Panasonic RF-562DGU User manual

Order No. MD0401005C3
FM-AMPORTABLE RADIO
RF-562DGU / RF-562DGC
Colour
(K)... Black
SPECIFICATIONS
Specification
RADIO
FrequencyRange
FM 88-108 MHz
MW 530-1605 kHz
SW 4.75-18 MHz
Power Requirement Battery; 3V, twoUM-1(R20/LR20)
batteries
Speaker 8 cm
Power output 800 mW(RMS max)
Jack
Output Earphone
Dimensions(WxH x
D) 210 x120 x65 mm
Weight 650 g(without batteries)
Notes:
1. Design and specificationsaresubject to changewithoutnotice.
2004 PanasonicAVCNetworks Singapore Pte. Ltd. All rights
1

reserved. Unauthorized copying and distribution isaviolation of
law.
1. Operating Instructions
1.1. Location of control
1. Speaker
2. Telescopicantenna
FM :Pull out the telescopicantenna and adjust its length and
anglefor optimum reception.
MW :The sensitive ferrite core antenna inside the unitwill provide
excellent MW reception inmost areas. For optimum reception,
turn the unitinthe direction which gives the best results, since
the ferrite core antenna isdirectional.
SW :Extend the telescopicantenna fullyand keep itvertical.
3. Tuning control
4. Earphone jack
-Avoidlistening for prolonged periods of time to prevent
hearing damage.
-The speaker isautomaticallycut off when an earphone is
connected.
5. On-off/volume control switch
Turn clockwise to switch the radioon, and adjust the volume level.
6. Batterycompartment
2. Disassembly and Main Component Replacement
Procedures and Operational Check
“ATTENTION SERVICER”
Some chassis components maybe have sharpedges. Be careful whendiassembling and
servicing.
2

1. Thissection describes procedures for checking the operation of
the major printed circuitboards and replacing the main
components.
2. For reassemblyafter operation checks or replacement, reverse
the respective procedures. / Special reassemblyprocedures are
described onlywhen required.
3. Select items from the following index when checks or
replacement are required.
Content
-Checking Procedure for MainP.C.B.
2.1. Checking Procedure for MainP.C.B.
Step1 : Remove the BatteryCover.
Step2 : Remove all the screws.
Step3 : Remove the rearcabinet as arrowshown.
3

Step4 : Remove the Volume Knob.
Step5 : Remove all the screws.
3. Notes of Schematic Diagram
(All schematic diagrams maybe modifiedat anytime withthe development of the new
technology)
Note:
SW1
:BAND switch
VR1
:VariableResistor
-The voltage value and waveforms are the reference voltage of this
unitmeasured byDC electronicvoltmeter (high impedance) and
oscilloscope on the basisof chassis. Accordingly, there mayarise
some error involtage values and waveforms depending upon the
internal impedance of the tester or the measuring unit.
< > :FM
-Importance safetynotice :
4

Components identified bymark have special characteristics
important for safety. Furthermore, special parts which have
purposes of fire-retardant (resistors), high-qualitysound
(capacitors), low-noise (resistors), etc. are used. When replacing
anyof components, be sure to use onlymanufacturer's specified
parts showninthe parts list.
Caution !
IC, LSI and VLSI are sensitive tostatic electricity.
Secondarytrouble canbe preventedbytaking care during repair.
-Cover the parts boxes made of plastics with aluminium foil.
-Put aconductive mat on the work table.
-Ground the soldering iron.
-Donot touch the pins of IC, LSI or VLSI with fingers directly.
4. Schematic Diagram
5. Printed Circuit Board
6. Wiring Connection Diagram
7. Measurements and Adjustments
7.1. Tuner Section
READ CAREFULLY BEFORE ATTEMPTING ALIGNMENT
1. Set volumecontrol to maximum.
2. Set band switch to MW, SW, AMand FM.
3. Set function selector to radio.
4. Set finetunning to centre.
5. Set power source voltageto 6VDC.
6. Outputofsignal generator should beno higher than necessaryto obtain an outputreading.
MW-RFALIGNMENT
5

