INSTRUCTION AND PARTS LIST A-C3F-C/ A-C3R-C 6/5/2019
A-C3F-4-10C/-0-9C
A-C3R-4-6C/2-5C
Automatic Spray Guns
OPERATING INSTRUCTIONS & REPLACEMENT PARTS
DESCRIPTION:The Automatic Spray Gun is an actuated
production spray gun, it includes a Carbide Inserted Tip with
Stainless Body and Stainless Steel needle with Carbide point for
abrasive material.See Page 2 for spray head options.
CONNECTIONS: Spray Gun has the following: Air inlet 1/4”
N.P.T (F) and Fluid inlet 3/8” N.P.T. (M).
PACKING WASHERS: Packings are available in PTFE for
natural lubricity and higher temperatures. See Page 2.
1. Mount Spray Gun in desired position.
2. Blow out all hoses (airlines) before connecting to Spray Gun
to remove foreign particles.
3. Connect hose from air supply to air inlet fitting.
4. Connect fluid supply to fluid inlet.
5. Tighten all hose connections securely.
6. Adjust air pressure to desired amount at the Air Regulator.
7. Adjust Fluid volume by turning the Fluid Adjusting Knob to
the left or right. Note: Do not use as shutoff by turning
all the way down, it may split the tip.
8. Adjust to proper fan pattern by turning the Fan Control
Screw to left or right.
TIP REPLACEMENT:
1. Turn off Air and Fluid Pressure.
2. Release Fluid Needle pressure from seat of Tip by taking off
the Cylinder Cap Assembly.
3. Loosen Aircap Nut and remove Multiplehead Assembly.
Leave Needle in place.
4. Unscrew Tip and place new Tip in position.
5. To reassemble reverse above procedure.
MAINTENANCE: Requirements of the Automatic Spray Gun
have been reduced to a minimum.(Old packing washers cause
leakage of air and Fluid). PTFE Packings are self-lubricating.
CLEANING: After each use flush clean solvent through the
fluid passages of the Spray Gun and Wipe off the outside with
clean solvent. Never leave the entire Spray Gun immersed in
solvent. Dirty Aircaps and Tips should be cleaned by soaking in
solvent and blown clean with air.
TROUBLE SHOOTING SPRAY PATTERNS:
(A) A ROUGH OR STIPPLED FINISH is caused by low or
restricted flow of air pressure or too heavy materials being
applied with gun too close to surface.
(B) A WET OR SAGGING FINISH is due to low air pressure
or restricted flow of air, material being too thin, or applied
too close to the surface.
(C) A SPUTTERING SPRAY is caused by air leaking into fluid
line or can be caused by a loose fluid tip, a broken or split
tip, lumpy material, a clogged vent hole in cover of material
cup, or air leak at fluid pipe attached to inside of tank cover,
or a clogged paint strainer. Sputtering may also be caused
by worn packing washers, or worn or scored needle.
TO CORRECT: Tighten tip securely or replace. Strain
material and clean strainer. Tighten fluid pipe in tank or
replace packings and needle in Spray Gun.
(D) AN ARCHED FAN SPRAY PATTERN is caused by dried
material accumulated in one fan port of the multiplehead,
distorting the pattern.
TO CORRECT: Dissolve material inside fan port with
suitable solvent applied with a small brush.
NOTE: Never use wire or sharp instruments to clean
Fan Ports as permanent damage to the fan ports will
result in destroying uniformity of the Fan Pattern.
(E) UNBALANCED FAN SPRAY PATTERN, heavy on one
side, may be caused by material collecting around outside
of the fluid tip and aircap, or by a loose aircap.
TO CORRECT: Remove aircap and clean fluid tip and
aircap with solvent then dry with air. Always be sure fan
aircap and aircap body are tightened securely.
(F) A HEAVY CENTER in a fan pattern is caused by
insufficient air pressure at the fan port. Rough or shady
edges are also caused by low air pressure.
TO CORRECT: Increase air line pressure.
(G) A SPLIT FAN SPRAY PATTERN, heavy on each end and
light in the center, is caused by excessive air pressure.
TO CORRECT: Reduce air pressure.
WARNING: Spray materials may be harmful if inhaled or
allowed to come into contact with the skin or eyes. Consult
the product label and Material Safety Data Sheet supplied
for the spray material. Follow all safety precautions.
CAUTION: Well Ventilated Area Required to remove
fumes, dust or overspray. Secure airhose and fluid
hose wrench tight for safety and to prevent leaks.
M a x i m u m A i r P r e s s u r e 1 0 0 P . S . I .
M a x i m u m F l u i d P r e s s u r e 4 5 P . S . I .
Paasche Airbrush Company
9511 58th Place
Kenosha, WI 53144
Phone: [phone]
Website: paascheairbrush.com
E-Mail: [email protected] Printed in the U.S.A.
OPERATION:

FAN PATTERN
• Application: Standard Spray
• Sizes: 0-9(.55), or 4-10(.93)
• Fluid Viscosity: Light to Medium (4 to 12 C.F.M. @40 or 50 P.S.I.)
1. 56CAFA-
2. U-3663
3. U-1649
4. U-C
5. A-U- 4L
Sleeve PTFE
Aircap Nut
Stainless Body with Carbide Tip Insert (Select Size above)
Stainless Needle
ROUND PATTERN
• Application: Standard Spray
• Sizes: 2-5(.73) & 4-6(.93)
• Fluid Viscosity: Light to Medium (3 to 6 C.F.M. @ 40 P.S.I.)
1. 56CRA-
2. U-3707
3. U-1649
4. U-C
5. A-U- 4L
Aircap Body (Select Size above)
Page 2
6.
7.
9.
10.
11.
12. 6. 13. 14. 15.
16.
WARNING: Do not use Knob as a shut-off
by turning all the way down - it will split the tip.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
A-UC-4L Stainless Steel Needle
U-3651 Fan Control Screw
(Includes O-Ring)
3A-4 O-Ring (1) (6 Pack)
C-41 Fluid Body
U-3502 Packing Set
U-3633 Large "O" Ring
U-3632 Small "O" Ring
U-1907B Shell
U-2966 Piston Spring
U-3656 PTFE Piston
U-2686A Cylinder Cap Assembly
Aircap Body (Select Size above)
Sleeve PTFE
Aircap Nut
Stainless Body with Carbide Tip insert (Select Size above)
Stainless Needle with Carbide point
8.

UM-20
MOUNTING ASSEMBLY
HL-3/16-10
AIR HOSE
HA-1/4-10
FLUID HOSE
page3
OPTIONAL ACCESSORIES

& 
  
 
     
   
    
    

  


 
     
  
    
 
   
  
 

 


   
 
    
     
  
 
      
      


   
    
