PERFORMANCE
SERIES VACUUMS
Parts Manual
OPERATING & MAINTENANCE
INTRODUCTION INSTRUCTIONS
The contents of this manual are based on the latest
productinformationavailableatthetimeofpublication.
Pacific reservestherighttomakechangesorimprove-
ments to its machines without notice.
FORYOURCONVENIENCE, RECORDTHE
FOLLOWINGIMPORTANTINFORMATION:
MODEL
SERIALNUMBER
PARTNUMBER
DATEPURCHASED
READTHIS BOOK
This operator’s book has important information for the
useand safeoperationofthis machine. Readthisbook
carefully before starting the machine. Keep this book
and tell all operators to read the book. If you do not
followtheinstructions, you can cause an injury ordam-
ageequipment, furniture or buildings.
For new books write to:
Pacific
2259South Sheridan Road
Muskegon,MI 49442
Carefullyinspect all components to ensurethatthereis
no concealed freight damage. If such damage is dis-
covered,filea “CONCEALED DAMAGE REPORT” im-
mediatelywiththe delivering carrier.

IMPORTANTSAFETYINSTRUCTIONS
READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS IN THIS BOOK BEFORE
USING THIS MACHINE! Ifyoudonotunderstand,askyoursupervisor.
WARNING: To reduce the risk of fire, electric shock, or injury:
1. DO NOT USETHESE VACUUMS FOR PICK UP OF WETDEBRIS.
2. Donotuse outdoors or on wet surfaces.
3. Donot allow to be used asatoy. Close attention is necessary whenusedbyornear children.
4. Youmustbetrainedtooperatethis machine. Operate this machine for its intended use only.
5. Donotoperate this machineunlessitiscompletelyassembled. Thedust bagand/orfiltersmust
be in place.
6. Keepthemachine anditselectrical componentsdry. Donotsubjectto rain.Storethemachinein
adrybuildingarea. Cleanthemachinewithadryclothonly.
7. Machines can cause an explosion when near flammable materials and vapors. Do not use or
storethismachinewithornearfuels,graindust,solvents,thinners,orotherflammablematerials.
Donotuseflammablestocleanthismachine.
8. Donot pick up anything that isburningorsmoking,suchascigarettes,matchesor hot ashes.
9. Maintenanceand repairs must be done by a qualified orauthorizedservicecenter.
10.Ifthemachineisnotworking asitshould,hasbeendropped,damaged,leftoutdoors, ordropped
intowater,returnittoaservicecenter.
11.Connectto aproperlygroundedoutletonly(See GroundingInstructions).
12.Toprevent electric shock, always remove the electrical plug from the electrical outlet before do-
inganyrepairsormaintenanceandwhenleavingthemachineunattended. Donothandleplugor
vacuumwithwethands.
13.Donot pull cord, use cord as ahandle,closeadooroncord,orpullcordaroundsharpedgesor
corners. Keepcord away from heatedsurfaces. Donot use with damagedcord or plug.
14.Turnoffallcontrolsbeforeunplugging.
15.Do not put objects into openings. Do not use with any opening blocked: keep free of dust, lint,
hairandanythingthat may reduceairflow.
16.Keephair, looseclothing,fingersandallpartsofthebodyawayfrom openingsandmovingparts.
17.Make sure all labels, decals, warnings, cautions and instructions are fastened to the machine.
2

This machine must be grounded. If it should malfunction or break
down, grounding provides a path of least resistance for electric
currenttoreduce therisk ofelectricshock. This machineisequipped
with a cord having an equipment-grounding conductor and ground-
ing plug. The plug must be inserted into an appropriate outlet that
is properly installed and grounded in accordance with all local
codes and ordinances.
WARNING - Improper connection of the equipment-grounding con-
ductor can result in a risk of electric shock. Check with a qualified
electrician or service person if you are in doubt as to whether the
outlet is properly grounded. Do not modify the plug provided with
the machine - if it will not fit the outlet, have a proper outlet installed
by a qualified electrician.
This machine is for use on a nominal 120-volt circuit, and has a
grounded plug that looks like the plug illustrated in figure A. A
temporary adapter that looks like the adapter illustrated in figures B
and C may be used to connect this plug to a 2-pole receptacle as
shown in figure B if a properly grounded outlet is not available.
The temporary adapter should be used only until a properly
grounded outlet (figure A) can be installed by a qualified electri-
cian. The green colored rigid ear, lug, or the like extending from the
adapter must be connected to a permanent ground such as a
properly grounded outlet box cover. Whenever the adapter is
used, it must be held in place by a metal screw.
NOTE: In Canada, the use of a temporary adapter is not permitted
by the Canadian Electrical Code
EXTENSIONCORDS
Use only three-wire 14/3 or larger gauge approved extension
cords that have three-prong grounding type plugs and three-pole
receptacles that accept the appliance’s plug. Replace or repair
any damaged cords or plugs.
When servicing, refer to authorized person only. Use only identi-
cal replacement parts.
GroundingInstructions
NOTE: Do not use adapters shown in figures B & C in Canada
3

