Ozito PWVCK-1312 User manual

HIGH PRESSURE
CLEANER
1300W 1450 PSI
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 220–240V ~ 50Hz
Motor: 1300W
Rated Flow: 5.7 l/min
Max. Flow: 6.8 l/min
Permissible Pressure: 10 MPa (1450 psi)
Rated Pressure: 7 MPa (1015 psi)
Inlet Water Pressure: 0.6 MPa (87 psi) max.
Water Supply Temp.: 40ºC max.
IP Rating: IPX5
Weight: 4.3kg
PWVCK-1312
WHAT’S IN THE BOX
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: bearings,
o-rings.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
•If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
•Failure to perform maintenance as set out within the
instruction manual.
•If the tool is disassembled or tampered with in any way.
•Professional, industrial or high frequency use.
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
ozito.com.au
0317
High Pressure Cleaner
3m High Pressure Hose
Gun & Lance
Deck & Patio Cleaner
Adjustable Spray Nozzle,
Detergent Spray Bottle

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
1. Accessory holder
2. Water inlet connector
3. High pressure hose connector
4. Quick connect system
5. On/Off switch
6. Carry handle
HIGH PRESSURE CLEANER (PWE-1300)
KNOW YOUR PRODUCT
1. ASSEMBLY
Fitting the accessory holder
1. Push accessory holder onto the high
pressure cleaner.
The holder can be used for storage of
the gun, lance and high pressure hose.
Deck & patio cleaner
1. Attach the extension onto the deck & patio
cleaner.
2. Fasten from the underside using the 2
screws provided
3. Attach the rotor arm to the deck & patio
cleaner and secure by inserting the U-clip.
SETUP & PREPARATION
ACCESSORIES
WARNING! ENSURE THE TOOL IS SWITCHED OFF AND
DISCONNECTED FROM THE POWER SUPPLY BEFORE
PERFORMING ANY OF THE FOLLOWING PROCEDURES.
7. Deck & patio cleaner
8. Rotor arm
9. Lance
10.Gun
11. High pressure hose
12.Screws & U-clip
13.Adjustable spray nozzle
14.Detergent spray bottle
10

Water supply
For use only with mains pressure water when a backow preventer is
installed on the inlet of the pressure washer. For further information
contact Ozito Customer Service.
1. Run water through
your garden hose
to remove any
foreign matter before
attaching to the pump
2. Attach garden hose
(min.Ø 1/2”) to the
water inlet connector
on the pump. Always
use a reinforced
hose with a standard
coupling for water
inlet. The hose should
be at least 6m in
length for proper
operation.
Note: A lter is tted to the inlet connector preventing any debris
from entering the pump. Inspect and clean the lter before use as
insufcient water supply could damage the pump.
2. CONNECTIONS
Gun and lance
1. Fasten the
lance to
the gun by
pushing and
twisting.
Quick connect system
The connections of the accessories are attached with a quick
connection system.
1. To Connect, push the
accessory onto the lance
connection.
High pressure hose
1. Connect the high pressure hose to
the gun.
2. Connect the opposite end of the high
pressure hose to the high pressure
cleaner
2. To remove, actuate the
quick connection system
and remove the accessory

3. OPERATION
OPERATION
Flat Fan
Solid Cone
-
+
On/Off switch
CAUTION! THIS PRODUCT MUST BE USED WITH A
RESIDUAL CURRENT DEVICE RATED 30mA OR LESS.
•To switch the machine On, set the
On/Off switch to position “I” (On)
•To switch the machine Off, move the
On/Off switch to position “0” (Off).
Spray gun
The trigger can be locked to prevent
accidental spraying. Disengage trigger
lock before squeezing trigger.
Adjustable spray nozzle
The shape of the water jet can be adjusted from solid cone or at fan
by turning the nozzle.
Detergent spray bottle
Fill the detergent spray bottle with suitable cleaning agent.
Note: Use only cleaning agents which are expressly suitable for
high pressure cleaners.
The quantity of cleaning
agent you want can be
adjusted by turning
(+ / - ) on the setting dial.
The cleaning agent will be
dispersed automatically.

PWVCK-1312
5. SPRAYING4. PRE-START PROCEDURE
1. Ensure power supply is
connected.
2. Ensure water supply is
connected.
3. Ensure water supply is turned on.
4. Squeeze trigger on the gun until there is a steady ow of water from
the nozzle.
1. Switch the machine On, set the On/Off
switch to position “I” (On
2. Squeeze trigger to begin spraying.
3. When nished, set On/Off switch to
position “0” (Off).
4. Release built up water pressure by
squeezing the trigger.
5. Turn water supply off.
6. Switch off the mains power supply
and remove the electrical plug.

