Panasonic EP3513-U1 Building instructions

EP3513 ORDER NO.HPD0509U24C1
-1 -
MASSAGE LOUNGER
EP3513-U1
SPECIFICATIONS
©2005 Matsushita Electric Works, Ltd.
All rights reserved. Unauthorized copying
and distribution is a violation of law.

EP3513 ORDER NO.HPD0509U24C1
-2 -
CONTENTS Page
1 COMPONENTS IDENTIFICATION…………………………………………………………………………………………………………………………3
2 MASSAGE RANGE（MOVEMENT RANGE OF MASSAGE WHEELS）………………………………………………………………………………5
3 TURNING ON THE POWER………………………………………………………………………………………………………………………………6
4 REQUIRED TOOLS…………………………………………………………………………………………………………………………………………7
5 DISPLAY METHOD OF MASSARG BLOCK TOTAL USE TIME AND OPERATION TIME…………………………………………………………8
6 DISASSEMBLY………………………………………………………………………………………………………………………………………………12
7 ACTUAL WIRING DIAGRAM……………………………………………………………………………………………………………………………52
8 CHECKING…………………………………………………………………………………………………………………………………………………55
9 GREASE……………………………………………………………………………………………………………………………………………………60
10 EXPLODED VIEW…………………………………………………………………………………………………………………………………………63
11 REPLACEMENT PARTS LIST……………………………………………………………………………………………………………………………70

EP3513 ORDER NO.HPD0509U24C1
-3 -
1. COMPONENTS IDENTIFICATION
1.1 MASSAGE LOUNGER

EP3513 ORDER NO.HPD0509U24C1
-4 -
1.2 CONTROLLER

EP3513 ORDER NO.HPD0509U24C1
-5 -
2. MASSAGE RANGE(MOVEMENT RANGE OF MASSAGE
WHEELS)SHIATSU MASSAGE, SWEDISH MASSAGE, KNEADING,
VIBRATING, TAPPING A, TAPPING B, WHOLE BACK ROLLING,
REGIONAL ROLLING
Width adjustment
Approx.2in. to 8in. (5cm to 21cm)
Intensity adjustment
Shiatsu, Swedish, Knead, Tap A, Tap B,
whole back roll, and Regional roll (from gentle to strong)
:2in. (5cm) - wide adjustability where massage heads push
out toward body as intensity increases.

EP3513 ORDER NO.HPD0509U24C1
-6 -
3. TURNING ON THE POWER
1. Plug the power plug into the power socket.
2. Turn the lock switch to the open position.
3. Turn on the power switch on the back of the unit.
･When the operating lock switch is pointing toward ‘lock’, the power switch cannot be moved to the ‘on’ position.
Timer
When the on/off button is pushed, a timer begins to prevent overuse. After approximately 15 minutes, time expires and the
massage wheel goes into storage position.
After each use.
･Be sure to turn the power switch to ‘off’.
･To prevent children from using this unit, lock the power switch by moving the operating lock
switch to the ‘lock’ position.
･As a further caution, unplug the power cord from the power socket after each use.

EP3513 ORDER NO.HPD0509U24C1
-7 -
4. REQUIRED TOOLS

EP3513 ORDER NO.HPD0509U24C1
-8 -
5. DISPLAY METHOD OF MASSAGE BLOCK TOTAL USE TIME
AND OPERATION TIME
5.1 ADJUSTMENT OF PRESSURE SENSOR
How to adjust the Pressure sensor
The adjustment of the Pressure sensor is necessary every time after the Main PCB or Massage mechanism block are
replaced or repaired disassembled & reassembled.
First, keep the Massage mechanism block unloaded without pressure and move it upward halfway.
- If the Massage mechanism block is at the highest or lowest position, you cannot arrange the pressure sensor correctly
because the fabric becomes tense with pressure.
- Keep the Controller cover closed.
1. Insert the Power plug into the power source and turn on the switch of the Power source switch block.
2. While pushing the buttons of Ⅱand Ⅲ, continue to push the On/off button for more than approximately three seconds.
3. After the buttons of Ⅱand Ⅲlight, open the Controller cover and push the Lateral button.
- On the screen of remaining operation time, the current pressure is shown (0-3), which the Massage balls are enduring.
4. Close the Controller cover and push the Focus button.
- The load on the Massage balls when the switch is pushed is considered basic point, and from then the scanning and the
sensing the body pressure are executed based on the basic point.
- When the adjustment of pressure sensor is finished, the remaining time is shown ‘0’ and the buttons of Ⅱand Ⅲgo off.

EP3513 ORDER NO.HPD0509U24C1
-9 -
5.2 DISPLAY METHOD OF MASSAGE BLOCK TOTAL USE TIME
1. Insert the Power plug into the power source and turn on the switch of the Power source switch block.
2. Close the Controller cover.
3. While pushing the buttons of Ⅲand Ⅳ, continue to push the On/off button for more than approximately three seconds.
4. After the buttons of User A and User C light, open the Controller cover and push the OK button.
- The accumulative usage time is shown on the Controller.
- If the accumulative usage time is less than five hours, it does not show anything.If it is less than 10 hours, it is shown five
hours.
- The maximum indication time is 5,000 hours.

