Panasonic Lumix H-FSA14140 User manual

Owner’s Manual
INTERCHANGEABLE LENS FOR DIGITAL CAMERA
Model No. H-FSA14140
PP
Please read these instructions carefully before using this product, and save this manual for future use.
If you have any questions, visit:
USA : http://shop.panasonic.com/support
Canada : www.panasonic.ca/english/support
DVQX1826ZA
F0319AR0
Register online at http://shop.panasonic.com/support (U.S. customers only)
until
2019/05/01
H-FSA14140_OI_DVQX1826ZA_eng.spa.book 1 ページ ２０１９年３月１８日 月曜日 午前１１時５１分

2
DVQX1826 (ENG)
Contents
Information for Your Safety.....................................2
Precautions........................................................... 4
Supplied Accessories ............................................. 5
Names and Functions of Components ................... 5
Attaching/Detaching the Lens................................. 6
Cautions for Use..................................................... 9
Troubleshooting .................................................... 9
Specifications........................................................ 10
Limited Warranty (ONLY FOR U.S.A.) ................. 11
Limited Warranty (ONLY FOR CANADA)............. 14
Information for Your Safety
Keep the unit as far away as possible from
electromagnetic equipment (such as microwave
ovens, TVs, video games, radio transmitters,
high-voltage lines etc.).
≥Do not use the camera near cell phones because
doing so may result in noise adversely affecting
the pictures and sound.
≥If the camera is adversely affected by
electromagnetic equipment and stops functioning
properly, turn the camera off and remove the
battery and/or the connected AC adaptor. Then
reinsert the battery and/or reconnect the AC
adaptor and turn the camera on.
The lens can be used with a digital camera
compatible with the lens mount standard for the
“Micro Four ThirdsTM System”.
≥It cannot be mounted on the Four ThirdsTM mount
specification camera.
≥The appearance and specifications of products
described in this manual may differ from the actual
products you have purchased due to later
enhancements.
≥Micro Four ThirdsTM and Micro Four Thirds Logo
marks are trademarks or registered trademarks of
Olympus Corporation, in Japan, the United States,
the European Union and other countries.
≥Four ThirdsTM and Four Thirds Logo marks are
trademarks or registered trademarks of Olympus
Corporation, in Japan, the United States, the
European Union and other countries.
≥G MICRO SYSTEM is a lens exchange type
digital camera system of LUMIX based on a Micro
Four Thirds System standard.
≥Other names of systems and products mentioned
in these instructions are usually the registered
trademarks or trademarks of the manufacturers
who developed the system or product concerned.
H-FSA14140_OI_DVQX1826ZA_eng.spa.book 2 ページ ２０１９年３月１８日 月曜日 午前１１時５１分

3
(ENG) DVQX1826
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
FCC Note:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
≥Reorient or relocate the receiving antenna.
≥Increase the separation between the equipment and
receiver.
≥Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
≥Consult the dealer or an experienced radio/TV technician
for help.
FCC Caution:
≥Any unauthorized changes or modifications to this
equipment would void the user’s authority to operate this
device.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Supplier’s Declaration of Conformity
Trade Name: Panasonic
Model No.: H-FSA14140
Responsible Party:
Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ
07102-5490
Support Contact: http://shop.panasonic.com/support
THE FOLLOWING APPLIES ONLY IN CANADA.
CAN ICES-3(B)/NMB-3(B)
ENGLISH
H-FSA14140_OI_DVQX1826ZA_eng.spa.book 3 ページ ２０１９年３月１８日 月曜日 午前１１時５１分

4
DVQX1826 (ENG)
∫Lens Care
≥Do not press the lens with excessive force.
≥When there is dirt (water, oil, and fingerprints, etc.)
on the surface of the lens, the picture may be
affected. Lightly wipe the surface of the lens with a
soft, dry cloth before and after taking pictures.
≥
When the lens is not in use, be sure to attach the
lens cap and lens rear cap to prevent dust and other
particles from accumulating on or entering the lens.
≥To protect the lens contact points 1, do not place
the lens with its mount surface facing down. In
addition, do not allow the lens contact points to
become dirty.
∫Dust and splash resistant
≥The dust and splash resistant of the camera
will not prevent the entry of dust or water
droplets completely. Take the following
precautions to provide satisfactory dust and
splash resistant performance. If the lens is not
working properly, consult the dealer or your
nearest Service Center.
–Attach to a digital camera that is dust and
splash resistant.
– When attaching or removing the lens, be careful so
that foreign objects such as sand, dust, and water
droplets do not adhere to or enter the lens mount
rubber, contact points, digital camera and lens.
–If the lens is exposed to water droplets or other
liquids, wipe them off with a soft, dry cloth.
≥To improve the dust and splash resistant
performance of the lens, a lens mount rubber is
used in the mount.
–The lens mount rubber will leave scuff marks on
the digital camera mount, but this does not
impact performance.
–For information on changing the lens mount
rubber, contact your nearest Service Center.
∫About Condensation (Fogging of the
Lens)
≥Condensation occurs when the ambient
temperature or humidity changes. Please be
careful, as it may cause lens stains, mold and
malfunction.
≥If condensation occurs, turn off the digital camera
and leave it for approx. 2 hours. The fog will
disappear naturally when the temperature of the
digital camera becomes close to the ambient
temperature.
Precautions
H-FSA14140_OI_DVQX1826ZA_eng.spa.book 4 ページ ２０１９年３月１８日 月曜日 午前１１時５１分

