Panasonic FV-10VEC2R User manual

CONTENTS
GENERAL SAFETY INFORMATION
DESCRIPTION
UNPACKING
SUPPLIED ACCESSORIES
DIMENSIONS
WIRING DIAGRAM
WIRING METHOD
DUCTWORK
INSTALLATION (WALL MOUNT)
INSTALLATION (CHAIN MOUNT)
START-UP PROCEDURE
2~3
5
OPERATION 14~16
TROUBLESHOOTING 19
MAINTENANCE 17~18
SPECIFICATIONS
PRODUCT SERVICE
READ AND SAVE THESE INSTRUCTIONS
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before attempting to install, operate or service the
Panasonic product. Please carefully read the “GENERAL SAFETY INFORMATION” (P.2~3) of
this manual before use. Failure to comply with instructions could result in personal injury or
property damage. Please explain to users how to operate and maintain the product after
installation, and this booklet should be presented to users.
Please retain this booklet for future reference.
BACK COVER
BACK COVER
6
8~9
6~7
9~12
13
14
4
4
4
Installation and Operating Instructions
Energy Recovery Ventilator
FV-10VEC2RModel No.

2
This symbol is used to alert users not to disassemble the equipment.
When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring
and other hidden utilities.
Canada only: Not to be installed in a ceiling thermally insulated to a value greater than
R40.
Never install the unit in a high humidity space, such as a bathroom, kitchen or laundry
room.
Do not disassemble the unit. It may cause fire or electric shock.
Use this unit only in the manner intended by the manufacturer. If you have any
questions, contact the manufacturer.
Installation work and electrical wiring must be performed by qualified person(s) in
accordance with all applicable codes and standards, including fire-rated construction.
Do not install with a method which is not approved in the instructions.
Ducted fans must always be vented to the outdoors.
Solid state controls may cause harmonic distortion which can cause motor humming
noise. To reduce the risk of fire or electric shock, do not use this unit with any solid-
state control device.
This symbol is used to alert users to a specific operating procedure that must be
followed in order to operate the unit safely.
This symbol is used to alert users to a specific operating procedure that must not be
performed.
This symbol is used to alert users to make sure of grounding when using the
equipment with the grounding terminal.
For Your Safety
Explanation of symbol word panels
To reduce the risk of injury, loss of life, electric shock, fire, malfunction, and damage to
equipment or property, always observe the following safety precautions.
The following symbols are used to classify and describe the type of instructions to be
observed.
The following symbol word panels are used to classify and describe the level of hazard, injury,
and property damage caused when the denotation is disregarded and improper use is
performed.
CAUTION
Denotes a potential hazard that could result in death or
serious injury.
Denotes a hazard that could result in minor injury.
Denotes a hazard that could result in property damage.
WARNING
WARNING
GENERAL SAFETY INFORMATION
NOTICE

Ceiling joist and wall stud must be subjected to static load more than five times the
weight of the product.
The special-purpose or dedicated parts, such as mounting fixtures, must be used if such
parts are provided.
Do not kink the power cord.
The OA duct and EA duct must be connected directly to the outside.
Make certain that the electric service supply voltage is AC 120 V, 60 Hz.
These fans are intended for residential use only.
Do not install the unit where ducts are configured as shown below.
Adapter
Protect the power cord from sharp edges, oil, grease, hot surfaces, chemicals or other
objects.
When the product is to no longer be used, it must not be left in place but removed,
to prevent it from possibly falling.
Follow all local electrical and safety codes, as well as the National Electrical Code (NEC)
and the Occupational Safety and Health Act (OSHA).
Always disconnect the power source before working on or near the fan, motor, fixture
or wiring cover.
For general ventilating use only. Do not use to exhaust hazardous or explosive materials
and vapors.
Sufficient air is needed for proper combustion and exhausting of gases through the
flue (chimney) of fuel burning equipment to prevent backdrafting. Follow the heating
equipment manufacturer’s guideline and safety standards such as those published by
the National Fire Protection Association (NFPA), and the American Society for Heating
Refrigeration and Air Conditioning Engineers (ASHRAE) and the local code authorities.
Excessive bending Successive bending Squeezed duct Bend close to duct adapter
3
Disconnect power by switching off wall switch first, then main switch and unplug the
product before working on unit when replacing the jumper cable with wall switch.
Install the unit in the area where air temperature is above 50 °F (10 °C) to avoid
condensation in unit.
Do not install the unit in the area where the air stream temperature may exceed 104 °F
(40 °C).
The unit must be installed in a mechanical room, basement, or other conditioned space.
CAUTION
GENERAL SAFETY INFORMATION
NOTICE

