Panasonic PT-LB3U User manual

M0510SS3041 -CH
Operating Instructions
Network Operation Manual
LCD Projector
PT-LB3E/PT-LB3EA/PT-LB3U
Model No.
PT-LB2VE/PT-LB2VEA/PT-LB2VU
PT-LB1VE/PT-LB1VEA/PT-LB1VU
AUTO
SETUP
MENU RETURN
ENTER
FREEZE
AV
MUTE
COMPUTER
VIDEO
DEFAULT
FUNCTION
WIN.
INDEX-
DIGITAL ZOOM
VOLUME
TQBH0215-3 (E/U/EA)

2
Contents
RequestRegardingSecurity ·············································3
Whatyoucando·······················································3
Checkyourcomputer···················································4
Necessary environment for computers to be connected · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4
Connecting with Wired LAN ··············································4
Networksettingoftheprojector ··········································5
Displaying the NETWORK menu ··············································5
NETWORK································································6
Wired LAN settings ·····································································6
Default network settings· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 6
NAME CHANGE ····························································7
NETWORK CONTROL·······················································7
STATUS ··································································8
INITIALIZE ································································8
UsingWebBrowser·····················································9
Before using the WEB control ····························································9
AccessingfromtheWebBrowser ············································10
Monitorinformationwindow ····························································11
Projector control window ·······························································12
Detailed set up window·································································12
Change password window ······························································16
Switching Languages ··································································16
UsingPJLinkprotocol ·················································17
Applicablecommands ·····················································17
Glossary ·····························································18
Trademarks ··························································18
The illustrations and screenshots in this manual may be different from those on your computer.

3
Request Regarding Security
When using this product, security breaches of the type described below are conceivable.
Leakage of your private information via this product
•
Illegal operation of this product by a malicious third-party
•
Harm to or cessation of operation of this product by a malicious third-party
•
Be sure to implement sufficient security measures.
Set passwords, and limit the users that are permitted login access.
•
Make sure the password is as hard to guess as possible.
•
Change the password periodically.
•
Panasonic Corporation and its affiliated companies never directly ask customers for their password.
•
Do not give out your password even if directly asked by a third-party representing themselves as Panasonic Corporation.
Always use on a network that has safety protection such as a firewall implemented.
•
What you can do
<WEB control> (See page 9)
The following operations are possible when using WebBrowser.
Setting and adjusting the projector
•
Displaying the projector status
•
Setting for message transmission
•
<PJLink> (See page 17)
Compatible with PJLink Class 1. The following operations can be performed from a computer when PJLink protocol is used.
Setting the projector
•
Querying the projector status
•
<Command control> (Refer to “SERIAL TERMINAL” in “Technical Information” of the Basic Manual.)
You can control the projector from a computer, using the control commands of the serial terminals.
If you use “WEB control”, “PJLink” or “Command control”, turn [ON] the [NETWORK CONTROL] in the NETWORK menu for the
projector. (See page 7)

4
Check your computer
Necessary environment for computers to be connected
First, check your computer to see whether or not it has a wired LAN
•function.
LAN : “Glossary” (See page 18)
Before connecting the computer to the projector, be sure to check the following settings.
•
Check 1 For LAN cable
Is the cable properly connected?
•
Use LAN cable that is compatible with category 5 or above.
•
Check 2 Wired LAN settings
<Computer with a built-in wired LAN function>
Is your wired LAN switched on?
•
<Computer without a built-in wired LAN function>
Is your wired LAN adapter properly recognized?
•
Is your wired LAN adapter switched on?
•
Install the wired LAN adapter driver beforehand.
•
For details on how to install the driver, refer to the instructions accompanying the wired LAN adapter.
Check 3 For WebBrowser
WebBrowser is necessary to use WEB control.
•
Compatible WebBrowser : Internet Explorer 6.0/7.0/8.0
•
Do not touch the LAN terminal or the metal part of the LAN cable, the static electricity may discharge from our hand (body)
causing a malfunction.
Connecting with Wired LAN
Connection can be made with wired LAN. However, confirm to your system administrator on network settings before changing
any settings.
Turn on the computer.
1
Make the network setting according to your system administrator.
2 If the projector settings are the default settings (See page 6), the computer can be used with the following network
settings.
IP ADDRESS 192.168.10.101
SUBNETMASK 255.255.255.0
DEFAULT GATEWAY 192.168.10.1

