Panasonic S-200PE1E8 Manual

85464849294003 REFERENCE NO. SM830194-03
TECHNICAL DATA
&
SERVICE MANUAL
Outdoor UnitIndoor Unit
S-200PE1E8, S-250PE1E8
Type E1
U-200PE1E8, U-250PE1E8
SM830194-03BigPAC-i.indb1SM830194-03BigPAC-i.indb1 2012/10/1120:58:272012/10/1120:58:27

i
IMPORTANT!
Please Read Before Starting
This air conditioning system meets strict safety and
operating standards. As the installer or service person,
it is an important part of your job to install or service the
system so it operates safely and efficiently.
For safe installation and trouble-free operation, you must:
Carefully read this instruction booklet before beginning.
Follow each installation or repair step exactly as shown.
Observe all local, state, and national electrical codes.
This product is intended for professional use.
Permission from the power supplier is required when
installing the 200 – 250 Type outdoor unit that is
connected to a 16 A distribution network.
If this equipment has been installed in a residential
area and any problems caused by high harmonic waves
occurred, attach a recommended harmonic filter to the
equipment. For details about a suitable harmonic filter,
please contact your sales distributors.
Pay close attention to all warning and caution notices
given in this manual.
WARNING
This symbol refers to a hazard or unsafe
practice which can result in severe person-
al injury or death.
CAUTION
This symbol refers to a hazard or unsafe
practice which can result in personal injury
or product or property damage.
If Necessary, Get Help
These instructions are all you need for most installation
sites and maintenance conditions. If you require help for a
special problem, contact our sales/service outlet or your
certified dealer for additional instructions.
In Case of Improper Installation
The manufacturer shall in no way be responsible for
improper installation or maintenance service, including
failure to follow the instructions in this document.
SPECIAL PRECAUTIONS
WARNING When Wiring
ELECTRICAL SHOCK CAN CAUSE
SEVERE PERSONAL INJURY OR DEATH.
ONLY A QUALIFIED, EXPERIENCED
ELECTRICIAN SHOULD ATTEMPT TO
WIRE THIS SYSTEM.
• Do not supply power to the unit until all wiring and tubing
are completed or reconnected and checked.
• Highly dangerous electrical voltages are used in this
system. Carefully refer to the wiring diagram and these
instructions when wiring. Improper connections and
inadequate grounding can cause accidental injury or
death.
• Ground the unit following local electrical codes.
• Connect all wiring tightly. Loose wiring may cause
overheating at connection points and a possible fire
hazard.
•Provide a power outlet to be used exclusively for each
unit, and a power supply disconnect, circuit breaker and
earth leakage breaker for overcurrent protection should
be provided in the exclusive line.
•To prevent possible hazards from insulation failure,
the unit must be grounded.
When Transporting
Be careful when picking up and moving the indoor and
outdoor units. Get a partner to help, and bend your knees
when lifting to reduce strain on your back. Sharp edges
or thin aluminum fins on the air conditioner can cut your
fingers.
When Installing…
…In a Room
Properly insulate any tubing run inside a room to prevent
“sweating” that can cause dripping and water damage to
walls and floors.
…In Moist or Uneven Locations
Use a raised concrete pad or concrete blocks to provide
a solid, level foundation for the outdoor unit. This prevents
water damage and abnormal vibration.
…In an Area with High Winds
Securely anchor the outdoor unit down with bolts and a
metal frame. Provide a suitable air baffle.
…In a Snowy Area (for Heat Pump-type Systems)
Install the outdoor unit on a raised platform that is higher
than drifting snow. Provide snow vents.
SM830194-03BigPAC-i.indb2SM830194-03BigPAC-i.indb2 2012/10/1120:58:282012/10/1120:58:28

ii
When Connecting Refrigerant Tubing
WARNING
• When performing piping work do not
mix air except for specified refrigerant
(R410A) in refrigeration cycle. It
causes capacity down, and risk of
explosion and injury due to high
tension inside the refrigerant cycle.
•Refrigerant gas leakage may cause
fire.
• Ventilate the room well, in the event that is refrigerant
gas leaks during the installation. Be careful not to allow
contact of the refrigerant gas with a flame as this will
cause the generation of poisonous gas.
• Keep all tubing runs as short as possible.
• Use the flare method for connecting tubing.
• Apply refrigerant lubricant to the matching surfaces of
the flare and union tubes before connecting them, then
tighten the nut with a torque wrench for a leak-free
connection.
• Check carefully for leaks before starting the test run.
• Do not leak refrigerant while piping work for an
installation or re-installation, and while repairing
refrigeration parts. Handle liquid refrigerant carefully as
it may cause frostbite.
When Servicing
• Turn the power OFF at the main power box (mains)
before opening the unit to check or repair electrical
parts and wiring.
• Keep your fingers and clothing away from any moving
parts.
• Clean up the site after you finish, remembering to
check that no metal scraps or bits of wiring have been
left inside the unit being serviced.
WARNING
• Do not clean inside the indoor and
outdoor units by users. Engage
authorized dealer or specialist for
cleaning.
• In case of malfunction of this
appliance, do not repair by yourself.
Contact the sales dealer or service
dealer for repair.
CAUTION
• Do not touch the air inlet or the sharp
aluminum fins of the outdoor unit.
You may get hurt.
• Ventilate any enclosed areas when
installing or testing the refrigeration
system. Escaped refrigerant gas, on
contact with fire or heat, can produce
dangerously toxic gas.
• Confirm after installation that no
refrigerant gas is leaking. If the gas
comes in contact with a burning stove,
gas water heater, electric room heater
or other heat source, it can cause the
generation of poisonous gas.
Others
CAUTION
• Do not touch the air inlet or
the sharp aluminum fins of the
outdoor unit. You may hurt.
• Do not sit or step on the unit,
you may fall down accidentally.
• Do not stick any object into
the FAN CASE.
You may be injured and the
unit may be damaged.
SM830194-03BigPAC-i.indb3SM830194-03BigPAC-i.indb3 2012/10/1120:58:282012/10/1120:58:28

