OZAK VP-125 Manual

WAIST HEIGHT TURNSTILE
INSTALLATION AND MAINTENANCE HANDBOOK
WARRANTY CERTIFICATE
www.ozak-t.com
KK-1302-0001 R(11)
29.03.2022

2
KK-1302-0001 R(11) 29.03.2022
1. GENERAL INFORMATION ........................................................................................................................................4
1.1. Preface
1.2. General Informaton on Turnstles
1.3. Wast Heght Turnstle Models
2. SAFETY AND OPERATION ........................................................................................................................................5
2.1. Safety Warnngs and Symbols
2.2. Power Supply Fuse
2.3. Safety Related Instructons
2.4. Operatng Condtons
3. HANDLING AND INSTALLATION ..............................................................................................................................6
3.1. Handlng
3.2. Installaton
3.3. Installaton Illustratons For Derent Surface Mountng Bracket Versons
3.4. Arm Mountng (Fxed Arm Models)
3.5. Arm Mountng (Drop Arm Models)
3.6. Wng Mountng (Wde Access/ DDA models)
4. TURNSTILE SYSTEM SPECIFICATIONS ....................................................................................................................9
4.1. Wast Hegh Turnstle System Specfcatons Table
4.2. System Specfcatons – Trpod Models
4.3. System Specfcatons- Wde Access / DDA Models - Turnstles For Reduced Moblty
4.4. Indcators
4.5. Equpment and Accessores
5. SETUP AND OPERATION...........................................................................................................................................12
5.1. Power and Groundng Connectons
5.2. Control Board Inputs and Outputs
5.3. Control Board External Component Connectons
5.4. Control Board Settngs
5.4.1. Blockng Passage Drecton
5.4.2. Dp Swtch Settngs
5.4.3. Magnetc Encoder Arm Stop Settngs
A) Trpod
B) VIP
5.5. Hydraulc Damper Settngs (Manual Models)
6. POST INSTALLATION CHECK LIST ............................................................................................................................24
7. SERVICE AND MAINTENANCE .................................................................................................................................24
7.1. Mantenance Instructons
7.1.1. Recommended User Mantenance
7.1.2. Perodc Mantenance by Techncal Servce Personnel
7.2. Trouble Shootng and Repar Gude
8. LIST OF REPLACEMENT SPARE PARTS ....................................................................................................................27
8.1. Wast Heght Model Turnstles
8.2. Wde Access / DDA Models - Turnstles For Reduced Moblty
9. CE DECLARATION OF CONFORMITY AND WARRANTY ..........................................................................................29
9.1. Warranty Certfcate
9.2. Warranty Terms and Condtons
9.3. Cases Excluded From The Coverage of Warranty
9.4. Declaraton of CE Complance
INDEX

3
KK-1302-0001 R(11) 29.03.2022
1. GENERAL INFORMATION
1.1 Preface
1.2 General Informaton on Turnstles
1.3 Wast Heght Turnstle Models
MANUFACTURER:
ÖZAK Geçi Teknolojileri Sanayi Ticaret A..
Address : Çuhane Caddesi No:130 41080 Köseköy-KARTEPE / KOCAELİ
Tel & Fax : [phone] Pbx.
E-mail : [e-mail]
Web : www.ozak-t.com
Thank you for choosng the products of Özak and your confdence n our company.
Your system has been desgned and manufactured to meet the most demandng requrements of professonal
access control applcatons. All components of your system have been selected wth utmost care and thoroughly
tested to ensure optmal performance and relablty.
To safely operate your product wth maxmum performance and servce lfe please follow the nstructons
wrtten n ths manual carefully, and keep t for future reference. In case of any operatonal questons or
unexpected ssues please refer to the explanatons contaned n ths document.
To obtain technical support or replacement parts please contact Özak Technical Service Department by
E-mail or telephone.
Özak Technical Service Department:
Telephone : [phone] Ext: 1301-1304
E-mail : [e-mail]
Özak reserves the right to change the contents of this document without prior notice!
Turnstles are devces that enable passage control and prevent uncontrolled or unauthorzed passages n
stadums, sports halls, lesure facltes, busness centers, publc transportaton areas, museums, banks, ndustral
facltes and all premses where collectve entrance and ext control are requred.
As passage controllng unts, turnstles have the ablty to work wth any type of access control system such as
barcode, magnetc card, proxmty card readers, tokens, buttons etc. Wth the excepton of dsabled wde-access
panel models, only“one person at a tme”phlosophy s adopted for all turnstle products. The turnstles are
desgned for b-drectonal operaton whle allowng smple mode selecton by a dp swtch for restrcted or one
way free passage.
The turnstles are made of stanless steel or electrostatc powder coated DKP sheet metal. In double-sded
models, two separate passage systems are ntegrated nto a sngle structure. As the turnstles are anchored on
a wde surface area, the overall structure s frmly balanced and robust. Due to ther structural characterstcs,
turnstles are not affected by ran, water, or smlar outdoor condtons. All mechancal components are
galvanzed for protecton aganst corroson.
Our turnstles are certfed wth “TSEK product qualty” (A Turksh certfcaton of qualty) and CE Declaraton of
Conformty.
400 E 602 602 D
700 E/700 E N1 715 B
715 E
705 E/705 E N1
700 R
FKR 777
702 R/702 R N1
SWG 101
MRKT 404
702 B
500 E/500 E N1
500 E-D/500 E-D N1
700 E-D/700 E-D N1
400 BUS 605 D605
705 E-D/705 E-D N1

