Ozito PWE-1500U User manual

PWE-1500U
EH-Art.-No.: 41.407.24 I.-No.: 11019
7
GB Original operating instructions
High Pressure Cleaner
Anl_PWE_1500U_SPK7.indb 1Anl_PWE_1500U_SPK7.indb 1 08.08.2019 14:41:3208.08.2019 14:41:32

- 2 -
2
8
2. 1.
13
12
11 12
10 15
9
12
b a
2
3.
12
14
1
2
2
1
47
5
3
6
16
16
12
Anl_PWE_1500U_SPK7.indb 2Anl_PWE_1500U_SPK7.indb 2 08.08.2019 14:41:4808.08.2019 14:41:48

- 3 -
3 4
8
15
b
a
12
7
15 4
5 6
5
16
7 8
16
16
17
1
12
Anl_PWE_1500U_SPK7.indb 3Anl_PWE_1500U_SPK7.indb 3 08.08.2019 14:41:5008.08.2019 14:41:50

- 4 -
98
12
16
10
11
14 A
Anl_PWE_1500U_SPK7.indb 4Anl_PWE_1500U_SPK7.indb 4 08.08.2019 14:41:5408.08.2019 14:41:54

GB
- 5 -
Caution! Wear ear-muffs. The impact of noise can cause damage to hearing.
Caution! Wear safety goggles. Sparks generated during working or splinters, chips and dust emitted
by the device can cause loss of sight.
Danger! Please read these instructions carefully before installing and operating the equipment!
Warning! High-pressure jets can be dangerous if not used properly. Do not direct the jet at persons, ani-
mals, live electrical equipment or the pressure cleaner itself.
This machine is not suitable for connecting to the drinking water network (see 5.2.4).
Anl_PWE_1500U_SPK7.indb 5Anl_PWE_1500U_SPK7.indb 5 08.08.2019 14:41:5608.08.2019 14:41:56

GB
- 6 -
Danger!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well.We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.
1. Safety regulations
Danger!
Read all safety regulations and instructions.
Any errors made in following the safety regula-
tions and instructions may result in an electric
shock, fire and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.
General safety regulations and accident pre-
vention
It is essential that you read the safety regulations
and operating instructions in their entirety and
follow the information contained therein in order
to eliminate the possibility of an accident or po-
tentially dangerous situation from occurring while
working with the high-pressure cleaner.
• The electrical connection must be installed by
an electrician in accordance with IEC 60364.
• The power plug must be plugged into a pro-
perly installed and earthed socket outlet with
connected earth-leakage circuit breaker (30
mA).
• Always check the device, the mains cable
and the plug before using the high-pressure
cleaner. Only operate the device when it is in
good working order and has not been dama-
ged in any way. Damaged parts must be im-
mediately replaced by a qualified electrician.
• Always pull the power plug out of the socket
outlet before doing any work on the high-
pressure cleaner, before changing the nozzle
and whenever the cleaner is not being used.
• Only use suitable extension cables when wor-
king outdoors. Extension cables must have a
minimum cross-section of 1.5 mm2.The plug
connections must have earthing contacts and
be rainwater-protected. Cables over 10 m in
length must have a cross section of at least
2.5 mm2.
• Warning! This device was developed to be
used with cleaning agents supplied or recom-
mended by the manufacturer.The use of any
other cleaning agents or chemicals can nega-
tively affect the safety of the device.
• Warning! Do not use the device when other
persons or animals are in the near vicinity un-
less they are wearing appropriate protective
clothing.
• Warning! High-pressure jets can be dange-
rous when the cleaner is not used properly.
Do not direct the jet toward persons, animals,
live electrical equipment or the device itself.
• Warning! Do not direct the jet toward yourself
or others in order to clean clothes and foot-
wear.
• Warning! Do not allow the high-pressure clea-
ner to be used by children or unauthorized
persons.
• Warning! High-pressure hoses, fittings and
couplings are important components that
help to ensure device safety. Only use high-
pressure hoses, fittings and couplings that
are recommended by the manufacturer.
• Warning! In order to ensure the operatio-
nal safety of the device, only use genuine
manufacturer’s replacement parts or parts
that have been approved by the manufacturer.
• Warning! Do not operate the device if the
mains cable or other important parts of the
device - e.g. safety-related elements, high-
pressure hoses, spray pistol - are damaged.
• Do not pull or carry the electric tool by its
mains cable. Protect the mains cable from be-
coming damaged by oil, solvents and sharp
edges. Do not pull or carry the electric tool by
its mains cable.
• Keep your place of work tidy.
• Ensure that the switch is turned off when con-
necting the unit to the power supply.
• Wear suitable work clothes.
• Check your high-pressure cleaner to ensure
that it is in good working order. If the cleaner
is not functioning properly, have it checked by
an authorized professional. Have all mainte-
nance and inspection work carried out only by
a qualified electrician or ISC GmbH.
• The water jet that emerges from the high-
pressure nozzle produces a „kickback“ on
the spray pistol. Therefore, make sure that
you have a solid footing and that you have a
firm hold of the pistol grip. In order to protect
yourself from possible flying objects (that are
released due to the high pressure), wear sui-
Anl_PWE_1500U_SPK7.indb 6Anl_PWE_1500U_SPK7.indb 6 08.08.2019 14:41:5608.08.2019 14:41:56

