Ozito DMM-080U User manual

MULTI
PURPOSE
MIXER
1050W
ORIGINAL INSTRUCTIONS
SPECIFICATIONS
Motor: 1050W
Input: 230-240V ~ 50Hz
No Load Speed: 0-550/min
Max. Mixing Capacity: 80L
Mixing Paddle Length: 590mm
Mixing Paddle Diameter: 125mm
Mixing Paddle Thread: M14 x 2.0mm
Weight: 3.05kg
DMM-080U
WHAT’S IN THE BOX
Multi-Purpose Mixer
ozito-diy.co.uk
Side Handle
Mixing Paddle
2 x Spanner
Spare Brushes (Pair)
WARRANTY
OZITO UK Unit 9 Stadium Court, Wirral International Business Park, Plantation Road, Bromborough, Wirral, CH62 3QG 0616
All of our products undergo strict quality checks to ensure that they reach
you in perfect condition. In the unlikely event that your device develops a
fault, please contact our service department at the address shown on this
guarantee card. You can also contact us by telephone using the customer
service number shown. Please note the following terms under which
guarantee claims can be made:
1. These warranty terms regulate additional warranty services, which the
manufacturer mentioned below promises to buyers of its new products
in addition to their statutory guarantee claims are not affected by this
guarantee. Our guarantee is free of charge to you.
2. The warranty services only covers defects due to material or
manufacturing faults on a product which you have bought from the
manufacturer mentioned below are limited to either the rectication of said
defects on the product or the replacement of the product, whichever we
prefer.
Please note that our devices are not designed for use in commercial, trade
or professional applications. A guarantee contract will not be created if the
device has been used by commercial, trade or industrial business or has
been exposed to similar stresses during the guarantee period.
3. The following are not covered by our guarantee:
- Damage to the device caused by a failure to follow the assembly
instructions or due to incorrect installation, a failure to follow the operating
instructions (for example connecting it to an incorrect mains voltage or
current type) or a failure to follow the maintenance and safety instructions
or by exposing the device to abnormal environmental conditions or by lack
of care and maintenance.
- Damage to the device caused by abuse or incorrect use (for example
overloading the device or the use or unapproved tools or accessories),
ingress of foreign bodies into the device (such as sand, stones or dust,
transport damage), the use of force or damage caused by external forces
(for example by dropping it).
- Damage to the device or parts of the device caused by normal or natural
wear or tear or by normal use of the device.
4. Your Product is guaranteed for a period of 36 months from the original
date of purchase and is intended for DIY (Do It Yourself) use only. Lithium
Ion batteries and chargers are covered by a 12 month warranty. Warranty
excludes consumable parts. Guarantee claims should be submitted
before the end of the guarantee period within two weeks of the defect
being noticed. No guarantee claims will be accepted after the end of the
guarantee period. The original guarantee period remains applicable to the
device even if repairs are carried out or parts are replaced. In such cases,
the work performed or parts tted will not result in an extension of the
guarantee period, and no new guarantee will become active for the work
performed or parts tted. This also applies if an on-site service is used.
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST
RETURN THE PRODUCT TO THE PLACE OF PURCHASE WITH YOUR
REGISTER RECEIPT.
Please refer to the restrictions of this warranty concerning wearing parts,
consumables and missing parts as set out in the service information in
these operating instructions.
CUSTOMER SERVICE HELPLINE
GB: 0151 294 4488
IRL: 1850 882711
Ozito-diy.co.uk

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
KNOW YOUR PRODUCT SETUP & PREPARATION
1. HANDLES
1 Collet
2 Side Handle
3 Mixer Housing
4 Handle Securing Knob
5 Rear Spade Handle
6 Forward / Reverse Lever
7 Variable Speed Dial
8 On/Off Trigger
9 Lock-On Button
10 Mid Handle
MULTI-PURPOSE MIXER
1 2 3 4 5
6 7 8 9 10
11 12 13 14
11 Mixing Paddle
12 Spanner 19mm
13 Spanner 22mm
14 Spare Brushes (Pair)
ACCESSORIES
WARNING! ENSURE THE TOOL IS SWITCHED OFF AND
DISCONNECTED FROM THE POWER SUPPLY BEFORE
PERFORMING ANY OF THE FOLLOWING ASSEMBLY.
Side Handle
Spade Handle
2 Rotate the handle in a
clockwise direction to secure
in place.
2 Screw the securing knob
clockwise into the recess to
secure in place.
1 Align the side handle
with 1 of the 3 hole
position in the mixer
housing.
The side handle provides additional comfort, control, and guidance for
the mixer. The handle can be tted in 3 positions to suit the user.
The rear spade handle provides additional control and support when
using the tool. It can be attached either horizontally, vertically or should
you require it, diagonally.
1 Place the spade
handle into the
locating boss at the
angle you desire.
3 To change the angle,
loosen the securing
knob. Adjust the
handle angle
and retighten the
securing knob.