4
KK-1302-0001 R(11) 29.03.2022
2. SAFETY AND OPERATION
2.1 Safety Warnngs and Symbols
2.2 Power Supply Fuse
For Safety and proper operaton of the turnstle, all nstallaton and repar work must be performed by qualfed
techncal personnel only!
HIGH VOLTAGE WARNING LABEL
SE
Gnd.
PN
WARNING / DİKKAT
220 V. 50 Hz.
WARNING !
Never remove the protectve cover of the
power supply unt for any reason!
Observe the warnng sgns, power and
fuse values when performng any work
on the turnstle. Warnng labels and
power supples may vary dependng on
the turnstle model and type
GROUNDING SYMBOL
GGndnd ..
PP
NN
POWER CONNECTOR FRONT VIEW
Use only the same type and ratng of fuse as selected by
the manufacturer!
The fuse and a spare are located nsde AC power socket
Spare Fuse
24 V DC POWER SUPPLY
FU

5
KK-1302-0001 R(11) 29.03.2022
3. HANDLING AND INSTALLATION
2.3 Safety Related Instructons
2.4 Operatng Condtons
3.1 Handlng
3.2 Installaton
1. Users must not dsmantle the turnstles. Mantenance can only be performed by competent and authorzed
personnel. Mantenance work attempted by non- qualfed ndvduals may create danger to users and the
turnstle.
2. Turnstle must not be nstalled at places where there s a rsk of exploson caused by electrcal arcs or a
probable gas leakage.
3. Turnstle must be kept away from flammable envronments.
4. Turnstle should not be nstalled at places where there s vbraton.
5. Turnstle must not be kept n excessvely most envronments.
6. Turnstle must not be exposed to heat.
7. Turnstles must not be subjected to abusve treatment such as mpact or excessve shakng.
8. Turnstle must be kept away from hgh level magnetc felds.
9. Operatng voltage/ power range must be observed n all nstallatons. .
10. The power must be stable, properly grounded, nsulated.
11. Turnstles can only be operated under the envronmental condtons and temperatures specfed by the
manufacturer.
12. Chldren must not be allowed to play wth the turnstles.
13. All connectons must be confrmed to be correct before supplyng power to the turnstle.
14. Only materals and equpment recommended by the manufacturer must be used for the turnstle when
makng connectons nto the nput and output termnals.
15. All parts and accessores used n the turnstles must be approved by the manufacturer.
16. In case of any electrcal archng or faults caused by such condton, power must be dsconnected and
authorzed servcer or manufacturer must be contacted as soon as possble.
17. The power must be cut off before cleanng or mantenance.
18. Only clean, soft and most fabrcs (no abrasve materals) should be used for cleanng the turnstle surfaces.
19. Damaged turnstles must not be operated, and the authorzed dealer or the manufacturer’s techncal
support center should be contacted as soon as possble for repar.
1. More than one person must not attempt to pass at the same tme.
2. Turnstle must not be forced, kcked, abused or tampered wth to gan passage wthout authorzaton.
3. Turnstles must not be washed for cleanng purposes (applyng water wth a hose or pourng water from a
bucket. etc). Wpng off wth non abrasve materals such as a damp cloth s suffcent n most cases.
4. Chemcals and abrasves must not be used n any case for cleanng. The manufacturer s not responsble for
damages resultng from use of such materals.
1. Please pay specal attenton to carry the turnstles as orgnally packed by the manufacturer.
2. Follow the handlng and carryng nstructons wrtten on the package.
3. Do not place a heavy load on the turnstle package.
4. Do not place the packed turnstle on a wet ground.
5. Do not leave the packed turnstle under ran.
6. Durng handlng, use an approprate lft/crane wth suffcent lftng capacty.
7. Before startng nstallaton ensure that there s no shppng damage or mssng parts and hardware nsde
the package.
1. The nstallaton place should be selected accordng to user’s requrements. Ths selecton should not
prevent the smooth operaton of the turnstles.
2. Ensure that the nstallaton surface s flat, even and of proper strength. Flatten any uneven/ rough areas f
necessary.
3. Mark the holes and drll wth a sze 10 drll bt. Clean the debrs nsde the holes by pressurzed ar.
4. Fll the holes wth chemcal plaster and fx anchorng bolts (sze 8) n place by rotatng. Chemcal plaster
dres n about 25 mnutes.
5. Place turnstle on anchorng bolts and tghten the nuts to secure n place.
6. Connect power and control cables.
** A model specic mounting plan is supplied with the turnstile.