The Panasonic Energy Recovery Ventilator (ERV) uses 2 blower fans driven by 2 DC motors.
The motor is designed to have an extended service life with reduced energy consumption.
It also incorporates a thermal-cutoff for safety.
The exhaust air (EA) duct includes an electric damper to prevent backdrafting. The outside
air (OA) duct includes an electric damper to prevent backdrafting.
Energy Recovery Introduction: Compared to an HRV (Heat Recovery Ventilator), the ERV can
also transfer humidity and recover energy from that humidity. The ERV can exchange energy
between the stale EA and the “fresh” OA, transferring heat and moisture into the incoming
cold air in a heating climate and pre-cooling and reducing the humidity of the incoming hot
air in a cooling climate. This tempering and treatment of the required ventilation air helps
maintain a fresh environment even when the heating or cooling system is not operating.
1
4
1Wall bracket
<Heating Climate>
Part name Appearance Quantity
Unpack and remove unit carefully from carton.
Refer to the supplied accessories list to verify that all parts are presented.
<Cooling Climate>
Heat&
Moisture
Fresh air Fresh air
Exhaust air
(EA)
Outside air
(OA)
Exhaust air
(EA)
Outside air
(OA)
Stale air
Indoor
Stale air
Indoor
Outdoor Outdoor
Hanger
Hanger
L plate
Installation and
operating instructions
Limited warranty
Plug cover
Screw
(M4X8)
Long screw
(ST4.2X20)
4
4
1
1
12
12
4
DESCRIPTION
SUPPLIED ACCESSORIES
UNPACKING
Heat&
Moisture

Unit:inches(mm)
5
DIMENSIONS
(150) Dia.
5 15/16 Dia.
(353.3)
13 7/8
(347.4)
13 11/16
13/16
(20.8)
12345
35 13/16 (909.6)
28 1/2 (723.6)
3 15/16
(99.2)
678910
1112
13
14
19
20
17 181615
RA
(100) Dia. 3 15/16 Dia.
(151) Dia.
5 15/16 Dia.
OA
(100) Dia. 3 15/16 Dia.
(117.9) 4 11/16
EA
(584.6)
23
8 7/8 (225.6)
EA: Exhaust air
OA: Outside air
SA: Supply air
RA: Return air
Part nameNo. Part nameNo.
Frame cover
Power cord (length 70 7/8 (1800))
EA adapter
EA damper assy.
EA fan assy.
DC motor
Frame body
Maintenance plate
Wiring cover
1
2
3
4
5
6
7
8
9
SA adapter
RA filter
OA filter
RA adapter
OA adapter
Energy recovery core
Plug
OA damper assy.
Center damper assy.
SA fan assy.
Control panel
10
11
12
13
14
15
16
17
18
19
20
SA

6
WIRING DIAGRAM
(1)The HVAC/AHU signal cord, wall switch cord, boost switch cord, wall switch and
boost switch are not supplied.
Note
WIRING METHOD
Jumper cable
(2)The terminal of wall switch has been connected by jumper cable for factory default.
(3) If a wall switch is not used to power down the ERV note that cutting power by
unplugging the unit, and/or opening the frame cover to maintenance, will disallow
the unit to run a power down process; leaving the dampers in the open position.
This could increase the risk of cold air infiltration which may lead to frost forming in
the ERV.
(4) If you do not intend to run the product for more than 24 hours we recommend you
connect product with a wall switch to control the standby and running of the product.