iii
2. The standards for minimum room volume are as follows.
(1) No partition (shaded portion)
(2) When there is an effective opening with the adjacent room
for ventilation of leaking refrigerant gas (opening without
a door, or an opening 0.15% or larger than the respective
floor spaces at the top or bottom of the door).
(3) If an indoor unit is installed in each partitioned room and
the refrigerant tubing is interconnected, the smallest room
of course becomes the object. But when mechanical
ventilation is installed interlocked with a gas leakage
detector in the smallest room where the density limit is
exceeded, the volume of the next smallest room becomes
the object.
3. The minimum indoor floor space compared with the
amount of refrigerant is roughly as follows: (When the
ceiling is 2.7 m high)
40.5
54.0
27.0
13.5
0.0 20100 30 40 60 70 80 90 100
50
67.5
81.0
94.5
108.0
121.5
135.0
148.5
162.0
175.5
189.0
202.5
216.0
229.5
243.0
256.0
270.0
m2m3
15
10
5
0
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
283.5
297.0
310.5
324.0
337.5
kg
Check of Density Limit
The room in which the air conditioner is to be installed
requires a design that in the event of refrigerant gas
leaking out, its density will not exceed a set limit.
The refrigerant (R410A), which is used in the air conditioner,
is safe, without the toxicity or combustibility of ammonia, and
is not restricted by laws imposed to protect the ozone layer.
However, since it contains more than air, it poses the risk of
suffocation if its density should rise excessively. Suffocation
from leakage of refrigerant is almost non-existent. With the
recent increase in the number of high density buildings,
however, the installation of multi air conditioner systems is
on the increase because of the need for effective use of floor
space, individual control, and energy conservation by curtailing
heat and carrying power, etc.
Most importantly, the multi air conditioner system is able
to replenish a large amount of refrigerant compared to
conventional individual air conditioners. If a single unit of the
multi air conditioner system is to be installed in a small room,
select a suitable model and installation procedure so that if the
refrigerant accidentally leaks out, its density does not reach the
limit (and in the event of an emergency, measures can be made
before injury can occur).
In a room where the density may exceed the limit, create an
opening with adjacent rooms, or install mechanical ventilation
combined with a gas leak detection device. The density is as
given below.
Total amount of refrigerant (kg)
Min. volume of the indoor unit installed room (m3)
< Density limit (kg/m 3)
The density limit of refrigerant which is used in multi air
conditioners is 0.3 kg/m 3(ISO 5149).
NOTE
1. If there are 2 or more refrigerating systems in a single
refrigerating device, the amount of refrigerant should be as
charged in each independent device.
For the amount of charge in this example:
The possible amount of leaked refrigerant gas in rooms A,
B and C is 10 kg.
The possible amount of leaked refrigerant gas in rooms D,
E and F is 15 kg.
e.g., charged
amount (10 kg)
Indoor unit
Outdoor unit
e.g., charged
amount (15 kg)
Room A Room B Room C Room D Room E Room F
Outdoor unit
Refrigerant tubing
Indoor unit
Mechanical ventilation device – Gas leak detector
Refrigerant tubing
Outdoor unit
Indoor unit
Very
small
room
Small
room
Medium
room
Large room
Range below the
density limit of
0.3 kg/m³
(Countermeasures
not needed)
Range above the
density limit of 0.3
kg/m³
(Countermeasures
needed)
Total amount of refrigerant
Min. indoor volume
Min. indoor floor area (when the ceiling is 2.7 m high)
SM830194-03BigPAC-i.indb4SM830194-03BigPAC-i.indb4 2012/10/1120:58:282012/10/1120:58:28