2. FITTING & REMOVING THE PADDLE 3. ON/OFF SWITCH
OPERATION
On/Off Trigger
Lock-On Button
2 To stop the mixer, release the
on/off trigger.
1 To start the mixer, squeeze the
on/off trigger.
2 To unlock the mixer, squeeze
the on/off trigger and then
release.
2 Screw the mixing paddle
clockwise into the collet nut.
Note: Ensure the mixing paddle is tightly secured in place before
operating.
1 To lock the mixer on,
squeeze the on/off
trigger then depress
the lock-on button.
1 Align the mixing
paddle with the collet
at the front of the
mixer.
3 Using the supplied
spanners, hold the
collet nut in place
whilst tightening
the nut on the
mixing paddle in a
clockwise direction.
4 To remove the
mixing paddle,
loosen the nut on the
mixing paddle using
both of the supplied
spanners.
The tool has a variable speed trigger, the further you depress the on/off
trigger the higher the speed of the mixer.
CAUTION! TO REDUCE THE RISK OF ELECTRICAL
SHOCK, THE USE OF A RESIDUAL CURRENT DEVICE
(RATED 30mA OR LESS) IS RECOMMENDED.
WARNING! ENSURE THE LOCK-ON BUTTON HAS BEEN
RELEASED BEFORE DISCONNECTING THE TOOL FROM
THE POWER SUPPLY. FAILURE TO DO SO WILL CAUSE
THE TOOL TO START IMMEDIATELY THE NEXT TIME IT
IS PLUGGED IN RESULTING IN POSSIBLE BODILY HARM
OR PROPERTY DAMAGE.

DMM-080U
3. CONTROLS 4. MIXING
Variable Speed Dial
Forward/Reverse Lever
2 To decrease the maximum
speed, rotate the variable
speed dial anti-clockwise.
2 To mix in a reverse
direction, push the
forward/reverse lever
towards the right
side of the mixer.
1 To increase the
maximum speed,
rotate the variable
speed dial clockwise.
1 To mix in a forward
direction, push the
forward/reverse
lever towards the left
side of the mixer.
The on/off trigger has a variable speed dial that limits the maximum
speed of the mixer.
FWD
REV
Before starting to operate the mixer, perform a few simple checks.
1 Depress and release the
variable speed trigger to
ensure it is not locked on.
3 Place the mixing paddle into
the material to be mixed.
2 Check the forward/reverse
lever is on desired setting.
4 Hold the mixer rmly and
squeeze the on/off trigger.
6 Move the mixing paddle through the material slowly to mix evenly.
Note: Do not force the mixer or apply additional pressure. Let the mixer
do all the work.
FWD
REV

Sparking visible through the housing air vents
A small amount of sparking may be visible through the housing vents.
This is normal and does not indicate a problem.
Excessive sparking visible through the housing air vents
and/or the mixer failing to operate
May indicate the carbon brushes have worn out and need to be
replaced. Carbon brushes should only be replaced by a qualied
electrician or power tool repairer.
Trigger is locked and cannot be pressed
The forward/reverse lever may be positioned in the middle. Push the forward/
reverse lever towards the left or right depending on the desired direction of
rotation.
MAINTENANCE
DESCRIPTION OF SYMBOLS
TROUBLESHOOTING
• Keep the vents on the mixer clean at all times, if possible, prevent foreign
matter from entering the vents.
• After each use, blow air through the mixer housing to ensure it is free from all
dust particles which may build up. Build up of dust particles may cause the
mixer to overheat and fail.
• If the enclosure of the mixer requires cleaning, do not use solvents. Use a
moist, soft cloth only. Never let any liquid get inside the mixer; never immerse
any part of the mixer into a liquid.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
Carbon Brushes
When the carbon brushes wear out, the mixer will
spark and/or stop. Discontinue use as soon as
this happens. Carbon brushes should be replaced
prior to recommencing use of the mixer. They are a
wearing component of the mixer and therefore not
covered under warranty. Continuing to use the mixer
when carbon brushes need to be replaced may cause permanent damage to
the mixer. Carbon brushes will wear out after many uses. When the carbon
brushes need to be replaced, take the mixer to an electrician or a power tool
repairer for a quick and low cost replacement. Always replace both carbon
brushes at the same time.
Note: Ozito Industries will not be responsible for any damage or injuries
caused by the repair of the mixer by an unauthorised person or by mishandling
of the mixer.
SPARE PARTS
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse or Homebase store.
For further information, or any parts visit
www.ozito-diy.co.uk or contact Ozito Customer Service:
Great Britain: 0151 294 4488
Ireland: 1850 882711
E-mail: [e-mail]
VVolts Hz Hertz
~Alternating current WWatts
/min Revolutions or
reciprocation per minute
Diameter
n
o No load speed
Read operation instruction
Warning
Double insulated
Wear ear protection
Wear eye protection
Wear breathing protection

