Ozito OZCM44A User manual

Cement Mixer
370 Watt
Operation Manual
1 Year Replacement Warranty
OZCM44A
To view the full range visit: www.ozito.com.au
0209

Input: 230 – 240V ~ 50Hz
Motor Size: 370W
Motor Speed: 1440/min
Drum Speed: 23-26/min
Gross Drum Volume: 220 Litres (7.7 cu ft)
Unmixed Dry Volume: 170 Litres (6 cu ft)
Mixed Wet Volume: 125 Litres (4.4 cu ft)
Drum Mouth: Ø470mm (181/2")
Weatherproof Rating: IP44
Weight: 63kg
Features: Quick Assembly
Easy Dump Control Handle
Pneumatic Wheels
Robust Steel Construction
Versatile Mixing Applications
2
SPECIFICATIONS – MODEL NO. OZCM44A
1. Drum
2. Motor Cover
3. Dump Control Handle
4. Drum Lock Mechanism
5. Frame
6. Rear Leg
7. Pneumatic Wheel
8. Drum Rotation Base
1
5
6
2
7
8
3
4

3
TABLE OF CONTENTS
SPECIFICATIONS…………………………………………
TABLE OF CONTENTS…………………………………..
INTRODUCTION………………………………………...
SAFETY INSTRUCTIONS………………………………..
ASSEMBLY………………………………………………..
OPERATION ……………………………………………..
MAINTENANCE …………….…………………………..
CONTENTS ……………………………………………...
WARRANTY………………………………………………
Page 2
Page 3
Page 4
Page 4
Page 8
Page 9
Page 10
Page 11
Page 12

INTRODUCTION
SAFETY INSTRUCTIONS
ELECTRICAL SAFETY
4
Congratulations on purchasing an Ozito Cement Mixer.
We aim to provide quality tools at an affordable price.
We hope you will enjoy using this tool for many years.
Your Ozito Cement Mixer OZCM44A has been designed
to mix cement, feeds, fertilizers, potting soils and the like.
It is intended for DIY use only.
Warning! When using mains-powered equipment, basic safety
precautions, including the following, should always be followed to reduce
risk of fire, electric shock, personal injury and material damage.
Read and understand the manual prior to operating this tool.
Save these instructions and other documents supplied with this tool for
future reference.
The electric motor has been designed for 230V and 240V only. Always check that the
power supply corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for
Australia and New Zealand.
If the supply cord is damaged, it must be replaced by an electrician or a power
tool repairer in order to avoid a hazard.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool.
Before use, inspect the extension lead for signs of damage, wear and ageing.
Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of
an extension lead not suitable for the power input of the tool or which is damaged
or defective may result in a risk of fire and/or electric shock.
It is recommended that the extension lead is a maximum of 25m in length. Do Not
use multiple extension leads.
!
!

5
GENERAL SAFETY INSTRUCTIONS
Warning! Read all instructions. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious injury. The term “Power Tool”
in all of the warnings listed below refers to your mains operated (corded)
power tool or battery operated (cordless) power tool.
SAVE THESE INSTRUCTIONS
1) WORK AREA
a) Keep work area clean and well lit. Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inattention while operating power
tools may result in serious personal injury.
b) Use safety equipment. Always wear eye protection. Safety equipment such as
dust mask, non-skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Avoid accidental starting. Ensure the switch is in the off position before
plugging in. Carrying power tools with your finger on the switch or plugging in
power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
!
!

6
GENERAL SAFETY INSTRUCTIONS (cont.)
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of these
devices can reduce dust related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate
for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that can not be controlled with the switch is dangerous and must
be repaired.
c) Disconnect the plug from the power source before making any
adjustments, changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools, unplugged & out of the reach of children and do
not allow persons unfamiliar with the power tool or these instructions to
operate the power tool. Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tools
operation. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc., in accordance with
these instructions and in the manner intended for the particular type of
power tool, taking into account the working conditions and the work to
be performed. Use of the power tool for operations different from intended
could result in a hazardous situation.
h) This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
i) Children should be supervised to ensure that they do not play with
the appliance.
5) SERVICE
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
b) If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.