5
(ENG) DVQX1826
Supplied Accessories
Product numbers correct as of March 2019. These
may be subject to change.
1Lens Pouch
2Lens Hood
3Lens Cap
4Lens Rear Cap
(The lens rear cap and lens cap are attached to
the interchangeable lens at the time of purchase.)
Names and Functions of
Components
1Lens surface
2Focus ring
Rotates the focus ring to focus when set to MF
(manual focus).
3Zoom ring
Rotate the zoom ring when you wish to take large
(tele) or wide (wide angle) pictures.
4O.I.S. switch
When the lens is attached to the camera, the image
stabilizer function is set to activate if the O.I.S.
switch is set to [ON].
VFC4430 VYC1119 VYF3514 VFC4605
2134
1 2 3 4 5 76
H-FSA14140_OI_DVQX1826ZA_eng.spa.book 5 ページ ２０１９年３月１８日 月曜日 午前１１時５１分

6
DVQX1826 (ENG)
≥We recommend setting the O.I.S. switch to [OFF]
when using a tripod.
5Lens fitting mark
6Contact points
7Lens mount rubber
Note
≥There may be differences in focus when you use
zoom after focusing. Focus again.
≥If the sounds of AF (auto focus) operation and
image stabilizer operation bother you during video
recording, it is recommended to record as follows:
– Set to MF (manual focus) to record.
– Set the O.I.S. switch to [OFF] and use a tripod to
record.
Attaching/Detaching the Lens
≥Refer also to the camera’s
owner’s manual for attaching
and detaching the lens.
≥Check that the camera is turned
off.
≥Remove the lens rear cap from the lens.
∫Attaching the Lens
Align the lens fitting
marks A on the
camera body and the
lens and then rotate
the lens in the
direction of the arrow
until it clicks.
• Do not press the lens release button B when
you attach a lens.
• Do not try to attach the lens when holding it at an
angle to the camera body as the lens mount may
get scratched.
• Check that the lens is attached correctly.
• Be sure to remove the lens cap when recording.
H-FSA14140_OI_DVQX1826ZA_eng.spa.book 6 ページ ２０１９年３月１８日 月曜日 午前１１時５１分

7
(ENG) DVQX1826
∫Detaching the Lens
While pressing on the
lens release button B,
rotate the lens toward
the arrow until it stops
and then remove.
• Attach the lens rear cap
so that the lens contact
point does not get scratched.
• Be sure to attach the body cap to the digital
camera to prevent dirt and dust from getting
inside the camera body.
∫Attaching the Lens Hood
(Supplied Accessory)
1 Align the fitting mark C
on the shorter petal of
the lens hood with the
mark on the tip of the
lens.
2 Rotate the lens hood in
the direction of the arrow
until it clicks and then
align the stop mark D on
the longer petal of the
lens hood with the mark
on the tip of the lens.
Hold the lens hood with
your fingers placed as
shown in the picture.
• Do not hold the lens
hood in a way that twists
or bends it.
H-FSA14140_OI_DVQX1826ZA_eng.spa.book 7 ページ ２０１９年３月１８日 月曜日 午前１１時５１分

8
DVQX1826 (ENG)
∫Temporarily Storing the Lens Hood
1 Turn the lens hood in the
direction of the arrow to
detach it.
2 Reverse the lens hood
and then attach it in the
same way as shown
previously.
Note
≥When taking pictures with the flash with the lens
hood attached, the lower portion of the screen
may turn dark and the control of the flash may be
disabled because the photo flash may be
obscured by the lens hood. We recommend
detaching the lens hood.
≥When using the AF assist lamp in the dark, detach
the lens hood.
≥To prevent dropping of the lens, you should never
carry the lens by just holding the lens hood.
∫Notes on Filter Use
≥It is possible to attach the lens cap or the lens
hood with the filter already attached.
≥If you use two or more filters at the same time,
part of a recorded image may darken.
≥It is not possible to attach any items other than
filters such as a conversion lens or adaptor to the
front of the lens and use it in combination with this
lens. Lens damage may result if such items are
attached.
H-FSA14140_OI_DVQX1826ZA_eng.spa.book 8 ページ ２０１９年３月１８日 月曜日 午前１１時５１分