5
Network setting of the projector
When making a connection between a computer and a projector with settings other than the default settings, perform the
procedure below to display the menu required when changing the initial settings.
Displaying the NETWORK menu
Press the [MENU] button on the projector.
1 The main menu appears.
FUNCTION
ENTER
SELECT
RETURN
LANGUAGE
PROJECTOR SETUP
SECURITY
NETWORK
POSITION
DISPLAY OPTION
PICTURE PICTURE MODE
CONTRAST
BRIGHTNESS
COLOR
TINT
DYNAMIC
0
−＋
0
−＋
0
−＋
0
−＋
SHARPNESS
COLOR TEMPERAT URE
DAYLIGHT VIEW
NOISE REDUCTION
TV-SYSTEM
DEFAULT
AUTO
OFF
AUTO
0
−＋
Select [NETWORK] with the [▲▼] buttons.
2 The network menu appears.
LANGUAGE
PROJECTOR SETUP
SECURITY
NETWORK
POSITION
DISPLAY OPTION
WIRED LAN
NAME CHANGE
STAT US
INITIALIZE
NETWORK CONTROL ON
FUNCTION
ENTER
SELECT
RETURN
Press the [ENTER] button
3 You can select the sub-menu item.
Depending on the signals which are input to the projector, it may not be possible to adjust some of the items and use some of
the functions. In the case of an item that cannot be adjusted or a function that cannot be used, the corresponding on-screen item
will not be displayed, and you will not be able to execute it even when you press the [ENTER] button.

6
Network setting of the projector (cont.)
NETWORK
Wired LAN settings
You can make detailed wired LAN settings.
Select [WIRED LAN] in the NETWORK menu and press the [ENTER] button.
1
WIRED DETA ILED SETUP
OK CANCEL
CANCEL
SELECT
DHCP
IP ADDRESS
SUBNETMASK
DEFAULT GATEWAY
192.168. 10.100
OFF
192.168. 10. 1
255.255.255. 0
DHCP
ON: If a DHCP server exists in the network to which the projector is connected, the IP address will automatically be
acquired.
OFF: If a DHCP server does not exist in the network to which the projector is connected, additionally set [IP
ADDRESS ], [SUBNETMASK ] and [DEFAULT GATEWAY ].
“Glossary” (See page 18)
Select each item with the [▲▼] buttons and change the settings following the
2 menu’s Operating guidance.
Select [OK] with the [▲▼] buttons and press the [ENTER] button.
3
Default network settings
The following settings are set before the projector leaves the factory.
DHCP OFF
IP ADDRESS 192.168.10.100
SUBNETMASK 255.255.255.0
DEFAULT GATEWAY 192.168.10.1

7
Network setting of the projector (cont.)
NAME CHANGE
You can change the projector name on the network.
Select [NAME CHANGE] in the NETWORK menu and press the [ENTER] button.
1
LANGUAGE
PROJECTOR SETUP
SECURITY
NETWORK
POSITION
DISPLAY OPTION
WIRED LAN
NAME CHANGE
STAT US
INITIALIZE
NETWORK CONTROL ON
FUNCTION
ENTER
SELECT
RETURN
2 Select characters with the [◄►▲▼] buttons and press
the [ENTER] button to enter the projector name.
Select [ALL DELETE] to remove all the entered characters. Press the [DEFAULT]
button on the remote-controller to clear a letter which is selected by the cursor in the
entry box.
Select [OK] with the [◄►▲▼] buttons and press the
3 [ENTER] button.
Select [CANCEL] to undo the changes.
NETWORK CONTROL
Set it to “ON”, if you want to control the projector from a computer that is network-connected.
Select [NETWORK CONTROL] in the NETWORK menu.
1
LANGUAGE
PROJECTOR SETUP
SECURITY
NETWORK
POSITION
DISPLAY OPTION
WIRED LAN
NAME CHANGE
STAT US
INITIALIZE
NETWORK CONTROL ON
FUNCTION
SELECT
RETURN
Select [ON] or [OFF] with the [◄►] buttons.
2
If you turn [ON] the [NETWORK CONTROL], “WEB control”, “PJLink” and “Command control” are available.
NAME CHANGE
A B C D E F G H I J K L M
N
a
O
b
P
c
Q
d
R
e
S
f
T
g
U
h
V
i
W
j
X
k
Y
l
Z
m
n
1
o
2
p
3
q
4
r
5
s
6
t
7
u
8
v
9
w
0
x
SPACE
ALL DELETE
y z
! " # $ % & ’ * +
-
/ /
= ? @ ^
_ ` | ~ ( ) < > [ ] { } , . : ;
＊＊＊＊＊＊
OK CANCEL
RETURN
ENTER
SELECT
DELETE

