Ozone Subzero V1 User manual

Recommendations
• Open your kite in a large space, big enough to spread your kite out fully.
• Use a tape measure to measure the bridles as in the image.
• Print out the sheet and write down any differences.
If your bridles are out by more than 15mm we recommend replacing them, please
get in touch with the shop/dealer you purchased the kite from and they can order
individual bridle lines or a full set if they do not already have stock.
measure bridles
speed system ZeRo position
You can check your Speed System lines by levelling the front and back line
pigtails, then tension the three top ends of the Speed System where the
bridle lines are attached, they should be at the same level + or - 15mm.
See picture below.
If the difference between the three ends is bigger than 15mm you should
replace your Speed System.
align if difference bigger
than 15mm, replace
speedsystem
checking BRidles and speed system foR stRetch oR shRinkage
We recommend you regularly check your kites bridles and speed system to keep your kite flying
at top performance. use the measurements on the next page to check your bridle lengths.

suBZeRo v1 Rigging diagRam
speed system
PA1
PA2
AR1 BR1 CR1
PB3
PB2
PB1
PC1
KR1
BRidle check sheet. all measuRements in mm
5m 7m 9m 11m 13m
A1 387 423 500 592 601
A2 309 333 396 476 477
A3 373 401 478 525 592
A4 262 272 330 362 414
A5 315 376 396 441 511
A6 213 255 260 290 345
A7 1362 1616 1836 2036 2215
AM1 1950 2350 2650 2900 3200
AM2 1650 2000 2250 2500 2700
AM3 1350 1600 1850 2050 2200
AR1 210 265 300 330 360
B1 361 391 461 547 550
B2 285 303 361 435 431
B3 354 377 449 492 554
B4 247 253 307 335 383
B5 309 368 385 427 494
B6 212 252 255 283 336
B7 574 658 748 848 927
B8 447 509 579 660 723
BM1 1950 2350 2650 2900 3200
BM2 1650 2000 2250 2500 2700
BM3 1350 1600 1850 2050 2200
BM4 800 970 1100 1200 1300
BR1 215 265 300 330 360
C1 417 454 531 621 629
C2 339 364 428 506 506
C3 410 441 518 565 632
C4 301 314 374 406 458
C5 365 431 454 500 572
C6 264 312 320 352 410
C7 625 717 813 917 1000
C8 501 571 647 732 799
CM1 1950 2350 2650 2900 3200
CM2 1650 2000 2250 2500 2700
CM3 1350 1600 1850 2050 2200
CM4 800 970 1100 1200 1300
CR1 220 265 300 330 360
K1 1313 1570 1779 1976 2139
K2 1049 1260 1428 1589 1718
K3 797 964 1092 1219 1317
K4 829 979 1135 1274 1388
K5 613 724 847 956 1043
K6 469 556 655 743 813
K7 437 519 609 692 758
KML1 750 880 1000 1100 1200
KML2 450 550 600 650 700
KR1 1460 1590 1710 1810 1900
ISL 2400 2800 3200 3500 3800
LSL 3170 3500 3800 3870 4130
AR1
AM1
A1 A2
AM2
A3 A4
AM3
A5 A6
A7
BR1
BM1
B1
B2
BM2
B3
B4
BM3
B5
B6
BM4
B7
B8
CR1
CM1
C1C2
CM2
C3C4
CM3
C5C6
CM4
C7
C8
KR1
KML1
K1 K2 K3
KML2
K4 K5 K6 K7
dimensions:
PB3 245
PA2 373
PA1 530
PB2 & PC1 405
PB1 960
