Panasonic CY-VRP112T1 User manual

Driving Recorder
Model:CY
-VRP112T1/T2/T3/T4/T5
Operating Instructions
Please read this instructions carefully before using this product and
keep this manual for future reference.
24240481301-A PTW0813-0 Printed in China

1
Contents
Safety Information..................................................................3
FCC Statement ......................................................................8
WEEE Notice .........................................................................9
CE Regulatory Notice ..........................................................10
Notes on Installation ............................................................10
Caution.................................................................................11
1Introduction...................................................................12
1.1 Features....................................................................12
1.2 Package Contents.....................................................12
1.3 Product Overview......................................................12
2Getting Started..............................................................14
2.1 Inserting the Memory Card.......................................14
2.2 Installing in Vehicles .................................................15
2.2.1 Mount to Windshield......................................15
2.2.2 Adjust the device position..............................16
2.3 Connecting to Power ................................................17
2.4 Powering the Camcorder On / Off............................18
2.4.1 Auto Power On/Off.........................................18
2.4.2 Manual Power On/Off....................................18
2.5 Initial Settings............................................................18
2.5.1 Set Automatic Recording...............................19
2.5.2 Set the Date and Time...................................19
2.5.3 Set the Satellite Synchronization ..................20
3Using the Car Recorder...............................................21
3.1 Recording Videos......................................................21
3.1.1 Record videos while driving...........................21
3.1.2 Driver Fatigue Alert........................................21

2
3.1.3 Record all other types of videos....................22
3.1.4 Emergency Recording...................................22
3.1.5 The Recording Screen...................................23
3.1.6 Taking Photographs.......................................24
3.1.7 4 GRID FUNCTION CHART in the LCD screen
…………………………………………………..25
3.2 Playback Videos and Photos....................................26
3.2.1 Playing Videos ...............................................27
3.2.2 Viewing Photos ..............................................27
3.2.3 The Playback Screen ....................................28
3.2.4 Deleting Files .................................................29
4Adjusting the Settings.................................................30
4.1 Using the Menu.........................................................30
4.2 Menu Tree.................................................................31
Default: Off...........................................................................33
5Installing the Software.................................................35
6SuperCar........................................................................36
7Specifications ...............................................................37
8Trouble Shooting..........................................................39

3
Safety Information
Warning
This pictograph intends to alert you to the presence of
important operating instructions and installation
instructions. Failure to heed the instructions may
result in severe injury or death.
Warning
Observe the following warnings when operating this unit.
■Driver shall not watch the screen of the recorder or operate
the device while driving.
Watching the screen or operating the unit prevents distracts from
focusing on road safety and could result in a traffic accident. Park the
vehicle in a safe location before operating the device.
■Never power the unit via an extension cord directly connected
to the battery, as to do so runs the risk of a short-circuit and
burnt PCB. Please use the cigarette lighter socket as a power
connection point.
■Make sure a correct power supply is used.
This unit is suitable for a vehicle equipped with a negative-ground
12V/24V battery. DO NOT use on any other battery system.
■Never dismantle or modify the unit.
Never dismantle the unit or attempt to modify or repair it on your own,
to do so could damage the unit or result in electrocution. If the product
requires servicing, please consult your dealer or our service station.
■Do not use this unit when it is out of order.
If the unit is out of order (no power, no sound etc.), or operates
abnormally (ingression of foreign objects, soaked by rain or emits
smoke or an odor), immediately switch off the unit and disconnect the
power supply, then consult the dealer or service station for assistance.

4
■Keep optional accessories (SD Card, etc.) away from the reach
of children.
There are risks that children may swallow the accessory. Keep
accessories away from the reach of children. In the event of
swallowing any the accessory, seek medical care immediately.

5
Safety Information
Warning
Observe the following warnings when installing this unit.
■ Install the product so that it does not hinder the view of the
vehicle.
■ Never install the unit within the range of air bag movement
or in a position that obstructs activation of the of air bag.
Please also verify warnings and precautions regarding the
vehicle’s air bag.
■ Make sure the wiring does not hinder passengers from
getting in/out of the vehicle.
Make sure the wiring is properly fixed to ensure safe driving.
Caution
This pictograph intends to alert you to the presence of
important operating instructions and installation
instructions. Failure to heed the instructions may result in
injury or material damage.
Caution
Observe the following cautions when using this unit.
■This unit i dessigned for use exclusively in vehicles.
■Never store the unit in a dusty or dirty place or near the vehicle’s
air-con/heater.
Long-term exposure to said environment may damage the unit.
■Never install/store the unit in a high-temperature environment as it
could result in damage.

