Panasonic GT series Instruction manual

PROGRAMMABLE DISPLAY
GT series
FP7 Connection Manual
WUME-GTCONFP7-02
2013.11 panasonic.net/id/pidsx/global

Contents
1. Introduction........................................................................................................................... 2
1.1 GT Models and Versions Connectable to FP7 ................................................................. 2
1.2 Restrictions ....................................................................................................................... 2
2. Wirings between GT series and FP7 ......................................................................................... 3
2.1 RS232C Connection ......................................................................................................... 3
2.2 RS-422 Connection........................................................................................................... 5
2.3 RS-485 Connection........................................................................................................... 7
3. Settings of GT Series (GTWIN).......................................................................................... 10
3.1 Creating New GT Series Screen Data ............................................................................ 10
3.2 Communication Parameters of GT Series ...................................................................... 11
3.3 Clock Setting ................................................................................................................... 12
4. Settings for FP7 .................................................................................................................. 13
5. FP7 Devices......................................................................................................................... 14
6. Device Setting using GTWIN ............................................................................................. 16

2
1. Introduction
This manual describes how to use programmable displays GT02/GT02L/GT05/GT12/GT32/GT32-E
connecting to FP7. Also refer to GT series Reference Manual (ACGM0357V6EN) and GT series User's
Manual (ARCT1F511E).
As for requesting for manuals, please contact your dealer or download the PDF data from our web site.
http://industrial.panasonic.com/ac/e/dl_center/manual/ (User registration is required. Free of charge)
1.1 GT Models and Versions Connectable to FP7
For using GT series connecting to FP7, the versions of GT series and tool software GTWIN applicable to
FP7 are required. For information on the applicable versions, refer to the table below.
If you use an old version of GTWIN, download the upgrade version from our web site to upgrade the old
version.
The firmware of GT series can be upgraded from tool software GTWIN. Firmware files can be also
downloaded from our web site.
http://industrial.panasonic.com/ac/e/dl_center/software/ (User registration is required. Free of charge)
Applicable versions to FP7
GT model Applicable version to FP7
GT02 Ver.1.50 or later
GT02L Ver.1.40 or later
GT05 Ver. 2.10 or later
GT12 Ver. 1.80 or later
GT32 Ver. 2.20 or later
GT32-E Ver. 1.20 or later
Other GT series Cannot be used.
GTWIN Ver. 2.D0 or later
1.2 Restrictions
There are the following restrictions on using GT series connecting to FP7.
The FP monitor function cannot be used.
Projects of FP7 (such as programs) cannot be uploaded or downloaded from the SD memory card slot of
GT. Use the SD memory card slot of FP7.
GT and FP7 cannot be connected via Ethernet.
A baud rate of 230400 bps cannot be used for connection. Set the baud rate and communication format
within the ranges usable for GT series.
The internal clock of FP7 cannot be changed from GT.

3
2. Wirings between GT series and FP7
2.1 RS232C Connection
Wiring between FP7 COM0 port and GT series (24V/RS232C type)
Wiring between FP7 COM0 port and GT series (5V/RS232C type)
Wiring between FP7 communication cassette AFP7CCS1 (RS232C 1-ch insulated type) and GT
series (RS232C type)

4
Wiring between FP7 communication cassette AFP7CCS2 (RS232C 2-ch insulated type) and GT
series (RS232C type)
Set the on-board switch of AFP7CCS2 to "3Wire".

5
2.2 RS-422 Connection
Wiring between FP7 communication cassette AFP7CCM1 (RS-422/RS-485 1-ch insulated type)
and GT series (RS-422/RS-485 type) (RS-422 connection)
Wiring between FP7 communication cassette AFP7CCM2 (RS-422/RS-485 2-ch insulated type)
and GT series (RS-422/RS-485 type) (RS-422 connection)

6
Settings on FP7
Set the on-board switches of each cassette to "RS-422".
For RS-422 connection, set the termination resistance switches of each cassette to "ON".

7
2.3 RS-485 Connection
Wiring between FP7 communication cassette AFP7CCM1 (RS-422/RS-485 1-ch insulated type)
and GT series (RS-422/RS-485 type) (RS-422 connection)
- 1:1 connection
- PLC multiple connection
- GT link function

8
Wiring between FP7 communication cassette AFP7CCM2 (RS-422/RS-485 2-ch insulated type)
and GT series (RS-422/RS-485 type) (RS-485 connection)
- 1:1 connection
Note) As for the PLC multiple and GT link function connections, refer to the connection diagrams in the
previous page.

