PACIFIC CYCLE KID Trax KT1555WM User manual

WARNING!
This manual contains important safety
and use informaon. Keep this manual for
future reference.
• An adult must read this enre manual
• Adult supervision is required at
all mes
TODDLER QUAD
KT1555WM, KT1556WM, KT1557WM
Age: 18 - 30 months
Weight: Maximum, 44 lbs (20 KG)
Speed: 2 MPH
Baery: 6 volt
Body style, seat lock, color,
and license may vary.

2
-- WARNING
Safety
1
FAILURE TO FOLLOW THE SAFETY INSTRUCTIONS LISTED BELOW MAY RESULT IN SERIOUS INJURY OR DEATH. The owner’s manual
contains assembly, use and maintenance instrucons.
Child Safety Warnings
• Adults supervising children must read and understand this enre
manual before allowing any child to use this product.
• Adults must evaluate their own children as to maturity, strength,
judgment and ability to follow safety rules. Published age
guidelines are not a substute for careful evaluaon of your own
child.
• Adults must teach children about thinking ahead while riding as
this may be the rst me a child has ever controlled a motorized
ride-on toy. While you supervise, see through the child’s eyes,
and verbally teach them about steering and avoiding obstacles in
the approved riding area.
• Riding a motorized ride-on toy toy can be a dangerous acvity,
even under the best of circumstances. Good choices regarding
where and when to ride, constant adult supervision of riding,
and pracce and careful riding by the child can all help to
minimize risk. However this ride-on toy is intended to move and
therefore it is possible to lose control, fall o and/or get into
dangerous situaons that no amount of care, instrucon or
experse can eliminate.
• If this inherent risk is not acceptable, adults should not allow
children to ride this ride-on toy.

3
--
Safe Riding Warnings
Before using the ride-on toy the child should understand the
controls and safety issues. They must also demonstrate the
capability to handle the ride-on toy and operate its controls. It is
the responsibility of the adult to educate the child and supervise
the use. Explain the following safety warnings to any child using
the ride-on toy before riding.
• Adults must teach their children not to allow other children to
use this ride-on toy. Adults must communicate this message to
the adult supervisors of friends and neighbors who have
children that play with your children.
• Never leave child unaended. Connuous adult supervision
required.
• Body parts such as hands, legs, hair and clothing can get caught
in moving parts. Never place a body part near a moving part or
wear loose clothing while using the ride-on toy.
• Always wear shoes when using the ride-on toy.
• Not to be used by children from 18 - 30 months of age.
• Do not exceed the maximum weight capacity of 44 lbs.
• Children must not have access to the charging equipment or
touch any part of the ride-on toy while it is charging.
• Always use common sense and safe pracces when using the
ride-on toy.
• Never use the ride-on toy in an unsafe manner. Examples
include but are not limited to:
• Pulling the ride-on toy with another ride-on or similar
moving product
• Allowing more than one rider
• Pushing the user from the back
• Traveling at an unsafe speed
• Any kind of stunt riding or other more risky use
• Going over jumps or other type of ramps
• Not riding in a seated posion
• Not riding with the baery or other covers fully closed
• ADULTS MUST SET UP PHYSICAL BARRIERS, SUCH AS GATES OR
FENCES, TO KEEP CHILDREN AWAY FROM HAZARDOUS AREAS.
• Always use the ride-on toy in a safe, secure environment with
connuous adult supervision.
• This ride-on toy does not have brakes or any braking capability.
Do not leave a child unaended while using this ride-on toy or
allow use of this ride-on toy in any locaon that requires
braking capability, as this could result in a roll away or loss of
control, which may cause serious injury or death.
• Do not ride in wet condions such as rain and snow. Doing so
may result in unexpected acon such as p over and skidding,
as well as damage to the electrical system and baery.
WARNING