iv
—— CONTENTS ——
Section 1. SPECIFICATIONS .................................................................................................
1-1. Unit Specifications ...............................................................................................................
1-2. Major Component Specifications .......................................................................................
1-3. Other Component Specifications .......................................................................................
1-4. Dimensional Data ...............................................................................................................
1-5. Refrigerant Flow Diagram .................................................................................................
1-6. Operating Range ................................................................................................................
1-1
2-1
3-1
1-8
1-10
1-13
1-13
1-14
1-15
1-18
1-22
1-42
1-47
1-49
3-2
3-4
1-4
1-2
1-7. Capacity Correction Graph According to Temperature Condition ................................
1-8. Noise Criterion Curves ......................................................................................................
1-9. ELECTRICAL WIRING.........................................................................................................
1-10. Installation Instructions ...................................................................................................
1-13. How to select AHU system ..............................................................................................
Section 2. TEST RUN .............................................................................................................
Section 3. ELECTRICAL DATA ..............................................................................................
3-2. Indoor Units (Electric Wiring Diagram, Schematic Diagram) ..........................................
3-1. Outdoor Units (Electric Wiring Diagram, Schematic Diagram) .......................................
4-1
4-2
4-8
Section 4. PROCESS AND FUNCTIONS................................................................................
4-2. Outdoor Unit Control PCB....................................................................................................
4-134-6. Indoor Unit Control PCB Switches and Functions ..........................................................
4-1. Control Functions ................................................................................................................
5-1
5-2
5-4
Section 5. SERVICE PROCEDURES......................................................................................
5-2. Contents of LED Display on the Outdoor Unit Control PCB.............................................
5-55-3. Symptoms and Parts to Inspect ..........................................................................................
5-85-4. Details of Alarm Messages ..................................................................................................
5-145-5. Table of Thermistor Characteristics .................................................................................
5-155-6. How to Remove the Compressor ......................................................................................
5-165-7. How to Remove the Electrical Component Box ..............................................................
5-175-8. Symptom: Thermostat in OFF continues or cycles OFF & ON too frequently .............
5-1. Meaning of Alarm Messages ...............................................................................................
2-2
2-22-2. Caution...................................................................................................................................
2-22-3. Test Run Procedure..............................................................................................................
2-32-4. Items to Check Before the Test Run...................................................................................
2-32-5. Test Run Using the Remote Controller...............................................................................
2-32-6. Precautions............................................................................................................................
2-42-7. Table of Self-Diagnostic Functions and Corrections (E1 Type).......................................
2-52-8. System Control......................................................................................................................
2-82-9. Test Run Procedure..............................................................................................................
2-92-10. Items to Check Before the Test Run..................................................................................
2-92-11. Preparation for Test Run....................................................................................................
2-102-12. Test Run.............................................................................................................................
2-102-13. Precautions........................................................................................................................
2-112-14. Table of Self-Diagnostic Functions and Corrections.....................................................
2-122-15. System Control..................................................................................................................
2-1. Preparing for Test Run ........................................................................................................
E1 Type
2-152-16. Caution...............................................................................................................................
2-162-17. Test Run Procedure..........................................................................................................
2-172-18. Items to Check Before the Test Run...............................................................................
2-172-19. Test Run Using the Remote Controller...........................................................................
2-172-20. Table of Self-Diagnostic Functions and Corrections (E1 Type)...................................
2-182-21. Automatic Address Setting..............................................................................................
2-212-22. Automatic Address Setting..............................................................................................
2-232-23. Caution for Pump Down...................................................................................................
E1 Type (for Link Wiring)
4-94-3. Outdoor Unit Filter PCB FIL-C906VH8.................................................................................
4-104-4. Outdoor Unit HIC Board HIC-C906VH8..............................................................................
4-114-5. Outdoor Unit Control PCB (CR-C906VH8P)......................................................................
1-11. HOW TO PROCESS TUBING ...........................................................................................
1-12. LEAK TEST, EVACUATION AND ADDITIONAL REFRIGERANT CHARGE ..................
SM830194-03BigPAC-i.indb5SM830194-03BigPAC-i.indb5 2012/10/1120:58:282012/10/1120:58:28

v
7-1
7-2
7-3
Section 7. REMOTE CONTROLLER FUNCTIONS SECTION...............................................
7-2. List of Simple Setting Items.................................................................................................
7-47-3. Detailed Settings Function ..................................................................................................
7-57-4. List of Detailed Setting Items ..............................................................................................
7-97-5. Simple Setting Items ............................................................................................................
7-117-6. Detailed Setting Items ........................................................................................................
7-147-7. Remote Controller Servicing Functions ..........................................................................
7-147-8. Test Run Function ..............................................................................................................
7-1. Simple Settings Function ....................................................................................................
8-1
8-2
8-2
Section 8. HOW TO INSTALL THE WIRELESS REMOTE CONTROLLER RECEIVER.......
8-2. Warning about Installing Remote Controls.........................................................................
8-1. Warning about Installation of Receivers ............................................................................
6-1
6-2
6-2
Section 6. OUTDOOR UNIT MAINTENANCE REMOTE CONTROL.....................................
6-2. Functions...............................................................................................................................
6-36-3. Normal Display Operations and Functions .......................................................................
6-66-4.
Monitoring Operations: Display of Indoor Unit and Outdoor Unit Sensor Temperatures .....
6-76-5.
Monitoring the Outdoor Unit Alarm History: Display of Outdoor Unit Alarm History ..........
6-76-6. Settings Modes: Setting the Outdoor Unit EEPROM ........................................................
6-1. Overview ...............................................................................................................................
Warning
8-3
8-5
8-3
8-4. Installing Batteries................................................................................................................
8-58-5. Setting the Current Time.......................................................................................................
8-58-6. Operation................................................................................................................................
8-68-7. Timer Operation.....................................................................................................................
8-78-8. Adjusting the Wind Direction...............................................................................................
8-78-9. Operating Multiple In/Outdoor Units Simultaneously (Group Control)............................
8-78-10. Using the Remote Control..................................................................................................
8-88-11. For Best Results..................................................................................................................
8-88-12. Addresses............................................................................................................................
8-98-13. Emergency Operation.........................................................................................................
8-98-14. Miscellaneous Settings.......................................................................................................
8-108-15. Before Requesting Service...............................................................................................
8-108-16. How to Install the Wireless Remote Controller Receiver...............................................
8-3. Names and Functions ..........................................................................................................
Optional Controller (Remote Controller)...............................................................................
SM830194-03BigPAC-i.indb6SM830194-03BigPAC-i.indb6 2012/10/1120:58:282012/10/1120:58:28

1-1
1
1. SPECIFICATIONS
1-1. Unit Specifications.....................................................................................................
1-4
1-2
1-22
1-18
1-15
1-14
1-13
1-13
1-10
1-2. Major Component Specifications .............................................................................
1-81-3. Other Component Specifications .............................................................................
Outdoor Unit
Indoor Unit
5. Dimensions of Wind-proof Duct .........................................................................................................
1. Tubing Length ....................................................................................................................................
2. Check of limit density .........................................................................................................................
3. SELECTING THE INSTALLATION SITE ..........................................................................................1-24
1-27
1-33
1-34
1-37
1-22
1-23
8. SELECTING THE INSTALLATION SITE ..........................................................................................1-38
1-42
1-47
1-49
4. Dimensions of Air-Discharge Chamber..............................................................................................
6. Dimensions of Snow-proof Duct.........................................................................................................
7. HOW TO INSTALL THE OUTDOOR UNIT .......................................................................................
9. HOW TO INSTALL THE INDOOR UNIT ............................................................................................1-39
1-4. Dimensional Data .....................................................................................................
1-5. Refrigerant Flow Diagram .......................................................................................
1-6. Operating Range ......................................................................................................
1-7. Capacity Correction Graph According to Temperature Condition .....................
1-8. Noise Criterion Curves ............................................................................................
1-9. ELECTRICAL WIRING..............................................................................................
1-10. Installation Instructions ..........................................................................................
1-11. HOW TO PROCESS TUBING ...................................................................................
1-12. LEAK TEST, EVACUATION AND ADDITIONAL REFRIGERANT CHARGE ..........
1-13. How to select AHU system ......................................................................................
SM830194-02BigPAC-i.indb1SM830194-02BigPAC-i.indb1 2012/09/0311:23:342012/09/0311:23:34