READ CAREFULLY BEFORE ATTEMPTING ALIGNMENT
1. Set volume control to maximum.
2. Set band switch to MW, SW, AM and FM.
3. Set function selector to radio.
4. Set fine tunning to centre.
5. Set power source voltage to 6V DC.
6. Output of signal generator should be no higher than necessary to obtain an output reading.
MW-RF ALIGNMENT
Signal Generator or Sweep
Generator
Radio Dial
Setting
Indicator (Electronic
Voltmeter or
Oscilloscope)
Adjustment
(Shown in
Fig.1)
Remarks
Connections Frequency
Fashion a loop of
several turns of
wire and radiate a
signal into loop
ant. of receiver.
511 kHz (GU)
514 ± 3 kHz
(GC)
Tuning
capacitor fully
closed.
Output meter across
voice coil.
L8 (MW OSC
MIN)
Adjust for
maximum
output.
Fashion a loop of
several turns of
wire and radiate a
signal into loop
ant. of receiver.
1,650 kHz (GC)
1639 ± 5 kHz
(GU)
Tuning
capacitor fully
open.
Output meter across
voice coil.
CT2 (MW
OSC MAX)
Adjust for
maximum
output.
Fashion a loop of
several turns of
wire and radiate a
signal into loop
ant. of receiver.
550 kHz Tune to signal. Output meter across
voice coil.
[*1] L3 (MW
ANT Coil)
Adjust for
maximum
output.
Adjust L3
by
moving
coil
bobbin
along
ferrite core.
Fashion a loop of
several turns of
wire and radiate a
signal into loop
ant. of receiver.
1,500 kHz Tune to signal. Output meter across
voice coil.
CT1 (MW
ANT MAX)
Adjust for
maximum
output.
Repeat
steps
(2) ~ (5).
SW-RF ALIGNMENT
8

Signal Generator or Sweep Generator Radio Dial
Setting
Indicator (Electronic
Voltmeter or
Oscilloscope)
Adjustment
(Shown in
Fig.1)
Remarks
Connections Frequency
Fashion a loop of
several turns of wire
and radiate a signal
into loop ant. of
receiver.
4.7 MHz Tuning
capacitor
fully closed.
Output meter across
voice coil.
L9 (SW OSC
MIN)
Adjust for
maximum
output.
Fashion a loop of
several turns of wire
and radiate a signal
into loop ant. of
receiver.
18.5 MHz Tuning
capacitor
fully open.
Output meter across
voice coil.
CT5 (SW
OSC MAX)
Adjust for
maximum
output.
Fashion a loop of
several turns of wire
and radiate a signal
into loop ant. of
receiver.
4.8 MHz Tune to
signal.
Output meter across
voice coil.
L4 (SW ANT
MIN)
Adjust for
maximum
output.
Fashion a loop of
several turns of wire
and radiate a signal
into loop ant. of
receiver.
18.0 MHz Tune to
signal.
Output meter across
voice coil.
CT6 (SW ANT
MAX)
Adjust for
maximum
output.
Repeat
steps
(6) ~ (9)
AM-IF ALIGNMENT
Signal Generator or Sweep
Generator
Radio Dial Setting Indicator (Electronic
Voltmeter or
Oscilloscope)
Adjustment
(Shown in
Fig.1)
Remarks
Connections Frequency
Fashion a loop of
several turns of
wire and radiate a
signal into loop
ant. of receiver.
455 kHz 30
percent Mod.
at 400 Hz
Point of non-
interference. (on/
about 600 kHz)
Output meter across
voice coil.
T2 (AM IF) Adjust for
maximum
output.
[*1] Cement antenna bobbin with wax after completing alignment.
FM-IF ALIGNMENT
9

