Panasonic KX-TGA641 User manual

Panasonic
Installation Manual
Additional Digital Cordless Handset
Model No. KX-TGA641
DEer
6.0
1I11 111111111111
*TGA641 *
Thank you for purchasing a Panasonic product.
This unit is an additional handset compatible with the following
series
of Panasonic Digital Cordless Phone:
KX- TG6411 /KX- TG6421 /KX- TG6431 /KX- TG6441/
KX-TG7431
You must registerthis handsetwith yourbase unit before it can
be used. This installation manual describes only the steps
needed to register and begin using the handset. Please read
the base unit's operating instructions for further details.
~bctrg.t"~batt~It,liJfQt~bout7bou,..befo .. eini:tial use.
-. " .. " .. "."."."."-- -." .- .'-'---:.;' .. : :-., '_." ---_. ..
Please read this installation manual before using the unit and
save it for future reference.
For assistance, visit our website:
http://www.panasonic.com/help
for customers in the U.S.A. or
Puerto Rico.
PNQX1634ZA DM1108DMO

Accessory information
Supplied accessories
Charger/PNWETGA641T
AC adaptor/PQLV219Z
.
...
.Qu.ntity
1
1
Rechargeable batteries/HHR-4DPA
(Part No. HHR-65AAABU
or N4DHYYY00002)
Handset cover*1IPNYNTGA641
TR
Belt c1ip/PNKE1029Z1
2
1
1
*1 The handset cover comes attached to the handset.
Note:
•Please read the base unit's operating instructions for additionall
replacement accessories.
Setting up
Connections
Note:
•Use only the supplied Panasonic AC adaptor PQLV219.
•The AC adaptor must remain connected at all times. (It
is normal for
the adaptor to feel warm during use.)
2For assistance, please visit http://www.panasonic.com/help

Battery installation/Battery charge
Important:
•Use the supplied rechargeable batteries. For replacement, we
recommend using the Panasonic rechargeable batteries noted on
page 2.
•Wipe the battery ends (±), 8) with adry cloth.
•Avoid touching the battery ends (±), 8) or the unit contacts.
•Confirm correct polarities ((f), 8).
•USE ONLY Ni-MH batteries AAA (R03) size.
•Do NOT use Alkaline/Manganese/Ni-Cd batteries.
Charge for about 7hours.
•When the batteries are fully charged, the charge indicator goes off.
Rechargeable Ni-MH
ONLY
Confirm "Charging"
is displayed.
~
~
Note:
•Ifthe batteries are fully charged, but the operating time seems to be
shorter, clean the battery ends ((f), 8) and the charge contacts with a
dry cloth and charge again.
For assistance, please visit http://www.panasonic.com/help 3

Controls
oCharge indicator
Ringer indicator
Message indicator
f) Speaker
eSoft keys
o [~] (TALK)
o [~] (SP-PHONE:
Speakerphone)
oHeadset jack
oDial keypad ([* ]: TONE)
oReceiver
oDisplay
~ [OFF]
6) Navigator key ([.]/[,])
.-:::] (Volume: [.]/[,])
~ [FLASH] [CALL WAIT]
Q) Microphone
~ Charge contacts
JIB JH jj
T T j
:n Ie IS I
Registering ahandset to abase unit
1Base unit:
.KX-TG6411 series
Press and hold [LOCATOR] for about 4seconds. (No registration
tone)
•KX-TG6421/KX-TG6431/KX-TG6441/KX-TG7 431 series
Press and hold [LOCATOR] for about 4seconds until the
registration tone sounds.
•If all registered handsets start ringing, press the same button to
stop. Then repeat this step.
•The next step must be completed within 90 seconds.
4For assistance, please visit http://www.panasonic.com/help

2Handset:
Press [OK], then wait until along beep sounds.
Note:
•If an error tone sounds,
or ifYis still displayed, register the handset
according to the base unit's operating instructions.
Display language
1 [MENU] ~ [U][1][1][0]
2[']/[.]: Select the desired setting.
3Press the middle soft key to save. ~ [OFF]
Belt clip
• To attach .To remove
Wall mounting
1Drive the screws (not supplied) into the wall.
2Mount the charger (0), then slide it down (@) and to the right (0)
until it is secure.
For assistance, please visit http://www.panasonic.com/help 5

For KX-TG7431 series users:
Available handset feature overview
Main feature differences
'>"'> .................
,~i?
»i> 1~~li. /
. Feature
,': ....
IO(.TGA641
.• 1Ct.;[(':",ilF''''·Y > •••.. (
••
.. ". ,·{.·'r .,:'. 'f, . ''':r\F
Description Same type
of handset Same type of handset
supplied with supplied with
KX-TG6411/KX-TG6421/ KX-TG7431 series
KX-TG6431/KX-TG6441
senes
Display size 1.8 inches
2.1 inches
Control type 3soft keys 3soft keys
(page 7) (Middle softkey: Center
of joystick)
Navigator key/ Joystick
.-:::J (Volume) key (Up/down/left/right)
(Up/down)
Display mode
*1
-•
Message lis(2 -•
*1 This feature allows you to select how the display shows:
-multiple items at atime
- 1 item at atime
in large characters
*2 The unit displays alist
of all recorded messages and allows you to
select the item to play back.
Note:
•For some features, the operations are slightly different from the
descriptions
in the KX-TG7431 series base unit's operating
instructions (page 8).
6For assistance, please visit http://www.panasonic.com/help