6. TROUBLE SHOOTING
MAINTENANCE
7. CLEANING & MAINTENANCE
IMPORTANT! BEFORE CLEANING YOUR HIGH PRESSURE
CLEANER OR CARRYING OUT ANY MAINTENANCE
PROCEDURE, MAKE SURE THAT THE MOTOR IS OFF AND
THE TOOL DISCONNECTED FROM THE POWER SUPPLY
TO PREVENT ACCIDENTAL STARTING.
IMPORTANT! WAIT UNTIL THE HIGH PRESSURE CLEANER
HAS COMPLETELY COOLED DOWN. RISK OF BURNS!
Cleaning
• Keep the safety devices free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it with compressed
air at low pressure.
• We recommend that you clean the appliance immediately after you
use it.
• Clean the appliance regularly with a damp cloth and some soft
soap. Do not use cleaning agents or solvents; these may be
aggressive to the plastic parts in the appliance. Ensure that no
water can get into the interior of the appliance.
• You must disconnect the hose and any spraying tools from the
compressor before cleaning. Do not clean the compressor with
water, solvents or the like.
Testing the water intake lter
Periodically check the intake lter in
order to prevent clogging, which could
jeopardize operation of the pump.
To do this, unscrew the connector
for the water inlet hose from the
high pressure cleaner and clean the
exposed inlet sieve under running
water.
Problem Cause Solution
The high pressure
cleaner does not start
1. No power supply 1. Check the power
supply, the power
plug and the
socket-outlet.
2. Insufcient supply
power
2. Make sure that
the extension
cable is not too
long.
3. Outside temperature
is too low
3. Never operate
with an outside
temperature of
below 5°c.
4. Motor is overheated 4. Allow the motor
to cool down.
If necessary,
remedy the
cause of the
overheating.
The motor starts but
there is no pressure
build-up
1. Water intake lter is
clogged
1. Clean the water
intake lter
2. Air intake in the
water inlet
2. Check the supply
hose and hose
connectors
and replace if
necessary
3. Water tap closed 3. Turn open the
water tap
The operating
pressure is irregular
1. Air intake in the
water inlet
1. Check the supply
hose and hose
connectors
and replace if
necessary

DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your
local council authority for recycling advice.
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
/min Revolutions or
reciprocation per minute
l/min Litres per minute dB Decibel level
psi Pounds per square inch BAR Pressure rating
Regulator compliance mark
Warning
Read instruction manual
Hp Horse power
Ingress protection from water
IPX5
WWatts
~Alternating current
Volts
VHz Hertz
Warning! High pressure jets can be dangerous if not used properly.
Do not direct the jet at persons, animals, live electrical equipment or
the pressure washer itself.
Double insulated MPa Megapascal
This machine is not suitable for connecting to the drinking water
network unless a backflow preventer is installed on the inlet of the
pressure washer.
96
Sound power level
8. STORAGE
The high pressure cleaner should be fully emptied of water each
time after use. This requires you to switch on the equipment without
a connected water supply and to squeeze trigger on the gun (max. 1
minute) until no more water emerges. Then you must switch off the
equipment.