GB
- 7 -
table protection gear.
• Use cleaning agents sparingly. Observe the
dosing instructions of the manufacturer.
• The high-pressure jet can damage vehicle
tires and tire parts. Keep a distance of at least
30 cm from the object being cleaned.
• If there is a power failure while you are using
the machine, be sure to switch off the machi-
ne for safety reasons.
• The electric pump always must be able to
draw on a sufficient supply of water. Dry ope-
ration causes severe damage to the seals.
Special safety information
• Danger of explosion – Do not spray flamma-
ble liquids.
• Water that has passed through the non-return
valve is not drinkable.
• During cleaning or maintenance or when
replacing parts or converting the machine to
a different function, pull the plug out of the
socket.
• CAUTION! Unsuitable extension cables can
be dangerous. If an extension cable is used,
it must be suitable for outdoor use. The power
connection must be kept dry and must not
come into contact with the ground.We there-
fore recommend using a cable drum where
the power socket is kept at least 60 mm abo-
ve the ground.
• Warning! Make sure that no exhaust gas
emissions occur near the air inlets.
• If pipe cleaning hoses are used, the hose
must be inserted at least one meter into the
pipe to prevent the hose from whipping out of
control.
• CAUTION! If you leave this equipment un-
supervised even for a short length of time,
switch it off and take the plug out of the so-
cket.
• This equipment must not be used by children.
Children must always be supervised to ensu-
re that they do not play with this equipment.
• This machine is not allowed to be used by
persons (including children) with reduced
physical, sensory or mental capacities or tho-
se with a lack of experience and knowledge.
• If the power cable for this equipment is dama-
ged, it must be replaced by the manufacturer
or OEM after-sales service or by similarly
trained personnel to prevent hazards.
• CAUTION:To prevent hazards arising from
the unintentional resetting of the thermal cut-
out, never connect the equipment to an exter-
nal switching device such as a timer switch
or to an electric circuit which is regularly swit-
ched on and off by a device.
2. Layout and items supplied
2.1 Layout (Fig. 1-2)
1. Handle
2. Accessory mount
3. On/Offswitch
4. Water inlet connector
5. Pressure cleaner
6. Power cable
7. Connector for high-pressure hose
8. Gun
9. Extension
10. Cleaning agent container
11. Setting wheel
12. Quick connection system
13. Rotating nozzle
14. Point / wide jet nozzle
15. High-pressure hose
16. Terrace cleaner
17. Rotor
A. Nozzle cleaning pin
2.2 Items supplied
Please check that the article is complete as spe-
cified in the scope of delivery. If parts are missing,
please contact our service center or the nearest
branch of the DIY store where you made your
purchase at the latest within 5 work days after
purchasing the article and upon presentation of
a valid bill of purchase. Also, refer to the warranty
table in the warranty provisions at the end of the
operating instructions.
• Open the packaging and take out the equip-
ment with care.
• Remove the packaging material and any
packaging and/or transportation braces (if
available).
• Check to see if all items are supplied.
• Inspect the equipment and accessories for
transport damage.
• If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suffocating!
Anl_PWE_1500U_SPK7.indb 7Anl_PWE_1500U_SPK7.indb 7 08.08.2019 14:41:5708.08.2019 14:41:57