8
Network setting of the projector (cont.)
STATUS
Your current settings appear.
Select [STATUS] in the NETWORK menu and press the [ENTER] button.
LANGUAGE
PROJECTOR SETUP
SECURITY
NETWORK
POSITION
DISPLAY OPTION
WIRED LAN
NAME CHANGE
STAT US
INITIALIZE
NETWORK CONTROL ON
FUNCTION
ENTER
SELECT
RETURN
The status of the following will appear.
NETWORK
DHCP “ON” - “OFF”
IP ADDRESS (See page 6)
SUBNETMASK (See page 6)
DEFAULT GATEWAY (See page 6)
MAC ADDRESS —
MAC ADDRESS : “Glossary” (See page 18)
INITIALIZE
You can reset the network settings to the factory default settings of the projector.
Select [INITIALIZE] in the NETWORK menu and press the [ENTER] button.
1
LANGUAGE
PROJECTOR SETUP
SECURITY
NETWORK
POSITION
DISPLAY OPTION
WIRED LAN
NAME CHANGE
STAT US
INITIALIZE
NETWORK CONTROL ON
ENTER
SELECT
RETURN
The entry of the password is prompted if [PASSWORD] is turned [ON] in the “ SECURITY” menu.
2 Select [OK] with the [◄►] buttons and press the [ENTER]
button.
INITIALIZE
RETURN
ENTER
SELECT
INITIALIZE
OK CANCEL

9
Using WebBrowser
Control a projector through the WebBrowser of a computer. It is called “WEB Control”.
(The example is when using Microsoft Internet Explorer.)
Before using the WEB control
Connect the projector and a computer with a LAN cable. (See page 4)
Projector settings
Turn [ON] the [NETWORK CONTROL] in the NETWORK menu.
Select [NETWORK CONTROL] in the NETWORK menu.
1
Select [ON] with the [◄►] buttons.
2 ON : This enables control on the WebBrowser.
OFF : This disables control on the WebBrowser.
LANGUAGE
PROJECTOR SETUP
SECURITY
NETWORK
POSITION
DISPLAY OPTION
WIRED LAN
NAME CHANGE
STAT US
INITIALIZE
NETWORK CONTROL ON
FUNCTION
SELECT
RETURN
Computer settings
Proxy server settings

Release the proxy settings of the WebBrowser used.
Open <Internet Properties> window.
1 Click [Start] → [Control Panel] → [Network and Internet Connections] → [Internet Option].
Click [Connections] tab → [LAN Settings].
2
3 If [Use a proxy server for your LAN] has been checked,
remove the check.
If [Use automatic configuration script] has been checked,
remove the check.
Click [OK].
4

10
Using WebBrowser (cont.)
Enabling JavaScript

If JavaScript has been set to disable, enable it.
Open <Internet Properties> window.
1 Click [Start] → [Control Panel] → [Network and Internet Connections] → [Internet Option].
Click the [Security] tab and set the security level to [Default Level], or select [Custom
2 Level] and check the [Enable] checkbox under [Active scripting].
Accessing from the WebBrowser
Start up the WebBrowser, and enter the IP address set to the projector.
1 The WebBrowser starts up and the authentication window appears.
http://10.69.104.56
<Top window>
Enter the User name and the Password.
2
Click [OK].
3 <Monitor information> window appears. (11 page)
The default user name and password settings are as follows:
•
User name: user1 (with user authority) / admin1 (administrator authority)
Password: panasonic (lower case)
Administrator authority has full access to the all features. User authority has access to “Status”, “Projector control” and “Change
•
password”. (User authority has no access to “Detailed set up”.)
Password used in this page is for accessing the web control window.
•(See page 16)
The system locks for several minutes if an incorrect password is entered three times in succession.
•
If you initialize the network settings, the password is reset to “panasonic”. Change the password to an appropriate one.
•
Make sure the password is as hard to guess as possible.
•
Change the password periodically.
•
If you have forgotten the password, perform [INITIALIZE] in the projector
•’s NETWORK menu (See page 8), and set a new one
in the “Change password” window of your WebBrowser. (See page 16)
Panasonic Corporation and its affiliated companies never directly ask customers for their password.
•
Do not give out your password even if directly asked by a third-party representing themselves as Panasonic Corporation.
The Top window may not appear depending on the WebBrowser. In this case start up WebBrowser again, or press the [Ctrl] + [R]
•
keys for example to update the screen.
Connection cannot be made while the WebBrowser is set to dial-up network. Cancel the dial-up network setting.
•
It may take some moments for WebBrowser to start up.
•

11
Using WebBrowser (cont.)
Monitor information window
This page indicates the projector status.
To access this page from other pages, click [Status] in the main menu (at the left of the window).
Projector status

On this window, click the [Projector status] tab.
Network status

On this window, click the [Network status] tab.
The monitor information is refreshed at fixed intervals, but the current exact information can be checked by clicking [View] →
[Refresh].
If [SELF TEST Error (Detail)] appears on the Monitor
information window, click it to view the error details.
If [FAILED] appears