HIGH PRESSURE CLEANER SAFETY WARNINGS
WARNING! When using mains-powered tools, basic safety precautions, including
the following, should always be followed to reduce risk of re, electric shock,
personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an
emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The electric motor has been designed for 230V and 240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
This tool is double insulated therefore no earth wire is required
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New
Zealand.
If operating a power tool in a damp location is unavoidable use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect
the extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged
or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension
lead not suitable for the power input of the tool or which is damaged or defective may result in a risk
of re and electric shock.
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)
power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools. Unmodied plugs and
matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the inuence of drugs, alcohol
or medication.
A moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to power source and/or battery pack, picking up or carrying the tool. Carrying power
tools with your nger on the switch or energising power tools that have the switch on invites
accidents.
d. Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control
of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-
related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the
power tool for operations different from those intended could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
b. If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a hazard.
GENERAL POWER TOOL SAFETY WARNINGS - PERSONAL SAFETY
ELECTRICAL SAFETY
RISK OF UNSAFE OPERATION
What can happen
• Unsafe operation of your high pressure cleaner could lead to serious injury or death to you or
others.
• The spray gun/wand is a powerful cleaning tool that could look like a toy to a child.
• Reactive force of spray results in gun/lance movement, potentially causing the operator to slip, fall
or misdirect the spray. Improper control of gun/wand can result in injuries to self, others and property
damage.
How to prevent it
• Become familiar with the operation and controls of the pressure cleaner.
• Keep children away from the pressure cleaner at all times.
• Never modify or remove the safety features of this product.
• Do not operate the machine with missing, broken or unauthorized parts.
• Never leave wand unattended while unit is running.
• Keep work area free of obstacles.
• Stand on stable surface and grip gun/lance rmly. Expect the gun to kick back when engaged
1) Do not use to pump ammable or explosive liquids such as gasoline, fuel oil, kerosene,solvents or
thinners. Pump should only be used with liquids compatible with water blaster component materials.
Failure to follow to this warning can result in serious personal injury, death and/or property damage.
2) Water high presser cleaner must be located on a solid level surface. Pump could tip or fall causing
serious injury.
3) Do not hold or suspend pump by means of a discharge pipe. Pipe could break or come loose.
WARNING!: This appliance has been designed for use with the cleaning agent supplied or
recommended by the manufacturer. The use of other cleaning agents or chemicals may adversely
affect the safety of the appliance.
WARNING!: Do not use the appliance within range of persons unless they wear protective clothing.
WARNING!: High pressure jets can be dangerous if subject to misuse. The jet must not be directed
at persons, live electrical equipment or the appliance itself.
• Do not direct the jet against yourself or others in order to clean clothes or foot-wear.
• To ensure appliance safety, use only original spare parts from the manufacturer or approved by
the manufacturer.
WARNING!: High pressure hoses, ttings and couplings are important for the safety of the appliance.
Use only hoses, ttings and couplings recommended by the manufacturer.
• Do not use the appliance if a supply cord or important parts of the appliance are damaged,
e.g. safety devices, high pressure hoses, trigger gun.
This machine is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge.
WARNING!: Water that has owed through backow preventer is considered to be non-potable.

WET & DRY
VACUUM
1250W 12L
INSTRUCTION MANUAL
SPECIFICATIONS
Input Power: 1250W
Suction Power Max.: 140 mbar
Air Flow: 27 l/s
Tank Capacity: 12 l
Hose Length: 1.5m
Hose Diameter: 35mm
IP Rating: IPX4
Product weight: 2.7 kg
PWVCK-1312
WHAT’S IN THE BOX
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: Filters and dust
bag.
WARNING
The following actions will result in the warranty being void.
•If the tool has been operated on a supply voltage other
than that specified on the tool.
•If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
•Failure to perform maintenance as set out within the
instruction manual.
•If the tool is disassembled or tampered with in any way.
•Professional, industrial or high frequency use.
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
ozito.com.au
0317
Suction Hose Ø35mm x 1.5m
Extension Tubes x 3
Crevice Tool
Castors x 4
Adapter
Floor Tool
Foam
Filter
Dust Bag
Filter Bag

3
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
1. Handle
2. Motor
3. Suction Hose
4. Extension Tubes
5. Filter Basket
6. Safety Float (hidden)
7. On/Off Switch
8. Tank Securing Clips
9. Vaccum Inlet
10.Tank
11. Floor Tool
12.Adaptor
13.Blow Outlet
14.Castors
WET & DRY VACUUM (VWD-1212)
ACCESSORIES
KNOW YOUR PRODUCT
1. ASSEMBLY
SETUP & PREPARATION
Assembling the Castors
1. Turn the container upside down.
2. Insert the castor assemblies into
the base of the tank.
Fitting the Motor
1. Whenttingthemotortothetank,
position it so that the tank securing
clips on the motor align with the
fastening points on the tank.
2. Fasten the tank securing clips to the
tank,makingsurethatthey
lock into place correctly.
3. Toremovethemotor,openthe
tank securing clips and lift the motor out
of the tank.
Fitting the Handle
1. Align the handle with the holes in the
top side of the motor. Fit the handle by
pressing it into the holes.
15.Filter Bag
16.Dust Bag
17.Foam Filter
18.Crevice Tool
1
2
3
4
5
6
7
8
9
10
11 13 1412
15 16 17 18

Fitting the Dust Bag
1. Forvacuumingne,drydirtitis
recommendedthatyoutthedust
bag. The dust bag is suitable for dry
vacuuming only. Using the dust bag
makes it easier to dispose of the
dust that has been collected.
2. Toattach,slipthedustbagover
the vacuum inlet.
Fitting the Foam Filter -
Vacuuming Liquid
Forwet-vacuuming,slipthesupplied
foamlteroverthelterbasket.
NOTE: Do not use the lter bag and/
or dust bag when vacuuming liquid.
Fitting the Filter Bag -
Vacuuming Dry Matter
For dry vacuum cleaning always use the
lterbag.Mountthelterbag,sothat
noairissuckedthroughtheltercage
withoutbeingltered.
NOTE: Do not use the foam lter
when vacuuming dry matter.
2. FITTING THE FILTER
IMPORTANT! NEVER USE THE WET AND DRY VACUUM
CLEANER WITHOUT A FILTER! ALWAYS ENSURE THAT
THE FILTERS ARE PERFECTLY SECURE!