GB
- 8 -
• Gun
• Extension
• High-pressure hose
• Cleaning agent container
• Rotating nozzle
• Point / wide jet nozzle
• Terrace cleaner
• Original operating instructions
• Safety instructions
3. Proper use
The pressure cleaner is designed to clean ve-
hicles, machines, buildings, facades, etc. in the
private sector.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse.The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
This machine is not allowed to be used by per-
sons (including children) with reduced physical,
sensory or mental capacities or those with a lack
of experience and knowledge.
4. Technical data
Rated voltage/frequency: .......220-240 V ~ 50 Hz
Power consumption: ................................ 1500 W
Rated pressure: ....................... 7.5 MPa (75 bar)*
Permissible pressure: ... max. 11.0 MPa (110 bar)
Rated flow rate: ......................................6.3 l/min
Max. water inlet pressure: ...........0.6 MPa (6 bar)
Protection class: ............................................II/&
Weight: .......................................................7.5 kg
* The rated pressure depends on the accessories
used with the pressure washer.
Danger!
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60335-2-79.
LpA sound pressure level ........................ 81 dB(A)
KpA uncertainty .............................................3 dB
LWA sound power level .......................... 96 dB(A)
KWA uncertainty .............................................3 dB
Wear ear-muffs.
The impact of noise can cause damage to hea-
ring.
Total vibration values (vector sum of three direc-
tions) determined in accordance with
EN 60335-2-79.
Vibration emission value ah≤2.5 m/s2
The specified vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equip-
ment is used and may exceed the specified value
in exceptional circumstances.
The specified vibration value can be used to
compare the equipment with other electric power
tools.
The specified vibration value can be used for initi-
al assessment of a harmful effect.
Keep the noise emissions and vibrations to a
minimum.
• Only use appliances which are in perfect wor-
king order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever ne-
cessary.
• Switch the appliance off when it is not in use.
• Wear protective gloves.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment’s construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
Anl_PWE_1500U_SPK7.indb 8Anl_PWE_1500U_SPK7.indb 8 08.08.2019 14:41:5708.08.2019 14:41:57

GB
- 9 -
maintained.
5. Before starting the equipment
It is recommend for the power supply to this ma-
chine either to be connected via a residual current
device circuit-breaker, which interrupts the power
flow as soon as the leakage current to earth ex-
ceeds 30 mA for 30 ms, or for it to be equipped
with an earth tester.
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Warning!
Always pull the power plug before making
adjustments to the equipment.
5.1 Using the equipment correctly
• The pressure cleaner must be stood on a le-
vel, stable surface.
• It is recommended that you adopt the correct
operating position every time you use the
equipment, with one hand on the gun and the
other on the lance.
• Never direct the water jet at electrical lines or
the equipment itself.
• So that the pump does not suffer any damage
when it is not in use, a small amount of leaka-
ge from the pump is normal.
• Never use the machine in potentially explosi-
ve areas under any circumstances!
• The operating temperature must be between
+5 and + 40°C.
• Do not cover or modify the lance or the spray
nozzles in any way.
• The pressure cleaner is designed to be used
with cold or lukewarm water (max. 60 °C); hig-
her temperatures can damage the pump.
• Do not use water that is dirty, gritty or con-
tains any chemical products, as these could
impair operation and shorten the life of the
equipment.
Caution: Risk of explosion
Do not spray flammable liquids.
Warning
Water that has passed through the non-return
valve is not drinkable.
Warning
If cleaning agent gets into contact with your skin
or into your eye, rinse immediately with lots of
clean water. Then consult a doctor or follow the
steps described on the safety data sheet or provi-
ded by the manufacturer of the cleaning agent.
5.2 Assembly
5.2.1 Assembling the equipment (Fig. 1)
Push the accessories holder (2) onto the high-
pressure cleaner (5).The holder can be used for
space-saving storage of the gun (8), the extensi-
on (9) and the high-pressure hose (15).
Note! Before using the pressure cleaner, make
sure that the high-pressure hose is completely
unwound.
5.2.2 Fitting the attachments (Fig. 2)
Before you use the high-pressure cleaner (5) you
must first fasten the extension (9) to the gun (8)
by pushing and twisting.
Then push the rotating nozzle (13) or the cleaning
agent container (10) onto the extension (9) by
means of the quick connection system.
Rotating nozzle
To remove particularly stubborn dirt, use the rota-
ting nozzle (13).
Solid cone / flat fan lance (14)
The shape of the water jet can be changed from
solid cone to flat fan by turning the nozzle (Fig. 8).
Cleaning agent container
You can adjust the quantity of cleaning agent you
want to add by turning (+ / -) on the setting wheel
(11). We recommend using the cleaning agent
sparingly.
5.2.3 Fitting the handle (Fig. 5)
Push the handle (1) onto the pressure washer (5)
and secure it using the 4 screws (long thread).
5.2.4 Assembling the terrace cleaner (Figs.
6-9)
Insert the extension for the terrace cleaner (16)
into the recess provided.
Then turn the terrace cleaner (16) over and insert
the two screws (short thread).Then place the
rotor (17) on the terrace cleaner (16) and secure
this by inserting the clip.
You can then attach the terrace cleaner (16) to
the extension (8) using the quick-lock system
(12).
Anl_PWE_1500U_SPK7.indb 9Anl_PWE_1500U_SPK7.indb 9 08.08.2019 14:41:5708.08.2019 14:41:57

