00549-XX
002-00558-XX
002-00559-XX
002-00569-XX
002-00560-XX
020-00177-XX
020-00183-XX
021-00610-XX
040-00166-00
040-00166-01
046-00346-XX
046-00878-XX
082-00341-XX
082-00342-XX
082-00343-XX
082-00379-XX
082-00382-XX
107-00094-XX
Plate, Stacker Carrier
Support, Wireform Paper Stack
Plate, Motor Mounting
Cage, Wireform
Shaft, .375-in. Diameter, Steel
Bracket, Shaft Support
Coil, Right Hand
Coil, Left Hand
Guide, Main Paper
Plate, Gear Train
Guide, Auxiliary Paper
Bushing, Coil
Bearing, Refolding Adjust, Long
Cover, Gear Train
Bearing, Refolding Adjust, Short
Riser Shaft
Cap, Riser
Cable Assy, Motor
Cable Assy, Control5
Baseplate Assembly, Refolding Deck
PCB, Motor Control5
PCB, Motor Control
Switch & Cable Assembly, Power On Override
Wedge, Paper (with flexible platform)
Glide, Floor
Gear, Pinion
Gear, Rack
Gear, Drive (for coils)
Cap, Rail End
Motor, Geared, 12 vdc (for coils)
1
1
2
2
2
2
2
2
1
2
1
4
2
2
2
4
4
1
1
1
1
1
1
1
6
1
2
8
4
2
5Order Part 040-00166-01 or higher.
5

Figure 4. Refolding Deck (Top View) LD0-B4
6

Figure 5. Refolding Deck (Bottom View) LD0-A1
7

Figure 6a. Electronics (Old) LD0-C1
Figure 6b. Electronics (New) LD0-D1