EP3513 ORDER NO.HPD0509U24C1
-10 -

EP3513 ORDER NO.HPD0509U24C1
-11 -
5.3 DISPLAY METHOD OF OPERATION TIME
While in the display method of Massage block total use time, push the buttons on the Controller to indicate the accumulative
usage time of each operations.

EP3513 ORDER NO.HPD0509U24C1
-12 -
6. DISASSEMBLY
6.1 Removing the Rear cover
1. Unscrew two screws on the Rear cover top and two pushturn
rivets and remove the Rear cover top pulling it.
2. Unhook the hook fixing the Rear cover bottom and the Rear
cover fixing plate.

EP3513 ORDER NO.HPD0509U24C1
-13 -
3. Remove two brushclips on the bottom of the Rear cover
bottom and remove the Rear cover bottom pulling it at your
direction.
Caution in assembly
- Install the Rear cover top & bottom so that the installing hooks are
hooked inside (on the top side two hooks, on each left/right sides
three hooks.).
- Screw screws on the Rear cover top manually.

EP3513 ORDER NO.HPD0509U24C1
-14 -
6.2 REMOVING THE MASSAGE MECHANISM BLOCK
Move the Massage mechanism block to the bottom pushing the
high/low adjustment button.
1. Unscrew four screws on the Rear cover fixing plate.
2. Unscrew four screws on the PCB cover and remove the PCB
cover.
3. Unscrew a screw on the Ground wire and disconnect
Connectors.

EP3513 ORDER NO.HPD0509U24C1
-15 -
4. Remove the Connecting cord for the power source from the
Massage block cover clip.
* When removing the Massage mechanism block, use the special
tool (WEP000S8967) if you cannot lean the Massage lounger
forward
* Use the special tool at only left side, because it may damage
the Sensor board located at right side if you use the tool on the
right side
5. Unscrew four screws on the Rail piece set left and remove the
Rail piece set left and install the special tool.
Caution
- If the Massage mechanism block may fall down, hold it by
your hand.
6. Unscrew four screws on the Rail piece set right and remove the
Rail piece set right.
Caution
If the Massage mechanism block may fall down, hold it by your
hand.

EP3513 ORDER NO.HPD0509U24C1
-16 -
7. Push the Massage mechanism block and remove the special
tool.
Caution
If you remove the tool, the Massage mechanism block may fall
down at your side.
8. Move the Massage mechanism block upward and remove it
from the Back frame.
9. When you install the Massage mechanism block, execute the
reverse procedures.
Caution
- Push the Massage mechanism block so that it does not fall
down.
Be sure to install the correct side Rail piece sets.
Caution when handling the Massage mechanism block
Be sure to handle the Massage mechanism block carefully so that the PCB of the Pressure sensor is not pushed to the desk or
given extra pressure when putting the Massage mechanism block, which could lead to the cracks of the PCB. This may
eventually cause the malfunction such as ‘The body pressure levels on the Controller does not increase.’ ‘It does not scan.’ or
‘The operation is not stable.’ Etc.

EP3513 ORDER NO.HPD0509U24C1
-17 -
6.3. REMOVING THE ARMREST & COTROLLER STAND
6.3.1. REMOVING THE CONTROLLER STAND
1. Unload the Controller from the Controller stand and unscrew
four screws on the Controller stand.
6.3.2. REMOVING THE ARMREST
1. Unscrew one screw on the Plug cover on the back of the
Armrest and remove the Plug cover and the Hose.
2. Unscrew three screws on the bottom of the Armrest and lift the
Armrest to remove.

EP3513 ORDER NO.HPD0509U24C1
-18 -
3. Remove the opposite side one also.
Caution in installing
Install the Armrest to the Pipe securely as the Figure.
6.3.3. DISASSEMBLY OF THE ARMREST
1. Remove the Controller stand cover using a slotted
screwdriver and remove the Side cover and unscrew a screw.
2. Remove two Push-turn rivets.

EP3513 ORDER NO.HPD0509U24C1
-19 -
3. Remove the Side cover.
4. Unscrew a screw.
5. Unscrew four Screw Ds and five Screw Es and remove the
Armrest.

EP3513 ORDER NO.HPD0509U24C1
-20 -
Caution in installing
When installing the Armrest, be sure not to have Hoses bent
and to install the Armrest so that the Cloth is under the
Armrest.
6. Unscrew two screws.
7. Pull out the Pin E first and the Pin G with the spring shrunk
with pliers.
The work will be easy if you hold the Spring with an Insulated tie.
Be careful of the Spring, which may pop up if it is not shrunk when
the Pins are pulled out.
