Panasonic PT-DS100XE ( ) User manual

Operating Instructions
Functional Manual
DLP™ Based Projector Commercial Use
Thank you for purchasing a Panasonic Projector.
Before operating this product, please read the instructions carefully and save this manual
J
for future use.
Before using your projector, be sure to read “
JPrecautions with regard to safety”
(Æpages 9 to 17).
TQBJ0342-2
Model No. PT-DZ110XE
PT-DS100XE
PT-DW90XE
ENGLISH
The projection lens is sold separately.
M0710KY3031 -DW

Important Safety Notice
2- ENGLISH
Important
Information
Important Safety Notice
Dear Panasonic Customer:
This instruction booklet provides all the necessary operating information that you might require. We hope it will
help you to get the most out of your new product, and that you will be pleased with your Panasonic DLP™ Based
projector. The serial number of your product may be found on its bottom. You should note it in the space provided
below and retain this booklet in case service is required.
Model number: PT-DZ110XE/PT-DS100XE/PT-DW90XE
Serial number:
WARNING: THIS APPARATUS MUST BE EARTHED.
WARNING: To prevent damage which may result in re or shock hazard, do not expose this appliance to rain
or moisture.
Machine Noise Information Ordinance 3. GSGV, January 18, 1991: The sound pressure level at the operator
position is equal or less than 70 dB (A) according to ISO 7779.
WARNING:
1. Remove the plug from the mains socket when this unit is not in use for a prolonged period of time.
2. To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to
qualied service personnel.
3. Do not remove the earthing pin on the mains plug. This apparatus is equipped with a three prong
earthingtype mains plug. This plug will only t an earthing-type mains socket. This is a safety feature. If you
are unable to insert the plug into the mains socket, contact an electrician. Do not defeat the purpose of the
earthing plug.
CAUTION: To assure continued compliance, follow the attached installation instructions, which includes using
the provided power cord and shielded interface cables when connecting to computer or peripheral
device. If you use serial port to connect PC for external control of projector, you must use optional
RS-232C serial interface cable with ferrite core. Any unauthorized changes or modications to
this equipment will void the user’s authority to operate.
Pursuant to at the directive 2004/108/EC, article 9(2)
Panasonic Testing Centre
Panasonic Service Europe, a division of Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, F.R. Germany
EEE Yönetmeliğine Uygundur.
EEE Complies with Directive of Turkey.

Important Safety Notice
ENGLISH - 3
Important
Information
Information for Users on Collection and Disposal of Old Equipment and used Batteries
These symbols on the products, packaging, and/or accompanying documents mean that used
electrical and electronic products and batteries should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take them
to applicable collection points, in accordance with your national legislation and the Directives
2002/96/EC and 2006/66/EC.
By disposing of these products and batteries correctly, you will help to save valuable resources and
prevent any potential negative effects on human health and the environment which could otherwise
arise from inappropriate waste handling.
For more information about collection and recycling of old products and batteries, please contact
your local municipality, your waste disposal service or the point of sale where you purchased the
items. Penalties may be applicable for incorrect disposal of this waste, in accordance with national
legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for
further information.
Information on Disposal in other Countries outside the European Union
These symbols are only valid in the European Union. If you wish to discard these items, please
contact your local authorities or dealer and ask for the correct method of disposal.
Note for the battery symbol (bottom two symbol examples):
This symbol might be used in combination with a chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical involved.
Environment care information for users in China
This symbol is only valid in China.

Important Safety Notice
4- ENGLISH
Important
Information
IMPORTANT: THE MOULDED PLUG (U.K. only)
FOR YOUR SAFETY, PLEASE READ THE FOLLOWING TEXT CAREFULLY.
This appliance is supplied with a moulded three pin power plug for your safety and convenience. A 13 amp fuse
is tted in this plug. Should the fuse need to be replaced, please ensure that the replacement fuse has a rating of
13 amps and that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover, you must ensure that it is retted when the fuse is replaced. If you
lose the fuse cover, the plug must not be used until a replacement cover is obtained. A replacement fuse cover
can be purchased from an Authorized Service Center.
If the tted moulded plug is unsuitable for the wall outlet in your home, then the fuse should be removed
and the plug cut off and disposed of safely. There is a danger of severe electrical shock if the cut off plug
is inserted into any 13 amp socket.
If a new plug is to be tted, please observe the wiring code as shown below.
If in any doubt, please consult a qualied electrician.
WARNING: THIS APPLIANCE MUST BE EARTHED.
IMPORTANT: The wires in this power cord are colored in accordance with the following code:
Green - and - Yellow:
Blue:
Brown:
Earth
Neutral
Live
As the colors of the wire in the power cord of this appliance may not correspond with the colored markings
identifying the terminals in your plug, proceed as follows.
The wire which is colored GREEN - AND - YELLOW must be connected to the terminal in the
plug which is marked with the letter E or by the Earth symbol or colored GREEN or GREEN -
AND - YELLOW.
The wire which is colored BLUE must be connected to the terminal in the plug which is marked
with the letter N or colored BLACK.
The wire which is colored BROWN must be connected to the terminal in the plug which is marked
with the letter L or colored RED.
How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse.

