Output Technology LaserMatrix Table Top Stacker Instruction Manual

LaserMatrix®
Table Top Stacker
(Models LM1000A118 & LM2400A101)
Replacement Parts Catalog

COPYRIGHT 

1994, OUTPUT TECHNOLOGY CORPORATION
All rights reserved. This document may not, in whole or in part, be copied, photocopied,
reproduced, translated, reduced to any electronic medium or machine readable form without prior
consent, in writing, from Output Technology Corporation.
Output Technology Corporation
2310 North Fancher Road
Spokane, WA 99212-1381
USA
We suggest you use genuine Output Technology Corporation supplies and authorized service
centers. Contact us at —
[phone] (Voice) or [phone] (Fax)
For service, please have the serial numbers of your printer and LaserMatrix Stacker handy so that
we can serve you more quickly.
Output Technology maintains a Bulletin Board System (BBS) service. In the U.S.A., call (509)
533-1217 to access our BBS service for the latest drivers, firmware, pricing, maintenance and
troubleshooting aids, and application information. Also, you can contact us at —
FTP: ftp.output.com/public/output
WWW: http://www.output.com
Part No: 066-00467-02
Rev. E
January 23, 1998 CTS 046-00886-00-3

1
GENERAL
This catalog contains itemized lists of all field replaceable parts for the LaserMatrtix Models
LM1000A118 & LM2400A101 Table Top Refolding Stacker. Ordering information is provided for
field replaceable units (FRUs). FRUs are illustrated at the end of this publication.
ORDERING INFORMATION
To order a field replaceable unit (FRU), proceed as follows:
1. Find the appropriate FRU item number from the illustrations in this publication.
2. From the FRU table on Page 5, match the FRU item number to the FRU part number.
3. Obtain the serial number of your stacker (along rim of refolding deck).
4. If applicable, have your Visa or MasterCard number and expiration date ready, and then
contact Output Technology Corporation by phone, fax, or mail:
2310 North Fancher Road
Spokane, WA 99212-1381
Phone: [phone]
Fax: [phone]
FIELD SERVICE TOOLS (Recommended)
zScrewdrivers
1/8" Straight slot
#1 Phillips
#2 Phillips
zOpen end wrenches or sockets, 3/8"
z3/8" nutdriver
zDiagonal cutters
zNeedle-nose pliers
zUtility knife
zCable ties

2
ACCESSORIES & MISCELLANEOUS
Part No. Description Qty Per Assembly
Standard Accessories (Figure 1)
001-00820-XX
001-00822-XX
001-00825-XX
001-00826-XX
020-00187-XX
020-00210-XX
066-00454-XX
LM1000CK100
Support, Wireform Paper Stack
Chute, Wireform Paper1
Guide, Paper
Bracket, Paper Chute1
Cable, Control, 16 PPM
Cable, Control, 24 PPM
Manual, Operator’s Guide
Power Supply (120 vac, 60Hz)
1
1
1
1
1
1
1
1
TÜV Accessories (International)
LM1000CK200 Power Supply (230 vac, 50Hz), Figure 2
020-00016-XX Adapter Cable for LM1000CK2002, Figure 3
Miscellaneous
066-00467-XX Manual, Replacement Parts Catalog N/A
047-00030-XX Ship Kit31
1The Paper Chute (001-00822-XX) and Paper Chute Bracket (001-00826-XX) are shipped pre-assembled.
2Included in LM1000CK200. 020-00016-XX is a standard TÜV computer cable for use with 220/230 vac, 50/60Hz power sources.
3Original shipping container or its replacement is required for proper shipment of refolding stacker.

3
Figure 1. Standard Accessories MD0-C1

4
Figure 2. TÜV Power Supply (LM1000CK200) LD0-F
Figure 3. Adapter Cable (020-00016-XX) Included with LM1000CK200 LD0-I

5
FIELD REPLACEABLE UNITS (FRUs)
The following list of FRUs is illustrated in Figures 4 through 6.
Item FRU Part No. Description Qty Per Assembly
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
18
19
20
20.5
21
22
24
001-00795-XX
001-00796-XX
001-00817-XX
001-00818-XX
001-00819-XX
001-00820-XX
001-00821-XX
001-00825-XX
002-00548-XX
002-00549XX
002-00559-XX
002-00560-XX
002-00564-XX
002-00568-XX
020-00183-XX
020-00186-XX
021-00617-XX
040-00166-00
040-00166-01
046-00346-XX
082-00343-XX
082-00386-XX
107-00097-XX
Coil, Right Hand
Coil, Left Hand
Plate, Motor Mounting
Shaft, Adjust
Housing, Riser
Support, Wireform Paper Stack
Plate, Stacker Carrier
Guide, Paper
Bushing, Coil
Bearing, Refolding Adjust, Long
Bearing, Refolding Adjust, Short
Cap, Riser
Coupling, Motor Shaft
Riser Shaft
Cable Assy, Control4
Cable Assy, Motor
Baseplate Assembly
PCB, Motor Control
PCB, Motor Control
Switch & Cable Assembly, Power On Override
Gear, Rack
Gear, Pinion
Motor, Geared, 12 vdc (for coils)5
1
1
2
2
2
1
1
1
2
2
2
2
2
2
1
1
1
1
1
1
2
1
2
4Order Part No. 040-00166-01 or higher.
5Replace with Part No. 107-00094-XX.

6
Figure 4. Table Top Stacker (Top View) MD0-B2

7
Figure 5. Table Top Stacker (Bottom View) MD0-A1

8
Figure 6a. Electronics (Old) MD0-E1
Figure 6b. Electronics (New) MD0-D1