Use auxiliary handle(s), if supplied with the tool. Loss of control can cause
personal injury.
Hold power tool by insulated gripping surfaces, when performing an operation
where the cutting accessory may contact hidden wiring or its own cord. Cutting
accessory contacting a “live” wire may make exposed metal parts of the power tool
“live“ and could give the operator an electric shock.
WARNING! This appliance is not intended for use by young or inrm
persons unless supervised by a responsible person to ensure that they can use the
appliance safely. Young children should be supervised to ensure they do not pla with
the appliance.
Recommendations for the use of a residual current device with a rated residual
current of 30mA or less.
• Always use the side handle, this gives you greater control of the accessory should
become jammed.
• Keep the cord clear of the accessory being used, do not wrap the cord around
your arm or wrist.
• Hold the tool by the insulated gripping surfaces when performing an operation
where the accessory may contact hidden wiring or its own cord.
• When removing an accessory from the tool avoid contact with skin and use proper
protective gloves when grasping the bit or accessory. Accessories may be hot
after prolonged use.
• Young children should be supervised to ensure that they do not play with the
appliance.
WARNING! Some dust created by power sanding, sawing, grinding, drilling
and other construction activities contain chemicals known to cause cancer, birth
defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks, cement and other masonry products, and;
• Arsenic and chromium from chemically-treated timber.
The risk from such exposures vary depending on how often you do this type of work.
To reduce your exposure to these chemicals; work in a well ventilated area, and
work with approved safety equipment, such as those dust masks that are specically
designed to lter out microscopic particles.
Always wear eye protection and a dust mask for dusty applications and when drilling/
chiselling overhead. Sanding particles can be absorbed by your eyes and inhaled
easily and may cause health complications.
MULTI-PURPOSE MIXER SAFETY WARNINGS
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of re, electric shock, personal injury and
material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before
operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
Before you connect the appliance to the mains supply make sure that the data on the rating plate are identical
to the mains data.
This tool is double insulated therefore no earth wire is required.
This tool is recommended for the use with a residual current device with a rated residual current of 30mA or less.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The
insulation system is for added protection against injury resulting from a possible electrical insulation failure within
the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the
extension lead for signs of damage, w ear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not
suitable for the power input of the tool or which is damaged or defective may result in a risk of re and electric
shock.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.

