Panasonic AN33014UA User manual

1
AN33014UA
Evaluation Board Manual
Panasonic Corporation
Automotive & Industrial Systems Company
Semiconductor Business Division

2
AN33014UA Evaluation board (front side)
GND
VCC
SW1
Enable control switch
Upper side (high): DCDC ON
Lower side (low): DCDC OFF
JPFLAG
If you connect this jumper
switch, the FLAG pin will be
connected to VREG(4.9V) via
a 200kΩ-register.
RT resistor
DCDC output pin
(sense pin / force
pin)
Output setting: 5V
SYNC input terminal
(external clock input)
RSENSE
Current detect resistor
R-RADJ
CFB adjusting resistor
If JP4 is selected,
RT pin connected 130kW.
This setting is Fsw = 490kHz.
Ferrite beads
MPZ1608S300A
Snubber circuit
SS, CT capacitor TL capacitor
VREG capacitor
BT capacitor
JP3 JP4 JP5
JP3 JP4 JP5 JP3 JP4 JP5
Select JP3:
RT=22kW
Fsw = 2MHz
Select JP5:
RT=330kW
Fsw = 200kHz
(below setting can select by JP3 or JP5)
C-VOUT1, 2
Output capacitor
Input capacitor
Coil
This is a two layer circuit board. The front side is shown below. (The back side is shown on the next page.)

3
AN33014UA Evaluation board (back side)
This is a two layer circuit board. The back side is shown below. (The front side is shown on the previous page.)
The RC constant for phase compensation
is set for output voltage

4
AN33014UA Evaluation board (schematic)
OSC
13
SS
ERAMP
Current
feed back
+
OCP
C-SS
C-VOUT1
CNT
Ext.CLK
EN
16
12
FB 11
COMP 10
SGND
7 N.C.
VREG
9
18 RADJ
FLAG 19
SYNC 17
RT 14
SST
PWM PRIDRV
PVCC
VCC
6
22 BT
1 N.C.
CBT 5V
L1
C-TL
RFLAG
CVCC3
CVCC4
CVCC5
TL 20
5 V to 25 V
15
CT
C-CT
(for Pull-up)
3 N.C.
BTVCC
21
PLL
CVREG
4 PVCC1
2 RSO
24 LX
OVP
SCP
VREG
VREF
(BGR)
TSD
UVLO
VINT OVP
(VCC)
23
PGND
Timer
Latch
8 RSIN
C-VOUT2
5 PVCC2
RA-1 RA-2
RSENSE
R-RADJ
RB-1 RB-2
CS1
RS1
C3
C1
R1
R2
C2
D1
RS2
R-RT2 R-RT3
R-RT1
JP3 JP4 JP5
JPFLAG
R7 R8
R9
RBTVCC

5
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS2012_[EIA0805]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
3.8(L) x 2.4(W)
8.3(L) x 8.3(W)
JIS1608_[EIA0603]
JIS322_[EIA1210]
JIS5750[EIA2220]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
JIS1608_[EIA0603]
Size
Timer Latch settingMurata
0.1μF
GCM188R11C104KA01JC-TL Soft Start settingMurata
0.1μF
GCM188R11C104KA01JC-SS LPF for PLLMurata
0.1μF
GCM188R11C104KA01JC-CT
OSC Setting Resistor (Fsw = 1370kHz at selecting JP5)PanasonicR=39kERA3AEB393VR-RT3
OSC Setting Resistor (Fsw = 2000kHz at selecting JP3)PanasonicR=22kERA3AEB223VR-RT1
for EvaluationPanasonicR=0ERJ3GEY0R00VRA-2,RB-2
Snubber CircuitMurata3300pFGCM1882C1H332JA01JCS1 Snubber CircuitPanasonicR=220ERA3AEB221VRS1
Output Current Sense ResistorPanasonicR=50mERJ6BWFR050VRSENSE for EvaluationPanasonicR=0ERJ3GEY0R00VR7,R8,R9,RBTVCC
Ferrite Beads for EMI filterTDK30 ohm at 100MHzMPZ1608S300ARS2
Current Feedback Adjustment ResistorPanasonicR=30kERA3AEB303VR-RADJ
Compensation & Feedback ResistorPanasonicR=30kERA3AEB303VRA-1 Compensation & Feedback ResistorPanasonicR=7.5kERA3AEB752VRB-1
Compensation CapacitorMurata470pFGCM1882C1H471JA01JC2
Output CapacitorMurata
0.1μF
GCM188R11C104KA01JC-VOUT2
Compensation CapacitorMurata27pFGCM1882C1H270JA01JC3 VREG CapacitorMurata
1μF
GCM188R71C105KA49JCVREG
OSC Setting Resistor (Fsw = 490kHz at selecting JP4)PanasonicR=130kERA3AEB134VR-RT2
Pull-up ResistorPanasonicR=200kERA3AEB204VRFLAG
Compensation & Feedback ResistorPanasonicR=1.5kERA3AEB152VR2 Compensation & Feedback ResistorPanasonicR=7.5kERA3AEB752VR1 Schottky DiodePanasonic-DB24416D1 InductorSUMIDA
10μH
CDRH8D43-100NCL1
Output Capacitor
TAIYO,YUDE
N
22μF
TMK325C7226MM-TC-VOUT1
Input CapacitorTDK
22μF
CKG57NX7R1H226MTCVCC3, CVCC4, CVCC5
Compensation CapacitorMurata2.2nFGCM1882C1H222JA01JC1
Bootstrap CapacitorMurata
0.1μF
GCM188R11C104KA01JCBT DescriptionMakerValuePart NameBoard Component Name
AN33014UA Evaluation board (components)
The BOM of this board is shown below.
Table 1 : component on the evaluation board (reference)
Note: The specifications of the BOM are reference values. Other components might be mounted depending on target values of output voltage, frequency, etc.