6
Safety Information
Caution
Observe the following cautions when using this unit.
■When disposing of the unit, follow statutory regulations to recycle
the built-in lithium battery, so as to prevent environmental pollution.
■For some vehicles, the unit continues recording after the engine has
being shut off. In such a case, the following measures shall be taken:
Manually shut off the cigarette lighter or remove the vehicle power
connector from the cigarette lighter.
■Always keep the lens clean to ensure clear images of driving.
■In the event the ambient temperature reaches 45°C or higher, the
vehicle power connection will still supply power to the unit, but the
lithium polymer battery will not be recharged. This is a typical feature
of lithium batteries and is not a malfunction.
The unit may be affected by RF interference from mobile phones.
If the interference is significant, use mobile phone as far away from
the unit as possible.

7
Safety Information
Caution
Observe the following cautions when installing this unit.
■It is recommended that the unit should be installation by a
professional.
The installation requires specialty and technical experience; to
ensure safety, entrust the dealer to carry out the installation.
■Make sure no wires are damaged.
Avoid damaging any wires while making the connection by keeping
away from screws on the chassis or moving parts of seats. Never
twist the wires or position them near a heat source.
■ Make sure the unit is installed correctly.
Avoid installing the unit at a location subject to vigorous vibrations.
The ideal installation location is near the back mirror where an
optimal view can be obtained.
Make sure the lens is within range of the windshield wiper so that a
clear view is ensured.
DO NOT install the unit on tinted window glass as that could
damage the light-colored film.
Make sure the unit is installed at a location that is free from any
influence of thermal film and away from any device that may
generate electronic interference.
Precautions when using a Micro SD Card
■Never remove the SD card when the unit is in the process of
shutting-down or operating. Failure to comply could corrupt the files
or damage the unit.
■A Class- 6 Micro SD card with 8GB capacity or more is
recommended (Max. support up to 32GB).
■Before using this unit, format the Micro SD Card by this unit.

8
FCC Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
FCC Caution: Any changes or modifications not expressly approved
by the party responsible for compliance could void the user's
authority to operate this equipment.

9
WEEE Notice
Information for Users on Collection and Disposal of Old
Equipment and Used Batteries
These symbols on the products, packaging, and/or accompanying
documents mean that used electrical and electronic products and
batteries should not be mixed with general household waste.
For proper treatment, recovery and recycling of old
products and used batteries, please take them to
applicable collection points, in accordance with your
national legislation and the Directives 2002/96/EC and
2006/66/EC.
By disposing of these products and batteries correctly,
you will help to save valuable resources and prevent any
potential negative effects on human health and the
environment which could otherwise arise from
inappropriate waste handling.
For more information about collection and recycling of old products
and batteries, please contact your local municipality, your waste
disposal service or the point of sale where you purchased the items.
Penalties may be applicable for incorrect disposal of this waste, in
accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please
contact your dealer or supplier for further information.
[Information on Disposal in other Countries outside the
European Union]
These symbols are only valid in the European Union. If you wish to
discard these items, please contact your local authorities or dealer
and ask for the correct method of disposal.

10
CE Regulatory Notice
Herewith confirm to comply with the requirements set out in the
Council Directives on the Approximation of the Laws of the Member
States relating Electromagnetic Compatibility of Radio and Telecom
device (1995/5/EC); the Low Voltage Directive (2006/95/EC); the
Restriction of The Use of Certain Hazardous Substances in
Electrical And Electronic Equipment Directive (2002/95/EC), Turkish
EEE Directive; the Commission Regulation (EC) No 1275/2008
implementing Directive 2005/32/EC of the European Parliament and
of the Council with regard to eco-design requirements for standby
and off mode electric power consumption of electrical and electronic
household and office equipment, and the Directive 2009/125/EC of
the European parliament and of the council establishing a
framework for the setting of eco-design requirements for
energy-related products.
Notes on Installation
1. Install the device near the rear-view mirror to obtain the best
open-field view. Do NOT install the camcorder in a location that will
obstruct your required driving view.
2. Make sure that the lens is within the wiping range of the windscreen
wiper to ensure a clear view even when it rains.
3. Do not touch the lens with your fingers. Finger grease may be left
on the lens and will result in unclear videos or snapshots. Clean the
lens on a regular basis.
4. Do not install the device on a tinted window. Doing so may damage
the tint film.
5. Make sure that the installation position is not hindered by the tinted
window.
6. In order to avoid the ripple in the LCD screen due to the car
engine vibration , suggest the driver to shift the gear to N
Position for the temporary stop.

11
Caution
Use the authorized charger only.
Never disassemble by yourself.
Never short-circuit the battery.
Dispose of the battery properly.
Exposing the battery to open flames can cause explosion.
Due to local laws and vehicles safety considerations, do not
operate the device while driving.
The results of GPS positioning are only for reference, and
should not affect the actual driving situation. The system also
cannot ensure the positioning accuracy.
GPS positioning accuracy may differ depending on weather
and location such as high buildings, tunnels, undergrounds, or
forests.
GPS satellite signals cannot pass through solid materials
(except glass). Tinted window will also affect the performance
of the GPS satellite reception.
GPS reception performance on each device may differ. The
system cannot determine the accuracy of the positioning
results from different devices.
The values displayed in this system, such as speed, position,
and the distance warning to the speed camera set points, may
be inaccurate due to the influence of surrounding environment.
They are for your reference only.

