Panasonic CZ-RD514C Installation and operation manual

F567908
OFF/ON
ENGLISH 2 ~ 3
DEUTSCH 4 ~ 5
NEDERLANDS 6 ~ 7
ITALIANO 8 ~ 9
EΛΛΗΝΙΚΆ 10 ~ 11
FRANÇAIS 12 ~ 13
ESPAÑOL 14 ~ 15
ESPAÑOL (LE) 16 ~ 17
PORTUGUÊS 18 ~ 19
PORTUGUÊS (BR) 20 ~ 21
БЪЛГАРСКИ 22 ~ 23
РУCCKИЙ 24 ~ 25
УKPAΪHCbKA 26 ~ 27
SVENSKA 28 ~ 29
NORSK 30 ~ 31
SUOMI 32 ~ 33
DANSK 34 ~ 35
中文 36 ~ 37
B.MALAYSIA 38 ~ 39
B.INDONESIA 40 ~ 41
ภาษาไทย
ภาษาไทย 42 ~ 43
ﻲﺑﺮﻋ 44 ~ 45
TIẾNG VIỆT46 ~ 47
HRVATSKA 48 ~ 49
TÜRKÇE 50 ~ 51
ҚАЗАҚША 52 ~ 53
User Manuals
Wired Remote Control
CZ-RD514C

2
OFF/ON
TEMP
TIMER/CLOCK
MODE
CHECK RESET
OFF/ON
CANCELCLOCK
SET
SELECTUP
DOWN
AC RC
MODE
FAN SPEED
AIR
SWING
WIRED REMOTE CONTROL
Press the remote control’s button
1TO TURN ON OR OFF THE UNIT
• Please be aware of the OFF indication on the remote
control display to prevent the unit from starting/stopping
improperly.
2TO SET TEMPERATURE
• Selection range: 16˚C ~ 30˚C.
3TO SELECT OPERATION MODE
AUTO mode - For your convenience
• Unit selects operation mode during startup according to
temperature setting and room temperature.
HEAT mode - To enjoy warm air
• Unit takes a while to warm up. The power indicator blinks
during this operation.
COOL mode - To enjoy cool air
• Use curtains to screen off sunlight and outdoor heat to
reduce power consumption during cool mode.
DRY mode - To dehumidify the environment
• Unit operates at low fan speed to give a gentle cooling
operation.
4TO SELECT FAN SPEED (5 OPTIONS)
FAN SPEED
• ForAUTO, the indoor fan speed is automatically adjusted
according to the operation mode.
5TO ADJUST AIRFLOW DIRECTION
• Keeps the room ventilated.
• In COOL/DRYmode, ifAUTO is set, the louver swing
left/right and up/down automatically.
• In HEAT mode, ifAUTO is set, the horizontal louver fix at
predetermined position. The vertical louver swing left/right
after the temperature rises.
• For Hide-Away models,AIR SWING buttons are not in
use.Airflow direction can not be adjusted.
6Press and hold for approximately 10 seconds to
show temperature setting in °C or °F.
7Press and hold for 5 seconds to dim or restore the
unit’s indicator brightness.
8Press to restore the remote control’s default setting.
9Not used in normal operations.
10 Retrieve error code.
• During operation, the unit stops and both aand bis
OFF indicates abnormality occurs.
1.Ensure ais OFF, press
CHECK
for 5 seconds.
2.Press or . If error code and abnormality can be
identified, awill be ON continuously, then write down
the error code.
3.Press
CHECK
for 5 seconds to quit checking.
4.Turn the unit off and reveal the error code to authorized
dealer.
Remote Control Display
aOPERATION LED
bOFF INDICATOR
cOPERATION MODE SELECTION INDICATOR
dTIMER/CLOCK SETTING DISPLAY
Lights up if Timer operation is selected
6 different programs can
be set in a day (1 ~ 6)
Time to be selected
(10 minutes step)
ON Timer. To automatically switch “ON” the unit.
OFF Timer. To automatically switch
“OFF” the unit.
Day to be selected
Indicates the selected day
Indicates the next timer
operation day
eFAN SPEED DISPLAY
fTEMPERATURE SETTING DISPLAY
gERROR CODE DISPLAY
Remote Control Preparation
1. Press
CLOCK
2. Press
UP
or
DOWN
to select current day.
3. Press
SET
to confirm.
4. Repeat steps 2 and 3 to set the current time.
d
a
g
3
5
1
4
2
f
6 10
b
c7 9 8
e

