Ozito PXC PXTBSS-036 User manual

STANDARD EQUIPMENT
0°
15°
22.5°
30°
45°
0°
15°
22.5°
30°
45°
0
10
20
30
40
50
60
60
50
40
30
20
10
PXTBSS-036
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 2 x 18V
No Load Speed: 3,800/min
Blade: Ø210 x Ø30 x 1.8mm
Blade Teeth: 40TCT
Bevel Angle: 0-45° Left
Mitre Angle: 0-60° Left & Right
Blade Height: 0-70mm
Max. Cutting Capacity: 70mm @ 90°; 45mm @ 45°
Table Size: 480 x 467mm
Extension Length: 370mm
Weight: 13.0kg
ozito.com.au
0922
Cordless Table Saw & 40TCT
Blade
Rip Fence, Stop Rail,
Sliding Mitre Gauge, Dust
Port Adaptor, Riving Knife,
Blade Guard, Push Stick &
2 x Spanners (10/13mm &
10/21mm)
210MM
TABLE SAW
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO INDUSTRIES PTY. LTD. 25 Fox Drive, Dandenong South, VIC 3175, Australia.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty and are excluded from the warranty extension. Warranty excludes
consumable parts.

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
0°
15°
22.5°
30°
45°
THIS SIDE OUT
40
210MM
TOOTH
Max. Speed 6,000/min
Bore: 30mm
Thickness: 1.8mm
TUNGSTEN
CARBIDE
TEETH
(8¼”)
WARNING!
Donot use tungsten carbide tipped blades for
masonryor metal cutting applications.
HW,t=40 EN 847-1
Installing The Dust Port Adaptor
A 35mm vacuum hose and vacuum can be attached to the extraction port on
the rear for dust extraction during use.
1. Undo the Phillips head screw on the back
of the unit.
2. Push the dust extraction adaptor onto the
port.
3. Replace the screw to lock the adaptor in
place.
4. Connect a suitable vacuum or dust extraction system to the dust
extraction adaptor for use with the table saw.
Installing The Riving Knife & Blade Guard
1. Unlock the table insert by using
a spanner to turn the insert lock.
Then lift and remove the table
insert.
2. Raise the blade to its highest position by
turning the adjustment wheel clockwise.
Note: Ensure the bevel angle is set to 0°.
3. Use the 10mm spanner to loosen the
riving knife bolt.
4. Insert the riving knife behind
the plate, leaving a 3-8mm gap
between the riving knife and
blade teeth.
5. Re-tighten the riving knife bolt.
6. Replace the table insert and use the
spanner to lock it in place.
1. Table
2. Extension Table
3. Blade Guard
4. Rip Fence
5. Rip Fence Lock Lever
6. Push Stick Storage
7. Push Stick
8. Bevel Scale
9. Bevel Lock Lever
10. Height Adjustment Wheel
11. On/Off Switch
12. Riving Knife
13. Spanner Storage
14. Dust Port Adaptor
15. Mitre Guide Storage
16. Battery Seating
17. Extension Table Lock Lever
This tool is compatible with all batteries & chargers from the Ozito PXC range.
For optimal performance, we recommend the use of 3.0Ah batteries or
higher to operate this PXC Table Saw.
CORDLESS TABLE SAW
BATTERY & CHARGER
KNOW YOUR PRODUCT
1. ASSEMBLY
SETUP & PREPARATION
0°
15°
22.5°
30°
45°
0
10
20
30
40
50
60
60
50
40
30
20
10
01234567891011121314151617181920212223
0123456789101112131415161718 cm
3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32210
0cm 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27
62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25
57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20
cm
0
10
20
30
40
50
60
60
50
40
30
20
10
01234567891011121314151617181920212223
0123456789101112131415161718 cm
3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32210
0cm 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27
62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25
57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20
cm
3 - 8mm
17
16
15
1 432
7
12
13
14
6
5
10 911 8
WARNING! ENSURE THE TOOL IS SWITCHED
OFF AND THE BATTERIES ARE REMOVED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.

Attaching The Blade Guard
1. Align the bolt on the blade guard
with the hole in the riving knife.
2. Tighten the blade guard bolt to
attach it to the riving knife.
Note: the blade guard must be able to move
freely, adjust if necessary.
WARNING! THE BLADE GUARD MUST ALWAYS BE
LOWERED OVER THE WORK PIECE AND MOUNTED
SECURELY BEFORE YOU BEGIN TO CUT.
WARNING! NEVER USE THE TABLE SAW WITHOUT
THE BLADE GUARD IN PLACE.
Storing The Push Stick
Always use the push stick to guide
material through the cut.
The push stick can be stored in its
own slot when not in use.
Installing The Battery Packs
1. Slide the batteries into the tool
base until it clicks into place.
2. To remove the battery, hold down
the battery release button and
slide the battery out.
WARNING! ALWAYS USE BATTERIES WITH THE
SAME AMOUNT OF CHARGE.
Setting The Cutting Depth
The depth should be adjusted so that no more than one tooth is protruding
through the timber. This helps to minimise splintering.
1. To lower the blade for a
smaller depth of cut, rotate the
adjustment wheel anti-clockwise.
2. To raise the blade for a larger
depth of cut, rotate the
adjustment wheel clockwise.
Setting The Bevel Angle
WARNING! THIS TOOL IS NOT INTENDED FOR
CHANNEL OR TRENCH CUTS.
1. Release the bevel lock by ipping
the lever up and left.
2. Slide the adjustment wheel to
the desired angle using the bevel
scale as a guide.
3. Secure the bevel angle by ipping
the bevel lock down and right.
2. ADJUSTMENTS
0°
15°
22.5°
30°
45°
THIS SIDE OUT
40
210MM
TOOTH
Max. Speed 6,000/min
Bore: 30mm
Thickness: 1.8mm
TUNGSTEN
CARBIDE
TEETH
(8¼”)
WARNING!
Donot use tungsten carbide tipped blades for
masonryor metal cutting applications.
HW,t=40 EN 847-1
0°
15°
22.5°
30°
45°
0°
15°
22.5°
30°
45°
0°
15°
22.5°
30°
45°
0°
15°
22.5°
30°
45°
THIS SIDE OUT
40
210MM
TOOTH
Max. Speed 6,000/min
Bore: 30mm
Thickness: 1.8mm
TUNGSTEN
CARBIDE
TEETH
(8¼”)
WARNING!
Donotuse tungsten carbide tipped blades for
masonryormetal cutting applications.
HW,t=40 EN847-1
THIS SIDE OUT
40
210MM
TOOTH
Max. Speed 6,000/min
Bore:30mm
Thickness:1.8mm
TUNGSTEN
CARBIDE
TEETH
(8¼”)
WARNING!
Donotusetungsten carbide tipped blades for
masonryormetalcutting applications.
HW,t=40 EN847-1