GB
- 10 -
5.2.5 Connecting the high-pressure hose
(Fig. 3/4)
Connect the high-pressure hose (15) to the gun
(8) and the high-pressure cleaner (5).
Note:
The connections for the high-pressure hose
and the accessories are equipped with a quick
connection system (12).To connect, simply push
the hose or the accessory onto the respective
connection.To remove, simply actuate the quick
connection system (12) and you can remove the
hose or the accessory.
Each time before fitting, always check that the
quick connection system (12) is correctly enga-
ged. Do this by pulling briefly on the hose or the
accessory.
5.2.6 Water inlet connector (Fig. 1/4)
The connection for the water inlet (4) is equipped
with a connector for standard hose coupling
systems. Plug the hose coupling on the supply
hose (min. Ø 1/2“/ca. 13 mm) to the water inlet
connector (4).
Always use a reinforced hose with a standard
coupling for the water inlet.The hose should be at
least 6 m in length. (Not supplied)
A backflow preventer must be installed between
the drinking water and the pressure cleaner! Ask
your local plumber about this.
5.2.7 Electrical connections (Fig. 1)
• Before you connect the equipment to the
power supply make sure that the data on the
rating plate are identical to the supply voltage.
• If you use any extension cables, make sure
that they are suitable for outdoor use and
have large enough wires:
1 – 10 m: 1.5 mm²
10-30m: 2.5 mm²
• Insert the power plug on the power cable (6)
into the socket outlet.
6. Operation
The equipment consists of an assembly with a
pump, which is encased in a shock absorbing
housing. For an optimal working position the
equipment comes with a lance and a non-slip
gun, whose shape and configuration comply with
the applicable regulations.
6.1 Using for the first time
Once you have completely assembled the pres-
sure cleaner and made all the connections, pro-
ceed as follows:
Open the water inlet. Press safety pin „a“ (Fig. 2)
on the spray gun and pull back trigger lever „b“
(Fig. 2) in order to bleed the trapped air out of the
equipment.
Turn on the equipment by switching the On/Off
switch (Fig. 1/3) to “ON”.
Now activate the trigger lever (b).
Pressure switch:
Function of the pressure switch:The following
happens when the gun is switched off: the pres-
sure switch trips, the power supply is disconnec-
ted, the pressure switch switches offthe pump,
and the high-pressure cleaner goes into stand-by.
As soon as you press the trigger lever (b), the
pump will restart.To turn offthe pressure cleaner
completely, set the On/Offswitch (Fig. 1/3) to
“OFF”. When the pump pressure exceeds the
pressure of the pre-set pump valve, the surplus
liquid will return to the inlet system.
6.2 Using cleaning agent
• Fill the cleaning agent container (10) with sui-
table cleaning agent.
• The cleaning agent will be added automati-
cally in low-pressure mode.
Note:
Use only cleaning agents which are expressly
suitable for high-pressure cleaners.
6.3 Holder for the gun/accessories (Fig. 1)
The gun and accessories can be kept in the provi-
ded accessories holder (2) in order to save space
when not in use.
7. Replacing the power cable
Danger!
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel
to avoid danger.
Anl_PWE_1500U_SPK7.indb 10Anl_PWE_1500U_SPK7.indb 10 08.08.2019 14:41:5708.08.2019 14:41:57