1-2
1Single-Type
1-1. Unit Specifications
High Static Pressure Ducted Type S-200PE1E8 / U-200PE1E8
MODEL No. Indoor Unit
Outdoor Unit
POWER SOURCE Indoor Unit
Outdoor Unit
PERFORMANCE
Capacity [min~max] kW
BTU / h
Cooling
20.0 [6.0~22.4]
68,200 [20,500~76,400]
Heating
22.4 [6.0~25.0]
76,400 [20,500~85,300]
Air circulation (Hi / Me / Lo) m3/ h 3,360 / 3,190 / 2,980
–11.1Liters / hMoisture removal (High)
176 (18)Pa (mmAg)External static pressure (High)
ELECTRICAL RATINGS
VVoltage ratings
342~456(outdoor) 198~264(indoor)VAvailable voltage range
ARunning amperes*
AMax–Running amperes**
kWPower input
400
11.0
–
7.12
2.81W / WC.O.P
415
9.8
–
6.53
3.43
–
400
10.1
–
6.50
3.45
–
380
10.4
–
6.47
3.46
–
415
10.7
–
7.15
2.80
––
380
11.4
–
7.09
2.82
–AMax.Starting amperes
FEATURES
Controls / Thermostat control
Timer
Fan speeds Indoor / Outdoor
Airflow direction (Indoor)
Air filter
Remote controller (Option)
Refrigerant control
Drain pump (Drain connection)
Compressor
Operation sound
Indoor - Hi / Me / Lo dB-A
dB-A 5757Outdoor - Hi
Color
(Approximate value)
Indoor
Microprocessor / I.C.thermostat
ON / OFF 72-hours
3 and Automatic control / Variable
–
Field supply
Wired: CZ-RTC2 / Wireless: CZ-RWSC2
–
25A Male screw (No Drain Pump)
Rotary
48 / 47 / 46
–
Munsell 1Y 8.5 / 0.5Outdoor
REFRIGERANT TUBING Indoor unit Outdoor unit
Limit of tubing length
Limit of tubing length at shipment
Limit of elevation difference
between the two units m (ft.)
m (ft.)
m (ft.) 100 (328)
5~30(16~98)
Outdoor unit is higher than indoor unit: 30 (98)
Outdoor unit is lower than indoor unit: 30 (98)
Refrigerant tube
outer diameter
Liquid tube mm (in.)
Gas tube mm (in.)
kgRefrigerant amount at shipment
DIMENSIONS & WEIGHT
Unit dimensions
Height mm (in.)
Width mm (in.)
Depth mm (in.)
Package dimensions
Height mm (in.)
Width mm (in.)
Depth mm (in.)
kg (lb.)
kg (lb.)
Net weight
Shipping weight
mShipping volume 3 (cu.ft)
9.52 (3 / 8)
25.4 (1)*1
–
Indoor unit
467 (18-12 / 32)
1,428 (56-7 / 32)
1,230 (48-14 / 32)
614 (24-11 / 64)
1,536 (60-15 / 32)
1,339 (52-23 / 32)
110 (243)
134 (295)
1.268 (44.8)
9.52 (3 / 8)
25.4 (1)*1
R410A - 5.3
Outdoor unit
1526 (60-5 / 64)
940 (37-1 / 64)
340 (13-25 / 64)
1676 (65-63 / 64)
1076 (42-23 / 64)
420 (16-17 / 32)
118 (260)
128 (282)
0.757 (26.7)
NOTE DATA SUBJECT TO CHANGE WITHOUT NOTICE.
*1 There are two types of supplied tubings. The one tubing port ø19.05 (flare process) is connected to the flared connection of the gas port
side’s service valve. The other “L” shaped tubing port is brazed in connection after cutting the tube at the proper length.
Then make a brazing connection to the main tubing (ø25.4).
Cooling:
Rating conditions (*): Indoor air temperature 27°C DB/19°C WB, Outdoor air temperature 35°C DB
Full load conditions (**): Indoor air temperature 32°C DB/23°C WB, Outdoor air temperature 43°C DB
Heating:
Rating conditions (*): Indoor air temperature 20°C DB, Outdoor air temperature 7°C DB/6°C WB
Full load conditions (**): Indoor air temperature 24°C DB, Outdoor air temperature 24°C DB/15.5°C WB
U-200PE1E8
220-230-240V, 50/60Hz, single-phase
380-400-415V, 50/60Hz, 3-phase
S-200PE1E8
SM830194-02BigPAC-i.indb2SM830194-02BigPAC-i.indb2 2012/09/0311:23:342012/09/0311:23:34