ENGLISH - 5
Important
Information
PreparationGetting StartedBasic OperationSettingsMaintenanceAppendix
While the luminance is the same as
the former model, the size is reduced
to about 1/2.
Volume Approx. 120 liters : PT-D10000E
Volume Approx. 60 liters : PT-DZ110XE
The lamp replacement cycle is longer
than the existing model. (Æpage 111)
Approx. 2 000 hours : PT-D10000E
(When four lamps are used)
Approx. 3 000 hours : PT-DZ110XE
(two lamps LAMP POWER : [HIGH])
The standby power is much less than
the existing model.
Approx. 25 W : PT-D10000E
Approx. 0.3 W : PT-DZ110XE
(STANDBY MODE : [ECO])
Reduced in size
Lengthened lamp
replacement cycle
Reduced standby power
Quick steps
J
For details, see the corresponding pages.
1. Set up your projector.
(Æpage 22)
2. Attach the projection lens.
(Æpage 38)
3. Connect with other devices.
(Æpage 35)
4. Connect the power cord.
(Æpage 39)
5. Start projecting.
(Æpage 40)
6. Select the input signal.
(Æpage 42)
7. Adjust the image.
(Æpage 42)

Important Safety Notice
6- ENGLISH
Important
Information Preparation Getting Started Basic Operation Settings Maintenance Appendix
Contents Be sure to read “Precautions with regard to safety”. ( pages 9 to 17)
Important Information
Important Safety Notice ............................ 2
Precautions with regard to safety............ 9
WARNING..............................................................9
CAUTION.............................................................12
Cautions when transporting .................................12
Cautions when installing ......................................13
Security................................................................15
Cautions on use...................................................15
Cleaning and maintenance ..................................16
Disposal ...............................................................16
Accessories..........................................................17
Preparation
About Your Projector .............................. 18
Remote control.....................................................18
Projector body......................................................19
Setting projector ID number to remote control.....21
Using a wired remote control ...............................21
Getting Started
Setting up................................................. 22
Projection method................................................22
Screen size and throw distance...........................23
Front leg adjusters and throwing angle................34
Connections............................................. 35
Before connection to the projector.......................35
Connecting example : AV equipment ...................36
Connecting example : Computers........................37
Removing/attaching the projection lens
(optional) .............................................. 38
How to install the projection lens .........................38
How to remove the projection lens.......................38
Basic Operation
Powering ON/OFF.................................... 39
Connecting the power cord..................................39
Powering up the projector....................................40
Making adjustment and selection.........................40
Powering off the projector....................................41
Direct power off function ......................................41
Projecting................................................. 42
Selecting the input signal.....................................42
How to adjust the focus, zoom and shift ..............42
Adjustment range after lens position
(optical shift)..................................................43
Moving the projection lens position to the home
position..........................................................44
Lens adjustment to compensate for uneven
screen focus..................................................44
Basic operations using the remote
control................................................... 47
Using the SHUTTER function ..............................47
On-screen display function ..................................47
Switching the input signal ....................................47
STATUS function..................................................47
Automatic adjustment ..........................................48
Using the FUNCTION button ...............................48
Displaying the internal test pattern.......................48
Changing the picture aspect ratio ........................49
Settings
Menu Navigation...................................... 50
Navigating through the menu...............................50
MAIN MENU ........................................................51
SUB MENU..........................................................51
PICTURE menu ........................................ 53
PICTURE MODE .................................................53
CONTRAST .........................................................54
BRIGHTNESS......................................................54
COLOR ................................................................54
TINT.....................................................................54
COLOR TEMPERATURE ....................................55
GAMMA................................................................56
SYSTEM DAYLIGHT VIEW .................................56
SHARPNESS.......................................................57
NOISE REDUCTION ...........................................57
DYNAMIC IRIS ....................................................57
SYSTEM SELECTOR..........................................58

