Panasonic WX-CH457P User manual

FrançaisEnglish
Operating Instructions
All-in-One Headset
Model No. WX-CH457P
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
No model number suffix is shown in this Operating Instructions.
PUQX1020YA
WX-CH457P_PUQX1020ZAV1.indb 1 2021/07/02 14:31:21

2
FEDERAL COMMUNICATIONS COMMISSION / INDUSTRY CANADA
INTERFERENCE STATEMENT
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
The available scientific evidence does not show that any health problems are associated
with using low power wireless devices. There is no proof, however, that these low power
wireless devices are absolutely safe. Low power Wireless devices emit low levels of
radio frequency energy (RF) in the microwave range while being used. Whereas high
levels of RF can produce health effects (by heating tissue), exposure of low-level RF
that does not produce heating effects causes no known adverse health effects. Many
studies of low-level RF exposures have not found any biological effects. Some studies
have suggested that some biological effects might occur, but such findings have not
been confirmed by additional research. WX-CH457P has been tested and found to
comply with FCC/IC radiation exposure limits set forth for an uncontrolled environment
and meets the FCC radio frequency (RF) Exposure Guidelines and RSS -102 of the IC
radio frequency (RF) Exposure rules.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
ENGLISH VERSION
Safety precautions
WX-CH457P_PUQX1020YAV1.indb 2 2021/07/06 13:30:46

English
3
WARNING:
 To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture.
 The apparatus should not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, should be placed on the apparatus.
 All work related to the installation of this product should be made by qualified service
personnel or system installers.
 The risk of hearing impairment due to exposure to excessive sound levels may be
reduced by listening at lower volumes and for shorter durations. Excessive sound
pressure from All-in-one headset can cause hearing loss. Do not use your headset at
high volume.
 Operating near 1.9 GHz electrical appliances may cause interference. Move away
from the electrical appliances.
 This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
 MEDICAL:
Consult the manufacturer of any personal medical devices, such as pacemakers, to
determine if they are adequately shielded from external RF (radio frequency) energy.
(The unit operates in the frequency range of 1.92 GHz to 1.93 GHz, and the power
output level is 115 mW (max.).)
Do not use the unit in health care facilities if any regulations posted in the area
instruct you not to do so. Hospitals or health care facilities may be using equipment
that could be sensitive to external RF (radio frequency) energy.
 Batteries (battery pack or batteries installed) shall not be exposed to excessive heat
such as sunshine, fire or the like.
CAUTION:
 Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
 These servicing instructions are for use by qualified service personnel only. To reduce
the risk of electric shock do not perform any servicing other than that contained in the
operating instructions unless you are qualified to do so.
 Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

The battery used in this device may present a risk of fire or chemical burn if mistreated.
Do not disassemble, heat above +40 °C {104 °F}, or incinerate. Replace battery with
WX-SB100 only.
Use of another battery may present a risk of fire or explosion.
 Dispose of used battery promptly. Keep away from children. Do not disassemble and
do not dispose of in fire.
WX-CH457P_PUQX1020ZAV1.indb 3 2021/07/02 14:31:22

4
The model number and serial number of this product may be found on the surface of the unit.
You should note the model number and serial number of this unit in the space provided and
retain this book as a permanent record of your purchase to aid identification in the event of theft.
Model No.
Serial No.
For U.S.A.
ICES-003
CAN ICES-003(A)/NMB-003(A)
For Canada
Safety precautions
Descriptions of graphic symbols
This symbol indicates caution symbol.
This symbol instructs user to comply with the contents of the Operating Instructions.
RSS-Gen
 Under Industry Canada regulations, this radio transmitter may only operate using
an antenna of a type and maximum (or lesser) gain approved for the transmitter by
Industry Canada. To reduce potential radio interference to other users, the antenna
type and its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful communication.
 This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause
undesired operation of the device.
For Canada
CAUTION:
The FCC ID number for this radio equipment is listed below.
FCC ID: ACJ9TAWX-CH457P
For U.S.A.
WX-CH457P_PUQX1020ZAV1.indb 4 2021/07/02 14:31:22

English
5
A lithium-ion battery that is recyclable
powers the product you have purchased.
Please call 1-800-8-BATTERY for information
on how to recycle this battery.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
8) Only use attachments/accessories specified by the manufacturer.
IMPORTANT SAFETY INSTRUCTIONS
WX-CH457P_PUQX1020ZAV1.indb 5 2021/07/02 14:31:22