6
KK-1302-0001 R(11) 29.03.2022
G
G
n
n
d
d
.
.
P
P
N
N
SN
Res
+24V
B-A
A-B
N.O.
N.O.
Com
Com
Gnd
Gnd
Emg
INB
Gnd
Gnd
INA
1
23
56
8
-Power+
Enable
B-AA-B
J5 J4
J3
TopIndicatorsSideIndicatorsComm.Port
SelenoidOut
SelenoidOut
DirectionSensors
ON
DipSwitch
1234
U2
U7
U1
RL1
RL2
U9
Prg:XXXXXXXXXXX
220 V AC
SMPS KONTROL KARTI
C1
S2
S1
P1
P1
R1
Power and Control Wiring
Turnstile Body
Surface Mounting
Bracket
Wire Routing
Area
C1
P1
~67 mm (*)
~297 mm (*)
Shaded areas for
cable routing
Surface
Mounting
Bracket
(*) Measurements vary according to model.
Electronic Main Board
Version 1
Version
2V
ersion 3
3.2.1 Installaton Illustratons For Dfferent Surface Mountng Bracket Versons

7
KK-1302-0001 R(11) 29.03.2022
3.3 Arm Mountng (Fxed Arm Models)
3.4 Arm Mountng (Drop Arm Models)
Arm must be mounted correctly to prevent loosenng and droppng durng use!
CORRECT INSTALLATION
A1
V1
C1
V2
T1
V3
R1
Rotor Head View
CORRECT
WRONG
Rotor Head
Fixing
Washer
M10
Lock
Washer
M10x30
Bolt M4x15
ScrewLID
M4
Star
Washer
M4x10
Screw
1111111
A1 R1 V1 V2 C1 T1 V3
Rotor Arm
Rotor Head Washer
M10 Lock Washer
M4x15 Allen Screw
M4x10 Allen Screw
M4 Star Washer
Rotor Head Bolt
Rotor Head Cover
Rotor
WRONG INSTALLATION
1. Seat the arm on the rotor 2. Place Allen screws (2 pcs) 3. Tighten screws with 5 mm. keys

8
KK-1302-0001 R(11) 29.03.2022
3.5. Wng Mountng (Wde Access/ DDA models)
1. Insert panel in place. 2. Tighten top xing screw 3. Ti
ghten bottom xing screw
4. TURNSTILE SYSTEM SPECIFICATIONS
4.1 Wast Heght Turnstle System Specfcatons Table
MANUEL MOTORIZED MOVEMENT LOCK CONTROL STOPPING MAIN ROTOR LOCKS
400 E X
400 BUS X
602 / 602 D X
500 E / 500 E-D X
500 E N1 / 500 E-D N1 X
702 B X
700 E / 700 E-D X
700 E N1 / 700 E-D N1 X
700 R X
FKR 777 XAcrylic / Other**
605 / 605 D X
705 E / 705 E-D X
705 E N1 / 705 E-D N1 X
715 E X
715 B X
SWG 101 X---- Spring Steel
MRKT 404 X
Locked Ball
Bearing
---- 4 Arms ----
702 R / 702 R N1 X Motor Solenoid Motor Polyamide 3 Arms Polyamide
* Al.: Aluminium
** Optional Materials : Acrylic, Painted Steel, Stainless Steel, Wood.
3 Arms
Motor Motor
1 Wing
Steel
Manuel Push
(opt. Motor)
Solenoid
Hydraulic
Damper
Polyamide
+
Steel
Chrome/*
Push
MATERIALS
Polyamide
ARM / WING
WAIST HEIGHT
MODELS
MECHANISM OPERATIONAL FEATURES
Chrome/*