Important Safety Notice
ENGLISH - 7
Important
Information
PreparationGetting StartedBasic OperationSettingsMaintenanceAppendix
Contents
To display pictures complying with the sRGB
standard ........................................................58
POSITION menu....................................... 59
SHIFT...................................................................59
ASPECT...............................................................59
ZOOM ..................................................................60
CLOCK PHASE ...................................................61
GEOMETRY (PT-DZ110XE/PT-DS100XE only) ..61
KEYSTONE (PT-DW90XE only) ..........................63
ADVANCED MENU................................... 64
DIGITAL CINEMA REALITY.................................64
BLANKING...........................................................64
INPUT RESOLUTION..........................................65
CLAMP POSITION ..............................................65
EDGE BLENDING ...............................................65
FRAME DELAY....................................................67
RASTER POSITION ............................................67
DISPLAY LANGUAGE menu ................... 68
Changing the display language............................68
DISPLAY OPTION menu .......................... 69
COLOR MATCHING ............................................69
LARGE SCREEN CORRECTION........................70
SCREEN SETTING (PT-DZ110XE/PT-DS100XE only) ....70
WAVEFORM MONITOR (PT-DZ110XE only) ......71
AUTO SIGNAL.....................................................72
AUTO SETUP......................................................72
RGB IN (Only RGB input) ....................................73
DVI-D IN...............................................................73
HDMI IN ...............................................................74
SDI IN (PT-DZ110XE/PT-DS100XE only) ............74
ON-SCREEN DISPLAY .......................................74
BACK COLOR .....................................................75
STARTUP LOGO .................................................75
FREEZE...............................................................75
PROJECTOR SETUP menu..................... 76
PROJECTOR ID ..................................................76
INSTALLATION....................................................76
HIGH ALTITUDE MODE ......................................76
COOLING CONDITION .......................................77
LAMP SELECT ....................................................77
LAMP RELAY.......................................................77
LAMP POWER.....................................................78
BRIGHTNESS CONTROL...................................78
STANDBY MODE ................................................82
SCHEDULE .........................................................82
RS-232C ..............................................................83
STATUS ...............................................................84
NO SIGNAL SHUT-OFF ......................................85
REMOTE2 MODE................................................85
FUNCTION BUTTON...........................................85
DATE AND TIME..................................................85
LENS CALIBRATION...........................................86
FILTER COUNTER RESET .................................86
SAVE ALL USER DATA........................................87
LOAD ALL USER DATA.......................................87
INITIALIZE ...........................................................87
SERVICE PASSWORD .......................................87
P IN P menu.............................................. 88
Using the P IN P function.....................................88
Setting the P IN P function...................................88
TEST PATTERN menu ............................. 89
TEST PATTERN...................................................89
SIGNAL LIST menu.................................. 90
Registering a signal to the list..............................90
Renaming a registered data.................................90
Deleting a registered data....................................90
Managing the sub memory list.............................91
SECURITY menu...................................... 92
SECURITY PASSWORD .....................................92
SECURITY PASSWORD CHANGE.....................92
DISPLAY SETTING .............................................93
TEXT CHANGE ...................................................93
MENU LOCK........................................................93
MENU LOCK PASSWORD..................................93
CONTROL DEVICE SETUP ................................94
NETWORK menu ..................................... 95
NETWORK SETUP..............................................95
NETWORK CONTROL........................................95
NETWORK STATUS............................................95
Network connections............................................96

Important Safety Notice
8- ENGLISH
Important
Information Preparation Getting Started Basic Operation Settings Maintenance Appendix
Contents
Accessing from the Web browser ........................97
Maintenance
Monitor Lamp indicators....................... 108
Managing the indicated problems......................108
Replacement ...........................................110
Before replacing the unit....................................110
Replacing the unit ..............................................110
Troubleshooting .....................................113
Appendix
Technical Information ............................115
PJLink protocol ..................................................115
Control commands via LAN ...............................116
Serial terminal....................................................118
REMOTE 2 IN terminal ......................................121
Two window display combination list .................122
Restoring the MENU LOCK PASSWORD
to default......................................................122
List of compatible signals...................................123
Specications ........................................ 125
Dimensions ........................................................127
About brand .......................................................127
Ceiling mount bracket safeguards....... 128
Attachment procedure........................................128
Index ....................................................... 129

Precautions with regard to safety
ENGLISH - 9
Important
Information
Precautions with regard to safety
WARNING
POWER