WIRING METHOD
7
1.Open the knock-out hole and remove
maintenance plate and wiring cover. (Fig.1)
4.Insert wires into the corresponding terminals deeply through the ribs. (Fig.1)
Make sure the screw of terminal securely fastens the copper wire and the copper
wire is not exposed.
5.Reinstall the wiring cover and maintenance plate.
If you are not connecting to the HVAC/AHU,
please open knock-out hole for wall switch
cord/boost switch cord connection only. (Fig.1)
Note
CAUTION
The capacity of wall switch, boost switch
should be more than 120 V~3 A to control
the power of the product.
2.Thread wall switch cord, boost switch cord and
HVAC/AHU signal cord (optional) through
conduits respectively and install the conduits
into knock-out holes. (Fig.1)
Wiring cover
Maintenance
plate
Knock-out hole for
HVAC/AHU signal
cord connection
Knock-out hole
for wall switch
cord and boost
switch cord
connection
Fig.1
Rib
Terminal
HVAC/AHU
signal cord
(optional)
Conduit
Wall switch
cord
(optional)
Boost switch
cord
(optional)
Note
Unit: inches (mm)
Wall switch cord/
HVAC/AHU signal cord/
Boost switch cord
Copper wire
1/4 (7)
3 1/2~4 (90~100)
3.Strip insulation cover for each wires as shown below.
Jumper cable
(1)The HVAC/AHU signal cord is optional,
please connect it when you want to control
the HVAC/AHU.
(2) If connecting with HVAC/AHU, the HVAC/AHU
will turn on while ERV turns on.
(3) If connecting with wall switch, please remove
the jumper cable first.

8
1.Mount wall bracket on stud with long screws
(ST4.2x20). (Fig.2)
This method can be used in stud as below.
INSTALLATION (WALL MOUNT)
Unit: inches (mm)
Note
(1)Attach with flanged edge facing outward
and edge without flange facing upward
when mounting wall bracket. (Fig.2)
(2)Choose the mounting hole on wall
bracket according to the distance
between studs.
2.Mount hanger on the back of frame body
with screws (M4X8) and mount L plate on the
two side of frame body with screws (M4X8).
(Fig.3)
24 (609.6)
16 (406.4)
19 (482.6)
Note
(1)When mount hanger , please attach with
the claw facing downward to frame body
that the side with power cord facing
upward.
(2)Choose the mounting hole according to
the distance between studs.
Unit: inches (mm)
A B
24 (609.6)
16 (406.4)
19 (482.6) 17 1/2 (444.5)
14 1/2 (368.3)
22 1/2 (571.5)
4-screws
(M4X8)
Hanger
Claw
Power cord
Fig.3
A
B
Unit: inches (mm)
4-long screws
(ST4.2x20)
Stud
Wall
bracket
Floor
Edge without
flange
>31 1/2 (800)
Fig.2
Stud
Flange
2-screws (M4X8)
L plate

5.Install plug covers into plugs on frame
cover. (Fig.6)
2-long screws
(ST4.2x20)
4.Mount L plate on to stud with long screws
(ST4.2X20). (Fig.5)
3.Hang ERV on to wall bracket.
Make sure the power cord is upward.
(Fig.4)
Fig.5
Unit: inches (mm)
24 (609.6)
16 (406.4)
19 (482.6)
9
4-plug covers
Fig.6
Fig.4
1.Install ducts according to one of three methods as shown below.
Method -Simplified ducted installation (Return method)
Note
DUCTWORK
This method draws return air from the return air duct
of the air furnace and supplies an equal amount of
outside air farther downstream into the return duct.
(Fig.7 & Fig.8)
(1)The ERV unit must be balanced.
(2)It is mandatory that HVAC/AHU signal cord be
connected.
(3)Check local codes and authority having
jurisdiction for acceptance. Fig.7
CAUTION
Power cord
Wall bracket
INSTALLATION (WALL MOUNT)

DUCTWORK
This method draws return air from specific points in the house and supplies an equal
amount of outside air into the return air duct of the air furnace. (Fig.9 & Fig.10)
Return air ducts of ERV should be installed in areas of the home where the poorest indoor
air quality exists (bathroom and kitchen).
The air furnace blower should be running when the ERV is operating to evenly distribute the
outside air throughout the house.
Method -Partially dedicated ducted installation
Note
(1)The ERV unit must be balanced.
(2)It is mandatory that HVAC/AHU signal cord be
connected.
(3)Check local codes and authority having
jurisdiction for acceptance.
Note
(1)Must have 2-3 feet of straight duct run from all duct attachment points on the
ERV. Do not use any elbows or other peripheral pieces inside of 2-3 feet when
attaching duct runs to the ERV.
(2)Unit is normally balanced on high speed with the furnace blower on.
(3)A minimum separation of 40 inches (1 m) is recommended between the two
direct connections.
(4)The exhaust air connection shall be upstream of the supply air connection to
prevent exhausting any fresh air.
(5)The distance between two outdoor hoods please see P.12.
(6)The airflow must be confirmed on site using the balancing procedures found in
P.14. Fig.8
10
36”
Air
furnace
(914 mm)
Min.
Dampers for
balancing
airflows
40" (1 m) Min.
Outdoors
OA
EA
RA
SA
Return
air Return air
Fig.9

