BELMONT
120/240 ASSEMBLY & INSTALLATION INSTRUCTIONS
[e-mail]
888 MARIN STREET
SAN FRANCISCO, CA
94124
PABLODESIGNS.COM
PABLODESIGNS.EU

pg. 2
CEILING MOUNT
120/240 ASSEMBLY INSTRUCTIONS
BELMONT
1. (US) ATTACH MOUNTING PLATE TO JUNCTION BOX
(EU) ATTACH MOUNTING PLATE TO CEILING
2. SLIDE CORDS THROUGH LENS COVER AND SNAP IN
PLACE. MAKE SURE TEXTURED SIDE FACES OUT.
3. SLIDE CORD THROUGH WOOD CANOPY COVER AND REST
COVER ON LAMP.
4. LOOSEN SET SCREWS ON STRAIN RELIEFS.
5. SLIDE CORD THROUGH STRAIN RELIEFS.
CUT CORD TO LENGTH LEAVING AN EXTRA 6-8 IN.
(16-20CM)
US
EU
IMPORTANT: WE RECOMMEND CEILING MOUNTING
BE INSTALLED BY AN ELECTRICIAN
LENGTH OF CORD SUPPLIED
10FT (305CM)
2
4
5
21
3
NOTE: MAKE SURE TEXTURED SIDE OF
LENS COVER FACES OUT

PURPLE
GREY
pg. 3
CEILING MOUNT
120/240 ASSEMBLY INSTRUCTIONS
BELMONT
6
7
89
10
BLACK
RED
6. WIRE POWER CORD TO TRANSFORMER:
(US: BLUE TO BLACK AND RED TO RED) (EU: RED TO RED
AND BACK TO BLACK)
NOTE: PURPLE AND GREY CORDS ARE USED ONLY
WITH 0-10 V DIMMER SWITCH.
7. WIRE TRANSFORMER TO JUNCTION BOX:
(US: BLACK TO BLACK AND WHITE TO WHITE)
(EU: BLUE TO BLACK AND BROWN TO RED)
8. SCREW CANOPY TO MOUNTING PLATE
9. LEVEL THE LIGHT BY ADJUSTING THE CORDS
(THE USE OF A LEVEL IS RECOMMENDED)
10. TIGHTEN SET SCREW.

11
12
120/240 ASSEMBLY INSTRUCTIONS
BELMONT
LIGHT – WIPE WITH A CLEAN, DRY CLOTH.
SHADE – TO REMOVE DUST AND SMALL DEBRIS: CLEAN WITH A SOFT HAIR BRUSH OR USE A VACUUM.
TO REMOVE OTHER SUBSTANCES: USE A DAMP CLOTH AND IF NEEDED A MILD DETERGENT.
pg. 4
SLIDE WOODEN COVER UP TO
CANOPY. COVER WILL
ATTACH MAGNETICALLY.
INSERT BOTTOM LENS
VERTICALLY. ONCE INSIDE,
SPIN UNTIL THE TEXTURED
SIDE IS DOWN AND DROP
INTO PLACE MAKING SURE IT
NESTS PROPERLY.
BULB TYPE
LED PANEL
FULL RANGE LIGHT CONTROL VIA
120V DIMMER (US)
OR ELV DIMMER (EU)
BULB REPLACEMENT
CONTACT MANUFACTURER FOR
BULB REPLACEMENT