9
(ENG) DVQX1826
Cautions for Use
Take care not to drop or knock the lens. Also
take care not to put a lot of pressure on the lens.
≥Take care not to drop the bag that you inserted the
lens in as it may strongly shock the lens. The camera
may stop operating normally and pictures may no
longer be recorded. Also, the lens may be damaged.
When using pesticides and other volatile
substances around the camera make sure that
they do not get onto the lens.
≥If such substances get onto the lens they can damage
the exterior case or cause the paint to peel.
Do not carry by the lens when the lens is
attached to the digital camera.
Do not point the lens at the sun or other strong
light sources.
≥This could cause the lens to collect an excessive
amount of light, resulting in fire and malfunction.
≥Under no circumstances should the unit be stored in
any of the following locations since doing so may
cause problems in operation or malfunctioning.
– In direct sunlight or on a beach in summer
– In locations with high temperatures and humidity
levels or where the changes in temperature and
humidity are acute
– In locations with high concentrations of sand, dust
or dirt
– Where there is fire
– Near heaters, air conditioners or humidifiers
– Where water may make the unit wet
– Where there is vibration
– Inside a vehicle
≥Refer also to the owner’s manual of the digital
camera.
≥When the unit is not going to be used for a prolonged
period, we recommend storing with a desiccant (silica
gel). Failure to do so may result in performance
failure caused by mold, etc. It is recommended that
you check the unit’s operation prior to use.
≥Do not leave the lens in contact with rubber or plastic
products for extended periods of time.
≥Do not touch the lens contact point. Doing so can
cause failure of the unit.
≥Do not disassemble or alter the unit.
Do not use benzine, thinner, alcohol or other
similar cleaning agents to clean the lens glass or
exterior cabinet.
≥Using solvents can damage the lens or cause the
paint to peel.
≥Wipe off any dust or fingerprints with a soft, dry cloth.
≥Use a dry, dust-free cloth to remove dirt and dust on
the lens mount rubber, zoom ring, or focus ring.
≥Do not use a household detergent or a chemically
treated cloth.
A rattling sound, etc. is heard when the digital
camera is turned on or off or the lens is shaken.
≥This is the sound of the lens moving and aperture
operation. It is not a malfunction.
Troubleshooting
H-FSA14140_OI_DVQX1826ZA_eng.spa.book 9 ページ ２０１９年３月１８日 月曜日 午前１１時５１分

10
DVQX1826 (ENG)
Specifications
Specifications are subject to change without notice.
INTERCHANGEABLE LENS FOR DIGITAL CAMERA
“LUMIX G VARIO 14– 140 mm/F3.5– 5.6 II ASPH./POWER O.I.S.”
Mount Micro Four Thirds mount
Focal length f=14 mm to 140 mm
(35 mm film camera equivalent: 28 mm to 280 mm)
Lens construction 14 elements in 12 groups (3 aspherical lenses, 2 ED lenses)
Aperture type 7 diaphragm blades/circular aperture diaphragm
Maximum aperture F3.5 (Wide) to F5.6 (Tele)
Minimum aperture value F22
Angle of view 75x (Wide) to 8.8x (Tele)
In focus distance 0.30 m (0.98 feet) to ¶ [from the focus distance reference line] (focal
length 14 mm to 21 mm),
0.50 m (1.64 feet) to ¶ [from the focus distance reference line] (focal
length 22 mm to 140 mm)
Maximum image magnification 0.25k (35 mm film camera equivalent: 0.5k)
Optical image stabilizer Yes
Filter diameter 58 mm
Maximum diameter Ø67 mm (2.6q)
Overall length Approx. 75 mm (3.0q)
(from the tip of the lens to the base side of the lens mount)
Mass (Weight) Approx. 265 g (0.58 lb)
Dust and splash resistant Yes
Recommended operating temperature 0oC to 40 oC (32 oF to 104 oF)
Permissible relative humidity 10%RH to 80%RH
H-FSA14140_OI_DVQX1826ZA_eng.spa.book 10 ページ ２０１９年３月１８日 月曜日 午前１１時５１分