9
Settings on FP7
Set the on-board switches of each cassette to "RS-485".
For RS-485 connection, set the termination resistance switches of each cassette to "ON".

10
3. Settings of GT Series (GTWIN)
3.1 Creating New GT Series Screen Data
For creating screen data to connect with FP7, "Panasonic FP7 series" should be selected for PLC Model.
Select "Panasonic FP7 series" for PLC Model on the GTWIN screen for creating a new file.
When selecting a GT model that is not supported for FP7, "Panasonic FP7 series" cannot be selected for
PLC Model. Use a GT model supported for FP7.

11
3.2 Communication Parameters of GT Series
For connecting GT series and FP7, the communication parameters of GT series and FP7 should be set
with GTWIN. Select "FIle" - "Configuration" - "GT Configuration" from the menu of GTWIN, and set the
parameters in the "Communication Parameters" page.
Settings
Baud rate Select a baud rate. Set the same baud rate as that of FP7.
Data length Select a data length. Set the same data length as that of FP7.
Parity bit
Select a communication parity. Set the same parity as that of FP7.
Retry
Set the number of retries when a communication error occurs. Communication
is retried for the specified number of times. When communication is not
achieved, it is considered as an error.
Wait
Set the wait time for a response being returned from PLC after the transmission
of a command from GT to PLC. When no response is received within the
specified wait time, the process is retried.
Display error code
Select whether error codes are displayed at the top right of the screen or not
when errors including a communication error are detected.
"Off" Error codes are not displayed.
"On (Hold)" Error codes are displayed. Once an error is detected, the
error code is held even after recovery from the error state.
"On (Unhold)" Error codes are displayed. When the GT is recovered from
an error, the error code display is cleared.
Transmission
delay
For connecting with RS232C or RS422, specify "0". For connecting with RS485,
adjust the setting with the GT and FP7 actually connected.

12
3.3 Clock Setting
The reference format of PLC internal clock for "Panasonic FP7 series" is different from that for traditional
"Panasonic FP series". GT supports the both formats. Select either FP7 or FP format.
Select from "Clock" - "Format" and "Transfer" - "Format" in "Setup 1" of GT Configuration. The FP7 clock
data is stored in SD50 to 56. To refer to the internal clock of FP7, set "Reference Device" to SD50.
PLC internal clock data storage device and format
Panasonic FP series
Panasonic FP7 series
Reference
device No.
Data format (Hex) Reference
device No.
Data format (Binary)
DT90054 (DT9054) Higher: Minute (H00 - H59)
Lower: Second (H00 - H59)
SD50 Year (Last two digits of
year: U1 - U99)
DT90055 (DT9055) Higher: Day (H01 - H31)
Lower: Hour (H00 - H23)
SD51 Month (U1 - U12)
DT90056 (DT9056) Higher: Year (H01 - H99)
Lower: Month (H01 - H12) SD52 Day (U1 - U31)
DT90057 (DT9057)
Higher: None
Lower: Day of the week
(H00 - H06)
SD53 Hour (U0 - U23)
SD54 Minute (U0 - U59)
SD55
Second (U0 - U59)
SD56
Day of the week (U0 - U6)
Note) Although the clock data of FP7 is stored in SD50 to SD56, any values cannot be written in these
areas. Therefore, the FP7 internal clock cannot be changed even by using the clock transfer function.
Update the FP7 internal clock by TIMEWT instruction after outputting the data to data register, etc. using
the clock transfer function.

13
4. Settings for FP7
For connecting GT series and FP7, the communication parameters of FP7 should be set with FPWIN
GR7. Execute "Option" - "FP7 Configuration" menu in FPWIN GR7, and set the parameters in the "Built-
in SCU" page.
Settings
COM0
Set when connecting the COM0 port of FP7 and GT.
COM1 settings
Set when connecting the 1CH of 1-ch or 2-ch type communication cassette
and GT.
COM2 settings
Set when connecting the 2CH of 2-ch type communication cassette and GT.
Communication
mode
Select "MEWTOCOL-7".
Unit number
Set a desired unit number. When using the PLC multiple connection, the unit
number specified by GTWIN corresponds to this unit number.
Baud rate
Set the same "Baud Rate" as that specified in GTWIN "GT Configuration" -
"Communication Parameters" - "Baud Rate".
Data length
Set the same "Data Length" as that specified in GTWIN "GT Configuration" -
"Communication Parameters" - "Data Length".
Parity
Set the same "Parity" as that specified in GTWIN "GT Configuration" -
"Communication Parameters" - "Parity".
Stop bit
Select "1".
RS/CS
Select "Disable".
Send waiting time
For connecting with RS232C or RS422, specify "0".
For connecting with RS485, adjust the setting with the GT and FP7 actually
connected.
Header STX
Select "Disable".
Modem initialization
Select "Not initialize".

