Panasonic HG-T Series User manual

2019.2 panasonic.net/id/pidsx/global
Thru-Beam Type Digital Displacement Sensor
HG-T series
User’s Manual
WUME-HGT-3

WUME-HGT-32
(MEMO)

WUME-HGT-3 3
Introduction
Thank you for purchasing an HG-T series thru-beam digital displacement sensor.
Before using this product, read and understand this User’s Manual. Use the product correctly
and in the optimum manner.
Keep this manual in a safe location for reference whenever necessary.
Types of Manuals
The following user’s manuals are available for the HG-T series. Refer to the appropriate manual
according to your need.
The user’s manuals are also available for download from our website (https://panasonic.net/id/
pidsx/global).
Unit name or purpose of use Manual name Manual Code
HG-T Control Unit HG-T User’s Manual WUME-HGT
USB Communication Tool
Software
HG-T Conguration Tool
HG-T Conguration Tool User’s Manual WUME-HGTCT
Please note
1) No part of this manual may be reproduced or reprinted in any form or by any means without
prior written permission from Panasonic.
2) The contents of this manual are subject to change without notice for future improvement.
3) This manual has undergone strict quality control; but should you discover any dubious infor-
mation, mistakes, misplaced pages, or missing pages, please contact your local dealer.

WUME-HGT-34
Manual Conguration
Chapter 1
Before Using This Product
This chapter explains safety and handling precautions,
laser safety standards, and other information that should
be checked before using this product.
Chapter 2
System Conguration This chapter explains the system conguration.
Chapter 3
Overview of HG-T Series
This chapter explains the principle of measurement and
how to use this product when controllers are connected.
Chapter 4
Installation and Connections
This chapter explains installation, connections, wiring, and
other work.
Chapter 5
Basic Usage
This chapter explains the flow of operations up to
measurement startup, the base screen displayed when
the power is turned ON, and basic operations.
Chapter 6
Setting up General Functions
This chapter explains details and settings for general
functions.
Chapter 7
Setting up Extended Functions
This chapter explains details and settings for extended
functions.
Chapter 8
Specications and Dimensions
This chapter explains the specications and dimensions.
Chapter 9
Maintenance This chapter explains maintenance and inspection.
Chapter 10
Troubleshooting This chapter explains troubleshooting and error codes.
Chapter 11
Appendix This chapter provides menu structure.

WUME-HGT-3 5
Contents
Introduction·······················································································3
Types of Manuals···············································································3
Manual Conguration··········································································4
Chapter 1 Before Using This Product··················································1-1
1.1 Safety Precautions ····································································· 1-2
1.2 Handling Precautions·································································· 1-3
1.3 Laser Safety Standards ······························································· 1-5
1.3.1 IEC / JIS / GB ········································································1-5
1.3.2 FDA·····················································································1-6
1.4 Terminology ·············································································· 1-8
1.5 Contents of Package ·································································· 1-9
Chapter 2 System Conguration ························································2-1
2.1 System Conguration·································································· 2-2
2.2. Description of Parts ··································································· 2-3
2.2.1 Controller··············································································2-3
2.2.2 Sensor Head ·········································································2-5
2.2.3 Sensor Head Connection Cable·················································2-6
2.2.4 Side View Attachment······························································2-6
Chapter 3 Overview of HG-T Series ···················································3-1
3.1 Principle of Measurement ···························································· 3-2
3.2 Role of Controllers ····································································· 3-3
3.3 Using Connected Controllers ························································ 3-4
Chapter 4 Installation and Connections ···············································4-1
4.1 Mounting the Controller ······························································· 4-2
4.1.1 Mounting on a DIN Rail····························································4-2
4.1.2 Removing from a DIN Rail ························································4-2
4.1.3 Controller Wiring Connection Diagrams·······································4-3
4.2 Attaching the Sensor Head··························································· 4-4
4.3 Connecting the Sensor Head Connection Cable ······························· 4-5
4.3.1 Connecting to the Sensor Head ·················································4-5
4.3.2 Disconnecting from the Sensor Head··········································4-6
4.3.3 Connecting to the Controller ·····················································4-7
4.3.4 Disconnecting from the Controller ··············································4-7
4.3.5 Connecting and Disconnecting to / from Controller Connector··········4-8
4.4 Connecting Controllers······························································ 4-11
4.4.1 How to connect ···································································· 4-12
4.4.2 How to remove····································································· 4-14
4.5 Mounting the Side View Attachment ············································· 4-15