Item Description
MAIN CPU BUS There is a problem with a microcontroller circuit. Contact your dealer.
FAN There is a problem with the fan or fan drive circuit. Contact your dealer.
INPUT AIR TEMPERATURE Input air temperature is high. The projector is likely being used in a high temperature
environment such as near heating equipment.
OUTPUT AIR TEMPERATURE Temperature surrounding the lamp is high. The exhaust vent is likely blocked.
LAMP REMAIN TIME The lamp has been used for longer than its rated useful life, and it is time to replace it.
LAMP STATUS The lamp could not be lit.
Allow the bulb of the light source to cool, and then turn on the projector.
INPUT AIR TEMP.SENSOR There is a problem with the air intake temperature sensor. Contact your dealer.
OUTPUT AIR TEMP.SENSOR There is a problem with the exhaust temperature sensor. Contact your dealer.
BATTERY The battery must be replaced. Contact your dealer.
AIR FILTER The air filter is clogged with dust.
Clean the air filter. (See Page 46 of "Operating Instructions Basic Manual")

12
Using WebBrowser (cont.)
Projector control window
You can make various projector settings.
If you migrate from other page, click [Projector control] in the main menu (at the left of the window).
Basic control window

On this window, click the [Basic control] tab.
Advanced control window

On this window, click the [Advanced control] tab.
Connection with the projector may not be possible immediately after the power is turned on. In this case wait a bit and then
make the connection again.
Detailed set up window
Network config

You can make detailed wired LAN settings.
1 Click [Detailed set up] → [Network config] in the
menu.
Confirm the notes that appear on the screen and
2 click [Next].
The settings window appears, showing the current settings.
To change the LAN settings, click [Change].
•
To return to the previous window, click [Back].
•

13
Using WebBrowser (cont.)
3 Complete the detailed settings and click [Next].
When [Next] is clicked, the next page appears, enabling you to
complete the detailed settings as desired.
After all required items have been entered, a confirmation window
appears.
Click [Submit].
4 The settings will be registered.
If you have changed the LAN settings that are currently in use, the connection may break off.
Adjust clock

Click [Detailed set up] → [Adjust clock] in the menu.
Time zone : Select the time zone and click [Set time zone].
Time : Enter the current date and time in [Date] and [Time],
and then click [Set date and time].

14
Using WebBrowser (cont.)
E-mail set up

You can specify two email recipients.
Click [Detailed set up] → [E-mail set up] in the menu.
[MAIL SERVER]
•
ENABLE : Enable or disable email transmission.
SMTP SERVER NAME : Enter the SMTP server name.
[MAIL OPTION]
•
MAIL FROM : Enter the sender’s email address.
MEMO : Enter a description of the sender.
[TEMPERATURE WARNING SET UP]
•
MINIMUM TIME : Enter the interval for sending email.
INPUT AIR TEMPERATURE : Select the temperature of the intake sensor
at which to send a warning message.
[E-MAIL ADDRESS]
•
E-MAIL ADDRESS : Enter the email addresses of the recipients.
MAIL CONTENTS : Change the type of message as desired.
When sending messages to mobile phones, select “SIMPLE”.
ERROR : Select ON to send email when errors occur.
LAMP RUNTIME : Select ON to send email when “at REMAIN” is reached.
INPUT AIR TEMPERATURE : Select ON to send email when the temperature set in [TEMPERATURE WARNING SET UP] is
exceeded.
PERIODIC REPORT : Send a message with the projector status at the selected date and time.
When [submit] is clicked, the settings are applied.
Consult your system administrator on MAIL SERVER and E-MAIL ADDRESS settings.
Ping test

You can confirm if a network connection is established with Mail server,
POP server, DNS server or the like.
Click [Detailed set up] → [Ping test] in the menu.
Input IP address : Enter the IP address of the server you want to
test, and then click [Submit].
If succeeded in connection, the following display appears.
If failed in connection, the following display appears.

