Illustrations in this Manual
CF-72 with Internal LAN Port
Supplementary Instructions
Personal Computer
This Supplementary Instructions manual explains how to get started with an internal LAN and point out cases where the operation
of the computer will differ from that in the Operating Instructions and/or Reference Manual.
®
Windows 98 : Information for Microsoft®Windows®98 users.
Windows NT : Information for Microsoft®Windows NT® Workstation Version 4.0 users.
Windows 2000 : Information for Microsoft®Windows®2000 Professional users.
Replace the step 8for the following.
First-time Operation “OPERATING INSTRUCTIONS (page 11, 12)”
Windows 98 Windows 2000
8SetupWindows
Moving the cursor ( ) or clicking buttons can be performed with the touch pad.
Windows 98
1In [Add New Hardware Wizard], press [Next].
2Select [Search for the best driver for your device], press [Next].
3Input [c:\util\drivers\clan], then press [Next].
4Press [Next], then press [Next].
If the [Insert Disk] is displayed, press [OK] and input [c:\util\drivers\clan], then
press [OK].
Each time the [Version Conflict] is displayed, select [Yes].
5Press [Finish].
The display will ask you to restart Windows, press [Yes].
At [Enter Network Password], press [OK].
6In [Add New Hardware Wizard], press [Next].
7Select [Search for the best driver for your device], press [Next].
8Input [c:\util\drivers\cmodem], then press [Next].
9Press [Next].
10 Press [Finish].
11 Select settings for your region and your keyboard layout, then press [Next].
(for U.S.A.: United States 101)
12 Enter your name, then press [Next].
13 Select [Skip] at the [Using Your Modem to Connect].
14 Select [Yes] at the [Cancel Dialing], then press [Next].
The License Agreement will be displayed.
(To next page)

2
5Enter your computer name and administrator password, then press [Next].
2After reading the agreement, select [I accept this agreement] or [I don't accept this
agreement], then press [Next].
3Select settings for your region, then press [Next].
4Enter your name and organization, then press [Next].
NOTE
If [I don't accept this agreement] is selected, the Windows setup will be aborted.
<During the setup procedure only after reinstalling>
The [Your product key] is displayed after you enter your name and organiza-
tion.
Input the Product Key written down in the “Customer's Record”, then press
[Next].
NOTE
CAUTION
Remember this password! If the password is forgotten, Windows 2000 cannot be
operated.
6Input the correct date, time and time zone and press [Next].
You can also complete these settings at a later time.
7At the [Networking Settings], select [Typical settings], then press [Next].
8At the [Workgroup or Computer Domain], select [No, this computer is not on a net-
work, or is on a network without a domain], then press [Next].
9Press [Finish]. The computer will restart.
10 At the [Network Identification Wizard], press [Next].
1At the [Welcome to the Windows 2000 Setup Wizard], press [Next].
Do not press any key or move the touch pad until [Windows 2000 Professional Setup]
is displayed.
CAUTION
Windows 2000
If [I do not accept the agreement] is selected, the Windows setup will be aborted.
<During the setup procedure after reinstalling only>
After accepting the agreement, the [Windows product key] is displayed.
Input the Product Key written down in the "Customer's Record" section, then
press [Next].
NOTE
15 After reading the agreement, select [I accept this agreement] or [I do not accept the
agreement], then press [Next].
16 Press [Finish].
17 Input the correct date, time and time zone and press [Close]. You can also complete
these settings at a later time.
Supplementary Instructions