6
Contents
Safety precautions……………………… 2
Before use ……………………………… 7
Preface …………………………………… 7
Features…………………………………… 7
System diagram ………………………… 8
Limitation of liability ……………………… 9
Disclaimer of warranty…………………… 9
Abbreviations …………………………… 9
Copyright ………………………………… 9
Precautions ……………………………… 10
Major operating controls and their
functions ……………………………… 12
Battery loading & replacement ……… 15
Loading …………………………………… 15
Replacement……………………………… 15
Color tip replacement procedure …… 16
Operating procedures ………………… 17
Turning on the power …………………… 17
Wearing the product……………………… 17
Volume adjustment ……………………… 18
Communications with customers (TALK) … 19
Communications with other store
personnel (PAGE)……………………… 20
Alert notification ………………………… 21
External device control ………………… 21
Dual lane operation ……………………… 22
Communication limitations ……………… 23
Out of communication range …………… 23
Battery …………………………………… 23
Turning off the power …………………… 23
Charging ………………………………… 24
Setting the unit ………………………… 25
ID registration …………………………… 25
Manager mode …………………………… 27
Canceling the manager mode ………… 29
Auto-Talk-Lock setup …………………… 30
Center Module search …………………… 32
Deletion of ID …………………………… 33
Setting mode……………………………… 34
Starting in setting mode ………………… 35
Talk button setting (1 blink)……………… 36
Page button setting (2 blinks)…………… 36
Voice prompt setting (3 blinks) ………… 36
Unused (4 blinks) ………………………… 37
Talk/Page Auto Off setting (5 blinks) …… 37
Initialization (6 blinks) …………………… 37
Center Module model selection (7 blinks) … 37
Headset Microphone Gain (8 blinks)…… 38
Talkback (9 blinks) ……………………… 38
Maintenance …………………………… 39
Troubleshooting ………………………… 40
Specifications …………………………… 41
Accessories……………………………… 41
Standard accessories …………………… 41
Optional accessories …………………… 41
Table of beep tones …………………… 42
WX-CH457P_PUQX1020ZAV1.indb 6 2021/07/02 14:31:22

English
7
Before use
 Preface
All-in-One Headset WX-CH457P is exclusively designed for Panasonic Wireless
Communication System, which is used with drive-thru order posts, etc. This product is
equipped with the microphone, earphone as well as battery compartment and control
buttons. With the built-in antennas, transmitter, and receiver, users can communicate with
other store personnel and customers.
 Features
 This product can be used with Center Module WX-CC411, WX-CC411A, WX-CC412,
WX-CC412A, WX-C3010.
 This product uses a system compliant with the 1.9 GHz band DECT* standard so it will
not suffer any interference from microwave ovens or wireless LANs which operate in the
2.4 GHz and higher frequency bands.
* Digital Enhanced Cordless Telecommunications
 Manager mode
Only one All-in-One Headset can be set to manager mode for each lane of the center
module. A person using this headset has the priority of communication.
 When the Auto-Talk-Lock function is activated, with the Auto-Talk-Lock function, users
can communicate with customers without holding down the button.
 It is possible to use voice prompt to check the settings of this product.
 When using this product in the dual lane system, it is possible to communicate without
changing the lane setting.
 It is possible to select the Talk-Lock or Press-To-Talk mode.
 It is possible to select the Page-Lock or Press-To-Page mode.
 Email notifications and other alerts can be sent to external parties through the Center
Module by operations from this product.
WX-CH457P_PUQX1020ZAV1.indb 7 2021/07/02 14:31:22

8
 System diagram
Product users can communicate with each other and with customers at the order post by
connecting wirelessly to the Center Module.
Center Module
WX-CC411/WX-CC411A/
WX-CC412/WX-CC412A/
WX-C3010
Speaker
Microphone
TALK
(Communications with
customers)
All-in-One Headset
WX-CH457P
Order Post
All-in-One Headset
WX-CH457P
All-in-One Headset
WX-CH457P
Vehicle
Detector
PAGE
(Communications with
other store personnel)
Before use
WX-CH457P_PUQX1020ZAV1.indb 8 2021/07/02 14:31:22