15
Using WebBrowser (cont.)
Example of email message sent
If [NORMAL] is selected under [MAIL CONTENTS]

＝＝＝ Ｐａｎａｓｏｎｉｃ ｐｒｏｊｅｃｔｏｒ ｒｅｐｏｒｔ（ＣＯＮＦＩＧＵＲＥ） ＝＝＝
Ｐｒｏｊｅｃｔｏｒ Ｔｙｐｅ ： ＬＢ２Ｖ
Ｓｅｒｉａｌ Ｎｏ ： Ｄ２３４５６７ＡＢ
－－－－－ Ｅ－ｍａｉｌ ｓｅｔｕｐ ｄａｔａ －－－－－
ＴＥＭＰＥＲＡＴＵＲＥ ＷＡＲＮＩＮＧ ＳＥＴＵＰ
ＭＩＮＩＭＵＭ ＴＩＭＥ ａｔ ［ ６０］ ｍｉｎｕｔｅｓ ｉｎｔｅｒｖａｌ
ＩＮＰＵＴ ＡＩＲ ＴＥＭＰＥＲＡＴＵＲＥ Ｏｖｅｒ ［ ３８Ｃ ／ １００Ｆ ］
ＥＲＲＯＲ ［ ＯＮ ］
ＬＡＭＰ ＲＵＮＴＩＭＥ ［ ＯＮ ］ ａｔ ＲＥＭＡＩＮ ［ ４００］ Ｈ
ＬＡＭＰ ＲＵＮＴＩＭＥ ［ ＯＮ ］ ａｔ ＲＥＭＡＩＮ ［ ２００］ Ｈ
ＩＮＰＵＴ ＡＩＲ ＴＥＭＰＥＲＡＴＵＲＥ ［ ＯＮ ］
ＰＥＲＩＯＤＩＣ ＲＥＰＯＲＴ
Ｓｕｎｄａｙ ［ ＯＮ ］ Ｍｏｎｄａｙ ［ ＯＮ ］ Ｔｕｅｓｄａｙ ［ ＯＮ ］ Ｗｅｄｎｅｓｄａｙ ［ ＯＮ ］
Ｔｈｕｒｓｄａｙ ［ ＯＮ ］ Ｆｒｉｄａｙ ［ ＯＮ ］ Ｓａｔｕｒｄａｙ ［ ＯＮ ］
００：００ ［ ＯＮ ］ ０１：００ ［ ＯＮ ］ ０２：００ ［ ＯＮ ］ ０３：００ ［ ＯＮ ］
０４：００ ［ ＯＮ ］ ０５：００ ［ ＯＮ ］ ０６：００ ［ ＯＮ ］ ０７：００ ［ ＯＮ ］
０８：００ ［ ＯＮ ］ ０９：００ ［ ＯＮ ］ １０：００ ［ ＯＮ ］ １１：００ ［ ＯＮ ］
１２：００ ［ ＯＮ ］ １３：００ ［ ＯＮ ］ １４：００ ［ ＯＮ ］ １５：００ ［ ＯＮ ］
１６：００ ［ ＯＮ ］ １７：００ ［ ＯＮ ］ １８：００ ［ ＯＮ ］ １９：００ ［ ＯＮ ］
２０：００ ［ ＯＮ ］ ２１：００ ［ ＯＮ ］ ２２：００ ［ ＯＮ ］ ２３：００ ［ ＯＮ ］
－－－－－ ｃｈｅｃｋ ｓｙｓｔｅｍ －－－－－
ＭＡＩＮ ＣＰＵ ＢＵＳ ［ ＯＫ ］
ＦＡＮ ［ ＯＫ ］
ＩＮＰＵＴ ＡＩＲ ＴＥＭＰＥＲＡＴＵＲＥ ［ ＯＫ ］
ＯＵＴＰＵＴ ＡＩＲ ＴＥＭＰＥＲＡＴＵＲＥ ［ ＯＫ ］
ＬＡＭＰ ＲＥＭＡＩＮ ＴＩＭＥ ［ ＯＫ ］
ＬＡＭＰ ＳＴＡＴＵＳ ［ ＯＫ ］
ＩＮＰＵＴ ＡＩＲ ＴＥＭＰ．ＳＥＮＳＯＲ ［ ＯＫ ］
ＯＵＴＰＵＴ ＡＩＲ ＴＥＭＰ．ＳＥＮＳＯＲ ［ ＯＫ ］
ＢＡＴＴＥＲＹ ［ ＯＫ ］
ＡＩＲ ＦＩＬＴＥＲ ［ ＯＫ ］
（Ｅｒｒｏｒ ｃｏｄｅ ００ ００ ００ ００ ００ ００ ００ ００）
Ｉｎｐｕｔ ａｉｒ ｔｅｍｐｅｒａｔｕｒｅ ： ２４ ｄｅｇＣ ／ ７５ ｄｅｇＦ
Ｏｕｔｐｕｔ ａｉｒ ｔｅｍｐｅｒａｔｕｒｅ ： ２６ ｄｅｇＣ ／ ７８ ｄｅｇＦ