4
----
Baery and Charging Warnings
The following safety hazards may result in serious injury or
death to the user of the ride-on:
Corrosive Material Warnings
• Baery posts, terminals and related accessories contain lead
and lead compounds (acids) chemicals and are toxic and
corrosive. Never open the baery.
• Contact or exposure to baery leakage (lead acid) may cause
serious injury. If contact or exposure occurs with the skin or in
the eyes, or if the chemical is swallowed, immediately call 911.
Safe Riding Warnings (connued)
• Do not ride near swimming pools or other bodies of water.
• Do not ride on roads, streets, near other ride-on toys or where
other types of moving objects are present.
• Do not ride at night or in condions of low visibility.
• Do not ride near drop-os such as steps, sloped surfaces
or hills.
• Do not ride into loose dirt, mud, sand, ne gravel, loose gravel
and rough surfaces.
• For best performance, ride-on at, hard surfaces.
• Never hitch (aach) on to another ride-on or pull anyone
or anything.
WARNING WARNING

5
--
Electric Shock / Fire Warnings
• Liquids on the baery may cause re or electric shock.
Always keep all liquids away from the baery and keep the
baery dry.
• Tampering or modifying the electric circuit system may cause a
shock, re or explosion and permanently damage the system.
Exposed wiring, circuitry in the charger may cause electric
shock. Always keep the charger housing closed.
• Regularly check charger, supply cord and connector for wear
and damage. Look for frayed or kinked wires, any exposed inner
wires, any missing insulaon. If any damage is observed do not
plug in the charger and do not charge
the baery.
WARNING
Flammable and Explosive Materials Warnings
• Use of a baery or charger other than the supplied rechargeable
baery and charger may cause a re or explosion. Only use the
supplied rechargeable baery and charger with the ride-on toy.
• Do not charge the baery near heat or ammable materials.
• Using the recharbeable baery and charger for any other
product many result in overheang, re or explosion. Never use
the rechargeable baery and charger with another product.
• Contact between the posive and negave terminals may result
in re or explosion. Avoid direct contact between the terminals.
Liing the baery by the wires or charger can cause damage to
the baery and may result in a re. Always li the baery by its
case or handles.
• Plug wall charger directly into a wall outlet. Do not use an
extension cord when charging as the use of an extension cord
can cause a re.
Baery and Charging Warnings (connued)

6
-- CAUTION
WARNING
If you are unsure of any informaon in this manual or have a queson regarding assembly or use please call customer service.
Always keep this manual for reference and include it with resale of the ride-on toy.
Re-Charge Interval and Time
Important!
• Damage to the baery may occur if it is allowed to drain
completely. Do not allow the baery to drain completely.
• Check the baery and charger (supply cord, connector) for
wear and damage before charging. Do not charge the baery if
damage has occurred. Do not use an extension cord when
charging the ride-on toy.
• On average you will need to charge the baery for 10 hours
and no more than 24 hours. Failure to charge the baery as
directed could cause permanent damage to the baery and
void the warranty.
• Only an adult who has read and understands the safety
warnings should handle, charge and recharge the baery.
Product Warning
WARNING
This product can expose you to chemicals including lead and
lead compounds, which is known to the State of California to
cause cancer, birth defects and other reproducve harm.
For more informaon go to www.P65Warnings.ca.gov.
Assembly Warnings
• The ride-on toy must be assembled by an adult who has read
and understands the instrucons in this manual.
• Choking hazard to children under the age of 3 years. This
ride-on toy contains small parts that are for adult assembly
only. Keep small children away when assembling.
• Remove and dispose of all protecve materials, plasc bags and
packaging before assembly.

7
PRE-RIDE SAFETY CHECKLIST
(To be performed by a supervising adult)
Before every ride, it is important to carry out the following
safety checks. Do not ride a baery powered ride-on toy that is
not in proper working condion! Replace any worn or broken parts
as needed.
Steering and Control
The steering wheel or handlebars are ghtened and secured in
the mount or dashboard.
The steering wheel or handlebars are posioned so that the
rider can easily operate and steer the ride-on. There must be
no diculty for the rider in turning and/or operang the
powered foot pedal or hand operated push buon.
The steering wheel or handlebars are aligned so that the
steering column and front wheels are oriented in the
same direcon.
Wheels
The wheels are securely aached to the baery powered
ride-on and the are in good condion. It is acceptable to have
slight lateral movement in each wheel.
The wheels have no holes or are worn down in any one area
and that the tracon strips are intact and secured to the
wheels.
The drive wheel is securely fastened to the gear box, which
houses the motor.
Ride-on
For all electrical components, make sure:
• The baery is fully charged
• The charging cord is NOT aached to the ride-on in
any way
• All connectors are securely snapped in place and will not
come detached while riding
• No wiring is exposed, worn, or detached in any way; the
motor is not hot to touch
• All electrical buons, including the power buon,
accelerator foot pedal or hand operated buon, and any
buons for lights and sounds, work properly
• If the ride-on’s electrical components show any sign of
damage or missing parts DO NOT RIDE unl the condion
is corrected
Make sure the ride-on is:
• Clean, dry, and in good condion
• All plasc pieces, including fenders, seat, footrests,
steering wheel or handlebars, wheels, bumpers, and/or
hub caps are securely aached
• There are no cracks or structural problems on the
ride-on toy
• If the ride-on toy shows any sign of damage or missing
parts DO NOT RIDE IT unl the condion is corrected
Make sure all safety labels are in place and readable, and
understood by the rider.