WUME-HGT-36
Chapter 5 Basic Usage ····································································5-1
5.1 Using the Base Screen································································ 5-2
5.1.1 Functions of Operation Keys and Display Unit ······························5-2
5.2 Flow of Operations up to Measurement Startup ································ 5-5
5.3 Explanation of Basic Operation ····················································· 5-7
5.3.1 Checking the Beam Axis ··························································5-7
5.3.2 Adjusting the Beam Axis···························································5-9
5.3.3 Reference Waveform Registration············································ 5-14
5.3.4 Teaching ············································································· 5-15
5.4 Operation Mode······································································· 5-22
5.4.1 Auto Edge Detection Mode ····················································· 5-22
5.4.2 Edge Detection Mode ···························································· 5-24
5.4.3 External Form/Width Detection Mode········································ 5-25
5.4.4 Inside Diameter/Gap Detection Mode ······································· 5-25
5.4.5 Central Position Detection Mode·············································· 5-26
5.5 Settings on the Base Screen (Using Shortcut Keys) ························ 5-27
5.5.1 Display Switching Mode ························································· 5-27
5.5.2 Preset ················································································ 5-32
5.5.3 Bank Mode·········································································· 5-34
5.5.4 Key Lock············································································· 5-38
5.5.5 Sensitivity Settings································································ 5-40
Chapter 6 Setting up General Functions··············································6-1
6.1 Flow of Measurement Data ·························································· 6-2
6.2 Setting Operation List ································································· 6-3
6.3 Detection Settings ( )······················································· 6-9
6.3.1 Operation Mode ( ) ······················································6-9
6.3.2 Measurement Direction ( )··········································· 6-10
6.3.3 Average Count (Response Time) ( ) ································ 6-11
6.4 Basic Settings ( )···························································· 6-14
6.4.1 HIGH Set Value ( ) ······················································ 6-14
6.4.2 LOW Set Value ( ) ······················································· 6-16
6.4.3 Hysteresis ( )···························································· 6-18
6.4.4 Teaching Types ( ) ······················································· 6-20
6.4.5 Tolerance <±>( )························································· 6-22
6.4.6 Preset Value ( )··························································· 6-23
6.4.7 Preset Data Selection ( ) ·············································· 6-24
6.4.8 Preset Save ( ) ························································· 6-25
6.4.9 Reference Waveform Save ( )······································ 6-26
6.4.10 Output Operation ( ) ················································· 6-27
6.4.11 Analog Output Selection ( ) ········································ 6-28
6.4.12 Menu Display Settings ( )·············································· 6-29
6.5 Initialization ( ) ······························································· 6-30
6.6 Maintenance ( )···························································· 6-31

WUME-HGT-3 7
Chapter 7 Setting up Extended Functions············································7-1
7.1 Setting Operation List ································································· 7-2
7.2 Advanced Settings ( ) ······················································ 7-9
7.2.1 Hold Settings ( ) ·····························································7-9
7.2.2 Simultaneous Input ( )(For Master Units Only)················· 7-17
7.2.3 External Inputs ( ) ······················································· 7-18
7.2.4 External Outputs ( ) ··················································· 7-21
7.2.5 External Output Delay Timer Selection ( )······················· 7-27
7.2.6 Number of Digits Displayed ( ) ······································· 7-31
7.2.7 Analog Scaling ( )······················································ 7-32
7.2.8 Eco Mode ( )·································································· 7-37
7.2.9 Alarm Settings ( ) ························································ 7-38
7.2.10 Key Lock Function Selection ( ) ·································· 7-44
7.2.11 Interference Prevention Function ( )(For Master Units Only) ··· 7-45
7.2.12 Sampling Cycle ( ) ··················································· 7-47
7.3 Calculation Settings ( )(For Master Units Only) ······················· 7-48
7.3.1 Calculation Mode ( ) ······················································ 7-48
7.3.2 Calculation Application Selection ( ) ································ 7-49
7.4 Copy Settings ( )······························································ 7-53
7.4.1 Copy Individual Selection ( )(For Master Units Only) ········· 7-54
7.4.2 Copy Batch Selection ( )(For Master Units Only) ·············· 7-56
7.4.3 Copy Execution ( )(For Master Units Only) ····················· 7-57
7.4.4 Copy Lock ( )(For Slave Units Only)·································· 7-58
7.5 Bank Settings ( ) ······························································ 7-59
7.5.1 Bank Save Selection( )··············································· 7-59
7.6 Calibration Settings ( )····················································· 7-61
7.6.1 Calibration Selection ( )·············································· 7-61
Chapter 8 Specications and Dimensions ············································8-1
8.1. Specications ··········································································· 8-2
8.1.1 Controller··············································································8-2
8.1.2 Sensor Head ·········································································8-8
8.2. Dimension Drawings ·································································· 8-9
8.2.1 Controller··············································································8-9
8.2.2 Sensor Head ······································································· 8-11
8.2.3 Side View Attachment···························································· 8-12
Chapter 9 Maintenance····································································9-1
9.1 Maintenance and Inspection························································· 9-2
9.1.1 Maintenance Precautions ·························································9-2
9.1.2 Main Inspection Items······························································9-2
Chapter 10 Troubleshooting···························································· 10-1
10.1 Troubleshooting ····································································· 10-2
10.2 Error Messages ····································································· 10-4
Chapter 11 Appendix ····································································· 11-1
11.1 Menu Structure(General Function Display)··································· 11-2
11.2 Menu Structure(Extended Function Display)································· 11-4

