Panasonic POD7C User manual

Housings:
Outdoor Dome
POD7C,
POD7CW
PRODUCT FEATURES
• Pendant or wall mount models are available
• Easy camera installation
• Tamper resistant access screws
• 24 Hour fan operation for effective heating and
condensation protection
• Thermostatically control 24VAC heater
• Separate power input for H&B and camera power
• Surge protection for video line and power line
• Ground-loop protection by optional unit PWBT1621
(Isolation Transformer)
• Optically clear dome material
SHIPPING
POD7C/POD7CW: 11 lbs 17” x 14” x 18”
DESCRIPTION
The POD7C and POD7CW are 7” outdoor dome housings for
CS564/CS854A/WV-NS324 unitized dome camera systems.
A heater and blower are standard on all models.
ELECTRICAL SPECIFICATIONS:
Power:
24 VAC 52 watts (excluding camera)
24 VAC 68 watts with camera
Surge Protector (Video):
Clamping differential node voltage between 240 - 300V and common
mode voltage from 27 - 36V
Ground Loop Isolator (Optional)
Model No.: PWBT1621
60Hz hum rejection: 1000V p-p
Bandpass: 10Hz to 25MHz
Insertion Loss: 0.3dB
MECHANICAL SPECIFICATIONS:
Size (hxwxd):
POD7C: 14” x 10” x 10”
POD7CW: 14” x 15” x 10”
Weight: 6.6 lbs. (without camera)
Construction:
Upper Housing: .25” high impact, UV stable white ABS plastic
Lower Dome: 7” Cell-cast acrylic (Distortion free)
Internal Brackets: 14 and 16-gauge powder coated steel
Mounting Brackets: Cast or machined aluminum
ENVIRONMENTAL SPECIFICATIONS:
Operating Temperature: -20° F to +120 F
Heater activates at +40° F (+/- 8°),
deactivates at +60° F (+/- 5° F), 24vac, 50W
Blower : Continuous operation
STANDARD ACCESSORIES:
• 8 pc. Molex male pins
• 2 pc. Molex 4 position connectors
• 1 pc. POD7C/CW Instructions
• 4 pc. 8-32 Phillips head screws for mount camera
• 3 pc. Cable ties for wire management
• 1 pc. Security tool (Toolhead driver)
MODELS:
POD7C - Dome Housing, Outdoor, 7”, Pendant Mount, Clear
Dome for Unitized Cameras
POD7CW - Dome Housing, Outdoor, 7”, Wall Mount, Clear
Dome for Unitized Cameras
OPTIONS/ACCESSORIES:
POD7C:
PPMF12D - Pendant Mount Bracket
PWM20G - Aluminum, Gooseneck Wall Mount Bracket
PWM30G - Aluminum, Parapet Mount Bracket w/o extension
PPRM30G - Aluminum, Parapet Mount Bracket
POD7CW:
PACA2 - Aluminum, Corner Mount Adaptor
PAPM3 - Aluminum, Pole Mount Adaptor
PSRCW2000B - Heavy-Duty Parapet Mount Bracket

DISTRIBUTED BY:
Panasonic Digital Communications & Security Company
Unit of Matsushita Electric Corporation of America
Security Systems
Executive Office: Three Panasonic Way, Secaucus, NJ 07094
Zone Offices:
Eastern: One Panasonic Way, Secaucus, NJ 07094 [phone]
Central: 1707 North Randall Road, Elgin, IL 60123 [phone]
Western: 6550 Katella Avenue, Cypress, CA 90630 [phone]
www.panasonic.com/cctv
4x .44O
3.25
2.00
.70R
1.67
1.18
2.13 5.50
3.50
3.05
2.73
8.25
10.72
7.00
9.84
5.06
2.25
2.79
9.17 7.00
POD7CW
POD7C
THREADEDS
1 1/2" NPT
POD7C,
POD7CW
BID SPECIFICATIONS
The outdoor dome camera housing shall be a Panasonic Model POD7C, POD7CW or equivalent. The housing
shall be designed for the Unitized Surveillance Device Series WV-CS564/CS854A/WVNS324. The housing shall
be constructed of UV stable white ABS plastic, acrylic, and aluminum & steel brackets. The lower dome portion
shall be constructed of distortion-free acrylic and be 7” in diameter, and shall be held in place with minimum of
(3) security fasteners. The housing shall include a camera mounting bracket that integrates a heater, blower,
video and power surge protector capable of clamping differential node voltage between 240 - 300V and
common mode voltage from 27 - 36V. A ground isolation transformer, Panasonic Model PWBT1621, shall be
available as an option. The housing shall support a temperature range of -20 to 120°F, with the 50W heater
turning on at 40°F and turn off at 60°F. The housing shall be powered with 24VAC (60Hz) and have a power
consumption not to exceed 68W including Unitized Camera. Pendant mount model (POD7C) shall include
an integral fitting compatible with standard 1 1/2” NPT pipe suitable for outdoor pendant mounting. The
POD7CW shall include an integral wall mount with four (4) mounting holes in a 5.5”H x 2”W mounting pattern.