GB
- 11 -
8. Cleaning, maintenance and
ordering of spare parts
Danger!
Always pull out the mains power plug before star-
ting any cleaning work.
8.1 Cleaning
• Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible.Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
• We recommend that you clean the device
immediately each time you have finished
using it.
• Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could
attack the plastic parts of the equipment. En-
sure that no water can seep into the device.
8.2 Maintenance
8.2.1 Testing the water intake filter
Periodically check the intake filter in order to pre-
vent clogging, which could jeopardize operation
of the pump.
To do this, unscrew the coupling for the water inlet
hose from the device and clean the exposed inlet
sieve under running water.
8.2.2 Long periods of nonuse (electric pump)
The machine should be fully emptied of water
each time after use.This requires you to switch on
the equipment without a connected water supply
and to press the trigger lever (b) (max. 1 min.) un-
til no more water emerges.Then you must switch
offthe equipment.
If the device is not used for an extended period
of time, lime deposits will begin to form in the
electric pump, which in turn can lead to starting
difficulties.
8.2.3 Cleaning the nozzle (Fig. 11)
Use the nozzle cleaning pin supplied (A) to clean
clogged nozzles.
8.3 Ordering replacement parts:
Please quote the following data when ordering
replacement parts:
• Type of machine
• Article number of the machine
• Identification number of the machine
• Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
9. Transport
Before transporting the equipment to a different
location, remove all connections.The equipment
is then free for transport.
10. Disposal and recycling
The unit is supplied in packaging to prevent its
being damaged in transit.This packaging is raw
material and can therefore be reused or can be
returned to the raw material system.
The unit and its accessories are made of various
types of material, such as metal and plastic. De-
fective components must be disposed of as spe-
cial waste. Ask your dealer or your local council.
11. Storage
Store the equipment and accessories out of
children’s reach in a dark and dry place at above
freezing temperature.The ideal storage tempe-
rature is between 5 and 30 °C. Store the electric
tool in its original packaging.
Anl_PWE_1500U_SPK7.indb 11Anl_PWE_1500U_SPK7.indb 11 08.08.2019 14:41:5708.08.2019 14:41:57

GB
- 12 -
12. Possible causes of failure
Fault Cause Remedy
The equipment
does not work
- No electrical voltage at the equip-
ment
- The cross section of the extension
cable is not large enough and/or
the extension cable is too long
- The mains voltage is lower than
that specified
- The pump is frozen
- Check the fuse, power cable and
power plug and have them replaced
by qualified personnel if necessary
- Use extension cables with larger
cross sections and/or use shorter
extension cables
- Contact the power supply company
if necessary
- Check and thaw if necessary
The motor starts but
there is no pressure
build-up
- The water intake filter is clogged
- Air intake in the water inlet
- The discharge nozzle is too large
- Water cock closed
- Clean the water intake filter (see
8.2.1)
- Check the supply hose and hose
connectors and replace if necessa-
ry
- Check and replace if necessary
- Turn open the water cock.
The operating pres-
sure is irregular
- Air intake in the water inlet - Check the supply hose and hose
connectors and replace if necessa-
ry
Anl_PWE_1500U_SPK7.indb 12Anl_PWE_1500U_SPK7.indb 12 08.08.2019 14:41:5708.08.2019 14:41:57

GB
- 13 -
For EU countries only
Never place any electric power tools in your household refuse.
To comply with European Directive 2012/19/EC concerning old electric and electronic equipment and
its implementation in national laws, old electric power tools have to be separated from other waste and
disposed of in an environment-friendly fashion, e.g. by taking to a recycling depot.
Recycling alternative to the return request:
As an alternative to returning the equipment to the manufacturer, the owner of the electrical equipment
must make sure that the equipment is properly disposed of if he no longer wants to keep the equipment.
The old equipment can be returned to a suitable collection point that will dispose of the equipment in
accordance with the national recycling and waste disposal regulations. This does not apply to any ac-
cessories or aids without electrical components supplied with the old equipment.
The reprinting or reproduction by any other means, in whole or in part, of documentation and papers
accompanying products is permitted only with the express consent of the iSC GmbH.
Subject to technical changes
Anl_PWE_1500U_SPK7.indb 13Anl_PWE_1500U_SPK7.indb 13 08.08.2019 14:41:5708.08.2019 14:41:57