English
9
 Limitation of liability
THIS PUBLICATION IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE,
OR NON-INFRINGEMENT OF THE THIRD PARTY’S RIGHT.
 Disclaimer of warranty
IN NO EVENT SHALL Panasonic Corporation BE LIABLE TO ANY PARTY OR ANY
PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE
PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:
(1) ANY DAMAGE AND LOSS, INCLUDING WITHOUT LIMITATION, DIRECT OR
INDIRECT, SPECIAL, CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF OR
RELATING TO THE PRODUCT;
(2) ANY INCONVENIENCE, LOSS, OR DAMAGE CAUSED BY INAPPROPRIATE USE
OR NEGLIGENT OPERATION OF THE USER;
(3) UNAUTHORIZED DISASSEMBLE, REPAIR OR MODIFICATION OF THE PRODUCT
BY THE USER;
(4) ANY PROBLEM CAUSING FAILED SIGNAL TRANSMISSION RESULTING IN
CONSEQUENTIAL INCONVENIENCE, LOSS OR DAMAGE, ARISING OUT OF
CAUSES SUCH AS SYSTEM MALFUNCTION, FAULT, SET UP OR INSTALLATION;
(5) ANY PROBLEM, CONSEQUENTIAL INCONVENIENCE, OR LOSS OR DAMAGE,
ARISING OUT OF THE SYSTEM COMBINED BY THE DEVICES OF THIRD PARTY.
 Abbreviations
The following abbreviations are used in this manual.
 All-in-One Headset (WX-CH457P) is referred to as this product or headset.
 Center Module (WX-CC411/WX-CC411A/WX-CC412/WX-CC412A/WX-C3010: sold
separately) is referred to as Center Module.
 Battery (WX-SB100: optional accessory) is referred to as battery.
 Battery Charger (WX-Z3040A: optional accessory) is referred to as battery charger.
Information on optional accessories and other items included in this manual is as of August
2021. For the latest information, inquire at the shop where you purchased this product.
 Copyright
Distributing, copying, disassembling, reverse compiling and reverse engineering of the
software provided with this product are all expressly prohibited. In addition, exporting any
software provided with this product violating export laws is prohibited.
WX-CH457P_PUQX1020ZAV1.indb 9 2021/07/02 14:31:22

10
Precautions
 This product is for indoor use only.
It cannot be used outdoors.
Avoid installation in a location where the unit will be exposed to direct sunlight for
extended periods or near a cooling or heating appliance.
Otherwise, deformation, discoloration, malfunctioning and/or problems in operation may
result. Operate the unit where it will not be splashed or sprayed by water.
 Handle this product carefully. This product uses parts that may be damaged by improper
handling or storage.
 Use the dedicated Battery WX-SB100 (optional accessory). Also check the operating
instructions for the Battery Charger WX-Z3040A (optional accessory).
 The supplied charging attachment is required when recharging the battery with the
battery charger. For further details, refer to page 24.
 Do not expose the battery to excessive heat, such as direct sunlight or fire.
 Follow the instructions of battery for care and handling.
 When using an implanted medical device, do not use this product. The medical device
may malfunction.
 Turn off this product when not in use, in order to save the battery life.
 When not using for long periods of time, do not leave the battery in this product. Be sure
to remove it.
 Use the dedicated charger for the battery. Generation of heat, ignition or rupture of the
battery may result.
 Do not throw the battery into a fire or expose it to excessive heat. Generation of heat,
ignition or rupture of the battery may result.
 Do not insert sharp objects into the battery, apply impact on the battery, or disassemble/
modify the battery. Generation of heat, ignition or rupture of the battery may result.
 Do not short positive (+) and negative (–) contact. Do not carry it around or store it
together with necklaces, hairpins, etc. Generation of heat, ignition or rupture of the
battery may result.
 Do not charge, use, or leave the battery where temperatures are high such as a place
close to fire or a place under the hot sun. Generation of heat, ignition or rupture of the
battery may result.
 Do not put this product close to a medical equipment. (Do not bring this product into
operating room, intensive care units (ICU) and coronary care units (CCU).) Radio waves
from this product may cause the trouble by a malfunction for medical equipment.
 Do not use this product close to an automatic control equipment like an automatic
door, fire alarm and so on. Radio waves from this product may cause the trouble by a
malfunction for automatic equipment.
 Do not disassemble this product. Otherwise, it may cause fire or electric shock.
 Before proceeding to maintain this product, remove the battery. Otherwise you may
receive an electric shock.
 When it is time to dispose of this product, ask a specialist contractor to do this for you.
Burning it gives off chemicals, possibly damaging your eyes, causing a fire and/or
burning yourself.
 Do not put this product on a place with moisture or dirt. There is the risk of injury.
WX-CH457P_PUQX1020ZAV1.indb 10 2021/07/02 14:31:22