9
KK-1302-0001 R(11) 29.03.2022
4.2 System Specfcatons – Trpod Models
400 E 702 R/702 R N1
500 E/500 E N1
602 D 700 E-D/700 E-D N1 700 R
702 B
400 BUS 500 E-D/500 E-D N1
602 700 E/700 E N1 FKR 777
1. System s desgned for b-drectonal operaton. In standard models, when power s cut off, arms freewheel to
allow free passage n both drectons; optonally the arms can be set up to lock (fal-lock) when power s cut off.
2. Mechancal parts of the turnstles are made of stanless steel and galvanzed metal. Man lock, balancng systems
and lock offsets of the rotatng equpment are made of njecton molded polyamde.
3. Once passage s permtted and arms rotate 30 degrees, arms wll not return, and untl the completon of the
movement another passage s not allowed by the system.
4. After each complete passage the manual system returns to standby poston smoothly and quetly by means of a
hydraulc shock absorber. Motor drven versons complete rotaton by a gentle push followng authorzaton.
5. Sgnalzaton s provded wth drecton ndcators placed on both sdes of the upper body of the turnstle (Whle
green arrow ndcates actve passage drecton, red bar shows the blocked passage drecton). In addton to the
vsual sgnalzaton wth green/ red ndcators, an audo buzzer sgnal s provded durng passage.
6. Solenods used wthn the system are drven by PWM for relablty, optmal energy effcency and less heat. They
do not warm up to more than 10 degrees of the ambent temperature.
7. Electronc board controllng the system s desgned as“coated nsde the hole.”Therefore, t s not affected by
vbraton.
8. The mcro-processor based electronc control system used n the turnstles can be programmed for varous
functons and operatng modes by a smple dp swtch selecton.
9. All nputs and outputs are solated by opto-coupler and relay components for ncreased relablty.
10. Turnstles can be actvated or blocked wth the sgnals receved from data collecton systems (full closed). For
droppng arm applcatons, an arm control unt, battery charger and a rechargeable battery are ncluded as
standard feature.
11. The power supply s supported by“swtchng-mode”technology for better voltage regulaton and energy
effcency.
12. Turnstle only allows passages of authorzed people. If a person does not pass wthn a pre-set tme lmt
followng authorzaton contact (selectable for 6, 12, 18 or nfnte seconds), the system automatcally locks and
returns to standby.
13. After passage, the system provdes dry contact relay output for each drecton. An optonal counter can be used.
14. Electronc control unt of the turnstle s protected aganst water for outdoor nstallatons.
15. Turnstles can work n syncronzaton wth door-type metal detectors; for securty purposes, even passage of
a person wth authorzaton can be blocked automatcally upon recevng contact from a metal detector. The
system can be returned to normal operaton by the operator.
16. In cases of emergency the turnstle can be swtched nto “emergency mode” wth a normally closed manuel
button or relay from fre alarm system. In emergency mode arms rotate freely n both drectons allowng free
passage.
17. Turnstle passage drectons can be arranged n dfferent combnatons. (For example: one drecton blocked,
other drecton controlled or free; both drectons controlled, or one drecton free and other controlled)
18. Turnstles allow passage of only one person at a tme for each authorzaton contact nto the control board.
19. Card readers or smlar access control systems can be ntegrated nto the turnstles separately or jontly for
controllng both sdes dependng on the needs and specfc requrements.
20. Once a passage s completed, an entrance or ext drecton data (dry contact) s provded to the data collecton
termnal.