DUCTWORK
This method draws return air from specific points in the
house and supplies outside air to specific locations of
the house. This system is not connected to an air
furnace. (Fig.11 & Fig.12)
Return air ducts should be installed in areas of the
home where the poorest indoor air quality exists (bath-
room and kitchen). Supply air ducts should be installed
to all bedrooms and living areas.
Method -Fully dedicated ducted installation
Note
(1)The ERV unit must be balanced.
(2)Check local codes and authority having jurisdiction for acceptance.
Fig.10
11
Air
furnace
(914 mm)
Min.
Dampers for
balancing airflows
OA
EA
RA
SA
Outdoors
Return air
Return air
36”
Return air from various parts of home.
(i.e. bathrooms, kitchens, utility areas)
Fig.11
Fig.12
Note
(1)Must have 2-3 feet of straight duct run from all duct attachment points on
the ERV. Do not use any elbows or other peripheral pieces inside of 2-3
feet when attaching duct runs to the ERV.
(2)The distance between two outdoor hoods please see P.12.
(3) The airflow must be confirmed on site using the balancing procedures found in P.14.
Outdoors
Return air from various parts of
home (e.g. bathrooms, kitchens,
utility areas)
Supply air to main
living areas (e.g.
bedrooms, living
room)
OA
EA
RA
SA
Note
(1) Must have 2-3 feet of straight duct run from all duct attachment
points on the ERV. Do not use any elbows or other peripheral
pieces inside of 2-3 feet when attaching duct runs to the ERV.
(2) Unit is normally balanced on high speed with the furnace blower on.
(3)The distance between two outdoor hoods please see P.12.
(4)The airflow must be confirmed on site using the balancing
procedures found in P.14.

2.Install insulated ducts to OA and EA adapter.
(Fig.13-1)
(1)Pull back the insulation to expose the flexible
duct.
(2)Attach the flexible duct to the adapter using
tie wrap. You can attach to the 4 inch or
6 inch according to size of flexible duct.
(3)Pull the insulation over the adapter.
(4)Apply UL181A certified pressure sensitive
tape or mastic to insulation duct and
adapter making an airtight seal.
3.Attach duct (rigid galvanized duct, etc) to the
SA and RA adapter using UL181A certified
pressure sensitive tape or mastic. You can
attach to the 4 inch or 6 inch according
to size of duct. (Fig.13-2)
Fig.13-2
Insulation
Insulation Mastic
Mastic Mastic
Tie wrap Tie wrap
DUCTWORK
12
OA and EA adapter
Attach to 4”
adapter
Attach to 4”
adapter Attach to 6”
adapter
SA and RA adapter
Fig.13-1
(1)
(3)
(2)
or
or
Attach to 6”
adapter
(4)
4.Install outdoor hood and connect with
insulated ducts.
When install them, please refer to the local
codes for detail.
The intake side duct must be
connected to the outside and at least
6 ft (1.8 m) away from the exhaust of
appliances such as furnace, dryer, fuel
burning appliances, etc.
(1)If separate hoods are used, locate them at
least 10 ft (3 m) apart. (Fig.14)
CAUTION
10’ (3 m)
Exhaust hood
with backdraft
flap (s)
Fig.14
Note
Intake hood
with bird screen
(No backdraft
flap (s))

Unit: inches (mm)
Unit:inches(mm)
Joist
28 1/2 (723.6)
1 1/4 (31.8)
1.Mount chain on joist by long screws
(ST4.2X20). (Fig.15)
This method should be used in 24” joist as
below.
4.Install plug covers into plugs on frame cover.
(Fig.18)
Fig.15
Ductwork please refer to P.9~P.12
5-chains
4-plug covers
Joist
5-long
screws
(ST4.2X20)
Fig.18
INSTALLATION (CHAIN MOUNT)
13
24 (609.6)
22 1/2 (571.5)
2.Mount hanger on frame body with screws
(M4X8). (Fig.16)
3.Hang the ERV on to chains. (Fig.17)
Note
Make sure ERV is horizontal after
installation.
A
B
Fig.16
(2)The length of each chain should be
20 inches~24 inches (500 mm~600 mm)
and the dimension A and B are
recommended as shown below.
Note
A B
Unit: inches (mm)
3/4 (20)
1/4 (6)
Fig.17
Hanger
Hanger
2-screws
(M4X8)
Chain
(1)The chains are not supplied.
Please purchase chain which must be
subjected to the weight of 66 lbs. (30 󴧃)
or above .