14
5. FP7 Devices
The following FP7 devices can be used from GT series.
Type
Symbol
No. range
Output
Local
Slot
Bit
Input memory
X
0 - 511F
Yes
Yes
No
Output memory
Y
0 - 511F
Yes
Yes
No
Internal relay R 0 - 2047F Yes Yes No
Link relay
L
0 - 1023F
Yes
Yes
No
Timer contact
T
0 - 4095
No
Yes
No
Counter contact C 0 - 1023 No Yes No
Pulse relay P 0 - 255F No Yes No
Error alarm relay
E
0 - 255F
No
No
No
System relay
SR
0 - 149F
No
No
No
Direct input IN 0 - 63F No No Yes
Direct output
OT
0 - 63F
Yes
No
Yes
Link register
LD
0.0 - 16383.F
Yes
Yes
No
Data register DT 0.0 - 999423.F Yes Yes No
Unit memory
UM
0.0 - 524287.F
Yes
Yes
Yes
Word
Input memory
WX
0 - 511
Yes
Yes
No
Output memory WY 0 - 511 Yes Yes No
Internal relay WR 0 - 2047 Yes Yes No
Link relay
WL
0 - 1023
Yes
Yes
No
System relay
WS
0 - 149
No
No
No
Link register LD 0 - 16383 Yes Yes No
Data register
DT
0 - 999423
Yes
Yes
No
System data
SD
0 - 119
No
No
No
Direct input WI 0 - 63 No No Yes
Direct output
WO
0 - 63
Yes
No
Yes
Unit memory
UM
0 - 524287
Yes
No
Yes
Double
word
Timer set value TS 0 - 4095 Yes Yes No
Timer elapsed value TE 0 - 4095 Yes Yes No
Counter set value
CS
0 - 1023
Yes
Yes
No
Counter elapsed value
CE
0 - 1023
Yes
Yes
No
Index register I 0 - E Yes No No
Note) The device range that can be actually used differs according to settings.

15
Output
Output is not possible from GT to the devices marked as "No" in "Output" in the above table.
The setting items related to output cannot be set on GTWIN.
Local devices
The devices marked as "Yes" in "Local" in the above table can be used as local devices. For using them
as local devices, specify the program block numbers. Program block numbers can be specified in the
range of 1 to 468, and they are expressed as "PB?_" before symbols.
Slot specification
As for the devices marked as "Yes" in "Slot" in the above table, the slot numbers should be specified.
Slot numbers can be specified in the range of 1 to 16, and they are expressed as "S?:" before symbols.
Bit specification of link register, data register and unit memory
For using a link register, data register or unit memory as bit devices, the bit numbers should be specified.
Bit numbers are specified next to "." (period) after device numbers.

16
6. Device Setting using GTWIN
The following window is displayed when setting devices on GTWIN.
Setting item
Description
① PLC
Select the unit number when using the PLC multiple connection
function. This item is displayed only when the PLC multiple connection
function is set in the GT configuration setting.
②
Global device
Select when specifying a global device.
③
Local device
Select when specifying a local device.
④Program block No. Set the program block number when selecting Local Device. This item
is available only when selecting Local Device.
⑤Slot No. Specify a slot number. This item is available only when the device with
slot specification has been selected.
⑥Device type Select a device type.
⑦
Device No.
Specify a device number.
①
②
③
④
⑤
⑥
⑦

17
The device input can be directly input not from the above-mentioned screen. When inputting the device
directly, input as below.
For global device without slot number specification, input [Device type (symbol)] + [Device No.].
Example) For input memory 511F
X511F
For local device, input [PB] + [Program block No.] + [_] + [Device type (symbol)] + [Device No.].
Example) For program block No. 100 and internal relay R200
PB100_R200
For the case with slot number specification, [S] + [Slot No.] + [:] + [Device type (symbol)] +
[Device No.].
Example) For slot No. 15 and unit memory UM100
S15:UM100

Record of changes
Manual No. Date Desceiption of changes
WUME-GTCONFP7-01
WUME-GTCONFP7-02
Mar.2013
Nov.2013
First Edition
Second Edition