ADDITIONAL SAFETY RULES FOR CEMENT MIXER
7
!
!Warning! For your own safety, do not try to use your cement mixer or plug it
in until it is completely assembled and installed according to the instructions
and until you have read and understood the following:
• Drugs, alcohol and medication. Do not operate the mixer while under the
influence of drugs, alcohol, or any medication that could affect your ability to use
it properly.
• Avoid dangerous conditions. Keep your work area clean and well lit. Cluttered
areas can cause accidents resulting in injuries. Do not use the mixer in wet or
damp areas or expose it to rain. Do not use it in areas where fumes from paint,
solvents or flammable liquids pose a potential hazard.
• Inspect your cement mixer. Check your cement mixer before turning it on. Keep
guards in place and in working order. Form a habit of checking to see that keys
and adjusting wrenches are removed from the cement mixer area before turning
on. Replace damaged, missing or failed parts before using it.
• Wear protective gear. Foreign objects may be thrown from the cement mixer
while in operation. This can cause facial injuries. Always wear safety goggles
and/or face shields.
• Loading the cement mixer. Do not attempt to load or unload the contents until
the cement mixer has stopped. Keep hands out of the way of all moving parts.
• Never leave cement mixer running unattended. Don’t leave cement mixer until
it has come to a complete stop.
• Disconnect power. Unplug when not in use, before making adjustments, changing
parts, cleaning, or working on the mixer.
• Maintain your cement mixer with care. Clean the cement mixer immediately
after use. Keep the cement mixer clean for best and safest performance.
• Moving the cement mixer. Do not tow the cement mixer by using a vehicle. Use
an approved trailer to move the cement mixer if it is to be transported.

8
ASSEMBLY
1. Insert the rear leg of the stand into the
front frame using the nut and bolt supplied.
Tighten the bolt . The rear leg is also used
to move the mixer to other locations. (Fig. 1)
2. Slide the wheels onto the front frame axle
and insert the cotter pin into the hole in the
axle to hold the wheels in place. (Fig. 2)
Check and maintain tyre pressure @
206kPa (30psi)
3. Attach the drum rotation base to the motor
gear box assembly frame using the heavy
duty anchor pin. After you connect the
motor frame and rotation base with the
anchor pin insert the cotter pin to hold the
anchor pin in place. (Fig. 3)
4. Slide the drum rotation base and motor
frame assembly onto the shaft of the
cement mixer frame. (Fig. 4)
5. Mount the cement mixer drum onto the
gear box shaft. Turn the drum clockwise on
the gear box shaft thread until the shaft is
completely located in the drum. (Fig. 5)
Frame
Bolt & nut
Rear leg
Cotter pins Frame
Wheel
Axle
Cotter pinAnchor pin
Drum rotation base Motor &
gear box frame
Motor frame &
rotation base
Shaft of
cement mixer
frame
Gear box shaft
Cement mixer
stand
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 2
Fig. 1

9
ASSEMBLY (cont.)
6. Insert the dump control handle through the
hole in the motor gear box frame. Locate 2
notches on the inside of the motor housing,
align with the handle and push the handle to fit
securely in the notches. Secure it with the
cotter pin provided. (Fig. 6)
Dump control
handle
Secure handle
with cotter pin
Fig. 6
OPERATION
Loading the drum
IMPORTANT: Completely unwind an extension cord (not supplied). Connect it to the
concrete mixer first before connecting to a power supply.
IMPORTANT: Always start the mixer before loading the drum. Load the drum while
it’s rotating.
IMPORTANT: Ensure material is not all loaded into the mixer at once. Add the
material steadily over the mixing blades instead to avoid the material from sticking to
the back of the drum.
Note: A built-in thermal protector has been built into the motor to prevent it from
overheating. The thermal protector restores automatically when the motor cools down.
For best loading results, proceed as follows:
•Add the required amount of stone into the drum.
• Add the required amount of sand into the drum.
• Add the required amount of cement into the drum.
• Pour the required amount of water into the drum.
Warnings:
1. Do not let the shovel mouth or any other devices enter the drum mouth
during loading.
2. Never place hands inside the revolving drum.
3. Place the mixer as close as possible to the work site. Do not move the mixer
when loaded. The front handle is only to be used to move the mixer when
the drum is empty.
4. Re-tighten all bolts and nuts after mixing for the first time.
Emptying the drum
IMPORTANT: Do not turn the mixer off while it’s full of material. Empty the drum with
the drum rotating.
Pour the mixed concrete by releasing the drum lock mechanism and lifting the dump
control handle while the machine is running. Be sure to pour the mix slowly and
smoothly to avoid tilting the concrete mixer.