English
11
When there is stubborn dirt on the surfaces of the product
Soak a soft cloth into a dishwashing liquid which has been diluted with water, wring it out
well, and then wipe the surfaces gently.
Then use a dry, soft cloth to take up all the traces of the liquid.
 Do not spray with alcohol, disinfectant, detergent, etc. Also, do not press on the
microphone with your fingers or a cloth to wipe it. These can cause the product to
malfunction.
Important
Microphone
WX-CH457P_PUQX1020ZAV1.indb 11 2021/07/02 14:31:22

12
<
;>

:
9
2
6
5
4
3
1
7
8
1Head pad
The size is adjustable by sliding the head pad side.
2Battery lock
When removing the battery, slide out the lock.
When loading a battery, insert the battery until the lock clicks.
3Color tip
Replacing the tip with a supplied color tip enables this product to be differentiated by
color.
4Ear pad
Put this on your ear.
Major operating controls and their functions
WX-CH457P_PUQX1020ZAV1.indb 12 2021/07/02 14:31:22

English
13
5USB connector cover
Covers the maintenance USB connector. The USB connector inside the USB connector
cover is for maintenance only and cannot be used for battery charging.
6Microphone boom
Rotate and adjust this to a position near your mouth.
The product can also be turned on and off by rotating this.
7Microphone
Captures sound.
8Lane indicator
Lights orange or green to indicate which lane is in operation.
Orange : Lane A is selected.
Green : Lane B is selected.
Orange blinking: Communication on Lane A in progress.
Green blinking : Communication on Lane B in progress.
9Power indicator
The indicator shows the status as follows.
Green : Power is supplied and the unit is operating.
This product does not have a power switch.Turn on/off the
power by rotating the microphone boom.
Green blinking : Power is supplied and manager mode is activated.
Red : The battery is almost exhausted. Replace the battery with a charged
one.
Red blinking : An error has occurred.
Orange blinking: Power is supplied and ID registration is in progress.
:Setting indicator
Lights only during setting to indicate the setting state.
;Volume control button [VOL]
Pressing the button will increase or decrease the sound level.
Press the button to increase the sound level. Each time the button is pressed, a beep
notifies the user that the volume is being increased. When the volume reaches the upper
limit, two beeps can be heard, and if you press the button again, the volume returns to
the lower limit.
When this product’s power is turned off and then turned back on, the volume will return
to the default setting. For details on volume adjustment, refer to page 18.
WX-CH457P_PUQX1020ZAV1.indb 13 2021/07/02 14:31:22

14
<Talk button [T]
This button controls communications with the customer.
This button’s operation differs depending on the settings of this product. For further
details, refer to “Talk button setting” (page 36).
<When the Talk -Lock mode is preset>
When you press the [T] button once, you can talk with a customer at the order post of
the connected lane. Press the button again to end the call.
<When the Press-To-Talk (PTT) mode is preset>
While the [T] button is being pressed, you can talk with a customer at the order post of
the connected lane.
Page button [P]
This button controls communications with store personnel.
This button’s operation differs depending on the settings of this product. For further
details, refer to “Page button setting” (page 36).
<When the Page-Lock mode is preset>
When you press the [P] button once, you can talk with store personnel of the connected
lane. Press the button again to end the call.
<When the Press-To-Page (PTP) mode is preset>
While the [P] button is being pressed, you can talk with store personnel of the connected
lane.
>Shift button [S]
The following functions can be performed by pressing this button or this button and
another button at the same time.
ySwitching lanes (page 22)
yAlert notification (page 21)
yConfiguring and canceling manager mode (pages 27 to 29)
yConfiguring Auto-Talk-Lock (pages 30 to 31)
yStarting setting mode and configuring settings (pages 34 to 38)
Major operating controls and their functions
WX-CH457P_PUQX1020ZAV1.indb 14 2021/07/02 14:31:23

English
15
Battery loading & replacement
 Refer to operating instructions included with the battery and battery charger.
 Charge the battery in advance.
Note
 Loading
1 Insert the battery in this product as shown in the figure below.
●Note the facing of the battery when inserting it.
●Insert the battery until the lock clicks.
Battery
Terminals of the
battery
 Replacement
1 Press the battery lock shown in the figure below, and then remove the battery.
Battery Lock
WX-CH457P_PUQX1020ZAV1.indb 15 2021/07/02 14:31:23