size 445 x 210 mm
Danger! - Read the operating instructions to re-
duce the risk of inquiry
Caution! Wear ear-mus. The impact of noise
can cause damage to hearing.
Caution! Wear a breathing mask. Dust which
is injurious to health can be generated when
working on wood and other materials. Never use
the device to work on any materials containing
asbestos!
Caution! Wear safety goggles. Sparks gene-
rated during working or splinters, chips and dust
emitted by the device can cause loss of sight.
Do not use the tool in rain or snow. Do not expose
the tool to wet conditions.
The reprinting or reproduction by any other me-
ans, in whole or in part, of documentation and
papers accompanying products is permitted only
with the express consent of the iSC GmbH.
Subject to technical changes
DMM-080U
GB Additonal operating & safety instructions Multi-Purpose Mixer
Service information
We have competent service partners in all countries named on the guarantee certicate whose contact
details can also be found on the guarantee certicate. These partners will help you with all service re-
quests such as repairs, spare and wearing part orders or the purchase of consumables.
Please note that the following parts of this product are subject to normal or natural wear and that the
following parts are therefore also required for use as consumables.
Category Example
Wear parts* Carbon brushes
Consumables*
Missing parts
* Not necessarily included in the scope of delivery!
In the eect of defects or faults, please register the problem on the internet at www.isc-gmbh.info. Plea-
se ensure that you provide a precise description of the problem and answer the following questions in all
cases:
• Did the equipment work at all or was it defective from the beginning?
• Did you notice anything (symptom or defect) prior to the failure?
• What malfunction does the equipment have in your opinion (main symptom)?
Describe this malfunction.
Yang/Product-ManagementWeichselgartner/General-Manager
- 135 -
explains the following conformity according to EU directives and norms for
the following product
Multi-Purpose Mixer DMM-080U (Ozito)
2014/29/EU
2005/32/EC_2009/125/EC
2014/35/EU
2006/28/EC
X2014/30/EU
2014/32/EU
2014/53/EC
2014/68/EU
90/396/EC_2009/142/EC
89/686/EC_96/58/EC
X2011/65/EU
X2006/42/EC
Annex IV
Noti ed Body:
Noti ed Body No.:
Reg. No.:
2000/14/EC_2005/88/EC
Annex V
Annex VI
Noise: measured LWA = dB (A); guaranteed LWA = dB (A)
P = KW; L/Ø = cm
Noti ed Body:
2004/26/EC
Emission No.:
Standard references: EN 60745-1; EN 60745-2-1;
EN 55014-1; EN 55014-2; EN 61000-3-2; EN 61000-3-3
Landau/Isar, den 10.06.2016
First CE: 16 Archive-File/Record: NAPR014341
Art.-No.: 44.722.24 I.-No.: 11016 Documents registrar: R. Gehard
Subject to change without notice Wiesenweg 22, D-94405 Landau/Isar
ISC GmbH · Eschenstraße 6 · D-94405 Landau/Isar
Declaration of conrmity

size 445 x 210 mm
Items supplied
Please check that the article is complete as
specied in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
instructions.
• Open the packaging and take out the equip-
ment with care.
• Remove the packaging material and any
packaging and/or transportation braces (if
available).
• Check to see if all items are supplied.
• Inspect the equipment and accessories for
transport damage.
• If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suocating!
Proper use
The machine has been designed to mix liquid and
powderery building materials such as paint, mort-
ar, adhesive, plaster and similar substances. The
relevant mixing action (which depends on the
consistancy of the materials and the quantity that
has to be mixed) must be set up for the appropri-
ate mixing tool.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
Technical data
Mains voltage: ........................ 230-240 V ~ 50 Hz
Power input: .............................................1050 W
No load speed: .....................................0-550/min
Mixing tool mount: ........................................ M14
Protection class:............................................. II/&
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
LpA sound pressure level .........................89 dB(A)
KpA uncertainty .............................................. 3 dB
LWA sound power level ...........................100 dB(A)
KWA uncertainty.............................................. 3 dB
Wear ear-mus.
The impact of noise can cause damage to
hearing. Total vibration values (vector sum of
three directions) determined in accordance with
EN 60745.
Vibration emission value ah= 2.85 m/s2
K uncertainty = 1.5 m/s2
The specied vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equip-
ment is used and may exceed the specied value
in exceptional circumstances.
The specied vibration value can be used to
compare the equipment with other electric power
tools.
The specied vibration value can be used for initi-
al assessment of a harmful eect.
Keep the noise emissions and vibrations to a
minimum.
• Only use appliances which are in perfect wor-
king order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever
necessary.
• Switch the appliance off when it is not in use.
• Wear protective gloves.
Caution!
Residual risks
Even if you use this electric power tool in ac-
cordance with instructions, certain residual
risks cannot be rules out. The following ha-
zards may arise in connection with the equip-
ment’s construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protecti-
on is used.
3. Health damage caused by hand-arm vibra-
tions if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
For EU countries only
Never place any electric power tools in your
household refuse.
To comply with European Directive 2012/19/EC
concerning old electric and electronic equipment
and its implementation in national laws, old elec-
tric power tools have to be separated from other
waste and disposed of in an environment-friendly
fashion, e.g. by taking to a recycling depot.
Recycling alternative to the return request:
As an alternative to returning the equipment to
the manufacturer, the owner of the electrical
equipment must make sure that the equipment
is properly disposed of if he no longer wants to
keep the equipment.The old equipment can be
returned to a suitable collection point that will
dispose of the equipment in accordance with the
national recycling and waste disposal regulations.
This does not apply to any accessories or aids
without electrical components supplied with the
old equipment.