The wall outlet or the circuit breaker shall be installed near the equipment and shall be
easily accessible when problems occur. If the following problems occur, cut off the power
supply immediately.
Continued use of the projector in these conditions will result in re or electric shock.
If foreign objects or water get inside the projector, cut off the power supply.
z
If the projector is dropped or the cabinet is broken, cut off the power supply.
z
If you notice smoke, strange smells or noise coming from the projector, cut off the power supply.
z
Please contact an Authorized Service Center for repairs, and do not attempt to repair the projector yourself.
During a thunderstorm, do not touch the projector or the cable.
Electric shocks can result.
Do not do anything that might damage the power cord or the power plug.
If the power cord is used while damaged, electric shocks, short-circuits or re will result.
Do not damage the power cord, make any modications to it, place it near any hot objects, bend it
z
excessively, twist it, pull it, place heavy objects on top of it or wrap it into a bundle.
Ask an Authorized Service Center to carry out any repairs to the power cord that might be necessary.
Insert the power plug securely into the wall outlet.
If the plug is not inserted correctly, electric shocks or overheating will result.
Do not use anything other than the provided power cord.
z
Do not use the provided power cord for other electrical equipment.
z
Do not use plugs which are damaged or wall outlets which are coming loose from the wall.
z
Clean the power plug regularly to prevent it from becoming covered in dust.
Failure to observe this will cause a re.
If dust builds up on the power plug, the resulting humidity can damage the insulation.
z
If not using the projector for an extended period of time, pull the power plug out from the wall outlet.
z
Pull the power plug out from the wall outlet and wipe it with a dry cloth regularly.
Do not handle the power plug with wet hands.
Failure to observe this will result in electric shocks.
Do not overload the wall outlet.
If the power supply is overloaded (ex., by using too many adapters), overheating may occur and re will result.
ON USE/INSTALLATION

Do not place liquid containers on top of the projector.
If water spills onto the projector or gets inside it, re or electric shocks will result.
If any water gets inside the projector, contact an Authorized Service Center.
Do not place the projector on soft materials such as carpets or sponge mats.
Doing so will cause the projector to overheat, which can cause burns, re or damage to the projector.
Do not set up the projector in humid or dusty places or in places where the projector may
come into contact with oily smoke or steam, ex. a bathroom.
Using the projector under such conditions will result in re, electric shocks or components deterioration.
Components deterioration (such as ceiling mount brackets) may cause the projector which is mounted on the
ceiling to fall down.
Do not install this projector in a place which is not strong enough to take the full weight of
the projector or on top of a surface which is sloped or unstable.
Failure to observe this will cause projector to fall down or tip over the projector, and severe injury or damage
could result.

Precautions with regard to safety
10 - ENGLISH
Important
Information
Do not place another projector or other heavy objects on top of the projector.
Failure to observe this will cause the projector to become unbalanced and fall, which could result in damage or
injury. The projector will be damaged or deformed.
Installation work (such as ceiling suspension) should only be carried out by a qualied
technician.
If installation is not carried out and secured correctly it can cause injury or accidents, such as electric shocks.
Do not use anything other than an authorized ceiling mount bracket.
z
Be sure to use the provided accessory wire with an eye bolt as an extra safety measure to prevent the
z
projector from falling down. (Install in a different location to the ceiling mount bracket)
Do not cover the air inlet port or the air outlet port.
Doing so will cause the projector to overheat, which can cause re or damage to the projector.
Do not place the projector in narrow, badly ventilated places such as closets or bookshelves.
z
Do not place the projector on cloth or papers, as these materials could be drawn into the air inlet port.
z
Do not place your hands or other objects close to the air outlet port.
Doing so will cause burns or damage your hands or other objects.
Heated air comes out of the air outlet port. Do not place your hands or face, or objects which cannot withstand
z
heat close to this port.
Do not look and place your skin into the lights emitted from the lens while the projector is
being used.
Doing so can cause burns or loss of sight.
Strong light is emitted from the projector’s lens. Do not look or place your hands directly into this light.
z
Be especially careful not to let young children look into the lens. In addition, turn off the power and disconnect
z
the power plug when you are away from the projector.
Do not insert any foreign objects into the projector.
Doing so will cause re or electric shocks.
Do not insert any metal objects or ammable objects into the projector or drop them onto the projector.
z
Never attempt to remodel or disassemble the projector.
High voltages can cause re or electric shocks.
For any inspection, adjustment and repair work, please contact an Authorized Service Center.
z
Do not project an image with the lens cover attached.
Doing so can cause re.
When replacing the lamp, do not touch the fan with your nger or another part of your
body.
If you do so, you may get hurt.
ACCESSORIES

Do not use or handle the batteries improperly, and refer to the following.
Failure to observe this will cause burns, batteries to leak, overheat, explode or catch re.
Do not use unspecied batteries.
z
Use manganese batteries but not rechargeable batteries.
z
Do not disassemble dry cell batteries.
z
Do not heat the batteries or place them into water or re.
z
Do not allow the + and
z
-
terminals of the batteries to come into contact with metallic objects such as
necklaces or hairpins.
Do not store batteries together with metallic objects.
z
Store the batteries in a plastic bag and keep them away from metallic objects.
z
Make sure the polarities (+ and
z
-
) are correct when inserting the batteries.
Do not use a new battery together with an old battery or mix different types of batteries.
z
Do not use batteries with the outer cover peeling away or removed.
z
Remove the empty batteries from the remote control at once.
z
Insulate the battery using tape or something similar before disposal.
z