1-3
1
Single-Type
1-1. Unit Specifications
High Static Pressure Ducted Type S-250PE1E8 / U-250PE1E8
–
57
Indoor unit
12.7 (1 / 2)
25.4 (1)
–
Indoor unit
467 (18-12 / 32)
1,428 (56-7 / 32)
1,230 (48-14 / 32)
614 (24-11 / 64)
1,536 (60-15 / 32)
1,339 (52-23 / 32)
120 (256)
144 (317)
1.268 (44.8)
Outdoor unit
1526 (60-5 / 64)
940 (37-1 / 64)
340 (13-25 / 64)
1676 (65-63 / 64)
1076 (42-23 / 64)
420 (16-17 / 32)
128 (282)
138 (304)
0.757 (26.7)
NOTE DATA SUBJECT TO CHANGE WITHOUT NOTICE.
*1 There are two types of supplied tubings. The one tubing port ø19.05 (flare process) is connected to the flared connection of the gas port
side’s service valve. The other “L” shaped tubing port is brazed in connection after cutting the tube at the proper length.
Then make a brazing connection to the main tubing (ø25.4).
Cooling:
Rating conditions (*): Indoor air temperature 27°C DB/19°C WB, Outdoor air temperature 35°C DB
Full load conditions (**): Indoor air temperature 32°C DB/23°C WB, Outdoor air temperature 43°C DB
Heating:
Rating conditions (*): Indoor air temperature 20°C DB, Outdoor air temperature 7°C DB/6°C WB
Full load conditions (**): Indoor air temperature 24°C DB, Outdoor air temperature 24°C DB/15.5°C WB
MODEL No. Indoor Unit
Outdoor Unit
POWER SOURCE Indoor Unit
Outdoor Unit
PERFORMANCE
Capacity [min~max] kW
BTU / h
Air circulation (Hi / Me / Lo) m3/ h
Liters / hMoisture removal (High)
Pa (mmAg)External static pressure (High)
ELECTRICAL RATINGS
VVoltage ratings
VAvailable voltage range
ARunning amperes*
AMax–Running amperes**
kWPower input
W / WC.O.P
AMax.Starting amperes
FEATURES
Controls / Thermostat control
Timer
Fan speeds Indoor / Outdoor
Airflow direction (Indoor)
Air filter
Remote controller (Option)
Refrigerant control
Drain pump (Drain connection)
Compressor
Operation sound
Indoor - Hi / Me / Lo dB-A
dB-AOutdoor - Hi
Color
(Approximate value)
Indoor
Outdoor
REFRIGERANT TUBING
Limit of tubing length
Limit of tubing length at shipment
Limit of elevation difference
between the two units m (ft.)
m (ft.)
m (ft.)
Refrigerant tube
outer diameter
Liquid tube mm (in.)
Gas tube mm (in.)
kgRefrigerant amount at shipment
DIMENSIONS & WEIGHT
Unit dimensions
Height mm (in.)
Width mm (in.)
Depth mm (in.)
Package dimensions
Height mm (in.)
Width mm (in.)
Depth mm (in.)
kg (lb.)
kg (lb.)
Net weight
Shipping weight
mShipping volume 3 (cu.ft)
25.0 [6.0~28.0]
85,300 [20,500~95,500]
13.9
Cooling
28.0 [6.0~31.5]
95,500 [20,500~107,500]
–
Heating
14.8
–
9.55
2.62
–
400
12.3
–
8.26
3.39
–
415
12.6
–
8.20
3.41
–
400
13.1
–
8.14
3.44
–
380
14.3
–
9.61
2.60
–
415
15.3
–
9.49
2.63
–
380
S-250PE1E8
U-250PE1E8
4,320 / 4,200 / 3,960
216 (22): at shipment 235 (24): using the booster cable
ON / OFF 72-hours
–
Field supply
–
51 / 50 / 49
220-230-240V, 50/60Hz, single-phase
380-400-415V, 50/60Hz, 3-phase
342~456(outdoor) 198~264(indoor)
Microprocessor / I.C.thermostat
3 and Automatic control / Variable
Wired: CZ-RTC2 / Wireless: CZ-RWSC2
25A Male screw (No Drain Pump)
Rotary
Munsell 1Y 8.5 / 0.5
Outdoor unit is higher than indoor unit: 30 (98)
Outdoor unit is lower than indoor unit: 30 (98)
100 (328)
5~30(16~98)
58
Outdoor unit
12.7 (1 / 2)
R410A - 6.5
25.4 (1)*1
SM830194-02BigPAC-i.indb3SM830194-02BigPAC-i.indb3 2012/09/0311:23:342012/09/0311:23:34

1-4
11-2. Major Component Specifications
(A) Indoor Units
High Static Pressure Ducted Type S-200PE1E8
MODEL No.
Source
Controller P.C.B. Ass'y
Fan (Number...diameter) mm
Fan motor
WModel...Nominal output
Power source
rpmNo. of pole...r.p.m. (230V, High)
Coil resistance
(Ambient temperature 20°C) Ω
BRN – WHT : 13.75
WHT – VLT : 4.47
VLT – ORG : 1.20
ORG – YEL : 2.21
YEL – BLK : 10.33
BLK – PNK : 12.90
Safety device
Operating temperature Open °C
Close °C
VAC, µFRun capacitor
Electronic expansion valve
Coil
Coil resistance (at 20°C) Ω
Valve body
Heat exchanger
Coil
mmRows...fin pitch
mFace area 2
S-200PE1E8
220 - 230 - 240V, single-phase, 50/60Hz
CR-UXRP71B-P (Microprocessor)
Centrifugal (2...ø220)
KFC4X-201B5P...180W
220 - 230 - 240V, single-phase, 50Hz
4P...1,012
130 ± 5
(115 ± 5)
450 VAC, 7.0 µF
–
–
–
Aluminium plate fin / Copper tube
3...2.0
0.540
SM830194-02BigPAC-i.indb4SM830194-02BigPAC-i.indb4 2012/09/0311:23:352012/09/0311:23:35