Signal Generator or Sweep
Generator
Radio Dial Setting Indicator (Electronic
Voltmeter or
Oscilloscope)
Adjustment
(Shown in
Fig.1)
Remarks
Connections Frequency
High side thru.
0.001Micro Farad to
test point TP3.
Negative side to test
point TP2.
10.7 MHz
(SWP)
Point of non-
interference. (on/
about 90 MHz)
Connect vert. amp. of
scope to test point
TP4. Negative side to
test point TP2.
T1 (FM-IF) [V] Adjust for
maximum
amplitude.
(Refer to
fig.
3).
High side thru.
0.001Micro Farad to
test point TP3.
Negative side to test
point TP2.
10.7 MHz
(SWP)
Point of non-
interference. (on/
about 90 MHz)
Connect vert. amp. of
scope to test point
TP5. Negative side to
test point TP4.
T3 (FM-IF) Adjust for
maximum
amplitude.
(Refer to
fig.
2).
FM-RF ALIGNMENT
Signal Generator or Sweep Generator Radio Dial
Setting
Indicator (Electronic
Voltmeter or
Oscilloscope)
Adjustment
(Shown in
Fig.1)
Remarks
Connections Frequency
Connect to test
point TP1 through
FM dummy antenna.
Negative side to test
point TP2.
86.2 MHz (GU)
87.35 MHz ± 50
kHz (GC)
Variable
capacitor
fully closed.
Output meter across
voice coil.
L2 (FM OSC
MIN)
[*2] Adjust
for
maximum
output.
Connect to test
point TP1 through
FM dummy antenna.
Negative side to test
point TP2.
109.2 MHz (GU)
108.28 MHz ± 70
kHz (GC)
Variable
capacitor
fully open.
Output meter across
voice coil.
CT4 (FM OSC
MAX)
CT9 must
be
prealign to
center
before
inserting
into
P.C.B..
Then [*2]
Adjust for
maximum
output.
Connect to test
point TP1 through
FM dummy antenna.
Negative side to test
point TP2.
106 MHz Tune to
signal.
Output meter across
voice coil.
CT3 (FM ANT
MAX)
[*2] Adjust
for
maximum
output.
Repeat
steps
(3) ~ (5)
[*2] Three output responses will be present; proper tuning is the center frequency.
ALIGNMENT POINT
* Please refer to Circuit Board and wiring Connection Diagram for test point locations.
10

DIALTHREADING
1. Remove chasisfrom cabinet (Refer to 2. Disassemblyand Main
Component Replacement Procedures and Operational Check)
2. Turn dial drum to fullycounter-clockwise. (Turn dial gear to fulley
clockwise.).
3. Route dial cord inordered character (1-6), turn 3times at Tuning
Shaft.
4. Cement dial cord ends.
DIALTHREADING
1. Turn dial drum to fullycounter-clockwise. (Turn dial drum to fully
clockwise.)
2. Set dial pointer to start point (0) of dial scale.
3. Attach dial cord to dial pointer.
8. Type Illustrations of ICs, Transistors & Diodes
9. Parts Location and Replacement Parts List
Notes:
-Important safetynotice:
Components identified bymark have special characteristics
important for safety.
Furthermore, special parts which have purposes of fire-retardent
(resistors), high-qualitysound (capacitors), low noise (resistors),
etc are used.
When replacing anyof these components, be sure to use only
manufacturer’sspecified parts showninthe parts list.
9

-The parenthesized indications inthe Remarks columns specifythe
areas or colour. (Refer to the cover page for area or colour)
Parts without these indications can be used for all areas.
-Capacitor values are inmicrofarads ( F) unless specified
otherwise, P= Pico-farads (pF), F= Farads.
-Resistance values are inohms, unless specified otherwise, 1K=
1,000 (OHM).
-The marking (RTL) indicates that the Retention Time islimited for
thisitems. After the discontinuation of thisassemblyin
production, the item will continue to be availablefor aspecific
period of time. The retention period of aavailabilityisdependent
on the type of assembly, and inaccordance with the laws
governing part and product retention. After the end of thisperiod,
the assemblywill no longer be available.
-[M] markings inthe Remarks columns indicates parts supplied by
PAVCSG.
-Reference for O/I book languages are as follows:
Ar: Arabic Du: Dutch It : Italian Sp:
Spanish
Cf : CanadianFrenchEn: English Ko: Korean Sw:
Swedish
Cz : Czech Fr: French Po: Polish Co:
Traditional
Chinese
Da : Danish Ge : German Ru: Russian Cn:
Simplified
Chinese
Pe : Persian
9.1. Cabinet
9.1.1. Cabinet PartsLocation
10