WUME-HGT-38
(MEMO)

1-1
1.1 Safety Precautions ···································································1-2
1.2 Handling Precautions·································································1-3
1.3 Laser Safety Standards ······························································1-5
1.3.1 IEC / JIS / GB ····································································· 1-5
1.3.2 FDA·················································································· 1-6
1.4 Terminology ·············································································1-8
1.5 Contents of Package ·································································1-9
Chapter 1
Before Using This Product

Before Using This Product
WUME-HGT-31-2
1.1 Safety Precautions Always observe
This section explains important rules that must be observed to prevent human injury and prop-
erty damage.
■ The hazards that may occur if the product is used incorrectly are described and classied by
level of harm.
WARNING Risk of death or serious injury.
CAUTION Risk of minor injury or property damage.
WARNING
●Never use this product as a sensing device for personnel protection.
●For sensing devices for personal protection, use products that conform to the laws and standards
related to personal protection in each country, such as OSHA, ANSI, and IEC.
●This product is designed to inspect (judge or measure) objects and so must not be used to ensure
safety, for example, to prevent accidents that a󰀨ect human lives or property.
● Do not look at or touch direct laser beams or other reections of light, as doing so is dangerous.
CAUTION
●For the controller DC power supply, only use a power supply that is isolated by means of an isola-
tion transformer or otherwise.
●There is a risk of short-circuiting and damage to the controller or power supply if a transformer such
as an autotransformer is used. There is a risk of short-circuiting and damage to the controller or
power supply if the controller is incorrectly mounted or connected.
●The HG-TC series controller is designed to be used with the HG-T series special-purpose sen-
sor head to satisfy the specications. If the controller is used with any sensor head other than the
special-purpose sensor head, the specications will not be satised and malfunctioning or another
problem may occur.

Before Using This Product
WUME-HGT-3 1-3
1.2 Handling Precautions
■I n this manual, the following symbols are used to indicate safety information that must be ob-
served.
Indicates an action that is prohibited.
Indicates an action that must be taken.
Indicates a matter that requires caution.
<Reference> Indicates supplemental information.
■Handling precautions
Specications
●This device has been developed / produced for industrial use only.
●This product (controller and sensor head receiver) uses an EEPROM. The EEPROM has a
service life of one million setting operations.
● Do not use this product outside the range of the specications. Risk of an accident and prod-
uct damage.
There is also a risk of a noticeable reduction of service life.
Power supply
● Verify that the supply voltage uctuations are within the rating.
●If power is supplied from a commercial switching regulator, ensure that the frame ground (F.G.)
terminal of the power supply is connected to an actual ground.
●Do not use during the initial transient time after the power supply is switched ON.
●To ensure performance, use the product at least 30 minutes (warm-up time) after the power
is turned ON.
Wiring
●Make sure that the power is OFF before performing wiring or connection work for the control-
ler.
●Note that there is a risk of damage or burning if the load is short-circuited or incorrectly wired.
●After you have completed wiring work, check the wiring carefully before switching on the
power.
●Do not wire in parallel with a high-voltage line or power line, or run through the same conduit.
Doing so may result in malfunctioning due to induction.
●Do not apply stress such as excessive bending or pulling to the extracted part of a cable,
●When connecting the sensor head connection cable to this product, do not apply force to the
product.