3. FITTING HOSES & NOZZLES 4. OPERATION
Connect the suction hose to the
corresponding connector on the
wetanddryvacuum,dependingon
the application required:
Vacuuming
Connect the suction hose to
the vacuum inlet.
Blowing
Connect the suction hose to
the blow outlet.
Extension Tube and Adaptor
1. The suction hose can be extended by attaching one or more sections
of the 3 part extension tubes.
2. The adapter must be inserted between
the extension tube and whichever of the
nozzles is required.
Suction Tools
Floor Tool
Theoortoolisforvacuumingsolidsandliquids
over medium to large areas.
Crevice Tool
The crevice tool is designed for cleaning crevices
and edges.
OPERATION
IMPORTANT! SWITCH OFF THE EQUIPMENT IF LIQUID
OR FOAM IS EMITTED WITH THE EXHAUST AIR WHEN
WET VACUUM CLEANING.
IMPORTANT! WHEN WET VACUUMING, THE SAFETY
FLOAT TURNS OFF THE WET AND DRY VACUUM
CLEANER AUTOMATICALLY WHEN THE MAXIMUM
LEVEL IS REACHED.
IMPORTANT! THE WET AND DRY VACUUM CLEANER
IS NOT SUITABLE FOR THE VACUUMING OF
COMBUSTIBLE LIQUIDS.
PWVCK-1312
On/Off Switch
Switch position 0: OFF
Switch position I: ON
Dry Vacuuming
Usethedustbagandthelterbag
for dry vacuuming (see 2. Fitting the
Filter).
Checkthatthelterissecurelyttedat
all times.
Wet Vacuuming
Forwet-vacuuming,usethefoamlter
(see 2. Fitting the Filter).
Checkthatthelterissecurelytted
at all times.
NOTE: The tank will collect 8.5 Litres
maxofuidandtheoatswitchwillturn
off the vac.
Blowing
Connect the suction hose to the blow
outlet on the wet and dry vacuum
cleaner.
This vacuum must be used with a residual current device
with a rated residual current of 30mA or less.

Cleaning
Keepallsafetydevices,airventsandthemotorhousingfree
of dirt and dust as far as possible.
We recommend that you clean the equipment immediately after
you use it.
Cleaning the motor housing
Clean the appliance regularly with a damp cloth and some soft soap.
Do not use cleaning agents or solvents; these may be aggressive to the
plastic parts in the appliance.
Cleaning the tank
The tank can be cleaned with a damp cloth and some soft soap or under
runningwater,dependingontheamountofdirt.
Cleaning the foam lter
Cleanthefoamlterwithalittlesoftsoapunderrunningwaterandallow
it to air-dry.
Storing
Ensure the Wet & Dry Vac has been fully emptied of any dry matter or
liquid before it is stored.
Wrap the power cable around the cable hook.
Keep all the accessories with the unit to avoid losing them.
Keep in a dry place out of reach of children.
MAINTENANCE DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recyclingpackagingreducestheneedforlandllandrawmaterials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your
local council authority for recycling advice.
Dust Bag (Pkt 5) VWDA-002
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
5. CLEANING & STORING
VVolts Hz Hertz
~Alternating current WWatts
ILitres Double insulated
Regulator compliance
mark l/s Litres per second
Read instruction manual Warning
IPX4 Ingress protection from
water mbar Pressure rating (millibar)
IMPORTANT! BEFORE CLEANING YOUR WET & DRY VAC
OR CARRYING OUT ANY MAINTENANCE PROCEDURE,
MAKE SURE THAT THE MOTOR IS OFF AND THE VAC
DISCONNECTED FROM THE POWER SUPPLY TO
PREVENT ACCIDENTAL STARTING.