9.1.2. Cabinet PartsList
Ref. No. PartNo. PartName& Description Remarks
CABINETAND CHASSIS
1RFKGF562DGCK FRONTCABINETASS’Y [M]GC1
1 RFKGF562DGUK FRONTCABINETASS’Y [M]GU1
1-1 RAS8P26-G SPEAKER [M]
2RKF4N010ZA-2 BACK CABINET [M]
3RJT4N010ZA ANTTERMINAL [M]
4RJC91001 BATT SPRING [M]
5RKK4N010ZA BATT COVER [M]
6XEARK132GC ROD ANTENNA [M]
7RNW823-A WASHER [M]
8XTN23+7C SCREW [M]
9XTV3+8G SCREW [M]
10 XTV3+12G SCREW [M]
11 RBN4N011RA VOLUMEKNOB [M]
11

9.2. Component Part list
Ref. No. PartNo. PartName& Description Remarks
P.C.B
RUP4N044XB-2 Main P.C.B. (GC)/ BatteryP.C.B. (GC) [M]
RUP4N044XA-7 Main P.C.B. (GU)/ BatteryP.C.B. (GU) [M]
INTEGRATED CIRCUITS
IC1 TA7358P IC (FRONTEND) [M]
IC2 AN7236 IC [M]
TRANSISTORS
Q1 2SC829BTA TRANSISTOR [M]
Q101 KTC3199LGRAT TRANSISTOR [M]
Q102 KTC3199LGRAT TRANSISTOR [M]
Q103 KTC3203YAT TRANSISTOR [M]
Q104 KTC3203YAT TRANSISTOR [M]
DIODES
D101 MA27B1TA DIODE [M]
VARIABLERESISTORS
VR1 RRVN16G4A14P VARIABLERESISTOR [M]
SWITCHES
SW1 RSS3F09ZA-B BAND SWITCH [M]
TRIMMER
CT1 RCV4RC2V2K-M VARIABLECAPASITOR [M]
CT2 RCV4RC2V2K-M CARIABLECAPACITOR [M]
CT3 RCV4RC2V2K-M CARIABLECAPACITOR [M]
CT4 RCV4RC2V2K-M VARIABLECAPASITOR [M]
CT5 RCVTZ11F TRIMMER CAPACITOR [M]
CT6 RCV05AF2-S TRIMMER CAPACITOR [M]
COILS& TRANSFORMERS
L2 RLD4Y53W FMOSC COIL [M]GU1
L2 RL04P004 FMOSC COIL [M]GC1
L3 RLVN5E02-0Z FERRITEANTENNA [M]
L4 RLVN5E02-0Z FERRITEANTENNA [M]
L5 RLQY30S1W RF CHOKECOIL [M]
L7 RLQY75S5 CHOKECOIL [M]
L8 RL02B108 AMOSC COIL [M]
L9 RL03B46 SW OSC COIL [M]
12

Ref. No. PartNo. PartName& Description Remarks
T1 RLI4B153 FMIFT [M]
T2 RLI2B153 AMIFT [M]
T3 RLI4B153 FMIFT [M]
T4 RLT3F30-1V I.P.T [M]
T5 RLT2F41-1V O.P.T [M]
CERAMIC FILTERS
CF2 RVFSFZ455JL CERAMIC FILTER [M]
RESISTORS
R1 ERDS2TJ220T RESISTOR [M]
R3 ERDS2TJ470T RESISTOR [M]
R6 ERDS2TJ334T RESISTOR [M]
R7 ERDS2TJ331T RESISTOR [M]
R8 ERDS2TJ560T RESISTOR [M]
R12 ERDS2TJ101T RESISTOR [M]
R13 ERDS2TJ103T RESISTOR [M]
R14 ERDS2TJ222T RESISTOR [M]
R15 ERDS2TJ682T RESISTOR [M]
R16 ERDS2TJ470T RESISTOR [M]
R20 ERDS2TJ180T RESISTOR [M]
R21 ERDS2TJ121T RESISTOR [M]
R22 ERDS2TJ470T RESISTOR [M]
R23 ERDS2TJ101T RESISTOR [M]
R101 ERDS2TJ334T RESISTOR [M]
R102 ERDS2TJ330T RESISTOR [M]
R104 ERDS2TJ562T RESISTOR [M]
R105 ERDS2TJ101T RESISTOR [M]
R106 ERDS2TJ330T RESISTOR [M]
R107 ERDS2TJ681T RESISTOR [M]
R109 ERDS2TJ223T RESISTOR [M]
R110 ERX12SJR22E METAL RESISTOR [M]
CAPACITORS
C1 ECBT1H4R7KC5 4.750V [M]
C3 ECBT1H220JC5 22 50V [M]
C4 ECFR1C223MR 0.022 16V [M]
C5 ECBT1H4R7KC5 4.750V [M]
C6 ECBT1H102KB5 1000P50V [M]
C8 ECBT1H150JC5 15 50V [M]
C9 ECBT1C103NS5 0.01 16V [M]
C10 ECBT1H220JC5 22 50V [M]
C11 ECBT1H470J5 47 50V [M]
C14 ECBT1C103NS5 0.01 16V [M]
C15 ECBT1C103NS5 0.01 16V [M]
C17 ECFR1C333MR 0.033 16V [M]
C19 ECFR1C223MR 0.022 16V [M]
C20 ECFR1C223MR 0.022 16V [M]
C21 RCEA0JKA470A 47 6.3V [M]
C22 ECFR1C223MR 0.022 16V [M]
C23 RCEA0JM471BK 470 6.3V [M]
13

