Panasonic MA3X717E User manual

Schottky Barrier Diodes (SBD)
Publication date: October 2008 SKH00237AED 1
This product complies with the RoHS Directive (EU 2002/95/EC).
MA3X717E (MA717WK)
Silicon epitaxial planar type
For switching
Features
Two MA3X717 is contained in one package
Forward voltage VF , optimum for low voltage rectification
Low VFtype of MA3X704E
Optimum for high frequency rectification because of its short
reverse recovery time (trr)
Absolute Maximum Ratings Ta= 25°C
Parameter Symbol Rating Unit
Reverse voltage VR30 V
Maximum peak reverse voltage VRM 30 V
Forward current Single IF
30 mA
Double 20
Peak forward current Single IFM
150 mA
Double 110
Junction temperature Tj125 °C
Storage time Tstg –55 to +125 °C
Electrical Characteristics Ta= 25°C±3°C
Parameter Symbol Conditions Min Typ Max Unit
Forward voltage VF1 IF= 1 mA 0.3 V
VF2 IF= 30 mA 1.0
Reverse current IRVR= 30 V 30 mA
Terminal capacitance CtVR= 1 V, f = 1 MHz 1.5 pF
Reverse recovery time *trr
IF= IR= 10 mA, Irr = 1 mA,
RL= 100 W1.0 ns
Detection efficiency ηVIN = 3 V(peak) , f = 30 MHz
RL= 3.9 kW, CL= 10 pF 65 %
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7031 measuring methods for diodes.
2. This product is sensitive to electric shock (static electricity, etc.). Due attention must be paid on the charge of a human body and the leakage
of current from the operating equipment.
3. Absolute frequency of input and output is 2 GHz
4. *: trr measurement circuit
Bias Application Unit (N-50BU)
90%
Pulse Generator
(PG-10N)
Rs= 50 Ω
Wave Form Analyzer
(SAS-8130)
Ri= 50 Ω
tp= 2 µs
tr= 0.35 ns
δ = 0.05
IF=10 mA
IR=10 mA
RL=100 Ω
10%
Input Pulse Output Pulse
Irr =1 mA
trtp
trr
VR
IF
t
t
A
Package
Code
Mini3-G1
Pin Name
1: Anode 1
2: Anode 2
3: Cathode
Marking Symbol: M3D
Internal Connection
1 2
3
Note) The part number in the parenthesis shows conventional part number.

MA3X717E
2SKH00237AED
This product complies with the RoHS Directive (EU 2002/95/EC).
IFVFIRVRVFTa
IRTaCtVR
10−2
0 0.4 0.8 1.2 1.6 2.0 2.4
10−1
1
10
102
103
Forward voltage VF(V)
Forward current IF(mA)
Ta= 125°C−20°C
75°C25°C
10−1
0 5 10 15 20 25 30
1
10
102
103
104
Reverse voltage VR(V)
Reverse current IR(µA)
Ta= 125°C
75°C
25°C
0
0.2
0.4
0.6
0.8
1.0
−40 0 40 80 120 160
Ambient temperature Ta(°C)
Forward voltage VF(V)
IF= 30 mA
10 mA
1 mA
10−1
−40 0 40 80 120 160 200
1
10
102
103
104
Ambient temperature Ta(°C)
Reverse current IR(µA)
VR= 30 V
3 V
1 V
0
0.8
1.6
2.4
3.2
0 10 20 30
Reverse voltage VR(V)
Terminal capacitance Ct(pF)
f = 1 MHz
Ta= 25°C

MA3X717E
SKH00237AED 3
This product complies with the RoHS Directive (EU 2002/95/EC).
Mini3-G1 Unit: mm
(0.95)
(0.95)
1.9 ±0.1
0.40
1.50
2.8
2.90
3
2
1
5°
0.4 ±0.2
0.16
10°
1.1
1.1
0 to 0.1 (0.65)
+0.10
−0.05
+0.25 −0.05
+0.2 −0.3
+0.20
−0.05
+0.2 −0.1
+0.3 −0.1
+0.10
−0.05