GB
- 14 -
Service information
We have competent service partners in all countries named on the guarantee certificate whose contact
details can also be found on the guarantee certificate. These partners will help you with all service re-
quests such as repairs, spare and wearing part orders or the purchase of consumables.
Please note that the following parts of this product are subject to normal or natural wear and that the
following parts are therefore also required for use as consumables.
Category Example
Wear parts* Carbon brushes, lance, hose
Consumables*
Missing parts
* Not necessarily included in the scope of delivery!
In the effect of defects or faults, please register the problem on the internet at www.isc-gmbh.info. Ple-
ase ensure that you provide a precise description of the problem and answer the following questions in
all cases:
• Did the equipment work at all or was it defective from the beginning?
• Did you notice anything (symptom or defect) prior to the failure?
• What malfunction does the equipment have in your opinion (main symptom)?
Describe this malfunction.
Anl_PWE_1500U_SPK7.indb 14Anl_PWE_1500U_SPK7.indb 14 08.08.2019 14:41:5708.08.2019 14:41:57

GB
- 15 -
Warranty certificate
Dear Customer,
All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the
unlikely event that your device develops a fault, please contact our service department at the address
shown on this guarantee card.You can also contact us by telephone using the service number shown.
Please note the following terms under which guarantee claims can be made:
1. These guarantee terms apply to consumers only, i.e. natural persons intending to use this product
neither for their commercial activities nor for any other self-employed activities.These warranty
terms regulate additional warranty services, which the manufacturer mentioned below promises to
buyers of its new products in addition to their statutory rights of guarantee.Your statutory guarantee
claims are not affected by this guarantee. Our guarantee is free of charge to you.
2. The warranty services cover only defects due to material or manufacturing faults on a product which
you have bought from the manufacturer mentioned below and are limited to either the rectification of
said defects on the product or the replacement of the product, whichever we prefer.
Please note that our devices are not designed for use in commercial, trade or professional applica-
tions. A guarantee contract will not be created if the device has been used by commercial, trade or
industrial business or has been exposed to similar stresses during the guarantee period.
3. The following are not covered by our guarantee:
- Damage to the device caused by a failure to follow the assembly instructions or due to incorrect
installation, a failure to follow the operating instructions (for example connecting it to an incorrect
mains voltage or current type) or a failure to follow the maintenance and safety instructions or by ex-
posing the device to abnormal environmental conditions or by lack of care and maintenance.
- Damage to the device caused by abuse or incorrect use (for example overloading the device or the
use or unapproved tools or accessories), ingress of foreign bodies into the device (such as sand,
stones or dust, transport damage), the use of force or damage caused by external forces (for ex-
ample by dropping it).
- Damage to the device or parts of the device caused by normal or natural wear or tear or by normal
use of the device.
4. The guarantee is valid for a period of 3 years starting from the purchase date of the device. Guaran-
tee claims should be submitted before the end of the guarantee period within two weeks of the de-
fect being noticed. No guarantee claims will be accepted after the end of the guarantee period. The
original guarantee period remains applicable to the device even if repairs are carried out or parts are
replaced. In such cases, the work performed or parts fitted will not result in an extension of the gua-
rantee period, and no new guarantee will become active for the work performed or parts fitted. This
also applies if an on-site service is used.
5. To make a claim under the guarantee, please register the defective device at: www.isc-gmbh.info.
Please keep your bill of purchase or other proof of purchase for the new device. Devices that are
returned without proof of purchase or without a rating plate shall not be covered by the guarantee,
because appropriate identification will not be possible. If the defect is covered by our guarantee,
then the item in question will either be repaired immediately and returned to you or we will send you
a new replacement.
Of course, we are also happy offer a chargeable repair service for any defects which are not covered by
the scope of this guarantee or for units which are no longer covered. To take advantage of this service,
please send the device to our service address.
Also refer to the restrictions of this warranty concerning wear parts, consumables and missing parts as
set out in the service information in these operating instructions.
Anl_PWE_1500U_SPK7.indb 15Anl_PWE_1500U_SPK7.indb 15 08.08.2019 14:41:5708.08.2019 14:41:57