Ref. No. PartNo. PartName& Description Remarks
C24 ECBT0J223NS5 0.022 6.3V [M]
C26 ECBT1H151KB5 150 50V [M]
C27 ECBT0J223NS5 0.022 6.3V [M]
C28 ECBT0J223NS5 0.022 6.3V [M]
C29 RCEA1HKA0R1B 0.150V [M]
C30 ECBT0J223MS5 0.022 6.3V [M]
C31 ECBT1C103MS5 0.01 16V [M]
C32 ECBT1H470J5 47 50V [M]
C33 ECBT1H100JC5 100 50V [M]
C34 ECBT1H102KB5 1000P50V [M]
C35 ECBT1H102KB5 1000P50V [M]
C37 ECBT1H102KB5 1000P50V [M]
C38 ECBT1C103NS5 0.01 16V [M]
C39 RCEA0JKA101B 100 6.3V [M]
C40 ECBT1H102KB5 1000P50V [M]
C41 ECBT1H331KB5 330 50V [M]
C43 ECBT1H100JC5 10 50V [M]
C44 ECBT1H220JC5 22 50V [M]
C45 ECQP2A361JZT 360 100V [M]
C46 ECQP2A272JZT 2700P100V [M]
C48 ECBT1H102KB5 1000P50V [M]
C102 RCEA1HKA010B 1 50V [M]
C104 ECBT1H102KB5 1000P50V [M]
C105 RCEA0JM102BK 1000P6.3V [M]
C106 RCEA0JU102EK 1000P6.3V [M]
C107 ECBT1C103MS5 0.01 16V [M]
C108 ECBT1C103MS5 0.01 16V [M]
C109 ECFR1C333MR 0.033 16V [M]
C110 ECBT1H102KB5 1000P50V [M]
C111 ECBT1H151KB5 150P50V [M]
9.3. Packing Materials&Accessories Parts List
Ref. No. PartNo. PartName& Description Remarks
PACKING MATERIALS
P1 RPK1336-2 GIFTBOX [M]
P3 RFCN0005 CARRYING CASE [M]
P2 RPNN0051 POLYFOAM(L&R) [M]
9.4. Packaging
14

FLE0401/K/S/N/E/J
15

ABCDEFG
1
2
3
4
5
6
7
8
9
MAIN P.C.B. (RUP4N044XB-2...GC)
(RUP4N044XA-7...GU)
BATTERY P.C.B. (RUP4N044XB-2...GC)
(RUP4N044XA-7...GU)
J 1
ANT
L 5
J 33
C33
R1
IC1
C41
C111
R102
Q101
R22
C9
C11
L2
C8
R20
C37
C34 C32
C35
C5
R3
C6
Q102
R104
T1
C14
C15
R7
R6
Q1
R21
C110
J2
R105
C105
J6
J7
T4
EP
D101
J3
C102 J4
J35
CF2
C31
C24
R107
R106
C29
Q103
C107
J11
C109
R110
C108 J9
R109
Q104
J5
VR1
J37
J12
C30
C28
J37
C27
C21
T2
R15
C10 VC1
CT4
CF1
CT3CT1
CT2
C3
J30
J13
J14
J15
IC2
J16
C17
J17
C4
J34
C19
J18
C20
R16
C40
C22
C23
C26
T3
R14
R13
T5
J20
J21
C106
J22
out
J28
J29
R8
R12
VC2 J26
C44
C45
L8
L9
CT5
J36
R23C38
C39
SW1
J30
C1
J31
L7
CT6
C46
J36
J10
C48
C43
L3
J27
J25
J32
C104
R101
L4
J8
DIP
TP1
TP2
TP3
TP7
TP6
TP5
TP4
TP8
TP9
TP12
TP10
J23 J24
-+
3V (UM-1, R20/L20 BATTERIES)
TP11