1-5
1
1-2. Major Component Specifications
(A) Indoor Units
High Static Pressure Ducted Type S-250PE1E8
BRN – WHT : 6,159
WHT – VLT : 1.08
VLT – ORG : 0.77
ORG – YEL : 0.87
YEL – BLK : 2.87
BLK – PNK : 5.98
MODEL No.
Source
Controller P.C.B. Ass'y
Fan (Number...diameter) mm
Fan motor
WModel...Nominal output
Power source
rpmNo. of pole...r.p.m. (230V, High)
Coil resistance
(Ambient temperature 20°C) Ω
Safety device
Operating temperature Open °C
Close °C
VAC, µFRun capacitor
Electronic expansion valve
Coil
Coil resistance (at 20°C) Ω
Valve body
Heat exchanger
Coil
mmRows...fin pitch
mFace area 2
S-250PE1E8
220 - 230 - 240V, single-phase, 50Hz
CR-UXRP71B-P (Microprocessor)
Centrifugal (2...ø250)
–
–
–
KFC4X-401B3P...400W
220 - 230 - 240V, single-phase, 50Hz
4P...1,211
130 ± 5
(115 ± 5)
450 VAC, 5.0 µF
Aluminium plate fin / Copper tube
3...2.0
0.655
SM830194-02BigPAC-i.indb5SM830194-02BigPAC-i.indb5 2012/09/0311:23:352012/09/0311:23:35

1-6
11-2. Major Component Specifications
(B) Outdoor Units
U-200PE1E8
MODEL No.
Source
Controller P.C.B. Ass'y
Control circuit fuse
Compressor
Model....number
Source
WNominal output
ccCompressor oil
Coil resistance
(Ambient temperature 25°C) ΩC – R : 0.552 R – S : 0.552
C – S : 0.552
Safety control
Overload relay models
Operation temperature Open °C
Close °C
WCrank case heater
Refrigerant amount at shipment kg
High pressure switch
Set pressure MPaOFF 4.15 0
– 0.15
3.15 ± 0.3MPaON
Fan
mmNumber...diameter
m3/ hAir circulation
Fan speeds (Max.)
Fan motor
Model No.
Source
No. of pole
WNominal output
Safety device
Operating temperature Open °C
Close °C
VAC, µF
Heat exchanger
Coil
mmRows...fin pitch
m2
U-200PE1E8
380-400-415V, 3-phase, 50/60Hz
CR-C906VH8P (Microprocessor)
20A
C-9RVN273H0K
246V (DC) / 3-phase / 60Hz (Inverter drive)
4,200
1,400
Discharge temperature control
–
–
25
R410A - 5.3
2...ø490
7,740
~860 rpm (Inverter drive control)
SIC-71FW-D8120
~280V / 3-phase
8
120
–
–
–
–
Aluminium plate fin / Copper tube
2...1.4
1.27Face area
Run capacitor
SM830194-02BigPAC-i.indb6SM830194-02BigPAC-i.indb6 2012/09/0311:23:352012/09/0311:23:35

1-7
1
1-2. Major Component Specifications
(B) Outdoor Units
U-250PE1E8
C – R : 0.608 R – S : 0.608
C – S : 0.608
MODEL No.
Source
Controller P.C.B. Ass'y
Control circuit fuse
Compressor
Model....number
Source
WNominal output
ccCompressor oil
Coil resistance
(Ambient temperature 25°C) Ω
Safety control
Overload relay models
Operation temperature Open °C
Close °C
WCrank case heater
Refrigerant amount at shipment kg
High pressure switch
Set pressure MPaOFF
MPaON
Fan
mmNumber...diameter
m3/ hAir circulation
Fan speeds (Max.)
Fan motor
Model No.
Source
No. of pole
WNominal output
Safety device
Operating temperature Open °C
Close °C
VAC, µF
Heat exchanger
Coil
mmRows...fin pitch
m2
Face area
Run capacitor
U-250PE1E8
380-400-415V, 3-phase, 50/60Hz
CR-C906VH8P (Microprocessor)
20A
282V (DC) / 3-phase / 60Hz (Inverter drive)
5,500
1,900
–
–
25
R410A - 6.5
2...ø490
7,080
~860 rpm (Inverter drive control)
SIC-71FW-D8120
~280V / 3-phase
8
120
–
–
–
–
3...1.4
1.27
C-9RVN393H0U
Discharge temperature control
Aluminium plate fin / Copper tube
4.15 0
– 0.15
3.15 ± 0.3
SM830194-02BigPAC-i.indb7SM830194-02BigPAC-i.indb7 2012/09/0311:23:352012/09/0311:23:35

1-8
11-3. Other Component Specifications
Outdoor Units U-200PE1E8
MODEL No. Outdoor Unit
Power Transformer
Rated
VAC, HzSource
Secondary
Coil resistance Ω
Thermistor (Coil / Air sensor): TH1, TH2, TH3, TH4
Resistance kΩ –10°C: 23.7±5% 20°C: 6.5±5%
–5°C: 18.8±5% 30°C: 4.4±5%
0°C: 15.0±5% 40°C: 3.1±5%
5°C: 12.1±5% 45°C: 2.6±5%
10°C: 9.7±5% 50°C: 2.1±5%
Thermistor (Discharge gas sensor): TH5
Resistance kΩ 60°C: 12.4±5% 90°C: 4.6±5%
70°C: 8.7±5% 100°C: 3.4±7%
75°C: 7.4±5% 110°C: 2.5±7%
80°C: 6.3±5% 120°C: 1.9±7%
85°C: 5.3±5% 130°C: 1.5±7%
Relay (Comp. Magnetic Contactor)
VACCoil rated
VAC, AContact rating
Coil resistance (at 20°C) Ω
Sol-Control-Valve
4 way valve
4 way valve
Electro magnetic coil
Thermal cut off temperature
Sol-control-valve
Magnetic coil
U-200PE1E8
–
–
–
–
–
–
KTM-35D-S1, DTN-C532G3H
CM-12
–
–
–
UKV-25D18
STF-0401G
STF-01AI518A1, AC 220-240 V, 50Hz / 60Hz
UKV-A053 (062), DC 12V
SM830194-02BigPAC-i.indb8SM830194-02BigPAC-i.indb8 2012/09/0311:23:352012/09/0311:23:35