IMPORTANT!
Whenusingtheequipment,afewsafetyprecautionsmustbeobservedtoavoidinjuries
and damage. Please read the complete operating manual with due care. Keep this manual
in a safe place so that the information is available at all times. If you give the equipment to any other
person,givethemtheseoperatinginstructionsaswell.
We cannot accept any liability for damage or accidents which arise due to a failure to follow these
instructions and the safety information.
• Do not leave appliance unattended when plugged in. Unplug from outlet when not in use and
before servicing and cleaning.
• Toavoidelectricshock,donotexposetorain.Storeindoors.
• Neveruseinthepresenceofexplosiveliquids,vapoursorexplosivedust–suchascoal
or grain.
• Never pick up asbestos or asbestos dust.
• Wooddustandchipsinaconnedareacangiverisetoreoranexplosion.Guardagainst
possible ignition sources.
• Donotpickupanythingthatisburningorsmouldering–suchasmetalgrindingdust,cigarette
ends,hotcoals,matchesorsimilar.
• Theapplianceisnotintendedforusebyyoungchildrenorinrmpersonswithoutsupervision.
Young children should be supervised to ensure they do not play with the appliance.
• Use only manufacturer’s recommended attachments and consumables.
• Never modify the cleaner in any way - this is dangerous and will invalidate the warranty.
• Donotusecleanerwithoutthelterinplace.
• If motor sound becomes higher pitched always check for the following:
- Blocked hose or accessory.
 -Blockedlter.
- Full container.
• Never try to move the cleaner by pulling with the mains lead.
• Alwayscheckthatthelterisclearandnotblocked.Keepallopeningsclearofanyblockages.
• Whenliftingtheunit,alwaysliftitwiththehandleorunderrimofbucket.Bewareofexcess
weight.
• Always switch the unit off before changing attachments or connecting different power tools.
• Always disconnect equipment from the appliance when it is not in use.
• If the cordset is damaged have it repaired by an authorised service centre.
• Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,
sensoryormentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeen
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• The wet and dry vacuum cleaner is designed for wet and dry vacuuming using the appropriate
lter.Theapplianceisnotsuitableforthevacuumingofcombustible,explosiveorharmful
substances.
• The equipment is to be used only for its prescribed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the manufacturer will be liable for any damage or
injuriesofanykindcausedasaresultofthis.
WET & DRY VACUUM SAFETY WARNINGS
WARNING! When using mains-powered tools, basic safety precautions, including
the following, should always be followed to reduce risk of re, electric shock,
personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an
emergency,beforeoperatingthetool.
Save these instructions and other documents supplied with this tool for future reference.
The electric motor has been designed for 230V and 240V only. Always check that the power
supply corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and
New Zealand.
Note: The power outlet used for the vacuum must be protected by a 30mA residual current device
or earth leakage circuit breaker.
Thistoolisdoubleinsulated,thereforenoearthwireisrequired.
Ifthesupplycordisdamaged,itmustbereplacedbyanelectricianorapowertoolrepairerin
order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this
tool.Theinsulationsystemisforaddedprotectionagainstinjuryresultingfromapossibleelectrical
insulation failure within the tool.
Using an Extension Lead
Alwaysuseanapprovedextensionleadsuitableforthepowerinputofthistool.Beforeuse,
inspecttheextensionleadforsignsofdamage,wearandageing.Replacetheextensionleadif
damaged or defective.
Whenusinganextensionleadonareel,alwaysunwindtheleadcompletely.Useofanextension
lead not suitable for the power input of the tool or which is damaged or defective may result in a
riskofreandelectricshock.
WARNING! Read all safety warnings and all instructions. Failure to follow the
warningsandinstructionsmayresultinelectricshock,reand/orseriousinjury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)
power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools.Unmodiedplugsand
matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply with a rated residual current of 30 mA or less. Use of an RCD
reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the inuence of drugs, alcohol
or medication.
Amomentofinattentionwhileoperatingpowertoolsmayresultinseriouspersonalinjury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment
suchasdustmask,non-skidsafetyshoes,hardhat,orhearingprotectionusedforappropriate
conditionswillreducepersonalinjuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to power source and/or battery pack, picking up or carrying the tool. Carrying power
toolswithyourngerontheswitchorenergisingpowertoolsthathavetheswitchoninvites
accidents.
d. Remove any adjusting key or wrench before turning the power tool on.
Awrenchorakeyleftattachedtoarotatingpartofthepowertoolmayresultinpersonalinjury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control
of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts.Looseclothes,jewelleryorlonghaircanbecaughtinmovingparts.
g. If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-
related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct
powertoolwilldothejobbetterandsaferattherateforwhichitwasdesigned.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the
power tool for operations different from those intended could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
b. If the supply cord is damaged, it must be replaced by the manufacturer,
itsserviceagentorsimilarlyqualiedpersonsinordertoavoidahazard.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
VVolts Hz Hertz
~Alternating current WWatts
ILitres Double insulated
Regulator compliance
mark l/s Litres per second
Read instruction manual Warning
IPX4 Ingress protection from
water mbar Pressure rating (millibar)