Precautions with regard to safety
ENGLISH - 11
Important
Information
Do not allow children to reach the AA/R6 batteries.
The battery can cause personal injury if swallowed.
z
If swallowed, seek medical advice immediately.
z
If the battery uid leaks, do not touch it with bare hands, and take the following measures if
necessary.
Battery uid on your skin or clothing could result in skin inammation or injury.
z
Rinse with clean water and seek medical advice immediately.
Battery uid coming in contact with your eyes could result in loss of sight.
z
In this case, do not rub your eyes. Rinse with clean water and seek medical advice immediately.
Do not disassemble the lamp unit.
If the lamp breaks, it could cause injury.
Lamp replacement
The lamp has high internal pressure. If improperly handled, an explosion and severe injury or accidents will result.
Replacement of the lamp should be carried out by a qualied technician.
z
The lamp can easily explode if struck against hard objects or dropped.
z
Before replacing the lamp, be sure to disconnect the power plug from the wall outlet.
z
Electric shocks or explosions can result if this is not done.
When replacing the lamp, allow it to cool for at least one hour before handling it otherwise it can cause burns.
z
Do not allow infants or pets to touch the remote control unit.
Keep the remote control unit out of the reach of infants and pets after using it.
z
Keep the attached screws and plain washers away from babies and infants.
If a baby swallows a screw by accident, it may be affected badly.
z
If a baby seems to have swallowed a screw, consult the doctor immediately.
z

Precautions with regard to safety
12 - ENGLISH
Important
Information
CAUTION
POWER

When disconnecting the power cord, be sure to hold the power plug and power connector.
If the power cord itself is pulled, the lead will become damaged, and re, short-circuits or serious electric shocks
will result.
When not using the projector for an extended period of time, disconnect the power plug
from the wall outlet and remove the batteries from the remote control.
Disconnect the power plug from the wall outlet before carrying out any cleaning.
Electric shocks can result if this is not done.
ON USE/INSTALLATION

Do not put your weight on this projector.
You could fall or the projector could break, and injury will result.
Be especially careful not to let young children stand or sit on the projector.
z
Do not place the projector in extremely hot locations.
Doing so will cause the outer casing or internal components to deteriorate, or result in re.
Take particular care in locations exposed to direct sunlight or near stoves.
z
Always disconnect all cables before moving the projector.
Moving the projector with cables still attached can damage the cables, which will cause re or electric shocks to
occur.
Do not place your hands in the openings beside the optical lens, while shifting the lens.
Failure to observe this could cause injury.
ACCESSORIES

Do not use the old lamp unit.
If used it could cause lamp explosion.
If the lamp has broken, ventilate the room immediately. Do not touch or bring your face
close to the broken pieces.
Failure to observe this will cause the user to absorb the gas which was released when the lamp broke and which
contains nearly the same amount of mercury as uorescent lamps, and the broken pieces will cause injury.
If you believe that you have absorbed the gas or that the gas has got into your eyes or mouth, seek medical
z
advice immediately.
Ask your dealer about replacing the lamp unit and check the inside of the projector.
z
Cautions when transporting
When transporting the projector or carrying it around, make sure that the lens cover is always in place, and
remove the lens. Please take care to keep them away from vibration and impacts, both the projector and the lens
are precision-made and easily susceptible to damage.
When transporting the projector, the leg adjusters must be housed and do not hold them. Please securely hold
only its bottom and none of its other parts or surfaces as this will result in malfunctions.

Precautions with regard to safety
ENGLISH - 13
Important
Information
Cautions when installing
After removing the projection lens, install the dust sponge attached to the

projector.
If the dust sponge is not installed, dust will be accumulated inside and can cause a trouble.
Do not use under the following conditions.

Do not set up the projector outdoors.
z
The projector is designed for indoor use only.
Avoid setting up in places which are subject to vibration or shocks.
z
If the projector is installed in a place where vibrations are transmitted or mounted in a car or a vessel,
vibrations or impacts will result in damage to the internal parts, causing failure. Install the product in a place
free from vibrations and impacts.
Avoid setting up in places which are subject to sudden temperature changes, such as near an air
z
conditioner or lighting equipment.
Failure to observe this will result in malfunctions or the lamp life will be shortened.
See “
■TEMP indicator” on page 109.
Avoid setting up in places which are near high-voltage power lines or near motors.
z
The product will be exposed to interference if it is installed in the vicinity of high-voltage electrical power lines
or power sources.
Do not install the projector at elevations higher than 2 700 m (8 858 ft) above sea level.
z
If using this projector at high elevations 1 400 - 2 700 m (4 593 - 8 858 ft) above sea level, set [HIGH
ALTITUDE MODE] to [ON].
If using this projector at elevations lower than 1 400 m (4 593 ft) above sea level, set [HIGH ALTITUDE
MODE] to [OFF].
Failure to observe this will result in malfunctions or the lamp life or life of other components will be shortened.
When installing and using the projector at an angle that exceeds 30° vertically, set [COOLING
z
CONDITION].
Failure to observe this will result in malfunctions or the lamp life or other components will be shortened.
Lens Focus