4.Install the plug covers back when the check is complete.
START-UP PROCEDURE
2.Connect the power cord to power then turn on the main switch on ERV for start-up.
If the ERV does not run, please check the wiring connections.
1.Fill in beginning time on the OA filter before starting up the unit.
The method of remove and install OA filter please refer to P.17~P.18 (Fig.20~22)
and P.18 (Fig.24~25).
3.Remove plug covers in plugs on frame cover and check static pressure.
Using a magnehelic gauge, measure the differential pressure of fresh air and exhaust air
respectively, then adjust the dampers for balancing airflows to make the test value reach
the differential pressure of setting volume as shown below.
<Control panel>
EA knob: Set the exhaust air volume with this knob.
The factory default is 100 CFM.
ASHRAE time knob: The operation state will be changed with this knob. It is in units of
1 hour, for example: set to “10”, 10 minutes (ON) 50 minutes (OFF) 10 minutes (ON)...
cycle operation. The factory default is 60 min/h.
Main switch: Power on or off for ERV. Push the main switch
completely to the on/off position when turning on/off.
1
2
3
4
SA knob: Set the supply air volume with this knob.
The factory default is 100 CFM.
The unit will consume some electricity unless you turn off the main switch.
OPERATION
Note
The SA air volume is limited less than “EA air volume + 20 CFM” when the outdoor
temperature is -22 °F (-30 °C)~14 °F (-10 °C). For example, when the EA air volume
setting is 50 CFM and the SA air volume setting is 100 CFM, actually the EA air volume
will be 50 CFM and the SA air volume will be 70 CFM.
Note
LowLow
High
High Fresh
Supply
air (SA)
The relation between volume
and differential pressure (reference)
Outside
air (OA)
Exhaust
air (EA)
Return
air (RA)
Differential pressure (Pa)
Stale
Volume
(CFM) Fresh
50
60
70
80
90
100
35
45
60
75
100
115
45
60
80
105
140
190
Stale
14
OA filter
BEGINNING TIME:

Filter reset button: Press the button after filter maintenance
for resetting accumulated running time.
Running indicator: When the indicator is on, indicates the
product is running.
6
7
It’s better that the product is operated for 24 hours in order to prevent from being frozen.
OPERATION
(1) The indicator will be on when the product accumulated
running time reaches to 90 days. The buzzing will sound
every hour and 10 seconds in a hour.
(2)If you want to turn off the indication of buzzer, please
press filter reset button about 3 seconds until there is the
sound of a long beep. Press filter reset button about 3
seconds again until there is sound of two quick beeps, the
buzzer indication will be turned on again.
Note
15
Filter indicator: The indicator will light on when the accumulated
running time is up to 3 months. When the indicator is on (with
buzzer sound), indicates need to maintain RA filter and OA filter.
5
The ERV will run as below:
I
O
1
2
3
4
5
6
7
10
20
30
40
50
60
50
60
70
80
90
100
50
60
70
80
90
100
Supply Air
Air fourni
(CFM)
(CFM)
min/h
min/h
Exhaust Air
Air
d'évacuation
Filter
Reset
Button
Bouton de
réinitialisation
du filtre
(pi3/min)
(pi3/min)
MAIN SWITCH
JUMPER CABLE
ON
Setting State
For example: when main switch and wall switch are ON, suppose the customer to set as
ASHRAE:50 min/h, SA:90 CFM, EA:90 CFM,
ON ON OFF
when boost switch is ON, ERV enforces the instructions ASHRAE:60 min/h, SA:100 CFM,
EA:100 CFM;
when boost switch is OFF, ERV restores setting instructions of customer ASHRAE:50 min/h,
SA:90 CFM, EA:90 CFM;
CONNECTED
ON
CONNECTED CONNECTED
ON
ON
10~60
50~100 50~100 50~100 50~100
50~100 50~100 50~100 50~100
10~60 10~60 10~60
OFF ON/OFF
ON/OFF
ON/OFF
OFF
Standby Product is
power off.
WALL SWITCH
BOOST SWITCH
EA SWITCH (CFM)
SA SWITCH (CFM)
ERV ACTION
ERV enforces the
following instructions
ASHRAE TIME
SWITCH (min/h)
ASHRAE: 60 min/h
SA:100 CFM
EA:100 CFM
ERV restores setting
instructions of customer
ASHRAE: 10~60 min/h
SA:50~100 CFM
EA:50~100 CFM
Note

