OZtrail LUMOS User manual

WARNING
AVOID CONTACT WITH OPEN FLAMES:
This tent is manufactured to meet CPAI-84 Fire Retardant
standards. The fabric may burn if in continuous contact with
open flame sources.
CONDENSATION IS NOT LEAKING:
Minimise condensation by ensuring your tent is well
ventilated through windows, doors or vents.
STITCH LINE
TENT OWNERS MANUAL
LUMOS FAST FRAME 12 PERSON
BEFORE YOU BEGIN
• This tent requires a minimum of two people to set up
• Read all the instructions before setting up your tent.
Check parts list to ensure you have full contents
• Find a Flat area for your tent, free from rocks, potholes
and branches
• Ensure that you use all pegs, ropes and additional poles only
as instructed
• If conditions are windy, arrange tent as to have narrowest
side of tent facing into the wind
• Keep away from Open Flames, DO NOT USE Stoves
or Burning Appliances inside the tent
CONTENTS
• Inner Tent x 1
• Rain fly x 1
• DuraPlus Vestibule Pole x 1
• Steel Portico Pole: x 2
• Awning poles x 10
• Pegs x 57
• Guy Ropes x 10
• 4 D-Cell Battery Box x 1
(Batteries not Included)
WARRANTY - For details see www.oztrail.com.au/warranty OZtrail
®
is a registered trademark of
Adventure Trading Australia Pty Ltd
Made in Bangladesh
STORAGE
• To maximise the life of your tent, always ensure it is clean of dirt
and debris.
• Never store if wet or damp. Consider airing your tent at home after
your trip and allow to completely dry before storing between trips
• Continued exposure to sunlight can degrade the polyesters used
to make tents. Always store your tent in its storage bag, away from
direct light in a cool, dry space
• Remove D-Cell batteries from battery box prior to storing
DuraPlus Vestibule Pole x 1:
Steel Awning Pole x 10:
Steel Portico Pole x 2:
Operating the Lumos LED Lighting System:
Slide battery pack into
pocket located inside
the tent.
Add 4-D batteries to
empty battery pack.
(Batteries not included)
Zip up pouch, then plug
in battery pack cord
into lighting connector.
CABIN
NIGHT
LIGHT
Press buttons
on switch box
located on
either inside
or outside of
tent to turn on
lighting.
Alternatively: Lumos System can run from a rechargable battery pack, Not Exceeding 5V, 1A output
Note: Nightlight mode may not operate if your rechargeable power pack incorporates an ‘auto-off’
function due to its low draw. For optimal operation we always recommend using D cell Alkaline Batteries.

STEP 2: RAISE THE ROOF
STEP 4: SECURE FLY TO INNER TENT
STEP 6: ALWAYS PEG OUT AND USE
GUY ROPES
STITCH LINE
TENT OWNERS MANUAL
LUMOS FAST FRAME 12 PERSON
STEP 1: LAYOUT THE INNER TENT
STEP 3: ERECT THE TENT
• Unfold the inner tent and outstretch over a flat, clear area
• Arrange the door so it is facing your desired area for entry & exit
• Fold leg poles away from the center of the tent, so the roof
framing stands up
• Extend the vertical frame legs until they click into position
• Repeat on the legs in the center and other corners of the tent
• Install Front Vestibule Pole by placing through sleeve located above the
door on Front of the screen room front
• Insert Vestibule pole into black plastic molding
• Insert Steel Portico Pole into opposite side of black molding
• Connect base of Portico Pole to ring and pin on Grey Webbing stitched
to Inner tent corner
• Secure rain fly to tent with Velcro tabs located on underside
of rain fly
• Connect the fly to the tent using red and grey buckles on
tent corners
• Locate roof poles and lift upwards from base, to the
horizontal position.
• The leg poles will angle at joints and partially stand up
• BEFORE raising the legs:
Lengthen the roof poles by extending Horizontally until
they Click into Place
STEP 5: ASSEMBLE THE AWNINGS
• Use the awning poles and additional ropes to suspending the
door panel overhead
• Peg out the tent and fly around the perimeter
• In windy and rainy conditions, awnings must be
dismantled, and doors must be closed, and guy ropes
must be set out
PACK UP: REMEMBER TO REMOVE BATTERY BOX PRIOR TO PACKING
TO TAKE DOWN THE TENT, REVERSE PREVIOUS STEPS
REMEMBER TO COMPLETELY LOWER LEGS BEFORE COLLAPSING HORIZONTAL ROOF POLES
AUSTRALIA
Designed & Imported by: Adventure Trading Australia Pty Ltd 71 Charles Ulm Place, Eagle Farm, QLD 4009
Roof P
ole
Legs
CLICK
CLICK