1-9
1
1-3. Other Component Specifications
Outdoor Units U-250PE1E8
–
–
–
–
–
–
–
KTM-35D-S1, DTN-C532G3H
CM-12
–
–
–
UKV-25D18
UKV-U030E, DC 12 V
STF-0712G
STF-01AI518A1, AC 220-240 V, 50Hz / 60Hz
MODEL No. Outdoor Unit
Power Transformer
Rated
VAC, HzSource
Secondary
Coil resistance Ω
Thermistor (Coil / Air sensor): TH1, TH2, TH3, TH4
Resistance kΩ
Thermistor (Discharge gas sensor): TH5
Resistance kΩ
Relay (Comp. Magnetic Contactor)
VACCoil rated
VAC, AContact rating
Coil resistance (at 20°C) Ω
Sol-Control-Valve
4 way valve
4 way valve
Electro magnetic coil
Thermal cut off temperature
Sol-control-valve
Magnetic coil
–10°C: 23.7±5% 20°C: 6.5±5%
–5°C: 18.8±5% 30°C: 4.4±5%
0°C: 15.0±5% 40°C: 3.1±5%
5°C: 12.1±5% 45°C: 2.6±5%
10°C: 9.7±5% 50°C: 2.1±5%
60°C: 12.4±5% 90°C: 4.6±5%
70°C: 8.7±5% 100°C: 3.4±7%
75°C: 7.4±5% 110°C: 2.5±7%
80°C: 6.3±5% 120°C: 1.9±7%
85°C: 5.3±5% 130°C: 1.5±7%
U-250PE1E8
SM830194-02BigPAC-i.indb9SM830194-02BigPAC-i.indb9 2012/09/0311:23:352012/09/0311:23:35

1-10
11-4. Dimensional Data
(A) Indoor Units: High Static Pressure Ducted Type
S-200PE1E8
S-250PE1E8
479
300
100
2
100
100
42
1428
1310
71 110051
964
9×100P=900
4 - 37 ×12
10×100P=1000
106 44
1070 1310
67
67
113
(236) 364364 1334
60
43320
100
50
178
23
209 344
1222
41
1170 1100
5555 1200
1310
Refrigerant tubing joint (liquid tube ø12.7 mm) (Flare nut) Refrigerant tubing joint (gas tube ø25.4 mm) (Brazing) Power supply outlet Drain port (O.D. 32 mm) Duct connection for suction Duct connection for discharge
1170 (Suspension bolt pitch)
28-ø3.5 (Holes all around)
1200 (Suspension bolt pitch)
(Hole for suspension bolt)
26-ø3.5 (Holes all around)
Unit: mm
Min. 600
(Space for
service)
Air suction side
(Suspension bolt pitch)
Min. 700 (Space for service) Refrigerant
tubing
Inspection
access
(600 x 600)
Electrical component box
Min. 610
Min. 130 Drain port
Drain pan
Ceiling face
Unit: mm
(Suspension bolt pitch)
SM830194-02BigPAC-i.indb10SM830194-02BigPAC-i.indb10 2012/09/0311:23:352012/09/0311:23:35

1-11
1
1
2
3
4
5
6
7
8
8
857
60
42
49
111
586
3077
22
39
940
A
18
410
10
20 380
26
290
105 219 75 75
170 660 110
13
60
34040
13
B
340
42
49
111
30
77
85 64
22
60
1526
25
4
8
7
6
5
8
7
6
5
4
3
2
1
R30
63 80
58
6149
759
60
3
33
52
46
65
121
43
486
5
7
5.5 62 49
67 7.5
1-4. Dimensional Data
(B) Outdoor Unit: U-200PE1E8
Air discharge
Air
intake
Unit: mm
VIEW A
Air
discharge
Air
intake
Anchor bolt
Anchor bolt
Air intake
Anchor bolt
Anchor bolt
VIEW B
Anchor bolt
2 x ø32 holes (holes for drain)
Of the 4 ø32 holes , use 1 of the 2 holes
specified for drain use to install the port. Use
rubber plugs to seal the remaining 3 holes.
Mounting hole (4-R6.5),
anchor bolt : M10
Refrigerant tubing (liquid tube),
flared connection (ø9.52)
Refrigerant tubing (gas tube),
flared connection (ø19.05)
Refrigerant tubing port
Electrical wiring port (ø16)
Electrical wiring port (ø19)
Electrical wiring port (ø29)
Electrical wiring port (ø38)
Bottom removable connection port Refrigerant tubing connection port
Remark:
There are two types of supplied tubings. The
one tubing port ø19.05 (flare process) is
connected to the flared connection of the gas
port side's service valve. The other "L" shaped
tubing port is brazed in connection after cutting
the tube at the proper length. Then make a
brazing connection to the main tubing (ø25.4).
Name Figure Q'ty
Reducing Joint Tube
(ø19.05 ø25.4) 1
Joint Tube (ø19.05) 1
SM830194-02BigPAC-i.indb11SM830194-02BigPAC-i.indb11 2012/09/0311:23:352012/09/0311:23:35