6Body style, seat lock, color, and license may vary.
Parts
2
Tool Required
Power Connecon
Assembly
3
❶

7
Body style, seat lock, color, and license may vary.
NOTICE
Charging the Baery
• A baery contains hazardous material that may cause serious
injury or death if handled, connected, or charged improperly.
Only an adult who has read and understands the warnings and
instrucons in this manual should handle, connect, or charge the
baery. Always contact Pacic Cycle at 1-877-741-6154 if you
have any quesons or concerns regarding handling, connecng,
or charging the baery.
• Charging the baery more than 24 hours could cause the baery
to explode or ignite resulng in serious injury, death or property
damage. Do not charge the baery for more than 24 hours.
Always disconnect the product from the charger aer the baery
is completely charged.
• A damaged supply cord, connector, or charger could cause burns
to the skin, an electrical re, serious injury, death, or property
damage. Always inspect the supply cord, connector, and charger
for damage. (e.g., frayed or kinked wires, exposed inner wires,
missing insulaon) before use. If damaged, do not use the supply
cord, connector or charger for any purpose and properly dispose
• Connecng the baery and baery charger to an extension
cord(s) could result in overheang, explosion, re, serious injury,
death, or property damage. Never charge the baery using an
extension cord. Always plug the charger directly into a wall
outlet.
• See addional baery and charging warnings on page 4.
• The baery may become damaged if allowed to drain
completely. Always keep the baery charged.
• The average me to charge the baery is between 10 and 12
hours. Failure to follow the instrucons regarding charging the
baery may result in permanent damage to the baery and void
the warranty.
WARNING

8Body style, seat lock, color, and license may vary.
24+
18 Charge the baery
for 18 hours
before rst use
Do not charge the
baery for more
than 24 hours
❸❷❺
❹
The product will not turn on while plugged into the charger.
Remove from charger prior to turning on.
TIP!
❻
❶

9
Body style, seat lock, color, and license may vary.
Use
4
Li nger o
buon to stop
Press the buon
to accelerate
Maximum Speed: 2 MPH
Note
Some toddler quads come with a light funcon. Light will operate
when the buon is pressed to accelerate.
Sound buon

10 Body style, seat lock, color, and license may vary.
Maintenance
5
❶
Baery Replacement and Disposal
The baery will eventually lose the ability to hold a charge.
Depending on the amount of use, and varying condions, the
baery should operate for one to three years. Follow the steps to
replace and dispose the baery that best represent the style of
baery compartment in your ride-on toy. Follow the instrucons
labeled Baery Removal: Compartment with Baery Cover for
ride-on toys that have a baery cover and Baery Removal:
Compartment with Baery Bar for ride-on toys that have a
baery bar.
Important! Recycle the dead baery responsibly. The baery
contains lead acid (electrolyte) and must be disposed of properly
and legally. It is illegal in most areas to incinerate lead acid baeries
or dispose of them in landlls. Take it to a federal or state-approved
lead acid baery recycler, such as an authorized service center or
your local automove baery retailer. Do not throw the baery
away with your regular household trash!
This ride-on toy contains a sealed lead acid NON
SPILLABLE BATTERY. This baery must be recycled.
Baery Removal: Compartment with Baery Cover