Before Using This Product
WUME-HGT-31-4
Usage environment
●This product is suitable for indoor use only.
●The light emitting and receiving surfaces of the sensor head must be free of water, oil, n-
gerprints, and other substances that refract light as well as dust, grit, and other objects that
intercept light.
If stains or dirt become attached to the sensor head surfaces, wipe them with a lint-free soft
cloth or lens cleaning paper. If the surfaces are very dirty, wipe o󰀨 dirt using a cotton swab (or
similar material) moistened with absolute alcohol.
●Do not allow ambient light such as sunlight to directly hit the light receiving section of the
sensor head. In particular, if precision is required, use this product by mounting a douser (or
similar material) on the sensor head.
●When a measured object with a strong specular reflection component (such as glass or
specular reector) is detected, it may not be detected correctly due to the inuences of light
reected from the measured object. In such a case, install a pair of emitter and receiver at
a certain angle so that reected light does not hit the emitter or receiver. After adjusting the
angle, always check the beam axis. After checking the beam axis, if the beam axis is aligned,
register the reference waveform. If the beam axis is misaligned, readjust the beam axis, and
register the reference waveform.
●Avoid using this product in environments where condensation occurs due to sudden tem-
perature change.
●Avoid dust, dirt, and steam.
●Avoid using the product in atmospheres that contain corrosive or other harmful gases.
●Ensure that the product does not come into contact with organic solvents such as thinner.
●Ensure that the product does not come into contact with strong acid or alkaline.
●Ensure that the product does not come into contact with oil or grease.
● This product cannot be used in atmospheres that contain ammable or explosive gases.
● Performance may not be satisfactory in a strong electromagnetic eld.
●Do not use this product in locations subject to severe vibration or shock.
●This product is a precision device. Do not drop or otherwise subject to shock. Risk of product
damage.
●Take care not to touch any terminals in the connector or allow foreign objects to enter the
connector.
●The sensor head is watertight, but the connector is not dustproof, waterproong, or corro-
sion-resistant due to its structural reasons, so measurements cannot be taken under the wa-
ter or in the rain. Pay attention to the environment where the product is used.
Other matters
●Never attempt to disassemble, repair, or modify the product.
●When the product becomes unusable or unneeded, dispose of the product appropriately as
industrial waste.

Before Using This Product
WUME-HGT-3 1-5
1.3 Laser Safety Standards
1.3.1 IEC / JIS / GB
To prevent laser products from a󰀨ecting their users, IEC, JIS, and GB have the following re-
spective standards:
IEC: IEC 60825-1-2014
JIS: JIS C 6802-2014
GB: GB 7247.1-2012
These standards classify laser products into classes according to the danger level of laser, and
prescribe safety and preventive measures that should be implemented for each class.
This product belongs to “Class 1 laser product” according to JIS C 6802-2014 “Safety of Laser
Products”.
●Explanation of danger level
Classication Overview of danger evaluation
Class 1 This class of laser beams is safe when the operating state of the product is rightly predictable.
Class 1M This class of laser beams is safe when the operating state of the product is rightly predictable,
but direct intrabeam viewing by optical means can be dangerous.
Class 2 This class of laser beams is visible light and low output. Normally, eyes are protected by aver-
sion reaction such as blinking.
Class 2M This class of laser beams is visible light and low output. Normally, eyes are protected by aver-
sion reaction such as blinking, but direct intrabeam viewing by optical means can be dangerous.
Class 3R Direct intrabeam viewing is potentially dangerous, but the level of risk is lower than Class 3B
laser.
Class 3B Direct intrabeam viewing is always dangerous.
Class 4 This class of laser beams is high output. It has the ability to cause dangerous di󰀨use reection.
Such laser beams cause skin disorders and have the risk of re occurrence.
●Warning label
On the emitter side <Label position>
♦HG-T1010 ♦HG-T1110