3
OPERATION DETAILS
OPERATION DETAILS
The timer setting will shown at wired remote control
only but not at indoor unit’sTIMER indicator.
Check Current Timer Program
Perform the step below to check the timer program for
a particular day.
1. Press Timer
MODE
to enter timer mode.
2.Press
SELECT
to enter day setting.
3. Press Timer
UP
or
DOWN
until your desired day is
shown, press
SELECT
to confirm your selection.
4. Press Timer
UP
or
DOWN
to check the set programs.
Modify Current Timer Program or Add New Timer
Program
1. Press Timer
MODE
to enter timer mode.
2.Press
SELECT
to enter day setting.
3. Press Timer
UP
or
DOWN
until your desired day is
shown.
4.Perform steps 4 to 7 of “Day and Timer Set Up
Method” to modify existing timer program, or add any
timer program.
Cancel Current Timer Program
Perform the step below to cancel the timer program for
a particular day.
1.Press
SELECT
to enter day.
2. Press Timer
UP
or
DOWN
until your desired day is
shown.
3.Press
SELECT
to enter program setting.
4. Press Timer
UP
or
DOWN
until your desired program is
shown.
Press
CANCEL
to cancel the program, will
disappear.
Disable & Enable Weekly Timer
• To disable weekly timer setting, press
MODE
, then
press
CANCE
L
.
• To enable previous weekly timer setting, press
MODE
,
then press
SET
.
DAILY TIMER SETTING
DAILY TIMER SETTING
• To turn ON or OFF the unit at a preset time.
TIMER/CLOCK
MODE
OFF/ON
CANCELCLOCK
SET
SELECTUP
DOWN
1• Press once to change the
display from Clock to Timer
or vice-versa.
• Press for more than 4
seconds to change the
display from Daily Timer to
WeeklyTimer or vice-versa.
3Set the time
4Confirm
2Select ON or
OFF timer
• To cancel ON or OFF timer, press
CANCEL
.
• Timer operation is based on the clock set in the
remote control and repeats daily once set.
• The timer closest to the current time will be activated
first.
• If timer is cancelled manually or due to power failure,
you can restore the previous setting by pressing
SET
.
WEEKLY TIMER SETTING
WEEKLY TIMER SETTING
• Daily timer and weekly timer could not be set at the
same time.
• Promotes energy saving by allowing you to set up to
6 programs in any given day.
1. Press Timer
MODE
for 4 seconds to change display to
weekly timer.
2. Press Timer
UP
or
DOWN
to select your desired day.
3.Press
SELECT
to confirm your selection.
4.“1” will be blinking, press
SELECT
to set program 1.
5. Press Timer
OFF/ON
to select ON or OFF timer.
6. Press Timer
UP
or
DOWN
to select your desired time.
If you want to set the timer together with your desired
temperature, press
TEMP
to select the temperature.
7.Press
SET
to confirm program 1. The selected day will
be highlighted with .
• After 2 seconds, the display will move to the next
program. Repeat steps 4 to 7 to set programs 2 to 6.
• Same timer program cannot be set in the same day.
• During timer setup, if no button is pressed within 30
seconds, or if the
SET
button is pressed, the setting at
that moment is confirmed and timer setup is ended.
NOTE
NOTE
• When wired remote control is installed ECONAVI,
AUTO COMFORT, MILD DRYoperation setting
from wireless remote control might be disabled.
But POWERFUL, QUIET, PATROL, e-ion operation
setting could be operate according to wireless remote
control.
• When wired remote control is in operation, the timer
setting from wireless remote control will be cancelled.

Panasonic Corporation
Website: http://panasonic.net/
Printed in Malaysia F567908 SS0810-0
