Pace TD-100 User manual

Operation and Maintenance Manual for the TD-100
and MT-100 Handpieces
P/N 5050-0532

©2003 PACE Inc., Annapolis Junction, Maryland Page 2 of 12
All Rights Reserved
TITLE PAGE
Safety Guidelines...........................................................................................................3
Handpiece Connection...................................................................................................3
Tip Cartridge Installation................................................................................................3
Accessory and Replacement Parts................................................................................4
Tips.................................................................................................................................5
Corrective Maintenance................................................................................................10
Service ..........................................................................................................................10
PACE WORLDWIDE LIMITED WARRANTY STATEMENT.........................................11
Contact Information.......................................................................................................12

©2003 PACE Inc., Annapolis Junction, Maryland Page 3 of 12
All Rights Reserved
Safety Guidelines
The following are safety precautions that personnel must understand and follow when using or servicing
this product.
1. POTENTIAL SHOCK HAZARD - Repair procedures on PACE products should be performed
by Qualified Service Personnel only. Line voltage parts may be exposed when the
equipment is disassembled. Service personnel must avoid contact with these parts when
troubleshooting the product.
2. To prevent personnel injury, adhere to safety guidelines in accordance with OSHA and other
applicable safety standards.
3. Heater Cartridge Tips are hot when the handpiece is powered on and for a period of time
after power off. DO NOT touch the cartridge. Severe burns may result.
4. PACE Tip & Tool Stands and handpiece cubbies are designed specifically for use with the
associated handpiece and houses it in a manner that protects the user from accidental burns.
Always store the handpiece in its holder. Be sure to place the handpiece in its holder after
use and allow for cooling before storing.
5. Always use PACE systems in a well ventilated area. A fume extraction system such as those
available from PACE are highly recommended to help protect personnel from solder flux
fumes.
6. Exercise proper precautions when using chemicals (e.g., solder paste). Refer to the Material
Safety Data Sheet (MSDS) supplied with each chemical and adhere to all safety precautions
recommended by the manufacturer.
Handpiece Connection
Connect the handpiece connector plug into the Power Receptacle in the following
manner.
1. Align guide on the connector with slot on power receptacle.
2. Insert connector into power receptacle.
3. Turn the connector housing clockwise to lock in place.
Tip Cartridge Installation
Both TD-100 and MT-100 tip cartridges are fitted with a key lock device. This feature ensures that tip
cartridges are held firmly in position and will maintain their orientation. MT-100 tip cartridges CANNOT be
fully inserted into the TD-100 and TD-100 tip cartridges CANNOT be fully inserted into the MT-100. To
install a tip cartridge, please follow the procedure below.
1. Line up the key lock feature on the tip cartridge with the notch on the front
of the handpiece.
2. Push the tip cartridge all the way into the handpiece.
To remove a tip cartridge, use the included hot grip removal pad to grasp the tip cartridge and pull
the tip cartridge out of the handpiece. Be careful when completing this procedure as the tip cartridge
may be hot and direct contact can cause injury.

©2003 PACE Inc., Annapolis Junction, Maryland Page 4 of 12
All Rights Reserved
Tips
cartridges can be changed at any time and without turning off the power to the unit.
Accessory and Replacement Parts
Description PACE Part Number
Tip Case – Holds 10 Tips
(Tips not included)
1310-0034-P1
Tip Stand – Allows for an
additional 10 tips to be
stored on the tool stand.
(Shown with TD-100 Tool
Stand, tips not included)
1321-0639-P1
TD-100 Handpiece (Tip
cartridge not included) 6010-0132-P1
Replacement TD-100 cord
assembly
3008-0131-P1
Replacement O-rings for
TD-100. Package of 5.
1213-0090-P5
TD-100 Tool Stand (TD-100
Handpiece and tips not
included)
1257-0258-P1
MT-100 Handpiece (Tips
not included)
6010-0140-P1
MT-100 Tool Stand 6019-0069-P1
Hot Grip Removal Pad 1100-0307-P1