Do not adjust the lens focus in the initial period after switching the projector on. The high clarity projector lens is
thermally affected by the light from the light source, making the focus unstable in the period just after switching
on. Please allow a warm-up time of at least 30 minutes before adjusting the lens focus.
Be sure to ask a specialized technician when installing the product to a

ceiling.
If the product is to be installed hanging from the ceiling, purchase an optional Ceiling Mount Attachment (For high
ceilings: Model No. ET-PKD310H, For low ceilings: Model No. ET-PKD310S). Please call a specialized technician
or contact an Authorized Service Center for installation.

Precautions with regard to safety
14 - ENGLISH
Important
Information
Cautions when setting the projectors 1

When installing and using the projector with a method other than oor standing installing using adjustable
z
feet, x it with the 5 ceiling mounting screws (shown in the gure).
(Screw diameter: M6, Tapping depth inside set: 8 mm)
Make a clearance of at least 5 mm between the projector bottom and setting surface by inserting spacers
z
(metallic) etc. between them.
The adjustable feet can be removed if they are not necessary for installation. However, do not use the screw
z
holes for them to x the projector.
Do not tighten other screws etc. into the screw holes for the adjustable feet.
Doing so can break the set.
When installing the removed adjustable feet again, note that the front and rear ones have different lengths.
(The longer screws are used for front feet. Length of front leg screw: 65 mm, Length of rear leg screw:
23 mm)
When installing the projector with a method other than oor standing installing, do not adjust its angle with the
z
adjustable feet. Doing so can break the set.
Ceiling mounting screws (M6)
Gap (Min. 5 mm)
Make sure air can circulate
around the air intake vent.
Failure to do so may result
in the projector not operating
properly.
Spacers
Base

Precautions with regard to safety
ENGLISH - 15
Important
Information
Cautions when setting the projectors 2

When placing the projector in conned space, a ventilation or air conditioning system must be equipped, and
z
keep enough ventilation space on the rear and both sides of the projector.
Make a clearance of at least 5 mm between the projector bottom and setting surface by inserting spacers
z
(metallic) etc. between them.
zDo not stack the projectors without using frame or shelf.
Do not cover the ventilation openings or place anything within 50 cm (20") of them
z
as this may cause damage or injury.
Avoid heating or cooling air of the air conditioning systems directly blow on to the
z
projector ventilation openings.
You can tilt the projector within ± 15 degrees horizontally.
z
Security
Take safety measures against following incidents.

Personal information being leaked via this product.
z
Unauthorized operation of this product by a malicious third party.
z
Interfering or stopping of this product by a malicious third party.
z
Security instruction

The connecting network must be secured by rewall or others.
z
Change your password regularly.
z
Do not use a password that is simple to guess.
z
Panasonic and its afliate companies would never directly inquire about your password.
z
Do not share your password with the general public.
z
Set a password, and place restrictions on the users who can log in.
z
Cautions on use
In order to get the picture quality

Draw curtains or blinds over windows and turn off any lights near the screen to prevent outside light or light
z
from indoor lamps from shining onto the screen.
Depending on where the projector is used, air exhaust vents or the warm air from air conditioning can cause
z
a shimmering effect on the screen. For this reason, take care not to shield the air exhaust vents and consider
the direction of the air owing from air conditioning.
over 50 cm (20")
over 10 cm (4")
over 50 cm (20") over 50 cm (20")
-
15°
+15°

Precautions with regard to safety
16 - ENGLISH
Important
Information
Do not touch the surface of the projector lens with your bare hand.
If the surface of the lens becomes dirty from ngerprints or anything else, this will be magnied and projected
onto the screen. Please put the lens cover on the projector when you do not use it.
Do not move the projector while it is operating or subject it to vibration or

impact.
The service life of its internal components will be shortened.
The projector has a high pressure mercury lamp that is characterized as

follows:
The brightness of the lamp will decrease over time.
z
The lamp may explode or shorten the lamp life by shocks or chipping damage.
z
In rare cases, it may burst shortly after the rst use.
z
The possibility of its bursting increases when the lamp is used beyond the replacement time.
z
If the lamp bursts, gas inside the lamp is released in the form of smoke.
z
The life of a mercury lamp varies according to the individual difference or conditions of use.
z
In particular, turning the power on and off frequently and/or repeatedly as well as continuous use for 22 hours
z
will greatly affect the life cycle. Provide a lamp for replacement in advance.
Lamp deterioration accelerates when used continuously for 22 hours or more. Lamp deterioration due to
z
continuous use can be reduced by using the “LAMP RELAY” function.
Connection to external device