3
11 At the [Users of This Computer], select [Users must enter a user name and password to
use this computer], then press [Next].
12 Press [Finish].
13 Enter your administrator password, then press [OK].
When [Digital Signature Not Found] is displayed, press [Yes].
14 Select [Device Manager] in [Start] - [Settings] - [Control Panel] - [System] - [Hard-
ware].
15 Double-click [Intel 8255x-based PCI Ethernet Adapter (10/100)] in [Network adapt-
ers].
16 Select [Driver] and press [Update Driver].
17 Press [Next], then press [Next].
18 Add the check mark for [Specify a location] and press [Next].
19 Input [c:\util\drivers\clan] and press [OK].
20 Add the check mark for [Install one of the other drivers] and press [Next].
21 Select the driver for which the [Provider] is [Intel], and then press [Next].
Each time [Digital Signature Not Found] is displayed, press [Yes].
22 Press [Finish] and press [Close].
NOTE
About the steps after 7, we recommend asking your system administrator or the
person in charge of the network.
At the [Getting started with Windows 2000]:
Press [Exit] to close.
When selecting [Discover Windows], the computer may ask you to install the Win-
dows 2000 CD. In such cases, close the windows, and then specify
[c:\winnt\cdimage\discover], then select [OK].
LAN Port
WARNING
Do not insert a telephone line connector (including a
PBX internal phone) into the LAN port. Doing so
may cause fire or electric shock.
Using LAN
This model has an internal LAN port.
Setting for LAN
Windows NT
Select [Network] in [Start] - [Settings] - [Control Panel]
1
2Select [Yes]
<When the settings for the modem have already been made>
After selecting [Adapter] and pressing [Add], proceed to step 5.
When using the LAN, set [Modem/LAN] to [Enable]* in the Setup Utility. (* Default)
3Select [Wired to the network] and then press [Next]
4Select [Select from list]

4
NOTE
7
8
9
10
11
Select [Intel(R) PRO Adapter] and then press [OK]
<When the settings for the modem have already been made>
1Select [Intel(R) PRO Adapter] and then press [OK]
2Select your protocol and network service (etc.).
3Press [Close] and follow the on-screen instructions, then proceed to step 12.
Press [Next]
Select your protocol and then press [Next]
Select your network service and then press [Next]
Press [Next]
Input [c:\winnt\i386] and then press [Continue]
<When the settings for the modem have already been made>
Perform this procedure only when the screen to insert the Windows NT CD is
displayed.
Follow the on-screen instructions.
The settings will vary for different network environments depending on the network
system being used. For more details, ask your system administrator or the person in
charge of the network.
12
In [Start] - [Run], input [c:\sp6\sp6i386.exe], then press [OK]
Follow the on-screen instructions.
13
5
6Input [c:\util\drivers\clan] and then press [OK]
Press [Have Disk]
Do not use standby or hibernation functions during communications.
Unable to connect to network (When the indicator of your HUB unit does not light):
Windows 98
1Select [Network] in [Start] - [Settings] - [Control Panel].
2Select [Intel 8255x-based PCI Ethernet Adapter (10/100)].
3Select [Properties].
4Select [Advanced].
5Select [Link Speed & Duplex] from [Property], set [Value] to the communication
speed (10 Mbps or 100 Mbps) suitable for your network environment, and then press
[OK].
Windows NT
1Select [Adapters] in [Start] - [Settings] - [Control Panel] - [Network].
2Select [Intel 8255x-based PCI Ethernet Adapter (10/100)].
3Select [Properties] - [Advanced].
4Select [Link Speed & Duplex] from [Setting], set [Value] to the communication speed
(10 Mbps or 100 Mbps) suitable for your network environment, and then press [OK].
Windows 2000
1Select [Device Manager] in [Start] - [Settings] - [Control Panel] - [System] - [Hard-
ware].
2Select [Intel 8255x-based PCI Ethernet Adapter (10/100)] from [Network adapters].
3Select [Action] - [Properties].
4Select [Advanced].
5Select [Link Speed & Duplex] from [Property], and set [Value] to the communication
speed (10 Mbps or 100 Mbps) suitable for your network environment, and then press
[OK].
Supplementary Instructions