©2003 PACE Inc., Annapolis Junction, Maryland Page 5 of 12
All Rights Reserved
Available Tips
A wide variety of tip cartridges are available for use with the TD-100 and the MT-100 Handpieces. Please
refer to the table below for available tip cartridge styles.
PACE P/N Description
1124-0001-P1 1/32" Conical Sharp Extended
1124-0002-P1 1/64" Conical Sharp
1124-0003-P1 1/64" Conical Sharp Bent 30 Degrees
1124-0004-P1 1/64" Conical Sharp Extended
1124-0005-P1 1/32" Conical
1124-0006-P1 3/128" Conical
1124-0007-P1 1/16" 90 Degree Chisel
1124-0008-P1 3/64" 30 Degree Chisel
1124-0009-P1 3/64" 30 Degree Bevel
1124-0010-P1 13/64" Chisel
1124-0011-P1 1/64" 60 Degree Bevel
1124-0012-P1 1/32" 30 Degree Chisel
1124-0013-P1 3/32" 30 Degree Chisel
1124-0014-P1 5/64" 60 Degree Bevel
1124-0015-P1 1/64" Conical, Sharp, Bent 30 Degrees,
Extended
1124-0016-P1 3/64" Chisel Bent 30 Degrees
1124-0017-P1 1/16" 60 Degree Chisel
1124-0018-P1 1/32" Conical Sharp Extended

©2003 PACE Inc., Annapolis Junction, Maryland Page 6 of 12
All Rights Reserved
1124-0019-P1 1/16" 30 Degree Chisel
1124-0020-P1 1/8" 90 Degree Chisel
1124-0021-P1 3/128" Conical Sharp Bent 30 Degrees
1124-0022-P1 1/16" Conical Sharp
1124-0023-P1 1/8" 90 Degree Chisel Extended
1124-0024-P1 1/16" 30 Degree Bevel
1124-0025-P1 1/16" Conical Sharp Extended
1124-0026-P1 1/16" Chisel Bent 30 Degrees
1124-0027-P1 3/128" Conical Sharp, Extended
1124-0028-P1 3/64" Chisel, Bent 30 Degrees, Extended
1124-0029-P1 1/32" 30 Degree Bevel
1124-0030-P1 1/32" Conical Sharp
1124-0031-P1 Heat Staking
1124-0032-P1 MiniWave
1124-0033-P1 Angled MiniWave, 3.3 mm
1124-0034-P1 Single Sided Chisel
1124-0035-P1 Angled MiniWave, 2.4mm
1124-0036-P1 1/128" Conical
1124-0037-P1 1/4 Flat Blade
1124-0038-P1 Single Sided Chisel, Fine Pitch

©2003 PACE Inc., Annapolis Junction, Maryland Page 7 of 12
All Rights Reserved
1124-0039-P1 Angled MiniWave, Fine Pitch
1124-0040-P1 MicroFine Single Sided Chisel, 0.9mm
(.035”)
1124-0041-P1 MicroFine Single Sided Chisel, 1.1mm
(.045”)
1124-0042-P1 MicroFine Conical, 0.25mm (.01”)
1124-0043-P1 MicroFine Bent Conical, 0.75mm (.03”)
1124-0044-P1 MicroFine Bent Conical, 0.5mm (.02”)
1124-0045-P1 Angled Micro-Wave Tip
1124-0046-P1 Micro-Wave Tip
Surface Mount Removal Tips for TD-100 Soldering Iron
Component
Type Dimension A Dimension B Part Number
Chip 402
Angle 2.2mm (.085”) 1124-0518-P1
Chip 1808 5mm (.195”) 1124-0520-P1
Chip 402 1mm (.04”) 1124-0521-P1
SOT 23 1.8mm (.07”) 1124-0522-P1
SOT 89 2.8mm (.11”) 1124-0523-P1
Chip 1206 3.6mm (.142”) 1124-0524-P1