Liu/Product-ManagementAndreas Weichselgartner/General-Manager
- 16 -
Derklärt folgende Konformität gemäß EU-Richtlinie und
Normen für Artikel
GB explains the following conformity according to EU directi-
ves and norms for the following product
Fdéclare la conformité suivante selon la directive CE et les
normes concernant l’article
Idichiara la seguente conformità secondo la direttiva UE e
le norme per l’articolo
NL verklaart de volgende overeenstemming conform EU
richtlijn en normen voor het product
Edeclara la siguiente conformidad a tenor de la directiva y
normas de la UE para el artículo
Pdeclara a seguinte conformidade, de acordo com as
diretiva CE e normas para o artigo
DK attesterer følgende overensstemmelse i medfør af
EU-direktiv samt standarder for artikel
Sförklarar följande överensstämmelse enl. EU-direktiv och
standarder för artikeln
FIN vakuuttaa, että tuote täyttää EU-direktiivin ja standardien
vaatimukset
EE tõendab toote vastavust EL direktiivile ja standarditele
CZ vydává následující prohlášení o shoděpodle směrnice EU
a norem pro výrobek
SLO potrjuje sledečo skladnost s smernico EU in standardi za
izdelek
SK vydáva nasledujúce prehlásenie o zhode podľa smernice
EÚ a noriem pre výrobok
Ha cikkekhez az EU-irányvonal és Normák szerint a
következőkonformitást jelenti ki
PL deklaruje zgodność wymienionego poniżej artykułu z
następującymi normami na podstawie dyrektywy WE.
BG декларира съответното съответствие съгласно
Директива на ЕС инорми за артикул
LV paskaidro šādu atbilstību ES direktīvai un standartiem
LT apibūdina šįatitikimąEU reikalavimams ir prekės normoms
RO declarăurmătoarea conformitate conform directivei UE şi
normelor pentru articolul
GR δηλώνει την ακόλουθη συμμόρφωση σύμφωνα με την
Οδηγία ΕΚ και τα πρότυπα για το προϊόν
HR potvrđuje sljedeću usklađenost prema smjernicama EU i
normama za artikl
BIH potvrđuje sljedeću usklađenost prema smjernicama EU i
normama za artikl
RS potvrđuje sledeću usklađenost prema smernicama EZ i
normama za artikal
RUS следующим удостоверяется, что следующие продукты
соответствуют директивам инормам ЕС
UKR проголошує про зазначену нижче відповідність виробу
директивам та стандартам ЄС на виріб
MK ја изјавува следната сообрзност согласно
ЕУ-директивата инормите за артикли
TR Ürünü ile ilgili AB direktifleri ve normlarıgereğince aşağıda
açıklanan uygunluğu belirtir
Nerklærer følgende samsvar i henhold til EU-direktivet og
standarder for artikkel
IS Lýsir uppfyllingu EU-reglna og annarra staðla vöru
Konformitätserklärung
High Pressure Cleaner PWE-1500U (Ozito)
2014/29/EU
2005/32/EC_2009/125/EC
2014/35/EU
2006/28/EC
X2014/30/EU
2014/32/EU
2014/53/EU
2014/68/EU
(EU)2016/426
Notified Body:
(EU)2016/425
X2011/65/EU_(EU)2015/863
X2006/42/EC
Annex IV
Notified Body:
Reg. No.:
X2000/14/EC_2005/88/EC
XAnnex V
Annex VI
Noise: measured LWA = 94 dB (A); guaranteed LWA = 96 dB (A)
P = 1,5 kW; L/Ø = cm
Notified Body:
2012/46/EU_(EU)2016/1628
Emission No.:
Standard references: EN 60335-1; EN 60335-2-79; EN 62233;
EN 55014-1; EN 55014-2; EN 61000-3-2; EN 61000-3-3
Landau/Isar, den 22.07.2019
First CE: 19 Archive-File/Record: NAPR022015
Art.-No.: 41.407.24 I.-No.: 11019 Documents registrar: Hirsekorn Sergey
Subject to change without notice Wiesenweg 22, D-94405 Landau/Isar
ISC GmbH · Eschenstraße 6 · D-94405 Landau/Isar
Anl_PWE_1500U_SPK7.indb 16Anl_PWE_1500U_SPK7.indb 16 08.08.2019 14:41:5708.08.2019 14:41:57

- 17 -
Anl_PWE_1500U_SPK7.indb 17Anl_PWE_1500U_SPK7.indb 17 08.08.2019 14:41:5808.08.2019 14:41:58

- 18 -
Anl_PWE_1500U_SPK7.indb 18Anl_PWE_1500U_SPK7.indb 18 08.08.2019 14:41:5808.08.2019 14:41:58

- 19 -
Anl_PWE_1500U_SPK7.indb 19Anl_PWE_1500U_SPK7.indb 19 08.08.2019 14:41:5808.08.2019 14:41:58

EH 08/2019 (01)
Anl_PWE_1500U_SPK7.indb 20Anl_PWE_1500U_SPK7.indb 20 08.08.2019 14:41:5808.08.2019 14:41:58