10
OPERATION (cont.)
Cleaning
Warning: Do not pour or spray water directly into or over the motor cover.
IMPORTANT: Never put any of your body parts (including hands) inside the drum
while it is rotating.
IMPORTANT: Wipe off any external material on the motor cover. Do not use
petrol, turpentine, lacquer or paint thinner, dry cleaning fluids or similar products.
The use of chemical products or solvents may damage the motor cover.
Thoroughly clean the mixer at the end of each days operation.
Keep your mixer clean. The slightest trace of material left in the drum will harden
and attract more material each time the machine is used.
Dried cement should be scraped out of the drum.
DO NOT throw bricks into the mixer drum to clean it out.
DO NOT beat on the drum with a shovel, hammer or other tools to break up
accumulation of dried cement mix as the cement mixer may be damaged.
The drum may be scoured for approximately 2 minutes, using a 1” stone and
water mixture. After this, discharge the stone/water mixture and hose down the
drum assembly inside and out.
The IP55 protection clad construction of the mixer enables the DRUM ASSEMBLY
ONLY to be hosed down safety. Avoid getting water on the motor housing, DO
NOT wet the motor.
1. Ensure that the power is disconnected from the tool prior to any maintenance
being carried out.
2. Ball bearings are packed with grease at the factory. No further lubrication of
bearings is required.
3. Lubricate all moving parts periodically. Wipe and other parts with an oily cloth
to keep corrosion to a minimum.
4. During normal use, painted surfaces can loose their coating during the mixing
process. Wipe all exposed surfaces regularly with an oily rag to prevent
corrosion. (Note: Rust is not a warrantable claim.)
5. Keep air vents clean of dust and dirt.
6. Remove dust and dirt from the cement mixer regularly with soft cloth, brush or
compressed air. Use a mild detergent and a soft cloth to clean plastic parts.
7. If the power cord is damaged, have it replaced by an electrician or a
power tool repairer.
8. Regularly check that all bolts, screws and nuts are securely fixed as these could
work loose during normal operation.
9. Check and maintain tyre pressure @ 206kPa (30psi)
Note: Ozito Industries will not be responsible for any damage or injuries caused
by the repair of the tool by an unauthorised person or by mishandling of the tool.
MAINTENANCE

11
DESCRIPTION OF SYMBOLS
!
!
DESCRIPTION OF SYMBOLS
CONTENTS
OZITO INDUSTRIES PTY LTD
Power tools that are no longer usable should not be disposed
of with household waste but in an environmentally friendly way.
Please recycle where facilities exist. Check with your local
council authority for recycling advice.
Recycling packaging reduces the need for landfill and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
1 x OZCM44A Cement Mixer (not assembled; see Page 8 of instruction manual)
1 x Instruction Manual
AUSTRALIA (Head Office)
1-23 Letcon Drive, Bangholme Victoria, Australia, 3175
Telephone: [phone]
Website: www.ozito.com.au
Email: [email protected]

WARRANTY
THIS WARRANTY FORM AND CONFIRMED BUNNINGS REGISTER RECEIPT SHOULD
BE RETAINED BY THE CUSTOMER AT ALL TIMES
The warranty is only made available by returning the product to your nearest
Bunnings Warehouse with a confirmed Bunnings register receipt.
PURCHASED FROM:________________________________________________
DATE PURCHASED: ________________________________________________
1 YEAR REPLACEMENT WARRANTY
Your Ozito tool is guaranteed for a period of 12 months from the original date of
purchase and is intended for DIY (Do it yourself) use only.
WARNING
The following actions will result in the warranty being void.
•Professional, Industrial or high frequency use.
• If the tool has been operated on a supply voltage other than that specified on
the tool.
• If the tool shows signs of damage or defects caused by or resulting from abuse,
accidents or alterations.
• If the tool is disassembled or tampered with in any way.
Note: Warranty excludes consumable parts such as brushes, batteries, sanding
pads, blades, discs, drill bits, collets, drive belts, wheels and other accessories.
YOUR WARRANTY FORM SHOULD BE RETAINED
BY YOU AT ALL TIMES.
SHOULD YOU HAVE ANY QUESTIONS PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY OR
REPAIR PLEASE TELEPHONE OUR CUSTOMER
SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL NUMBER
AND DATE OF PURCHASE AVAILABLE. AN OZITO CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL AND ANSWER ANY QUESTIONS
YOU MAY HAVE RELATING TO THE WARRANTY POLICY OR PROCEDURE.