Before Using This Product
WUME-HGT-31-6
1.3.2 FDA
●Exporting to the USA
If this product is incorporated into facilities or equipment to be exported to the USA, it is subject
to the laser regulations of the U.S. Food and Drug Administration (FDA). To prevent laser prod-
ucts from a󰀨ecting their users, PART1040 (Performance Standards for Light-Emitting Products)
was established as one of the FDA regulations. These standards classify laser products into
classes according to the danger level of laser and prescribe safety and preventive measures
that should be implemented for each class.
This product complies with the FDA regulations (21 CFR 1040. 10 and 1040.11) in accordance
with FDA Laser Notice No. 50. (Class 1 laser product)
●FDA regulations
Requirements Class (*1)
I IIa II IIIa IIIb IV
Performance (for all laser products)
Protective housings [1040.10(f)(1)]
Safety interlock [1040.10(f)(2)]
Location of controls [1040.10(f)(7)]
Viewing optics [1040.10(f)(8)]
Scanning safeguard [1040.10(f)(9)]
R*2
R*3, *4
N/A
R
R
R*2
R*3, *4
R
R
R
R*2
R*3, *4
R
R
R
R*2
R*3, *4
R
R
R
R*2
R*3, *4
R
R
R
R*2
R*3, *4
R
R
R
Performance (for laser systems)
Remote interlock connector [1040.10(f)(3)]
Key control [1040.10(f)(4)]
Emission indicator [1040.10(f)(5)]
Beam attenuator [1040.10(f)(6)]
Manual reset [1040.10(f)(10)]
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
R
R
N/A
N/A
N/A
R
R
N/A
R
R
R*10
R
N/A
R
R
R*10
R
R*13
Performance (for special-purpose products)
Medical use [1040.11(a)]
Surveying, leveling, and alignment [1040.11(b)]
Demonstration [1040.11(c)]
S
S
S
S
S
S
S
S
S
S*8
S
S
S*8
NP
S*11
S*8
NP
S*11
Labeling (for all laser products)
Certication and identication [1010.2,3]
Protective housings [1040.10(g)(6), (7)]
Openings [1040.10(g)(4)]
Class warning [1040.10(g)(1), (2), (3)]
R
D
N/A
N/A
R
R*5
N/A
R*6
R
R*5
N/A
R*7
R
R*5
N/A
R*9
R
R*5
N/A
R*12
R
R*5
N/A
R*12
Information (for all laser products)
User information [1040.10(h)(1)]
Product literature [1040.10(h)(2)(i)]
Service information [1040.10(h)(2)(ii)]
R
N/A
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R:Required
N/A: Not applicable
S: Same requirements as for other products of the class
NP: Not permitted
D:Depends on the internal radiation level

Before Using This Product
WUME-HGT-3 1-7
*1: Based on the maximum level of exposure to radiation during operation
*2: Required wherever and whenever if exposure to laser radiation exceeding the limit of Class 1 is not neces-
sary to fulll the functions of the product
*3: Required for protective housings that are opened during operation or maintenance if radiation exposure that
occurs when the housing is opened is not always necessary
*4: Requirements for interlock di󰀨er according to the class of internal radiation.
*5: Wording di󰀨ers according to the level and wavelength of laser radiation inside the protective housing.
*6: A label that indicates a warning statement
*7: CAUTION logo
*8: A means is required to measure the level of laser radiation for the purpose of human body irradiation.
*9: CAUTION is used when the radiation level is 2.5 mWcm-2 or lower, and DANGER is used when the radiation
level is higher than 2.5 mWcm-2.
*10: Time lag is required between reading and emission.
*11: Exception handling is required for laser products and light show for demonstration of Class IIIb or IV.
*12: DANGER logo
*13: Required since August 20, 1986
● Recognition / identication label
<Label position>
Emitter
♦Common to HG-T1010 and HG-T1110

Before Using This Product
WUME-HGT-31-8
1.4 Terminology
Term Description
Controller - Master unit A controller that can be used on a standalone basis
Controller - Slave unit A controller that is used by connecting to a master unit
Sensor head - Emitter A sensor head emitter that is used by connecting to a controller
Sensor head - Receiver A sensor head receiver that is used by connecting to a controller
Sensor head connection
cable A cable that is used to connect a sensor head and controller
Side view attachment An attachment that is used to refract laser beams from the sensor head at 90 degrees
End plate A plate that is used to secure both ends of controllers to prevent the connectors from
coming o󰀨 and causing a communication failure when controllers are connected
Communication unit An interface unit that enables measurement data and other data of connected control-
lers to be monitored. (Note 1)
(Note 1): For details on communication units, refer to the user's manual for each communication unit.