When connecting the projector to a computer or external device, use the power cord supplied with the
corresponding device and a commercially available shielded interface cable.
Optical components

It may be necessary to replace the optical components such as DLP chips and Polarizing plates in less than 1
year if using the projector in a high temperature environment or in a very dusty, oily smoke or tobacco smoke
environment. For more details, please contact your dealer.
DLP chips

The DLP chips are precision-made. Note that in rare cases, pixels of high precision could be missing or always lit,
but this is not a malfunction. Please take note that directing a laser beam onto the lens surface can damage the
DMD element.
Cleaning and maintenance
Ask an Authorized Service Center to clean the inside of the projector at

least once a year.
If dust is left to build up inside the projector without being cleaned out, it can result in re or problems with
operation. It is a good idea to clean the inside of the projector before the season when humid weather arrives.
Ask your nearest Authorized Service Center to clean the projector when required.
Please discuss with the Authorized Service Center regarding cleaning costs.
Be sure to remove the power plug from the wall outlet before cleaning.
z
Use soft and dry cloth to clean the cabinet.
z
Use a soft cloth moistened in warm water to clean away oil. Do not use solvents such as benzene, thinner,
and alcohol, detergents for kitchens, or a chemical cloth. If using such solvents, the outer case will become
deformed, and the paint may peel off.
Do not clean the lens surface with fuzzy or dusty cloths.
z
If dust adheres to the lens, it will be magnied and projected on the screen. Use a soft and clean cloth to wipe
off dust.
Disposal
When discarding this product, please contact your local authorities or dealer and ask for the correct method of
disposal.

Precautions with regard to safety
ENGLISH - 17
Important
Information
Accessories
Make sure the following accessories are provided with your projector.
Remote control (x1)
(N2QAYB000550)
Power cord (x1)
(TXFSX01RGRZ)
Power cord (x1)
(TXFSX02RGRZ)
Drop-prevention bracket (x2)
(TTRA0238)
Safety cables (x2)
Washers (x4)
Wire rope xing screw (x2)
CD-ROM (x1)
(TXFQB02VKN)
AA/R6 batteries for
remote control (x2)
Lens xing screw (x1)
(XYN4+J18FJ)
Attention
After unpacking the projector, discard the power cord cap and packaging material properly.
z
For lost accessories, consult your dealer.
z
The part numbers of accessories and separately sold components are subject to change without notice.
z
Store small parts in an appropriate manner, and keep them away from young children.
z

About Your Projector
18 - ENGLISH
Preparation
About Your Projector
Attention
Do not drop the remote control.
z
Avoid contact with liquids or moisture.
z
Do not attempt to modify or disassemble the remote control.
z
Do not let strong light shine onto the signal receptor. The remote control may malfunction under strong light such as
z
uorescent.
Note
The remote control can be used within a distance of about 30 m if pointed directly at the remote control receiver. The
z
remote control can control at angles of up to ± 15 °C vertically and ± 30 °C horizontally, but the effective control range may
be reduced.
If there are any obstacles between the remote control and the remote control signal receptor, the remote control may not
z
operate correctly.
The signal will be reected off the screen. The operating range may differ due to the screen material.
When the projector receives a signal from the remote control, the Power indicator will ash.
z
Remote control
JTop view
Front view
J
Installing/removing batteries
Press the tab and
lift up the cover.
Insert the batteries according to
the polarity diagram indicated
inside. (insert the side rst).
Remove the batteries in the
reverse order to setting.
Bottom view
J
Remote control wired terminal
(Æpage 21)
Remote control signal emitters
Species the ID of the remote control.
(Æpage 21)
Restores the default factory setting.
(Æpage 50)
Assign the frequently use functions
from options for shortcut.
(Æpage 48)
These buttons are used together with
▲▼◄► to adjust focus, zoom and
shift by the projection lens.
(Æpages 40, 42)
Switches the image aspect ratio.
(Æpage 49)
Pressing this button toggles the
projector’s internal mechanical shutter
to black out the projector.
(Æpage 47)
Pressing this button while projecting
an image automatically corrects the
picture positioning on the screen.
While the auto setup feature is active,
a message “PROGRESS” appears on
the screen. (Æpage 48)
Returns to the standby mode.
Makes the remote control available
to control any ID projectors.
(Æpage 21)
Displays projector information.
Enter ID number of the remote
control and adjustment values of
menu items.
Displays the test pattern.
(Æpage 48)
Displays and clears the on
screen indications.
(Æpage 47)
<MENU> button
Displays and clears the main menu, and
returns to the previous menu when the
menu is displayed.
Navigation and <ENTER> buttons
Navigate through the menu items with
▲▼◄►, and activate them with the
<ENTER> button. (Æpage 50)
These buttons select the RGB1,
RGB2, DVI-D, VIDEO, S-VIDEO
and SDI terminals. (Æpage 47)
Starts the projection while in the
standby mode.
Remote control indicator
Flashes by pressing any
buttons.