Joystick
Soft keys
•KX-TGA740
Soft keys
Control type
•KX-TGA641
.i_.~T-~1·
:~JlJ
J,!,~~.: t1 : ...• ~ .
. I. .:::::::J
K~~,··,I .
. ?~T __ ~_I_:~I· ......... ......,1.
Navigator key
·,··'FIRdlion··'.·,·····.'···:·
• <KX·TG,~141
' IQC~TGA'40 .....
,.... .' .....
Using soft keys Left, middle, Left, center
right ofjoystick
*1 ,
right
Scrolling through vanous lists or items
[.]/[.]
(.]/(.]*1
Adjusting the receiver or speaker
(.]/[.]
[']/(.]*2
volume:
-while talking
-while listening to messages
Moving the cursor (right or left) to edit
[.]/[.] (~]/[ .... r3
number or name
Skipping orrepeating during message -
(~]/[ .... ]*4
playback
*1 Pressing down the center of the joystick.
*2 Pushing the joystick down or up.
*3 Pushing the joystick right or left.
*4 To skip messages, push the joystick right.
To repeat messages, push the joystick left.
For assistance, please visit http://www.panasonic.com/help 7

Operational differences for some features
The following features include different operations from the descriptions
in the KX-TG7 431 series base unit's operating instructions. The
differences are described in the boxed text.
Shared phonebook: Searching by first character (alphabetically)
11[t+J] -) [SEARCH] I
2Press the dial key ([0] - [9], [*], or [0]) which contains the
character you are searching for.
3[Y]/[!]: Scroll through the phonebook if necessary.
4 [~]
Call block (Caller 10 subscribers only): Storing unwanted callers
•From the caller list:
1[MENU] -) [0][2][1 ][3]
2[Y]/[!]: Selectthe entry to be blocked. I
• To edit the number, press [EDIT] repeatedly until the phone
number
is shown in the 1O-digit format.
3 [SAVE]
4[Y]/[!]: "Call block" -) [SELECT]
5[Y]/[!]: "Yes" -) [SELECT] -) [OFF]
Caller list: Editing a caller's phone number before calling back
1[MENU] -) [0][2][1 ][3]
I2 [Y ]/[!]: Select the desired entry. I
3Press [EDIT] repeatedly until the phone number is shown in the
desired format.
4 [~]
8For assistance, please visit http://www.panasonic.com/help

Caller list: Storing caller information to the phonebook
1[MENU] ~ [0][2][1][3]
I2 [, ]/[ A]: Select the desired entry.
•
To edit the number, press [EDIT] repeatedly until the phone
number is shown
in the desired format.
3 [SAVE]
4 [,]/[A]: "Phonebook" ~ [SELECT]
5Continue from step 2, "Editing entries", in the operating instructions.
For your safety
To prevent severe injury and loss of life/property, read this section carefully before
using the product to ensure proper and safe operation
of your product.
WARNING
Power connection
•Completely insert the AC adaptor/power plug into the poweroutlet. Failure to do
so may cause electric shock and/or excessive heat resulting
in afire.
•Regularly remove any dust, etc. from the AC adaptor/power plug by pulling it
from the poweroutlet, then wiping with adry cloth. Accumulated dust may cause
an insulation defect from moisture, etc. resulting
in afire.
•Unplug the product from power outlets
if it emits smoke, an abnormal smell, or
makes an unusual noise. These conditions can cause fire or electric shock.
Confirm that smoke has stopped emitting and contact the Panasonic Call Center
at 1-800-211- PANA (1-800-211-7262).
Installation
• To prevent the risk of fire orelectrical shock, do not expose the product to rain or
any type of moisture.
•Do not place or use this product near automatically controlled devices such as
automatic doors and fire alarms. Radio waves emitted from this product may
cause such devices to malfunction resulting
in an accident.
CAUTION
Installation and relocation
•The AC adaptor is used as the main disconnectdevice. Ensure thatthe AC outlet
is installed near the product and is easily accessible.
For assistance, please visit http://www.panasonic.com/help 9

Battery
• We recommend using the supplied batteries or additional/replacement batteries
noted
on page 2for replacement battery information. USE ONLY rechargeable
Ni-MH batteries AAA (R03) size.
• Do not mix old and new batteries.
•Do not open or mutilate the batteries. Released electrolyte from the batteries
is
corrosive and may cause burns or injury to the eyes or skin. The electrolyte is
toxic and may be harmful
if swallowed.
•Exercise care when handling the batteries. Do not allow conductive materials
such as rings, bracelets, or keys to touch the batteries, otherwise ashort circuit
may cause the batteries and/or the conductive material to overheat and cause
burns.
•Charge the batteries provided with or identified for use with this product only,
in
accordance with the instructions and limitations specified in this manual.
•Only use acompatible base unit (or charger) to charge the batteries. Do not
tamper with the base unit (or charger). Failure to follow these instructions may
cause the batteries to swell or explode.
Attention:
Anickel metal hydride battery that is
recyclable powers the product you have
purchased.
Please call 1-800-8-BATIERY (1-800-822-
8837) for information
on how to recycle this
battery.
Other information
•Operating the product near electrical appliances may cause interference. Move
away from the electrical appliances.
•Use only the power cord and batteries indicated
in this manual. Do not dispose
of batteries
in afire. They may explode. Check with local codes for possible
special disposal instructions.
-------- " .. ,,''''~--
Routine care
•Wipe the outer surface
of the product with asoft moist cloth.
• Do not use benzine, thinner, or any abrasive powder.
Notice for product disposal, transfer, or return
•This product can store your private/confidential information. To protect your
privacy/confidentiality, we recommend that you erase information such as
phonebook or caller list entries from the memory before you dispose of, transfer,
or return the
prodUCt.