12
1 Introduction
1.1 Features
•Full HD Car Camcorder (1920x1080 @ 30fps)
•2.4” LCD color screen
•128 degree Wide angle lens
•Motion detection
•Automatic Emergency recording for collision detection
•Supports Micro-SDHC up to 32GB (Class 6 or greater speed
required for HD video)
1.2 Package Contents
The package contains the following items. In case there is any
missing or damaged item, contact your dealer immediately.
Car Recorder
Bracket
CD-ROM
Car adapter
Quick Start Guide
Warranty Card

13
1.3 Product Overview
No.
Item
No.
Item
1
Bracket Socket
8
LED Light
2
Microphone
9
LCD Panel
3
Power Button
10
Up Button ( )
4
Memory Card Slot
11
Down Button ( )
5
USB Connector
12
Enter Button ( )
6
HD(Mini HDMI) Connector
13
Wide Angle Lens
7
Back Button ( )
14
Speaker
Note:
To operate the device, press the corresponding buttons (7, 10, 11, 12) according to
guide icons shown the screen.
Top and Bottom Views
Side (Left and Right) Views
Front View
Rear View
1
3
4
10
8
13
2
5
7
11
12
6
14
9

14
2 Getting Started
2.1 Inserting the Memory Card
Insert the memory card with the gold contacts facing the back of the
camcorder. Push the memory card until it clicks into place. (Use
class 6 or above the micro SD cards for this camcorder; It is
recommended to format the micro SD cards before the initial use.)
To remove the memory card
Push to eject the memory card out of the slot.
Note:
1. Do not remove or insert the memory card when the device is powered on. This may
damage the memory card.
2. Please use a 8GB, Class 6 or above Micro SD card Support to 32GB as the maximum.
3. Please format the micro SD cards before the initial use.

15
2.2 Installing in Vehicles
2.2.1 Mount to Windshield
1. Attach the bracket to the device.
Slide it into the bracket holder until
you hear a click.
2. With the suction-cup laying flat,
position the suction-cup on the
windshield.
3. Hold the base firmly on the
windshield and press down the
clamp to mount the car holder to
the windshield. Make sure the
base is securely locked in place.

16
2.2.2 Adjust the device position
1. Loose the knob to swivel the
device vertically.
2. Loose the knob to swivel
the device horizontally up
to 360°.
3. Then tighten the knob to make sure the device is securely
locked in place.
Knob
Knob

17
2.3 Connecting to Power
Use only the exclusive car adapter to power up the device and
charge the built-in battery.
1. Connect one end of the car adapter to the USB connector of
the camcorder.
2. Plug the other end of the car charger to the cigarette lighter
socket of your vehicle. Once the vehicle engine is started, the
camcorder automatically powers on.
Note:
1. The orange LED lights up while the battery is charging.
2. Please take note if the environment temperature reaches 45°C or above, the car
adapter still can supply power to camcorder, but it will not charge the battery. This is
the characteristic of Lithium polymer battery and is not a malfunction.

18
2.4 Powering the Camcorder On / Off
2.4.1 Auto Power On/Off
Once the vehicle engine is started, the device automatically turns on.
If the Automatic Record function is enabled, the recording will
automatically start right after the camcorder powers on.
See Set Automatic Recording (2.5.1).
Once the vehicle engine shuts down, the camcorder automatically
saves the recording and turns off the power within 10 seconds.
See Delay Shutdown (4.2).
2.4.2 Manual Power On/Off
To manually turn on the power, press the
POWER button.
To turn off, press and hold the POWER
button for at least 2 seconds.
To reset, press and hold the POWER button
for at least 4 seconds.
2.5 Initial Settings
Before using the device, we recommend you to enable the
Automatic Record function and set up the correct date and time.

19
2.5.1 Set Automatic Recording
To enable the recording to start automatically after you turn on the
power, do the following:
1. Press the button to enter the
OSD menu.
2. Press the / button to select
Automatic Record and press the
button.
3. Press the / button to select On and press the
button.
4. Press the button to exit the menu.
2.5.2 Set the Date and Time
To set the correct date and time, do the following:
1. Press the button to enter the OSD menu.
2. Press the / button to select Date / Time and press the
button.
3. Press the / button to adjust
the value and press the button
to move to another field.
4. Repeat step 3 until the date and time
setting is complete.
Note:
1.When the battery is drained dry and the satellite synchronization is off, the user must
reset the date/time before the function-automatic record is started. If the user doesn't
reset the date/time, the device will give you alert (you can see the as
attached) after one minute and the automatic record will be started .
2.But if the sattlelite is synchronized ,the device can do automatic record immediately.