ＳＥＴ ＲＵＮＴＩＭＥ ７９ Ｈ
ＬＡＭＰ ＯＮ １９０ ｔｉｍｅｓ
ＬＡＭＰ ＨＩＧＨ ０ Ｈ
ＬＡＭＰ ＲＥＭＡＩＮ ２９２１ Ｈ
－－－－－－－－ Ｃｕｒｒｅｎｔ ｓｔａｔｕｓ －－－－－－－－－
ＭＡＩＮ ＶＥＲＳＩＯＮ ０．２２
ＮＥＴＷＯＲＫ ＶＥＲＳＩＯＮ ０．０１．００
ＬＡＭＰ ＳＴＡＴＵＳ ＬＡＭＰ＝ＯＦＦ
ＩＮＰＵＴ ＳＩＧＮＡＬ
－－－－－ Ｗｉｒｅｄ Ｎｅｔｗｏｒｋ ｃｏｎｆｉｇｕｒａｔｉｏｎ －－－－－
ＤＨＣＰ Ｃｌｉｅｎｔ ＯＦＦ
ＩＰ ａｄｄｒｅｓｓ １０．６９．１０４．５６
ＭＡＣ ａｄｄｒｅｓｓ ００：０Ｂ：９７：４１：Ｅ３：１６
Ｗｅｄ Ｍａｒ ３１ ００：５３：４２ ２０１０
－－－－－ Ｍｅｍｏ －－－－－
ｌｂ２ｖ
＝＝＝ Ｐａｎａｓｏｎｉｃ ｐｒｏｊｅｃｔｏｒ ｒｅｐｏｒｔ（ＥＲＲＯＲ） ＝＝＝
Ｐｒｏｊｅｃｔｏｒ Ｔｙｐｅ ： ＬＢ２Ｖ
Ｓｅｒｉａｌ Ｎｏ ： Ｄ２３４５６７ＡＢ
－－－－－ ｃｈｅｃｋ ｓｙｓｔｅｍ －－－－－
ＭＡＩＮ ＣＰＵ ＢＵＳ ［ ＦＡＩＬＥＤ ］
ＦＡＮ ［ ＯＫ ］
ＩＮＰＵＴ ＡＩＲ ＴＥＭＰＥＲＡＴＵＲＥ ［ ＯＫ ］
ＯＵＴＰＵＴ ＡＩＲ ＴＥＭＰＥＲＡＴＵＲＥ ［ ＯＫ ］
ＬＡＭＰ ＲＥＭＡＩＮ ＴＩＭＥ ［ ＯＫ ］
ＬＡＭＰ ＳＴＡＴＵＳ ［ ＯＫ ］
ＩＮＰＵＴ ＡＩＲ ＴＥＭＰ．ＳＥＮＳＯＲ ［ ＯＫ ］
ＯＵＴＰＵＴ ＡＩＲ ＴＥＭＰ．ＳＥＮＳＯＲ ［ ＯＫ ］
ＢＡＴＴＥＲＹ ［ ＯＫ ］
ＡＩＲ ＦＩＬＴＥＲ ［ ＯＫ ］
（Ｅｒｒｏｒ ｃｏｄｅ ８０ ００ ００ ００ １０ ００ ００ ００）
Ｉｎｐｕｔ ａｉｒ ｔｅｍｐｅｒａｔｕｒｅ ： ２４ ｄｅｇＣ ／ ７５ ｄｅｇＦ
Ｏｕｔｐｕｔ ａｉｒ ｔｅｍｐｅｒａｔｕｒｅ ： ２６ ｄｅｇＣ ／ ７８ ｄｅｇＦ
ＳＥＴ ＲＵＮＴＩＭＥ ７９ Ｈ
ＬＡＭＰ ＯＮ １９０ ｔｉｍｅｓ
ＬＡＭＰ ＨＩＧＨ ０ Ｈ
ＬＡＭＰ ＲＥＭＡＩＮ ２９２１ Ｈ
－－－－－－－－ Ｃｕｒｒｅｎｔ ｓｔａｔｕｓ －－－－－－－－－
ＭＡＩＮ ＶＥＲＳＩＯＮ ０．２２
ＮＥＴＷＯＲＫ ＶＥＲＳＩＯＮ ０．０１．００
ＬＡＭＰ ＳＴＡＴＵＳ ＬＡＭＰ＝ＯＦＦ
ＩＮＰＵＴ ＳＩＧＮＡＬ ＣＯＭＰＵＴＥＲ１ －－－
０．００ｋＨｚ ／ ０．００Ｈｚ
－－－－－ Ｗｉｒｅｄ Ｎｅｔｗｏｒｋ ｃｏｎｆｉｇｕｒａｔｉｏｎ －－－－－
ＤＨＣＰ Ｃｌｉｅｎｔ ＯＦＦ
ＩＰ ａｄｄｒｅｓｓ １０．６９．１０４．５６
ＭＡＣ ａｄｄｒｅｓｓ ００：０Ｂ：９７：４１：Ｅ３：１６
Ｗｅｄ Ｍａｒ ３１ ０１：２８：４６ ２０１０
－－－－－ Ｍｅｍｏ －－－－－
ｌｂ２ｖ
If you have completed the email settings If an error occurs
If [SIMPLE] is selected under [MAIL CONTENTS]