1-12
1
Air discharge
Air
intake
Unit: mm
VIEW A
Air
discharge
Air
intake
Anchor bolt
Anchor bolt
Air intake
Anchor bolt
Anchor bolt
VIEW B
Anchor bolt
2 x ø32 holes (holes for drain)
Of the 4 ø32 holes , use 1 of the 2 holes
specified for drain use to install the port. Use
rubber plugs to seal the remaining 3 holes.
Mounting hole (4-R6.5),
anchor bolt : M10
Refrigerant tubing (liquid tube),
flared connection (ø12.7)
Refrigerant tubing (gas tube),
flared connection (ø19.05)
Refrigerant tubing port
Electrical wiring port (ø16)
Electrical wiring port (ø19)
Electrical wiring port (ø29)
Electrical wiring port (ø38)
Bottom removable connection port Refrigerant tubing connection port
Remark:
There are two types of supplied tubings. The
one tubing port ø19.05 (flare process) is
connected to the flared connection of the gas
port side's service valve. The other "L" shaped
tubing port is brazed in connection after cutting
the tube at the proper length. Then make a
brazing connection to the main tubing (ø25.4).
Name Figure Q'ty
Reducing Joint Tube
(ø19.05 ø25.4) 1
Joint Tube (ø19.05) 1
1-4. Dimensional Data
(B) Outdoor Unit: U-250PE1E8
8
857
60
42
49
111
586
30
77
22
39
940
A
18
410
10
20 380
26
290
105 219 75 75
170 660 110
13
60
34040
13
B
R30
5.5 62 49
67 7.5
63 80
58
6149
340
759
60
3
33
52
46
65
121
43
42
49
111
30
77
85 64
22
60
1526
25
8
5
6
8
4
7
5
6
8
4
1
2
3
4
56
7
7
1
2
3
4
5
6
7
8
SM830194-02BigPAC-i.indb12SM830194-02BigPAC-i.indb12 2012/09/0311:23:362012/09/0311:23:36

1-13
1
S
HP
M
M
EC
P
ø9.52
(3/4")
S
HP
M
M
EC
P
ø12.7
(3/4")
1-5. Refrigerant Flow Diagram
Outdoor Unit : U-200PE1E8
Outdoor Unit : U-250PE1E8
Indoor Unit : S-200PE1E8
Compressor
High pressure
switch
Heat
exchanger
Accumulator
Gas line
service valve
Check valve 4-way valve
Liquid line
service valve
Freeze-prevention coil
(Attached to the heat exchanger)
Strainer
Heat
exchanger
Strainer
Distributor
Heat
exchanger
Strainer
Distributor
Heat
exchanger
Distributor
Accumulator
Compressor
Accumulator
Gas line
service valve
4-way valve
Liquid line
service valve
Strainer
Freeze-prevention coil
(Attached to the heat exchanger)
Accumulator
Strainer
Cooling cycle
Heating cycle
Solenoid
valve
Solenoid
valve
Distributor
Liquid tank
Strainer
ø25.4 (brazing)
Solenoid
valve
High pressure
switch
Check valve
Solenoid
valve
ø25.4 (brazing)
Temperature
Cooling
Heating
Outdoor air intake temp.
43°C DB
–15°C DB
15°C WB
–20°C WB
Indoor air intake temp.
32°C DB / 23°C WB
18°C DB / 14°C WB
30°C DB / – WB
-
Minimum
Minimum
Maximum
Maximum
1-6. Operating Range
Indoor Unit : S-250PE1E8
SM830194-02BigPAC-i.indb13SM830194-02BigPAC-i.indb13 2012/09/0311:23:362012/09/0311:23:36

1-14
1
1.0 1.0 0.97 0.96 0.96 0.95 0.94 0.890.91 0.88 0.87 0.870.87 0.88 0.89
-20 -15 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 6543
1.00.950.91 0.92
60
80
80
60
40
100
120
140
352515545-15
100
120
-5 -10 5010-5
120
40
60
80
100
120
40
60
80
100
15-15-20
0
0
20
40
60
80
100
120
140
20
40
60
80
100
120
140
0
0
20
40
60
80
100
120
140
20
40
60
80
100
120
140
4 6 8 10 12 14 16 18 20 22 24 264 6 8 10 12 14 2016 18 22 24
46 8101214 2016 18 22 24 26 28 30 4 6 8 10 12 14 2016 18 22 24 26 28 30 32
Input coefficient (%) Capacity coefficient (%) Input coefficient (%) Capacity coefficient (%)
Cooling capacity ratio (maximum capacity) Heating capacity ratio (maximum capacity)
1-7. Capacity Correction Graph According to Temperature Condition
U-200PE1E8 / U-250PE1E8 (For 50 Hz and 60 Hz)
Indoor air intake temp (WB)
22WB
19WB
16WB
22WB
19WB
16WB
Indoor air intake temp (WB)
Outdoor air intake temp (°C DB)
16°C
20°C
24°C
Outdoor air intake temp (°C DW)
24°C
20°C
16°C
125%
U-200PE1E8
Power consumption ratio (%)
Capacity (kW)
Rated capacity ratio for cooling
121%
Power consumption ratio (%)
Capacity (kW)
Rated capacity ratio for heating
123%
U-250PE1E8
Power consumption ratio (%)
Capacity (kW)
Rated capacity ratio for cooling
125%
Power consumption ratio (%)
Capacity (kW)
Rated capacity ratio for heating
1. The graphs " " of the characteristics show the value under the following conditions.
Equivalent tubing length : 7.5m
Difference of elevation : 0m
Wind speed : High
2. " " marking indicates the maximum capacity / maximum power consumption under the JIS condition.
Maximum capacity indicates the maximum value in the parentheses of the specifications (cooling and heating capacity).
3. The characteristic of heating capacity excludes the decline of capacity when frosting (including defrost drive).
NOTE 1
1. The graphs " " of the characteristics show the value under the following conditions.
Equivalent tubing length : 7.5m
Difference of elevation : 0m
Wind speed : High
2. " " marking indicates the rated capacity / rated power consumption under the JIS condition.
" " marking indicates the maximum capacity / maximum power consumption under the JIS condition.
3. The characteristic of heating capacity excludes the decline of capacity when frosting (including defrost drive).
NOTE 2
To calculate the heating capacity with consideration for frosting/defrosting operation, multiply the heating
capacity found from the capacity graph by the correction coefficient from the table above.
Outdoor unit heating capacity correction coefficient during of frosting/defrosting (RH approximately 85%)
Outdoor intake air
temperature
°C WB
Correction coefficient
Indoor air intake temp (°C WB)
Indoor air intake temp (°C WB)
SM830194-02BigPAC-i.indb14SM830194-02BigPAC-i.indb14 2012/09/0311:23:362012/09/0311:23:36