Before Using This Product
WUME-HGT-3 1-9
1.5 Contents of Package
The following accessories are included in the product package. Before using the product, make
sure that no items are missing.
Controller
HG-TC101 /
Master unit of high-performance
NPN output type
HG-TC101-P / Master unit of high-perfor-
mance PNP output type
●Controller: 1 pc.
●Instruction Manual
(English / Japanese, Chinese / Korean): 1 PC each
● General Information for Safety, Compliance,
and Instructions (23 languages): 1 PC
HG-TC111 / Slave unit of high-perfor-
mance NPN output type
HG-TC111-P /
Slave unit of high-perfor-
mance PNP output type
●Controller: 1 pc.
● Instruction Manual
(English / Japanese, Chinese / Korean): 1 PC each
● General Information for Safety, Compliance,
and Instructions (23 languages): 1 PC
HG-TC113 / Slave unit of wire-saving type
●Controller: 1 pc.
●Instruction Manual
(English / Japanese, Chinese / Korean): 1 PC each
● General Information for Safety, Compliance,
and Instructions (23 languages): 1 PC
Sensor head
HG-T1010 / Measurement width 10 mm,
standard type
●Sensor head (emitter and receiver): 1 set
●Instruction Manual
(English / Japanese, Chinese / Korean): 1 PC each
● General Information for Safety, Compliance,
and Instructions (23 languages): 1 PC
HG-T1110 / Measurement width10 mm,
slim type
●Sensor head (emitter and receiver): 1 set
●Instruction Manual
(English / Japanese, Chinese / Korean): 1 PC each
● General Information for Safety, Compliance,
and Instructions (23 languages): 1 PC
Side view attachment
HG-TSV10 / Side view attachment
●Attachment: 1 pc. (Note 1)
●M2 screw with washer (length: 4mm): 2 pcs.
(Note 1):
HG-TSV10 is sold by one unit. Two units are
required for a pair of emitter and receiver.

Before Using This Product
WUME-HGT-31-10
Sensor head connection cable
CN-HT-C2 / Cable length 2 m
CN-HT-C5 / Cable length 5m
CN-HT-C10 / Cable length 10m
CN-HT-C20 / Cable length 20m
●Connection cable: 1 pc.
End plate
MS-DIN-E / End plate
●Plate: Set of 2 pcs.
●Instruction manual
Communication unit
SC-HG1-USB / USB Communication Unit
●Communication unit: 1 pc.
●Instruction manual

2-1
2.1 System Conguration·································································2-2
2.2. Description of Parts ··································································2-3
2.2.1 Controller··········································································· 2-3
2.2.2 Sensor Head ······································································ 2-5
2.2.3 Sensor Head Connection Cable ············································· 2-6
2.2.4 Side View Attachment ·························································· 2-6
Chapter 2
System Conguration

System Conguration
WUME-HGT-32-2
2.1 System Conguration
The HG-T series consists of controllers, sensor head connection cables, and sensor heads.
For the controllers, master units (two types) and slave units (three types) are available. Up to 15
slave units can be connected to one master unit. For the sensor heads, two types are available.
For the sensor head connection cables, four types are available.
Connecting a communication unit to the end of the connection enables information to be
checked from outside. (Note)
●Always shut OFF the power before connecting or disconnecting a slave unit or commu-
nication unit to / from the master unit. If you connect or disconnect a unit with the power
ON, the controller may become damaged.
●Insert the male connector all the way into the female connector. If the connectors are not
completely connected, the controller may become damaged.
●To connect units, always mount them on a DIN rail. To do so, mount end plates MS-DIN-E
(optional) so as to enclose the connected units at both ends.
●When connecting slave units to the master unit, connect only NPN output type units or
only PNP output type units. Dissimilar output types cannot be connected together.
Sensor head
• HG-T1010
• HG-T1110
Controller - Master unit
• HG-TC101
• HG-TC101-P
Sensor head connection cable
• CN-HT-C2
• CN-HT-C5
• CN-HT-C10
• CN-HT-C20
Controller - Slave unit
• HG-TC111
• HG-TC111-P
• HG-TC113
Up to 15 units can be connected(Note)
(Note): When a communication unit is connected, up to 14 slave units can be connected.