Ｐｒｏｊｅｃｔｏｒ Ｔｙｐｅ：
［ＬＢ２Ｖ］
Ｓｅｒｉａｌ Ｎｏ：
［］
－－－ Ｅ－ｍａｉｌ ｓｅｔｕｐ ｄａｔａ
－ＴＥＭＰ． ＷＡＲＮＩＮＧ ＳＥＴＵＰ
ＭＩＮＩＭＵＭ ＴＩＭＥ ：
ａｔ ［ ６０］ ｍｉｎｕｔｅｓ ｉｎｔｅｒｖａｌ
ＩＮＰＵＴ ＡＩＲ ＴＥＭＰ． ：
Ｏｖｅｒ ［ ３８Ｃ ／ １００Ｆ ］
－
ＥＲＲＯＲ ［ＯＮ ］
ＬＡＭＰ ＲＥＭＡＩＮ ［１０００Ｈ］
ＬＡＭＰ ＲＥＭＡＩＮ ［ ９９９Ｈ］
ＩＮＰＵＴ ＴＥＭＰ． ［ＯＮ ］
－ＰＥＲＩＯＤＩＣ ＲＥＰＯＲＴ
Ｓｕｎ［ＯＮ ］ Ｍｏｎ［ＯＮ ］
Ｔｕｅ［ＯＮ ］ Ｗｅｄ［ＯＮ ］
Ｔｈｕ［ＯＮ ］ Ｆｒｉ［ＯＮ ］
Ｓａｔ［ＯＮ ］
００：００［ＯＮ ］ ０１：００［ＯＮ ］
０２：００［ＯＮ ］ ０３：００［ＯＮ ］
０４：００［ＯＮ ］ ０５：００［ＯＮ ］
０６：００［ＯＮ ］ ０７：００［ＯＮ ］
０８：００［ＯＮ ］ ０９：００［ＯＮ ］
１０：００［ＯＮ ］ １１：００［ＯＮ ］
１２：００［ＯＮ ］ １３：００［ＯＮ ］
１４：００［ＯＮ ］ １５：００［ＯＮ ］
１６：００［ＯＮ ］ １７：００［ＯＮ ］
１８：００［ＯＮ ］ １９：００［ＯＮ ］
２０：００［ＯＮ ］ ２１：００［ＯＮ ］
２２：００［ＯＮ ］ ２３：００［ＯＮ ］
－－－ ｃｈｅｃｋ ｓｙｓｔｅｍ
ＦＡＮ ［ ＯＫ ］
ＬＡＭＰ ［ ＯＫ ］
ＴＥＭＰ． ［ ＯＫ ］
ＦＩＬＴＥＲ ［ ＯＫ ］
ＯＴＨＥＲ ［ ＯＫ ］
Ｅｒｒｏｒ ｃｏｄｅ ：
００ ００ ００ ００
００ ００ ００ ００
－－－ Ｔｅｍｐｕｒａｔｕｒｅ
Ｉｎｐｕｔ ａｉｒ：
２４ Ｃ ／ ７５ Ｆ
Ｏｕｔｐｕｔ ａｉｒ：
２６ Ｃ ／ ７８ Ｆ
－－－ Ｌａｍｐ ｒｅｍａｉｎ
ＬＡＭＰ ２９２１ Ｈ
－－－－－ Ｍｅｍｏ －－－－－
ｌｂ２ｖ
Ｐｒｏｊｅｃｔｏｒ Ｔｙｐｅ：
［ＬＢ２Ｖ］
Ｓｅｒｉａｌ Ｎｏ：
［］
－－－ ｃｈｅｃｋ ｓｙｓｔｅｍ
ＦＡＮ ［ ＯＫ ］
ＬＡＭＰ ［ ＯＫ ］
ＴＥＭＰ． ［ ＯＫ ］
ＦＩＬＴＥＲ ［ ＯＫ ］
ＯＴＨＥＲ ［ ＦＡＩＬＥＤ ］
Ｅｒｒｏｒ ｃｏｄｅ ：
８０ ００ ００ ００
１０ ００ ００ ００
－－－ Ｔｅｍｐｕｒａｔｕｒｅ
Ｉｎｐｕｔ ａｉｒ：
２４ Ｃ ／ ７５ Ｆ
Ｏｕｔｐｕｔ ａｉｒ：
２６ Ｃ ／ ７８ Ｆ
－－－ Ｌａｍｐ ｒｅｍａｉｎ
ＬＡＭＰ ２９２１ Ｈ
－－－－－ Ｍｅｍｏ －－－－－
ｌｂ２ｖ
If you have completed the email settings If an error occurs