OPERATINGPROCEDURES
WARNING! For the safe operation of this machine
follow the instructions given in this booklet and
the training given by your supervisor. Failure to
do so can result in personal injury and/or damage
to machine and property!
DONOTOPERATEMACHINE INANEXPLOSIVE EN-
VIRONMENT!
NEVERUSE THIS MACHINETO PICK UPVOLATILE
OREXPLOSIVE MATERIALS!
The model shown in this manual is intended for com-
mercial use.
PREPARATION
Pleaseseetheoperatinginstructionsmanualincluded
with your unit for assembly instructions.
OPERATION
1. Plug the machine’s power cable into a prop-
erlygrounded outlet(seeGroundingInstructions).
2. Release the handle by stepping on the pedal
and lowering handle until motor starts. To
lower handle further (for cleaning under ob-
jects), step on pedal again and lower handle
as much as necessary.
3. Useshort back and forth strokes to cover small
areas.
4. To turn the unit off, raise the handle to the up-
right position.
5. The necessary time to properly clean carpet
depends on the carpet thickness and the
amount of dust/dirt.
6. To store your upright, roll the cable trying not
to twist it and hang it from the cord hook at the
top part of the handle tube.
7. Make sure that the height of the vacuum is
adjusted to the proper level using the height
adjustment knob on the hood of the unit.
MAINTENANCE
ALWAYS turn the vacuum OFF and UNPLUG the
power cord from the electrical outlet before doing
any clean-up or repairs, and when the machine is
left unattended.
AFTEREACHUSE:
1. Vacuum filter bag: If the bag is full or damaged
install a new one.
HEPA Paper Bag, 3 Pack - Part # 660605
Standard Paper Bag, 3 Pack – Part # 660601
Cloth Shake Out Bag (optional) – Part # 660615
2. Power cord and plug: Check for cuts or nicks; if
damaged, have the cord replaced at a factory au-
thorizedservice center.
3. Wheels: Remove any strings or debris that may
restrictthefreemovementofthewheels.
4. Brush: Remove any strings or debris. Replace if
becomesworn or damaged.
Storage: Store the machine in a clean dry area.
VACUUM MOTORMAINTENANCE:
Havethe vacuummotorinspected annuallybya factory
authorizedservice technician. This service willprolong
the life of the motor.
4

NOTES
5

PERFORMANCE127GEXTERNALPARTS
6

PERFORMANCE127GEXTERNALPARTSLIST
7
ITEM # PART # DESCRIPTION QTY
1 663901 GRIP-HANDLE 1
2 669002 HANDLE-UPPER BLACK 1
3 962242 SCREW 10 X 3/8 4
4 664502 CORD HOOK-BLACK 2
5 667204 RETAINER-CORD 1
6 962251 SCREW 8 X 1/2 CAB 1
7 W526D NUT-UPRIGHT HANDLE 10-32 NYLON 2
8 660625 ZIPPER BAG ASSEMBLY 1
9 669001 HANDLE-LOWER BLACK 1
10 665101 LABEL-COMMERCIAL FOR HOOD 1
11 664202 CHASSIS 1
12 662301 HOOD 1
13 662103 CLIP-BELT RETAINING 1
14 903040 BELT-POLY .210 X 13 7/16-83A 1
15 962258 SCREW-SPECIAL HANDLE (2 PIECES) 2
16 660605 HEPA PAPER BAG PACKAGE (3 BAGS) 1
17 665102 LABEL-CRI CERTIFICATION 1