10
KK-1302-0001 R(11) 29.03.2022
4.4 Indcators
4.5 Equpment and Accessores
605 D
705 E/705 E N1 605 715 B
705 E-D/705 E-D N1 605 D 715 E
1. Mcroprocessor controlled, b-drectonal wde access system (Only 715-B ve 715-E models are un-
drectonal)
2. PWM DC motor drven system for quet and effcent operaton.
3. Panel unlocks and opens 90°automatcally n ether drecton when a contact s receved on Input A or Input
B termnals. The panel stops and tres to contnue ts movement once more f t meets an obstacle durng ts
movement. If the obstacle s stll present an alarm s actvated and the panel s released. The system self-
resets wthn 8 seconds.
4. Tmng can be re-set manually or by an optonal photocell unt for mmedate closng of the panel followng
a passage.
5. Emergency Mode: The panel opens automatcally n ether drecton as determned by the dp swtch
settng when emergency mode s actvated by openng a normally closed swtch or fre alarm relay contact.
Unt returns to normal operaton when emg-gnd contact s re-establshed.
The system features status indicators on both sides for user guidance.
RED CROSS: System is closed GREEN ARROW:Passage allowed.
In addition to the side indicators, an optional top passage indicator is available which provides further guidance by a blinking green
arrow during passage. In alarm mode the indicators alternately blink in red and green and buzzer is heard.
Buzzer is heard when a passage is authorized.
The
system
4.3 System Specfcatons- Wde Access/ DDA Models-Turnstles For Reduced Moblty
Pass Guidance Pressure Earth
Quake
Under
Arm
Passage
Climb
Over
Pasagge
Weight
400 E ΟΟ Ο Ο Ο − Ο Ο − Ο Ο Ο − Ο Ο
400 BUS ΟΟ Ο Ο Ο − Ο Ο − Ο Ο Ο − Ο Ο
602 / 602 D ΟΟΟΟΟΟΟ Ο ΟΟΟΟΟΟΟ
500 E / 500 E-D ΟΟΟΟΟΟΟ Ο ΟΟΟΟΟΟΟ
500 E N1 / 500 E-D N1 ΟΟΟΟΟΟΟ Ο ΟΟΟΟΟΟΟ
702 B   ΟΟΟΟΟΟ Ο ΟΟΟΟΟΟΟ
702 R / 702 R N1   ΟΟΟΟΟΟ Ο ΟΟΟΟΟΟΟ
700 E / 700 E-D ΟΟΟΟΟΟΟ Ο ΟΟΟΟΟΟΟ
700 E N1 / 700 E-D N1 ΟΟΟΟΟΟΟ Ο ΟΟΟΟΟΟΟ
700 R ΟΟΟΟΟΟΟ Ο ΟΟΟΟΟΟΟ
FKR 777   ΟΟΟΟΟΟ Ο ΟΟΟΟΟΟΟ
605 / 605 D ΟΟ Ο Ο Ο − Ο Ο Ο Ο − Ο Ο Ο Ο
705 E / 705 E-D ΟΟ Ο Ο Ο − Ο Ο Ο Ο − Ο Ο Ο Ο
705 E N1 / 705 E-D N1 ΟΟ Ο Ο Ο − Ο Ο Ο Ο − Ο Ο Ο Ο
715 E ΟΟ Ο Ο Ο − Ο Ο Ο Ο − Ο Ο Ο Ο
715 B ΟΟ Ο Ο Ο − Ο Ο Ο Ο − Ο Ο Ο Ο
SWG 101 −−−−−−−− − −−−−−−−
MRKT 404 −−−−−−−− − −−−−−−−
Waist Height (Tripods)
Turnstiles for
Reduced Mobility
Free
Passage
Counter Passage
Limiter
Standard Features
Indicators
MODEL
Optional Features / Accessories
Alarm Unit
Photocell Coin
System
Intercom
Unit
Heater
Positive
Dropping
Arm
Remote
Control
Card
Reader
System
- Standard
O - Optional

11
KK-1302-0001 R(11) 29.03.2022
5. SET UP AND OPERATION
5.1 Power and Groundng Connectons
TURNSTILE POWER WARNING LABEL
Groundng (Gnd.)
Proper groundng must be ensured to
prevent shock hazard!
Power and groundng connectons
must be made by a qualfed electrcan
n accordance wth the relevant
local regulatons usng approprate
materals!
Never remove the protectve
cover of the power supply unt
for any reason! In case of a
power supply falure, the power
supply unt must be replaced
wth an orgnal unt obtaned
from Ozak.
G
G
n
n
d
d
.
.
P
P
N
N
SN
Res
+24V
B-A
A-B
N.O.
N.O.
Com
Com
Gnd
Gnd
Emg
INB
Gnd
Gnd
INA
1
23
56
8
- Power +
Enable
B- AA-B
J5 J4
J3
Top IndicatorsSide IndicatorsComm.Po rt
Selenoid Out
Selenoid Out
Direction Sensors
ON
DipSwitch
1234
U2
U7
U1
RL1
RL2
U9
Prg: XXXXXXXXXXX
220 V AC
SMPS Control Board
Wire Routing Area
Mounting Bracket
3 x 1,5 TTR Power cable
minimum 2 meters above
surface
Data cable (CAT 5, Cat 6 etc.)
minimum 2 meters above
surface
Concrete
depth
150 mm
FU
Gnd.
PN
WARNING / DİKKAT
220 V. 50 Hz.
SE
FU