16
Using WebBrowser (cont.)
Authentication set up

Click [Detailed set up] → [Authentication set up] in the menu.
Auth : Change the authentication method as desired.
SMTP Auth : For SMTP authentication, change the
authentication method to use, as desired.
Pop Server name : Enter the POP server name.
User name : Enter the user name for the SMTP or POP server.
Password : Enter the password for the SMTP or POP server.
SMTP server port :
Enter the SMTP server port number.
POP server port : Enter the POP server port number.
When [submit] is clicked, the settings are applied.
Command port set up

Click [Detailed set up] → [Command port set up] in the menu.
COMMAND PORT : Specify a port number to be used for command
control and click [Set port].
Change password window
Password settings

Click [Change password] in the main menu.
Set a password for accessing the web control window.
Enter the previous password and the new password.
Enter the new password in [Retype] and click [OK].
You can enter a password up to 16 characters (upper case/lower case)
•
and symbols.
When log in as administrator, you can reset the User name and the
•
Password (forced change) that logged in with administrator/user
authority.
Switching Languages
Switch the language of the web control window.
Click [English] / [ ] in the main menu.

17
Using PJLink protocol
The projector’s network functions conform to PJLink Class 1 standards, enabling the following operations from a computer using
the PJLink protocol.
Setting the projector
•
Querying the projector status
•
To use PJLink protocol, turn [ON] the [NETWORK CONTROL] in the NETWORK menu for the projector. (See page 7)
Applicable commands
The following commands are used to control the projector with the PJLink protocol.
Command Control details Notes
POWR Power control
Parameters
0 = Standby
1 = On
POWR ? Power status query
Parameters
0 = Standby 1 = On
2 = Cooling down 3 = Warming up
INPT Input switching Parameters
11 = COMPUTER1 12 = COMPUTER2
21 = VIDEO 22 = S-VIDEO
INPT ? Input switching query
AVMT AV mute control Parameters
30 = AV mute off
31 = AV mute on
AVMT ? AV mute status query
ERST ? Error status query
Parameters
1st byte : Indicates fan errors; a number from 0 to 2
2nd byte : Indicates lamp errors; a number from 0 to 2
3rd byte : Indicates temperature errors; a number from 0 to 2
4th byte : Fixed at 0
5th byte : Indicates filter warnings; a number from 0 to 2
6th byte : Indicates other errors; a number from 0 to 2
Numbers from 0 to 2 indicate the following
0 = No error detected 1 = Warning 2 = Error
LAMP ? Lamp status query
Parameters
1st number (1–5 digits) : Cumulative hours of lamp use
2nd number : 0 = lamp off ; 1 = lamp lit
INST ? Input switching list query The following values are returned in this parameter
“11 12 21 22”
NAME ? Projector name query Returns the name set in “NAME CHANGE” in “NETWORK”
INF1 ? Manufacturer name query Returns “Panasonic”
INF2 ? Model name query Answers the model name of the projector in use.
INFO ? Query for other information Returns the version number or similar identification
CLSS ? Class information query Returns “1”
PJLink security authentication

The password used for PJLink is same as the one you set in the WEB control.
Configure this without specifying the password for the WEB control, if you use it without authentication.
For details on PJLink specifications, refer to the Japan Business Machine and Information System Industries Association
website.
The URL is http://pjlink.jbmia.or.jp/english/

18
Glossary
Item Descriptions Page
LAN Abbreviation for Local Area Network. This is a network with a relatively narrow range such as
inside a company.
4
DHCP Abbreviation for Dynamic Host Configuration Protocol. This function automatically assigns IP
addresses to the connected equipment. If a device with the DHCP server function is present
within a LAN, it automatically assigns IP addresses to the connected equipment.
6
IP address Internet Protocol (IP) is a protocol for distributing data, and the address corresponding to the
data distribution destination is called the IP address. The same IP address cannot be used
within the same LAN.
6
Subnetmask This limits the range of the IP addresses assigned to computers in order to divide the network
into a number of sections during TCP/IP connection. The value used to divide the network at
this time is called the subnetmask.
6
Default Gateway The devices that are used for different network standards from yours. Default Gateway
enables a connection with other network, by adjusting bilateral differences such as
communication protocols. If no gateway is specified for the IP address of access destination,
data will be sent to the host set as the default gateway.
6
MAC address Each network adapter has its own ID No.
A discrete ID No. is assigned to each and every network adapter around the world. These
IDs are used to exchange data between adapters. These IDs are a combination of a discrete
number managed and assigned by the IEEE to each individual manufacturer and a unique
number assigned to each individual adapter by the manufacturer.
8
Trademarks
Microsoft
•® and its logo are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or
other countries.
PJLink is a pending trademark in Japan, the United States and other countries and regions.
•
Other company names, product names or other names noted in this manual are trademarks or registered trademarks of the
•
respective companies. Note that ® and TM marks are not indicated in the text of this manual.
Notes:
Unauthorized use or reproduction of part or all of this manual is strictly prohibited.
•
Panasonic cannot be held liable for any effects resulting from the use of this manual.
•
Panasonic reserves the right to revise this manual contents without notice.
•

Web Site : http://panasonic.net/avc/projector/
© Panasonic Corporation 2011