About Your Projector
ENGLISH - 19
Preparation
Projector body
JFront view Side views
J
Û: Attach a commercial burglar prevention cable.
Burglar hook port Û
Auto Cleaning
Filter (ACF)
compartment
(Æpage 110)
Remote control
signal receptor
Air exhaust port
Air intake port
Air intake port
Air intake port
Lamp unit compartment
(Æpage 111)
Air exhaust port
Filter indicator (FILTER)
Indicates the lter status. (Æpage 109)
Remote control
signal receptor
Temperature indicator (TEMP)
Indicates the temperature status. (Æpage 109)
Front leg adjusters
Screw up/down to adjust
the projection angle.
Lamp2 indicator (LAMP2)
Indicates the lamp2 unit status. (Æpage 108)
Lamp1 indicator (LAMP1)
Indicates the lamp1 unit status. (Æpage 108)
Power indicator (STANDBY(R) / ON(G))
Indicates the power supply status.
Security lock
Air intake portTerminals on side
CONTROL
PANEL
AC IN terminal
Connect the power cord to supply
electronic power to the projector.
<MAIN POWER> switch
Switch the projector on/off.
JRear view Bottom view J
Attention
Keep your hands and other objects away from the air outlet port.
Keep your hand and face away.
z
Keep heat-sensitive articles away.
z
Inserting your nger may result in injury.
z
Heated air from the air outlet port can cause burns or deformations.

About Your Projector
20 - ENGLISH
Preparation
CONTROL PANEL
J
Terminals on side
J
Attention
Do not touch the LAN terminal with your bare hands or body, as body parts may have charged static electricity. Failure to
z
do so may cause malfunctions.
Do not touch the metallic parts of LAN terminal and cable.
Please connect the LAN to indoor devices only.
z
VIDEO
Switches to VIDEO input.
S-VIDEO
Switches to S-VIDEO input.
RGB1
Switches to RGB1 input.
RGB2
Switches to RGB2 input.
DVI-D/HDMI
Switches to DVI-D or HDMI input.
SDI
Switches to SDI input.
(PT-DZ110XE/PT-DS100XE only)
<AUTO SETUP> button
Pressing this button while projecting an image
automatically corrects the picture positioning on
the screen. While the auto setup feature is active,
a message “PROGRESS” appears on the screen.
(Æpage 48)
▲▼◄► button
Use these buttons to select menu items,
change settings, adjust levels, and to enter the
[SECURITY] password.
<SHUTTER> button
Pressing this button toggles the projector’s
internal mechanical shutter to black out the
projector. (Æpage 47)
<ENTER> button
Press to activate a menu selection or to initiate a
function.
<LENS> button
This button is used together with ▲▼◄► to
adjust focus, zoom and shift by the projection
lens.
<MENU> button
Displays and clears the main menu, and returns to the previous
menu when the menu is displayed.
If you hold it down for at least 3 seconds while the on-screen
indication is [OFF], the [OFF] state is canceled. (Æpage 50)
<POWER ON> button
Starts the projection while in the
standby mode.
<STANDBY> button
Returns to the standby mode.
SDI IN
Connect an SDI signals.
(PT-DZ110XE/PT-DS100XE
only)
SERIAL IN/OUT
Connect an RS-232C cable from/to a computer.
DVI-D IN
Connect a single link DVI-D
signals.
HDMI IN
Connect a HDMI signals. RGB2 IN
Connect an RGB or YPBPRsignals.
RGB (YPBPR)1 IN
Connect an RGB or YPBPRsignals.
REMOTE 2 IN
Connect a cable from an
external control circuit.
REMOTE 1 IN/OUT
When two or more main
units are used in the system,
they can be connected and
controlled with wired remote
control cable.
LAN
Connect a LAN cable for network
connection.
VIDEO IN
Connect a VIDEO signals.
S-VIDEO IN
Connect an S-VIDEO signals.