PERFORMANCE127DCEXTERNALPARTS
8
8

PERFORMANCE127DCEXTERNALPARTSLIST
9
ITEM # PART # DESCRIPTION QTY
1 663901 GRIP-HANDLE 1
2 669002 HANDLE-UPPER BLACK 1
3 962242 SCREW 10 X 3/8 4
4 664502 CORD HOOK-BLACK 2
5 667204 RETAINER-CORD 1
6 962251 SCREW 8 X 1/2 CAB 1
7 W526D NUT-UPRIGHT HANDLE 10-32 NYLON 2
8 660630 DIRT CUP BAG ASSM 1
9 669001 HANDLE-LOWER BLACK 1
10 665101 LABEL-COMMERCIAL FOR HOOD 1
11 664202 CHASSIS 1
12 662301 HOOD 1
13 662103 CLIP-BELT RETAINING 1
14 903040 BELT-POLY .210 X 13 7/16-83A 1
15 962258 SPECIAL HANDLE SCREW (2 PIECES) 2

PERFORMANCE127G&127DCINTERNALPARTS

PERFORMANCE127G&127DCINTERNALPARTSLIST
11
ITEM # PART # DESCRIPTION QTY ITEM # PART # DESCRIPTION QTY
1 665002 KNOB-HEIGHT ADJUSTMENT 1 28 980718 WASHER-STAR 10 X .204 5
2 662301 HOOD-PACIFIC YELLOW 127 1 29 664901 YOKE 1
3 663401 BAFFLE-MOTOR 1 30 666601 YOKE SUPPORT ASSM 1
4 962254 SCREW B 10-16 X 3/4 4 30-A 668201 SPACER-YOKE 2
5 669701 WHEEL-REAR 2 30-B 666602 SUPPORT-YOKE 1
6 924084 NUT-BLIND 2 31 667702 SHAFT-YOKE 1
7 962256 SCREW-HEX 10-16 X 5/8 6 32 663403 GASKET-MOTOR BASE 1
8 962243 SCREW 10 X 5/8 2 33 962252 SCREW 8 X 3/4 CAB 2
9 980714 WASHER-FLAT 5/16 X 1/2 3 34 665003 KNOB-BAG 1
10 668301 SPRING-FRONT AXLE 1 35 667705 SHAFT-BALL ARM 1
11 667501 WHEEL-FRONT 2 36 668302 SPRING-KNOB 1
12 667201 PLATE-AXLE RETAINING 3 37 980710 WASHER-FLAT (02-0101) 1
13 660501 AXLE-FRONT 1 38 667203 RETAINER-UPRIGHT BAG 1
14 962257 SCREW-SELF TAPPING BT 6 1 39 667004 PEDAL 1
15 661401 CAM ASSM 1 40 668304 SPRING-HANDLE CAM 1
15-A 661402 CAM-HANDLE 1 41 667703 AXLE-REAR WHEEL 1
15-B 667701 SHAFT-CAM 1 42 980715 WASHER-GROUND 1
16 962248 SCREW 6 X 5/8 BC PH 2 43 662303 FAN COVER W/ GASKET ASSM
(NOT SOLD SEPARATELY) 2
17 661404 PLATE-CAM 1 43-A n/a COVER-FAN (NOT SOLD SEPARATELY) 1
18 664202 CHASSIS 1 43-B n/a GASKET-FAN COVER 1
19 661201 BUMPER-BLACK 1 44 962246 SCREW 6 X 3/8 “A” PH CAB 2
20 980708 WASHER-C PO-25 1 45 962255 SCREW T 8-32 X 1/4 1
21 660901 BRUSH ROLL ASSM-12" 1 46 664701 SPACER-BAG KNOB 1
21-A 663402 GASKET-END CAP 1 47 911537 CONNECTOR 1
21-B 902039 SUPPORT-LEFT BEARING 1 48 911533 SWITCH-UPRIGHT 1
21-C 669801 WASHER-FELT 2 49 903040 BELT-POLY .210 X 13 7/16-83A 1
21-D n/a BRUSH ROLL W/O ENDCAPS 1 50 911534 ACTUATOR-SWITCH 1
21-E 902040 BALL BEARING-RIGHT 11/16 1 51 665201 MOTOR ASSM 1
22 667202 BAR-BOTTOM PLATE RETAINER 1 52 911535 LEAD-GROUND 1
23 667901 BOTTOM PLATE 1 52-A n/a CORD-GREEN GROUNDED 2
24 662701 AIR DUCT 1 52-B n/a TERMINAL-GROUNDED CONNECTION 3
25 668001 CORD ASSM-LINE 1 53 911536 ACTUATOR SWITCH ASSM 1
26 663801 GROMMET H1232 1 665004 LEXAN FAN KIT (NOT SHOWN) 1
27 W106D NUT-HEX No.10-24 3 W527D NUT-PULLEY (NOT SHOWN) 1