OPERATION
16
<Operation mode>
EA damper open
OA damper open
Center
damper
closed
EA damper closed
CirculationHeat exchange
OA damper closed
Center
damper
open
FV-10VEC2R is recommended for areas where temperature is -22 °F (-30 °C)~104 °F (40 °C).
Supply
air (SA)
Outside
air (OA)
Exhaust
air (EA)
Return
air (RA)
Supply
air (SA)
Return
air (RA)
Outdoor temp. Operation mode and time (min) Air exchange mode
60
>14 °F (-10 °C)
14 °F (-10 °C)~
5 °F (-15 °C)
5 °F (-15 °C)~
-4 °F (-20 °C)
-4 °F (-20 °C)~
-17 °F (-27 °C)
-17 °F (-27 °C)~
-22 °F (-30 °C)
Circulation mode
Stop operating
···
···
60 9
···
35 9
9
9
···
27
···
···
20
-22 °F (-30 °C) ···
474 9
Repetition
When the ASHRAE timer is set to 60 min/h or the boost switch is on.
(The operation time of air exchange mode depends on the ASHRAE timer setting, and it is
automatically set to 60 min/h when the boost switch is on.)

17
Electric shock may result. Disconnect power by switching off wall switch first, then
main switch and unplug the product before working on unit when replacing the
jumper cable with wall switch.
Fig.20
Fig.19
Fig.21
Rotate the plug
clockwise then take
it out.
Lock plate
Frame cover
4-plugs
MAINTENANCE
Electric shock may result. Disconnect power by switching off main switch first, then
unplug the product before working on unit when it is in default mode.
CAUTION
1.Open the frame cover by unlocking the
latches. (Fig.20)
Routine maintenance must be performed
every 2 or 3 months, clogged filters may
cause condensation on the unit due to air
flow reduction.
Never use petrol, benzene, thinner or any
other such chemicals to clean the ERV.
Do not allow water to enter ERV.
Do not immerse resin parts in water over
60 °C.
Please wear gloves to avoid pinching
fingers during maintenance.
(1)If not convenient for maintenance, can
also rotate the lock plate at the hinge and
remove the frame cover. (Fig.21)
(2)There is a spring on the inside of frame
cover, please do not damage or deform
it, otherwise, the ERV may not operate.
(Fig.21)
Note
Note
Please pay attention to dust, condensation
water or parts that may drop down when
the frame cover is opened.
There may be moisture in ERV after running
long time in cold climate, please remove the
4 plugs on frame cover to discharge conden-
sation before open the frame cover. (Fig.19)
1
2
Latch
Spring
(inside)
12

18
MAINTENANCE
3.Clean energy recovery core with vacuum
cleaner. (Fig.23)
5.Reinstall and close frame cover by locking the
latches, then reset the lock plate. (Fig.25)
6.Connect power, press filter reset button
with sound of “beep”, then filter indicator
and buzzer sound will be off. (Fig.26)
4.Replace the OA and RA filters.
Make sure the RA filter adapts to the convex
and the direction of the arrow on the OA
filter is in the same direction as the air flow
displayed on the nearby label. (Fig.24)
Fig.24
OA filter
Convex
RA filter
Lock plate
Latch
Main
switch
Filter reset
button
AIR FLOW
AIR FLOW
Fig.23
Energy recovery
core
Fig.25
2
1
Fig.26
I
O
10
20
30
40
50
60
50
60
70
80
90
100
50
60
70
80
90
100
Supply Air
Air fourni
(CFM)
(CFM)
min/h
min/h
Exhaust Air
Air
d'évacuation
Filter
Reset
Button
Bouton de
réinitialisation
du filtre
(pi3/min)
(pi3/min)
2.Remove OA filter and RA filter to clean with
vacuum cleaner. (Fig.22)
It is suggested to replace the OA filter every
6 months. Please fill in beginning time on
new OA filter before replacing.
Please replace OA filter by Panasonic Model
FV-FL0810VE1or FV-FL1310VE1.
Note
OA filter
RA filter
Step
Step
Fig.22
BEGINNING TIME:
1
2