12
KK-1302-0001 R(11) 29.03.2022
5.2 Control Board Inputs and Outputs
For TRN 1203
SN
Access Control Terminal
Res
+24V
B-AB-A or A-B A-B
N.O. N.O.
Com Com
Gnd Gnd Emg INB Gnd Gnd
Gnd
Gnd
INA
1
23 7
56
8
- Power +
B-AA-B
J3
Top IndicatorsSide Indicators
Solenoid Out
Solenoid Out
Direction Sensors
ON
DipSwitch
1234
U2
U7
U1
RL1
RL2
U9
Prg: XXXXXXXXXXX
Rx
Tx
I/O_1
I/O_2
I/O_3
I/O_4
Out_P3
Out_P2
Out_P1
+5 V
+24 V
Gnd
0.5 - 1 sn dry contact
or open collector input
888888
Optional counter
1N4001
or similar
Busy Out
or or
TRN1203
0.5 - 1 sn
busy
B-AA-B
Enable
Gnd
Passage conrmation dry contact output Use with access control systems, counters etc. accessories (0.5 sec. N.O. contact)
Buzzer Jumper (Buzzer disabled when removed.)
Connect a jumper from Enable A-B or B-A to Gnd to block a passage direction.
Res: Manual Time Reset (Optional)
24 VDC
Optional counter
sample connection
B A
During Passege = 0
Emg: Emergency-Free Access Mode (when contact is open.)
Gnd
Enable
*Motor Control
(Motorized Models)
*

13
KK-1302-0001 R(11) 29.03.2022
For TRN 1901
*Motor Control
(Motorized Models)
1
EXT1
EXT2
2375
6
8
Top IndicatorsSide IndicatorsMotor OutSolenoid Out Solenoid Out
- Power + Direction Sensors
ON
1 2 3 4
Rx
Tx
I/O_1 I/O_2 I/O_3 I/O_4
Out_P3 Out_P2 Out_P1
+5 V
+24 V
Gnd
Access Control Terminal
Gnd
Micro USB Connection
Programming input socket
PC,tablet,cell phone etc connection plug
Emg;Emergency input (Normally Closed contact-free passage when contact open)
Res: Manuel Time Reset (optional)
0.5 - 1 sec dry contact
collector input
veya veya
0.5 - 1 sn
Busy Out
Gnd
Inhibit terminal/ blocks access when shorted to gnd
Alarm
Res Emg InB Gnd Gnd Gnd
InA
InhA InhB
+24VBusy
A-B N.o.
Com
B-A N.o.
Com
AL
N.o.
Com
B-A or A-B
24 VDC
Optional counter
sample connection
888888
Optional counter
1N4001 etc.
Busy = 0
Closed in alarm
RL ARL BRL AL
Passage conrmation relay contact terminals; Use with access control systems, counter etc. (500mS N.O. contact)
B A
I.S.P.
Gnd
Ext
In 1
Ext
In 2
Ext
Out 1
+24 VGnd
Dry contact or open collector input/ access violation alarm photosensor inputs
*

14
KK-1302-0001 R(11) 29.03.2022
For TRN 2101 S/E
Gnd
Wi module for communication
PC, tablet, cellphone etc. communication with.
or or
0.5 - 1 sn
Busy Out
Gnd
Alarm
B-A veya A-B
888888
Busy = 0
Closed in alarm
B A
I.S.P.
Gnd
1
EXT1
Buzz.On/O
2345
6
Top IndicatorsSide IndicatorsExternal OutSolenoid Out
9
+ Battery -
Solenoid Out
ON
1234
Rx
Tx
I/O_1 I/O_2 I/O_3 I/O_4
Out_P3 Out_P2 Out_P1
+5 V
+24 V
Gnd
Res Emg InB Gnd Gnd Gnd
InA
InhA InhB
+24VBusy
A-B N.o.
Com
B-A N.o.
Com
AL
N.o.
Com
RL ARL BRL AL
Ext
In 1
Ext
In 2
Ext
Out 1
+24 VGnd
Direction Sensors
8
- Power +
10 11
+ Motor Out -
MAS-12 Position sensor
Drop arm connector socket
Motor out
12V DC battery
24V SMPS
M
N
S
Access Control Terminal
Programming input socket
Emg; Emergency input (Normally Closed contact-free passage when contact open)
Res: Manuel Time Reset (optional)
0.5 - 1 sec dry contact
collector input
Inhibit terminal/ blocks access when shorted to gnd
24 VDC
Optional counter
sample connection
Optional counter
Passage conrmation relay contact terminals; Use with access control systems, counter etc. (500mS N.O. contact)
Dry contact or open collector input/ access violation alarm photosensor inputs
1N4001 etc.
TRN 2101 E version includes motor driver. Drop arm and batt. charge circuits on left. TRN 2101 S version does not include these circuits. except power input socket (8)