PERFORMANCE128G&128DCEXTERNALPARTS
12

PERFORMANCE128G&128DC EXTERNALPARTSLIST
13
ITEM # PART # DESCRIPTION QTY
1 663901 GRIP-HANDLE 1
2A 668002 CORD ASSM-3" 1
2B 908113 CORD-50’ EXTENSION 1
3 667204 RETAINER-CORD 1
4 962251 SCREW 8 X 1/2 CAB 1
5 962242 SCREW 10 X 3/8 4
6 664501 CORD HOOK 2
7 669004 HANDLE-UPPER 1
8 W526D NUT-UPRIGHT HANDLE 10-32 NYLON 2
9 962259 SPECIAL HANDLE SCREW (2 PIECES) 2
10 669003 HANDLE-LOWER 1
11 962246 SCREW 6 X 3/8 “A” PH CAB 1
12 665005 KNOB-HEIGHT ADJUSTMENT 1
13 N/A
14 667601 FELT 1
15 N/A
16 665103 LABEL-HEIGHT ADJUSTMENT 1
17 662302 HOOD 1
18 668311 SPRING-HOOD 2
19 W525D NUT 10-32 2
20 980718 WASHER-STAR 10 X .204 2
21 667203 RETAINER-UPRIGHT BAG 1
22 962244 SCREW 10-30 X 5/8 1
23 667705 SHAFT-BALL ARM 1
24 668302 SPRING-KNOB 1
25 664701 SPACER-BAG KNOB 1
26 665003 KNOB-BAG 1
27 962003 SCREW 10-32 x 3/4 1
28 962247 SCREW 6 X 5/16 1
29 W143D NUT HEX 8-32 2
30 980718 WASHER-STAR 10 X .204 2
31 962063 SCREW 8-32 X 3/8 1
32 660615 CLOTH SHAKE OUT BAG ASSM (OPTIONAL) 1
32A N/A
32B 668501 STRAP-PLASTIC 2
33 660625 ZIPPER BAG ASSM 1
33A N/A
33B 662402 CONNECTOR-PAPER BAG 1
33C 668306 SPRING 1
33D 664101 HOSE-ZIPPER BAG 1
34 663404 BAG COUPLING GASKET ASSM 1
34A 663406 GASKET-BAG COUPLING 1
34B 662403 COUPLING-BAG 1
36 662102 CLIP-BAG 1
37 668305 SPRING 1
38 660630 DIRT CUP BAG ASSM 1
PART # DESCRIPTION
660601 STANDARD PAPER BAG PACKAGE (3 BAGS)
660605 HEPA PAPER BAG PACKAGE (3 BAGS)
665102 LABEL-CRI CERTIFICATION
EXTRAS