19
Problem
1.The ERV doesn’t
work.
2.The HVAC/AHU
doesn’t work
when ERV works.
3.Buzzer sound
(10 sec in a hour)
and ERV works.
4.Buzzer sound
(30 sec in a hour)
and ERV doesn’t
work.
5.ERV doesn’t work
base on the setting
air volume.
Running
indicator
(Green)
Display
Off Off
On Off
On Off
Off
Off
Off
On
Blink*
(0.5 s)
Blink*
(0.5 s)
Blink*
(0.5 s)
*The time under “Blink” means the frequency of blink.
Blink*
(0.5 s)
On
On
On
On
Check the power cord is connected.
Filter
indicator
(Red)
Action
TROUBLESHOOTING
If a problem is encountered, please investigate it by going through the following items.
If the problem still persists, please disconnect the power and contact the dealer for repair.
Check the frame cover is closed.
Check the main switch in product body is on.
Check if the spring on the inside of frame cover
is damaged or deformed.
ERV running interval according to the ASHRAE
time setting.
Damper may be frozen shut, please wait for
maximum 24 hours for defrosting.
Please disconnect the power and contact the
dealer to check the HVAC/AHU wiring connect.
SA motor error, please disconnect the power
and contact the dealer for repair.
Off
Blink*
(2 s)
Blink*
(2 s)
EA motor error, please disconnect the power
and contact the dealer for repair.
OA damper error, please disconnect the power
and contact the dealer for repair.
Off EA damper error, please disconnect the power
and contact the dealer for repair.
Blink*
(4 s)
Off Center damper error, please disconnect the
power and contact the dealer for repair.
Temperature sensor error, please disconnect the
power and contact the dealer for repair.
PCB board error, please disconnect the power
and contact the dealer for repair.
When product runs in circulation mode for
defrosting, the air volume will be more than
setting and sound will be slightly louder than
normal operation.
When outdoor temperature is less than 14 °F
(-10 °C), the product will restrict air volume
automatically to protect energy recovery core.
The RA filter and OA filter need to be maintained.
If you do not want the buzzer notification, please
long press the filter reset button for 3 sec to cancel it.
When outdoor temperature is low ( -22 °F (-30 °C),
ERV stops operating automatically.

Warning Concerning Removal of Covers.
The unit should be serviced by qualified technicians only.
Your product is designed and manufactured to ensure a minimum of maintenance.
Should your unit require service or parts, call Panasonic Call Center at 1-866-292-7299 (USA)
or 1-800-669-5165 (Canada).
P0123-0 10VC2R450A
Printed in Mexico
Two Riverfront Plaza, Newark, NJ 07102
www.panasonic.com
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
www.panasonic.com
Panasonic Corporation 2023 Issue date:01/2023
PRODUCT SERVICE
<Ventilation Performance>
<Energy Performance>
The testing of the ventilation performance and the energy performance in accordance with
CSA-C439 standard.
FV-10VEC2R
FV-10VEC2R
Model No.
Model No. Mode
Heating
Cooling
Supply
temperature Net air flow Apparent
sensible
effectiveness
Sensible
recovery
efficiency
Total recovery efficiency
Net
moisture
transfer
Air
direction
Voltage
(V)
Frequency
(Hz) Duct
Exhaust
Exhaust
&
Supply
Supply Fan unit
Static
pressure
Net air flow
(CFM)
Power
consumption
(W)
Power
consumption
(W)
4“/6” 0.1”WG
0.4”WG
-25
4923
25
27
53
57-13
-25 30 64-13
32
°F °C L/s CFM
95 35
0
31 66
32 0
40
60%
55%
29
77
100
32
663195 35 42
39
68
80%
65%
56%
77%
73%
83%
67%
60%
81%
77%
0.78
0.71
0.58
0.74
0.71
85
32 0
120 100
100
100 81
90100
60 50
(22.4)
SPECIFICATIONS
Weight
Ib.(󴧃)