15
KK-1302-0001 R(11) 29.03.2022
5.3 Control Board External Component Connectons
For TRN 1203
SN
Res
+24V
B-A
A-B
N.O.
N.O.
Com
Com
Gnd
Gnd
Emg
INB
Gnd
Gnd
INA
1
23 7
56
8
- Power +
J3
Top IndicatorsSide Indicators
Selenoid Out
Selenoid Out
Direction Sensors
ON
DipSwitch
1234
U2
U7
U1
RL1
RL2
U9
Prg: XXXXXXXXXXX
10
11
2
3
1
6
57
13
A
A
8
D
D
C
C
B
B
9
12
Motor Control
B-AA-B
Enable
Gnd
14
1. Solenod A-B
2. Top Passage Indcator and Buzzer
3. Sde ndcators
4. Optonal Comm. Port
5. Solenod B-A
6. Drecton Photo Sensor
7. Motor Control
8. Power Input (24 VDC)
9. Dp Swtch
10. Control Inputs
11. Passage Confrmaton Contact
12. Buzzer Enable/Dsable
13. External Module Connector
(Motor Drver, Drop Arm Control etc.)
14. Inhbt Termnal
A. Board Seral Number
B. Stock Code
C. Producton Number
D. Board Model
--------------------------------------------------------------
Match socket and cable
numbers when replacng
boards and other parts !
Pay attenton to pn
markers when replacng
mcroprocessors !

16
KK-1302-0001 R(11) 29.03.2022
For TRN 1901
1. Solenod A-B
2. Top Indcator
3. Sde Indcator Outputs
4. USB Comm. Port
5. Solenod B-A
6. Drecton Photosensor Inputs
7. Motor Control (Motorzed Models)
8. Power Inpıt
9. Dp Swtch
10. Control Inputs
11. Passage Feedback Relay Outputs
12. Buzzer
13. Auxlary Modul Connectons (Motor
Drve, Drop Arm Control Board etc.)
14. Inhbt Termnal
15. ISP Connecton
16. Extra Comms. Modul Connecton
17. Extra Connector
18. Auxlary Connector
A. Board Seral Number
B. Stock Code
C. Producton Number
D. Board Model
--------------------------------------------------------------
B
B
DipSwitch
A
A
D
D
C
C
C
1
EXT1
EXT2
2375
6
8
Top IndicatorsSide IndicatorsMotor OutSolenoid Out Solenoid Out
- Power + Direction Sensors
ON
1234
Rx
Tx
I/O_1
I/O_2
I/O_3
I/O_4
Out_P3
Out_P2
Out_P1
+5 V
+24 V
Gnd
Res
Emg
InB
Gnd
Gnd
Gnd
InA
InhA
InhB
+24VBusy
A-B
N.o.
Com
B-A
N.o.
Com
AL
N.o.
Com
RL ARL BRL AL
Ext
In 1
Ext
In 2
Ext
Out 1
+24 VGnd
1
2
4
3
7
5
8
6
13
9
10
11
14
15
18
16
17
12
Match socket and cable
numbers when replacng
boards and other parts !

17
KK-1302-0001 R(11) 29.03.2022
For TRN 2101 S/E
B
A
D
C
1
EXT1
Buzz.On/O
2345
6
Top IndicatorsSide IndicatorsExternal outSolenoid Out
9
+ Battery -
Solenoid Out
ON
1234
Rx
Tx
I/O_1
I/O_2
I/O_3
I/O_4
Out_P3
Out_P2
Out_P1
+5 V
+24 V
Gnd
Res
Emg
InB
Gnd
Gnd
Gnd
InA
InhA
InhB
+24VBusy
A-B
N.o.
Com
B-A
N.o.
Com
AL
N.o.
Com
RL ARL BRL AL
Ext
In 1
Ext
In 2
Ext
Out 1
+24 VGnd
Direction Sensors
8
- Power +
10
11
+ Motor Out -
20
14
19
7
16
17
9
10
11
21 22
23
12
13
8
52
3
41
6
18
15
Match socket and cable
numbers when replacng
boards and other parts !
1. Solenod A-B
2. Top Indcator
3. Sde Indcator Outputs
4. External Out
5. Solenod B-A
6. Drecton Photosensor Inputs
7. Wf Module For Communcaton
8. Power Inpıt
9. Battery Socket
10. Motor Output Socket
11. Drop Arm Socket
12. Buzzer
13. Auxlary Modul Connectons
(Motor Drve, Drop Arm Control
Board etc.)
14. Inhbt Termnal
15. ISP Connecton
16. Extra Comms. Modul Connecton
(RS 485 / 232 / TCP IP)
17. Buzzer On/Off
18. Dp Swtch
19. Control Inputs
20. Passage Feedback Relay Outputs
21. Servce Button
22. Reset Button
23. Auxlary Connector
--------------------------------------
A. Board Seral Number
B. Stock Code
C. Producton Number
D. Board Model