PERFORMANCE128G&128DCINTERNALPARTS
14
30

PERFORMANCE128G&128DCINTERNALPARTSLIST
15
ITEM # PART # DESCRIPTION QTY ITEM # PART # DESCRIPTION QTY
1 663405 GASKET-AIR DUCT 1 29 W525D NUT 10-32 2
2 662703 AIR DUCT-RIGHT 1 30 662304 COVER-FAN (NOT SOLD SEPARATELY) 1
3 665202 MOTOR ASSM 1 30A N/A GASKET-FAN COVER
4 W515D SCREW 8-32 X 1/2 6 30B N/A COVER-FAN
5 980712 WASHER-FLAT 6 31 903040 BELT-POLY .210 X 13 7/16-83A 1
6 N/A 32 664203 CHASSIS 1
7 N/A 33 661202 BUMPER-BLACK 1
8 667704 AXLE-REAR WHEEL 2 34 667502 WHEEL-FRONT 2
9 962250 SCREW 6-32 x 3/8 3 35 662101 CLIP 2
10 980710 WASHER-FLAT (02-0101) 5 36 667205 RETAINER-FRONT AXLE 2
11 661406 PLATE-CAM GUIDE 1 37 660502 FRONT AXLE ASSM 1
12 661405 CAM SPRING ASSM 1 38 668309 SPRING-FRONT AXLE 1
13 662702 AIR DUCT-LEFT 1 39 930015 RIVET-TYPE B 1
14 669702 WHEEL-REAR 2 40 980709 WASHER-FLAT 1
15 980708 WASHER-C PO-25 5 41 661101 BUSHING 1
16 667707 SHAFT-SOCKET 1 42 668310 SPRING-FRONT AXLE 1
17 663802 GROMMET 1 43 660901 BRUSH ROLL ASSM-12" 1
18 911540 SWITCH ACTUATOR ASSM 1 45 667902 BOTTOM PLATE 1
18A 911539 ACTUATOR-SWITCH 1 46 667202 BAR-BOTTOM PLATE RETAINER 1
18B 667708 SHAFT-SWITCH 1 47 980711 WASHER-FLAT 2
19 666801 SOCKET-TUBE 1 48 962253 SCREW 8-32 1
20 668307 SPRING 1 49 W143D NUT HEX 8-32 2
21 661403 CAM-HANDLE 1 50 980717 WASHER-STAR 2
22 668308 SPRING-CAM 1 51 911538 LEAD-GROUND 1
23 667706 SHAFT-CAM 1 52 980716 WASHER-STAR 1
24 980707 WASHER-C 2 53 962249 SCREW 6-32 1
25 667005 PEDAL 1 55 980713 WASHER-FLAT 5/16 X 1/2 4
26 668303 SPRING 1 665004 LEXAN FAN KIT (NOT SHOWN ON DIAGRAM)
27 962245 SCREW 1-32 X 1/2 2 W528D NUT-PULLEY (NOT SHOWN ON DIAGRAM)
28 980718 WASHER-STAR 10 X .204 2

WARRANTYPOLICY
LIMITED WARRANTY
ThePacific PerformanceSeries Vacuumshavebeenmanufactured,testedand inspected in accordance with specific
engineeringrequirementsandisWARRANTEDtobefreefromdefectsinworkmanshipandmaterialsasfollows:
Five(5)years parts, one (1) year labor – Chassis (128G& 128DC)
Two (2) years parts, one (1) year labor - Chassis (127G & 127DC), Fan (All), Yoke (All), Switch (All)
One (1) year parts & labor –All other components unless excluded below.
Thiswarranty extends to the originaluser/purchaserandonly when used, operated andmaintainedinaccordance with
Pacific OperatingandMaintenanceinstructions.
This warranty does not apply to the following wear parts and accessories of the machine including:
Part Number Part Name
660605
660903
660901
668001
908113
903040
Nor does it apply to damage or failure caused by improper use, abuse or neglect. Warranty credit or replacement of
return parts including motors, pumps, etc., is subject to incoming inspection of those items.
To secure repair under this warranty,the following procedure should be taken:
· Theinoperativemachineor warranted parts must be delivered to the authorized service center with shipping and
deliverychargesprepaid. Ifunable to locateaservicecenter, you may contactPacific at the address listed herein
forthelocation of the nearest repair center or agent or forother instructions pertainingtoyour warranty difficulty.
· Upon compliance with the above warranty procedure, all warranted repairs would be completed at no additional
charge or cost to the user.
· OnlyPacific orits authorized dealersandagentsmaymakenochargewarrantyrepairson thisproduct. Allothers
do so at their own risk.
This warranty limits Pacific liability to the repair of the product and/or warranted parts replacement and does not
include incidental orconsequential damages arising fromthe use of a Pacific machinewhether defective or not.
This warranty is in lieu of all other expressed or implied warranties and is extended to the original purchaser/user.
HEPAPaperBags
BrushRoll
Brush RollAssm.
CordAssembly
CordAssembly
Belt
2259 South Sheridan Road
Muskegon, MI 49442
Phone: [phone] Fax: [phone]
www.pacificfloorcare.com [e-mail]
07/08