©2003 PACE Inc., Annapolis Junction, Maryland Page 8 of 12
All Rights Reserved
Chip 0805 2.4mm (.095”) 1124-0525-P1
SOIC 14/16 5.2mm (.205”) 10.5mm (.415”) 1124-0504-P1
SOIC 20 9.6mm (.377) 13.6mm (.535”) 1124-0505-P1
SOP 28 10.8mm (.426”) 18.6mm (.734”) 1124-0506-P1
SOP 40 11.9mm (.467”) 25.7mm (1.01”) 1124-0507-P1
SOP 44 13.1mm (.516”) 28.4mm (1.12”) 1124-0508-P1
TSOP 56 18.8mm (.739”) 14.1mm (.557”) 1124-0509-P1
TSOP 28 12mm (.471”) 8.5mm (.333”) 1124-0510-P1
SOIC 8 5.1mm (.202) 4.65mm (.183”) 1124-0519-P1
TSOP 40 18.8mm (.74”) 10.4mm (.410) 1124-0526-P1
PLCC 28
Socket 9.3mm (.365”) 9.3mm (.365”) 1124-0511-P1
PLCC 32 14.2mm (.561”) 11.7mm (.459”) 1124-0512-P1
PLCC 44 16.8mm (.662”) 16.8mm (.662”) 1124-0513-P1
QFP 144 20.6mm (.81”) 20.6mm (.810”) 1124-0514-P1
PLCC 28 11.8mm (.465”) 11.8mm (.465”) 1124-0515-P1
QFP 100/128 22mm (.865”) 16mm (.628”) 1124-0516-P1
PLCC 20 9.3mm (.365”) 9.3mm (.365”) 1124-0527-P1
PLCC 18 7.6mm (.3”) 12.8mm (.505”) 1124-0528-P1
TQFP 80 12.5mm (.491”) 12.5mm (.491”) 1124-0529-P1
PLCC 52 19.4mm (.762”) 19.4mm (.762”) 1124-0530-P1
QFP 80/100 26.6mm (1.05”) 26.6mm (1.05”) 1124-0531-P1
Blade 10.8mm (.425”) 1124-0501-P1
Blade 16mm (.630”) 1124-0502-P1
Blade 21.2mm (.835”) 1124-0503-P1
Blade 25MM (.984”) 1124-0532-P1
Surface Mount Removal Tips for MT-100 MiniTweez
PACE P/N Description
1124-1001-P1 Chip
0.2mm (.008”)
1124-1002-P1 Chip
0.5mm (.02”)

©2003 PACE Inc., Annapolis Junction, Maryland Page 9 of 12
All Rights Reserved
1124-1003-P1 Chip
1mm (.04”)
1124-1004-P1 Chip
2mm (.08”)
1124-1005-P1 SOP 6
6mm (.24”)
1124-1006-P1 SOP 8
8mm (.31”)
1124-1007-P1 SOP 10
10 mm (.39”)
1124-1008-P1 SOP 13
13mm (.51”)

©2003 PACE Inc., Annapolis Junction, Maryland Page 10 of 12
All Rights Reserved
Corrective Maintenance
The TD 100 handpiece features a replaceable O-ring that protects
the contact area from flux fume and other contamination. The O-
ring may need to be replaced over time. To replace the O-ring
follow the procedure below:
1. Disconnect the TD 100 from the power source
2. Remove the tip cartridge
3. Unscrew the cap from the back of the TD 100
4. Slide the connector assembly out of the handle
5. Remove and replace the old O-ring from the connector
assembly (Old “O-ring” may remain in handle)
6. Reinstall the connector assembly. Be sure to line up the
keyways on the handle and connector assembly. Do not
force the connector assembly into the handle.
7. Reinstall the cap and make sure it is fully seated against
the handle
8. Install a tip cartridge
The O-rings on the MT-100 do not need to be replaced.
Handpiece Troubleshooting
Most malfunctions are simple and easy to correct. Refer to Table 3.
Symptom Probable Cause Solution
Defective Heater Change Tip CartridgeHandpiece will
not heat Power Source
Malfunction Contact PACE
Table 3: Troubleshooting
Service
Please contact PACE or your local distributor for service and repair.
O-ring
Tip Cartridge
End Cap

©2003 PACE Inc., Annapolis Junction, Maryland Page 12 of 12
All Rights Reserved
PACE Incorporated retains the right to make changes to specifications contained herein at any time,
without notice. Contact your local authorized PACE Distributor or PACE Incorporated to obtain the latest
specifications.
The following are trademarks and/or service marks of PACE, Incorporated, MD, USA:
INSTACAL™, FUMEFLO™, HEATWISE™, PACEWORLDWIDE™, PERMAGROUND™,
POWERPORT™, POWERMODULE™, TEMPWISE™, TIP-BRITE™, AUTO-OFF™,and
TEKLINK™.
The following are registered trademarks and/or service marks of PACE Incorporated, Annapolis Junction
Maryland U.S.A.
ARM-EVAC®, FLO-D-SODR®, MINIWAVE®, PACE®, SENSATEMP®, SNAP-VAC®,
SODRTEK®, SODR-X-TRACTOR®, THERMOFLO®, THERMOJET®, THERMOTWEEZ®,
VISIFILTER®, THERMO-DRIVE®, and TOOLNET®.
PACE products meet or exceed all applicable military and civilian EOS/ESD, temperature stability and
other specifications including MIL STD 2000, ANSI/JSTD 001, IPC7711, and IPC A-610.
Additional copies of this manual or other PACE literature may be obtained from:
www.paceworldwide.com