5
Using the Computer as a Network Computer
This is a function to automatically power ON the computer from a network server. To use
this function, it is necessary to have a network environment that accommodates Wake up
from LAN.
To use this function:
Windows 98 Windows 2000
1Select [Device Manager]*1in [Start] - [Settings] - [Control Panel] - [System].
2Select [Intel 8255x-based PCI Ethernet Adapter (10/100)] from [Network adapters].
3Select [Properties]*2.
4Select [Power Management] and add the check mark for [Allow this device to bring the
computer out of standby], and then press [OK].
*1Windows 2000: [Hardware] - [Device Manager]
*2Windows 2000: [Action] - [Properties]
Windows NT
Set [Wake up from LAN] to [Enable] with the Setup Utility. ( page 7)
Be sure to connect the AC adaptor, and enable the supply of power.
Make settings to allow the use of a Local Area Network.
Windows 98 Windows 2000
When using the Wake up from LAN function, delete the check mark for [Prompt for
password when computer goes off standby] in [Start] - [Settings] - [Control Panel] -
[Power Management]* - [Advanced].
* Windows 2000 : [Power Options]
The Wake up from LAN function will not operate under the following conditions:
- When the computer has been shut down.
-Windows 98
When the computer has been placed in standby or hibernation mode from MS-DOS
mode.
This works on Windows 98 or Windows 2000 irrespective of the [Wake up from LAN]
setting of the Setup Utility.
Windows NT
The Wake up from LAN function will not operate under the following conditions:
- When the computer has been shut down by sliding the power switch for more than
four seconds.
- When the password has been input incorrectly, and the computer has returned to
standby, hibernation, or power off status.
When using the Wake up from LAN function, the password is not necessary even if
the password has been set in the Setup Utility.
When using the computer as a network computer, some additional settings may have to be
made depending on the usage conditions. We recommend asking your system administrator
or the person in charge of the network.
Wake up from LAN
NOTE

6
Windows 98
Modem “REFERENCE MANUAL (page 50,52)”
Replace the step 2for the following.
21Select [Modems] in [Start] - [Settings] - [Control Panel].
2Select [Lucent Win Modem] and press [Remove].
3Select [Dialing Properties].
Input the necessary information (items such as the country, area code, etc.) and press
[OK], then press [Close].
Reinstallation “OPERATING INSTRUCTIONS (page 26)”
Add the following information in step 8of “Setup Windows after reinstalling”.
The driver for the internal LAN port is in [c:\util\drivers\clan]. Be sure to select [Intel(R) PRO
Adapter].
Windows NT
Specifications “OPERATING INSTRUCTIONS (page 33)”
Internal LAN IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
Add the following information.
Windows NT
21Select [Start] - [Run].
2Type [c:\util\drivers\cmodem\setup.exe] and press [OK].
3Select [Next], then select [Next].
4Select [Finish].
Replace the step 2for the following.
Supplementary Instructions
Replace the step 14 for the following.
14 Perform the setup procedure for Windows by following the instructions on the screen.
Windows 98 Windows 2000 Supplementary Instructions page 1 - 3
Windows 98 Windows 2000

7
Modem/LAN
Wake up from LAN*
Setup Utility “REFERENCE MANUAL (page 56)”
Replace the “Advanced”menu for the following.
Parameters ( : Default)
Device Configuration: [BIOS]
Serial Port: [Auto]
IrDA Port: [Auto]
Parallel Port: [Auto]
Mode: [ECP]
Sound Controller: [Enable]
Modem/LAN: [Enable]
Wake up from LAN: [Disable]
*[Disable] is automatically set when [Modem/LAN] is set to [Disable].
Wake up function works on Windows 98 or Windows 2000 irrespective of the [Wake up form LAN]
setting.
When the [Wake up from LAN] has been enabled;
In the OFF state, if you are not recharging your battery pack or if the pack is fully charged, your computer
consumes approximately 3.0 W.
Disable
Enable
Disable
Enable

FJ1100-0
DFQX5236ZA
Panasonic Personal Computer Company,
50 Meadowlands Parkway, Panazip 2F-5,
Secaucus, NJ 07094
Panasonic Canada Inc.
5770 Ambler Drive Mississauga,
Ontario L4W 2T3
© 2000 Matsushita Electric Industrial Co., LTD. All Rights Reserved.
Printed in Japan
