OZtrail FAST FRAME User manual

WARNING
AVOID CONTACT WITH OPEN FLAMES:
This tent is manufactured to meet CPAI-84 Fire Retardant
standards. The fabric may burn if in continuous contact with
open flame sources.
CONDENSATION IS NOT LEAKING:
Minimise condensation by ensuring your tent is well
ventilated through windows, doors or vents.
STITCH LINE
TENT OWNERS MANUAL
FAST FR AME 3 P ER S ON
BEFORE YOU BEGIN
• This tent requires a minimum of two people to set up.
• Read all the instructions before setting up your tent.
Check parts list to ensure you have full contents.
• Find a flat area for your tent, free from rocks, potholes
and branches.
• Ensure that you use all pegs, ropes and additional poles only
as instructed.
• If conditions are windy, arrange tent to have narrowest
side of tent facing into the wind.
• Keep away from open flames, DO NOT USE stoves
or burning appliances inside the tent.
STORAGE
• To maximise the life of your tent, always ensure it is clean of
dirt and debris.
• Never store if wet or damp. Consider airing your tent at home
after your trip and allow to completely dry before storing
between trips.
• Continued exposure to sunlight can degrade the polyesters
used to make tents. Always store your tent in its storage bag,
away from direct light in a cool, dry space.
CONTENTS
• Inner Tent x 1
• Rain Fly x 1
• Awning Poles x 2
• Pegs x 18
• Guy Ropes x 14
WARRANTY - For details see www.oztrail.com.au/warranty
SEE OTHER SIDE FOR PITCHING INSTRUCTIONS
Steel Awning Pole x 2:
OZtrail
®
is a registered trademark of
Adventure Trading Australia Pty Ltd
Adventure Trading Australia Pty Ltd
71 Charles Ulm Place,
Eagle Farm, QLD 4009
AUSTRALIA
Made in Bangladesh
Designed & Imported by:
Designed & Imported by:

STEP 2: ERECT THE INNER TENT FRAME
STEP 4: SECURE FLY TO INNER TENT
STEP 6: ALWAYS PEG OUT AND USE
GUY ROPES
STITCH LINE
TENT OWNERS MANUAL
FAST FR AME 3 P ER S ON
STEP 1: LAYOUT THE INNER TENT
STEP 3: PUT ON THE FLY
• Unfold the inner tent and outstretch over a flat, clear area
• Arrange the door so it is facing your desired area for entry & exit
• Place rain fly over the inner tent
• Secure rain fly to tent with Velcro tabs located on underside
of rain fly
• Connect the fly to the tent using the buckles on the tent
corners
• Locate the lower leg section of the frame
• Raise to near vertical orientation
• Extend middle roof pole until the locking button clicks into the
locked position
• Extend the leg section until the locking button clicks into the
locked position, repeat on other legs
STEP 5: ASSEMBLE THE AWNINGS
PACK UP:
TO TAKE DOWN THE TENT, REVERSE THE PREVIOUS STEPS
• Use the awning poles and additional ropes to suspend the door
panels overhead
• Peg out the tent and fly around the perimeter
• In windy and rainy conditions, awnings must be
dismantled, and doors must be closed, and guy ropes
must be set out