11
Body style, seat lock, color, and license may vary.
❸
❷
❶

12 Body style, seat lock, color, and license may vary.
❹
❺
❻
Baery Removal: Compartment with Baery Bar
❷
❶

13
Body style, seat lock, color, and license may vary.
❸
❹❺

14 Body style, seat lock, color, and license may vary.
The ride-on toy should be checked for damage, missing or badly
worn parts before each use.
• Check the ghtness of the fasteners before each use.
• Check the ghtness of the wheels before each use.
• Ensure the baery is securely in place before each use.
• Store the ride-on toy indoors or cover it with a tarp to protect it
from the wet weather. Keep it away from sources of heat, such
as stoves and heaters.
• Do not leave the vehicle in the sun for long periods of me or
fading may occur. Store in shade or cover with tarp.
• Do not wash the vehicle with a hose.
• Do not wash the vehicle with soap and water.
• Clean the vehicle with a so, dry cloth. To restore shine to plasc
parts, use a non-wax furniture polish. Do not use car wax, abrasive
cleaners or wash the vehicle with soap and water.
Water will damage the motor, electrical system and baery.
Note
❻

15
Body style, seat lock, color, and license may vary.
Service
6
Do not return this product to the place of purchase. If your ride-on
toy needs service, repairs or replacement parts, call:
Pacic Cycle Consumer Relaons
Hours: 8:00 am – 5:00 pm (CST) Monday - Friday
Phone: [phone]
Email: cus[email protected]
For a complete list of replacement parts, please contact
Pacic-Cycle Consumer Relaons. To order parts, please have the
model and serial number available, which can be found underneath
the seat on the baery cover.
FCC Statement
Any changes or modicaons to this unit not expressly approved by
the party responsible for compliance could void the user's authority
to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protecon
against harmful interference in a residenal installaon. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucons,
may cause harmful interference to radio communicaons.
However, there is no guarantee that interference will not occur in a
parcular installaon. If this equipment does cause harmful
interference to radio or television recepon, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This ride-on toy contains a sealed lead acid NON
SPILLABLE BATTERY. This baery must be recycled.

16 Body style, seat lock, color, and license may vary.
Warranty
7
90 Day Limited Warranty
Pacic Cycle, Inc. (PC) warrants this product to the original retail
purchaser as follows: The ride-on toy and baery is warraned
against defecve materials or workmanship for 90 days from the
date of original purchase. An original receipt is required to validate
your warranty. PC will, at its opon, provide replacement parts or
replace this product. PC reserves the right to substute if the part
or model has been disconnued. To make a claim under this
warranty you must contact us at www.kidtraxtoys.com; fax us at
1-800-858-2800, 24 hours a day; write to Kid Trax Consumer
Relaons Department, Kid Trax Toys, P.O. Box 344 Olney, IL 62450 or
call 1-877-741-6154 from 8 a.m. to 5 p.m., Monday through Friday,
CST. Proof of purchase is required, and shipping charges are the
responsibility of the consumer.
Warranty Limitaons
This warranty does not include damages which arise from accident,
misuse, abuse, neglect or other causes not arising out of defects in
materials or workmanship, nor does it cover damages arising out of
service by other than an authorized PC service center. For personal
use only. Not for commercial use. The original owner shall pay all
labor charges connected with the repair or replacement of all parts.
Under no circumstances does this limited warranty include the cost
of shipment or transportaon to or from an authorized repair
center or Kid Trax retailer.
Limitaon of Damages
The warranty and remedies as set forth are exclusive and in lieu
of all others, oral or wrien, expressed or implied. In no event will
PC or the dealer selling this product be liable to you for any
damages, including incidental or consequenal damages, arising
out of the use or inability to use this product. Some states do not
allow limitaons as the exclusion or limitaon of incidental or
consequenal damages, so the above limitaons may not apply
to you.
Limitaons of Warranes and Warranty Terms
Any warranes, including implied warranes of the merchantability
and tness for a parcular purpose, shall be limited to the duraon
and terms of the express wrien warranty. This warranty gives you
specic legal rights, and you may have other rights, which vary from
state to state.
Neither PC nor the dealer selling this product authorized any person
to create for it any other warranty, obligaon or liability in
connecon with this product.
Pacic Cycle Consumer Relaons
Hours: 8:00 am – 5:00 pm (CST) Monday - Friday
Phone: [phone]
Email: cus[email protected]

In U.S.A.
© 2017 Pacic-Cycle Inc.
4902 Hammersley Rd.
Madison, WI 53711
Body style, seat lock, color, and license
may vary. Made in China