C8
15P
C11 47P
IC1
RF AMP
FM
MW
SW
C
S1-1 3
16
4
T1
RLI4B153
FM
MW
SW
C
S1-2
BAND SW
C
S1-3
BAND SW
C
C
S1-5
BAND SW
4
12
3
CT1
L3
RLVN5E02-0Z
8
57
4
3
16
4
CT2 C44
22P
C45
360P
3
16
4
CT5 C49
2.2P
C46
2700P
FM
MW
SW
FM
MW
SW
R8
56
1 2 3 4 5 6 789
WHIP
ANTENNA
13
2
MAIN CIRCUIT
SCHEMATIC DIAGRAM -1
MIXER OSC
C43
10P
R1
22
L3
GC...RLO4P002-E
GU...RLE4Y53W
CF1
RVF107WDZT
IC1
TA7358P
FM FRONT END
CT4
C10
22P
C9
0.01
L3
R12
100
C32
47P
L5
RLQY30S1W
L6
PRINTED COIL
C33
100
C5
4.7P
3
L2
PRINTED
CT3
C3
22
C6
0.001
C35
0.001
R20
18
C37
0.001
R3
47 R22 47
C14
0.01
R6
330K
Q1
Q1
2SC829BTA
FM IF AMP
R21
120 R7
330
C15
0.01
C
S1-4
BAND SW
FM
MW
SW
C
S1-6
BAND SW
FM
MW
SW
C1
4.7P
L7
RLQY75S5
CT6
Q102
C105
6.3V1000
R105
100
R101
330K
R104
5.6K
Q101
R102
33
Q101 102
KTC3199LGRAT
AMP
C102
50V1
VR1
50K C104
0.001
C111
150P
C110
0.001
T4
RLT3F30-1V
R106
33
R107
680
D101
MA27B1TA
C106
6.3V1000
C107
0.01
R110
22
Q103
Q104
C108
0.01
C109 0.033
T5
RLT2F41-1V
R109
22K
C4
0.022 C48 0.001
1 2 3 4 65
18 17 16 15 14 13
C20
0.022
C21
6.3V 47
C24
0.022
3
1 6
4
T2
RLI2B153
13
2
6
45
CF2
RVFSFZ455JL
C17
0.033
C19
0.022
C22
0.022
C40
0.001
987
10
1112
C27
0.022
C28
0.022
R15
6.2K
C31
0.01
C23
6.3V470
C40
0.001
R13
10K
T3
RLI4B153
3
16
4
R14
2.2K
C30
0.022
C29
50V0.1
R16
47
IC2
AN7236
FM/AM IF, DET
AF AMP &
AM MIX, OSC
C38
0.01
C39
6.3V 100
R23
100
EARPHONE
( 3.5 Mini)
C41
330P
BATTERY UM-1X2
BATTERIES 3V
PM DYNAMIC
SPEAKER
10cm,16
: +B SIGNAL LINE
: FM SIGNAL LINE
: MAIN SIGNAL LINE
Q103 104
KTC3203YAT
AMP
BATTERY CIRCUIT
C34
0.001

out
VR1
CF1
SW1
L4
+ -
SPEAKER
8cm 800mW
(RMS max)
Pbf
+
-
BATTERY P.C.B.
MAIN P.C.B.
6V (UM-1, R20/L20 BATTERIES)

TA7358P
1
9
10
18
AN7236 2SC829BTA
KTC3203YAT KTC3199LGRAT
Anode
A
Ca
Cathode
MA27B1TA
BCE
E
C
B