16
Color tip replacement procedure
Replacing the color tip enables this product to be differentiated by color.
Replace the color tip (accessory) as shown in the figure below.
Color tip
(black, red, blue, yellow, green)
WX-CH457P_PUQX1020ZAV1.indb 16 2021/07/02 14:31:23

English
17
Operating procedures
Prior to operating this product, confirm that the system setup for this product, Center
Module, order post, and other devices has been completed.
 Turning on the power
1 Insert the battery in this product and then rotate the microphone boom to turn
on the power.
●When the power is turned on, the voice messages “Hello”, “Headset xx” (xx: ID
number registered in the Center Module) and “Lane x” (x: Connected Lane number)
are heard from the earphone.
 Wearing the product
1 Wear this product.
Place this product on your head with the ear pad side up against your ear.
The length can be adjusted on the head pad side.
Earphone
Head pad
Microphone
boom
Rotate the microphone boom to adjust it so that the microphone boom tip is positioned
near your mouth.
 You can also attach a strap (commercially
available) to this product.
Note
Strap
(commercially
available)
WX-CH457P_PUQX1020ZAV1.indb 17 2021/07/02 14:31:23

18
 Volume adjustment
Select a proper sound level by pressing the [VOL] button.
[VOL] button
The volume level is adjustable to any of 5 levels. Each press of the [VOL] button increases
the volume level, and the volume level becomes the minimum when the maximum volume
level is exceeded.
12345
Minimum Initial state Maximum
 When the [VOL] button is pressed, a confirmation tone can be heard from the
earphone. One beep can be heard when the volume level changes, and two beeps
can be heard when the volume level becomes the maximum.
 When you hold down the [VOL] button, the volume level changes every 0.7 second.
 When this product’s power is turned off, the volume setting returns to the initial state.
Note
Operating procedures
WX-CH457P_PUQX1020ZAV1.indb 18 2021/07/02 14:31:23

English
19
 Communications with customers (TALK)
Any store personnel wearing the headset can communicate bidirectionally with any
customer who is at the order post.
 You will hear a beep in this product when a vehicle arrives at the order post.
When the Talk-Lock mode is preset
1 Press the [T] button.
●A beep is heard from the earphone to confirm that communication has been
established. In this state, you can talk with a customer at the order post by speaking
into the microphone of this product.
2 Press the [T] button again.
●Communication is interrupted and the conversation is ended.
When the Press-To-Talk (PTT) mode is preset
1 Hold down the [T] button.
●A beep is heard from the earphone to confirm that communication has been
established. In this state, you can talk with a customer at the order post by speaking
into the microphone of this product.
2 Release the [T] button.
●Communication is interrupted and the conversation is ended.
[T] button
 The Talk-Lock mode and the Press-To-Talk (PTT) mode can be configured in the
setting mode. For further details, refer to pages 35 and 36.
 Do not hold the microphone boom while communicating on this product. Doing so will
result in feedback, causing the order post, etc. to output abnormal sound.
Note
WX-CH457P_PUQX1020ZAV1.indb 19 2021/07/02 14:31:23

20
 Communications with other store personnel (PAGE)
Store personnel wearing headsets can communicate with each other. The sound cannot be
heard at the order post.
When the Page-Lock mode is preset
1 Press the [P] button.
●A beep is heard from the earphone to confirm that communication has been
established. In this state, you can talk with a store personnel by speaking into the
microphone of this product.
2 Press the [P] button again.
●Communication is interrupted and the conversation is ended.
When the Press-To-Page (PTP) mode is preset
1 Hold down the [P] button.
●A beep is heard from the earphone to confirm that communication has been
established. In this state, you can talk with a store personnel by speaking into the
microphone of this product.
2 Release the [P] button.
●Communication is interrupted and the conversation is ended.
[P] button
 The Page-Lock mode and the Press-To-Page (PTP) mode can be configured in the
setting mode. For further details, refer to pages 35 and 36.
 Do not hold the microphone boom while communicating on this product. Doing so will
result in feedback, causing the order post, etc. to output abnormal sound.
Note
Operating procedures
WX-CH457P_PUQX1020ZAV1.indb 20 2021/07/02 14:31:23