18
KK-1302-0001 R(11) 29.03.2022
Wrng Dagram For AVIR 800 Only
Operaton Sequence 1. Check reader nput (Normally Open) Note: If reader s not used, place jumper between In1 and Gnd 2. Check thermal scanner (NC contact opens for 2 sec. f temp. readng s wthn set range) Note: If thermal Scanner s not used, leave termnal In2 open 3. Check Left and Rght hand sensors (Normally Closed-Open contact when hand nsde) 4. Release turnstle for one passage (relay contact to IN A--Gnd termnals of turnstle control board) Note: System s noperable when lqud level sensor output closes-Low level warnng lght ON.
PROXIMITY CARD
READER
OR
TURNSTILE INPUT
THERMAL SCANNER
RIGHT HAND
SENSOR
LEFT HAND SENSOR
LIQUID LEVEL
SENSOR
24VDC POWER SUPPLY
GND
+24V
IFC1010 INTERFACE BOARD
DRY CONTACT
OR
RELAY OUT
RELAY
TRN1901
TURNSTILE CONTROL BOARD
Insert jumper into IN 1 and GND if reader is not used
NO
NC
NC
NO
NC 2 sec. open if
temp. ok

19
KK-1302-0001 R(11) 29.03.2022
To block entry nto A or B drecton, short enable pns (J4,J5). Turnstle wll not allow passage n the blocked
drecton and ndcator for that drecton wll turn red to show blocked access. Ths feature can be used wth a
metal detector to automatcally block access for securty purposes or settng the turnstle for one way traffc
operaton.
Connect a jumper from Inhbt A-B or B-A to Gnd to
block a passage drecton.
open open
nhbted nhbted
5.4 Control Board Settngs
5.4.1 Blockng Passage Drecton
For TRN 1203
To block entry nto A or B drecton, short enable pns (J4,J5). Turnstle wll not allow passage n the blocked
drecton and ndcator for that drecton wll turn red to show blocked access. Ths feature can be used wth a
metal detector to automatcally block access for securty purposes or settng the turnstle for one way traffc
operaton.
Connect a jumper from Enable A-B or B-A to Gnd
to block a passage drecton.
nhbted nhbted
open open
For TRN 1901 - For TRN 2101S/E

20
KK-1302-0001 R(11) 29.03.2022
5.4.2 Dp Swtch Settngs
• Trpod Turnstles: Tme out and mode settngs of the turnstle are selected by the dp swtch located on the
control board as explaned below.
FIG
FIG
1
1
FIG
FIG
2
2
FIG
FIG
4
4
FIG
FIG
3
3
B A B A B A
B A
FUNTION (PROGRAM) SELECTION
3
1
3
2
4
4D
IAGRAM
DIPSWITCH
FUNCTION
OFF Bi-directional operation
A-B free, B-A controlled access
Single input, activation in both directions
B-A free, A-B controlled access
OFF
OFF
OFF
ON
ON
ONON
TIME SETUP
DIPSWITCH
12 TIME
OFF OFF 6 sec.
12 sec.
18 sec.
INFINITY
OFF
OFF
ON
ON
ONON
SWITCH NO
1 TIME SETUP 1
TIME SETUP 2
PROGRAM SETUP 1
PROGRAM SETUP 2
2
3
4
EXPLANATION
ON
OFF
ON
OFF
ON
OFF
FIG 1. B-drectonal controlled passage: A card reader or button s used for each drecton
FIG 2. B- drectonal passage by a sngle control devce: A sngle reader or button connected nto In A
allows passage n both drectons
FIG 3. A drecton free, B drecton controlled passage: Example: Controlled entry –free ext nto a buldng.
FIG 4. B drecton free, A drecton controlled passage
• Wide Access/ DDA Models: Swtch number 2: Sets‘stay open’ duraton to 2 seconds. Default s 6 seconds.
Swtch number 3: Sets emergency openng drecton
Swtch number 4: Allows open/ tmeout reset -close commands by a sngle
contact nto In A or B. Panel closes wthout watng for tmeout perod
when nput contact s repeated.
All other settings are as explained in table above
TSC Manager app allows quck access to turnstle settngs
wth on/off swtch optons n the menu.
TSC Manager applcaton can be downloaded from google
playstore whch s avalable n all androd phones. Scan the
QR code on the rght to download TSC Manager applcaton.
