Pablo BOLA DISC Programming manual

pg. 1
BOLA
DISC / FELT
120/240V ASSEMBLY & INSTALLATION INSTRUCTIONS
[e-mail]
888 MARIN STREET
SAN FRANCISCO, CA
94124
PABLODESIGNS.COM

pg. 2
120/240V ASSEMBLY INSTRUCTIONS
BOLA CANOPY
1. ATTACH MOUNTING PLATE TO JUNCTION BOX OR CEILING
2. WIRE TRANSFORMER TO BUILDING
(US: BLACK TO BLACK AND WHITE TO WHITE)
( EU: BLUE TO BLACK AND BROWN TO RED)
3. CUT CORD TO DESIRED LENGTH AND PASS THROUGH
CANOPY. WIRE TRANSFORMER TO LAMP
(US: BLUE TO BRAIDED AND RED TO RED)
(EU: BLACK TO BRAIDED AND RED TO RED)
4. TIGHTEN SET SCREWS ON CORD RELIEF
5. BRING CANOPY UP TO MOUNTING PLATE WITH BOLTS
PASSING THROUGH THE HOLES
6. SCREW BOTH CAPS DOWN, SECURING THE CANOPY
IMPORTANT: WE RECOMMEND CEILING MOUNTING
BE INSTALLED BY AN ELECTRICIAN
LENGTH OF CORD SUPPLIED
10FT (305 CM)
2
3
4
6
5
21
RED

pg. 3
120/240V ASSEMBLY INSTRUCTIONS
BOLA DISC
NOTE: DISC COMES WRAPPED IN PROTECTIVE SLEEVE.
LEAVE SLEEVE ATTACHED UNTIL LAMP IS FULLY ASSEMBLED
USE PROVIDED GLOVES WHEN HANDLING LAMP.
HOLD HEAT SINK AGAINST DISC AND
SCREW STEM ONTO STATIONARY HEAT SINK
CAPTURING DISC.
CAREFULLY SCREW GLOBE TO HEAT SINK.
TEAR PROTECTIVE SLEEVE OFF OF DISC.
2
3
21
CARE:
WIPE WITH A DRY CLEAN CLOTH.
BULB TYPE
LED
FULL RANGE LIGHT CONTROL VIA
120V DIMMER (US)
OR ELV DIMMER (EU)
BULB REPLACEMENT
CONTACT MANUFACTURER FOR BULB
REPLACEMENT
LENGTH OF CORD SUPPLIED
10FT (305CM)

pg. 4
FELT
120/240V ASSEMBLY INSTRUCTIONS
BOLA FELT
SCREW STEM AND HEAT SINK TOGETHER
MOVE FELT SHADE
CAREFULLY SCREW GLOBE TO LED HEAD.
2
3
21
LIGHT – WIPE WITH A DRY CLEAN CLOTH.
SHADE – TO REMOVE DUST AND SMALL DEBRIS: CLEAN WITH A SOFT HAIR BRUSH OR USE A VACUUM.
TO REMOVE OTHER SUBSTANCES: USE A DAMP CLOTH AND IF NEEDED A MILD DETERGENT.
