Panasonic ST4 Instruction Manual
Table of Contents
v
Table of Contents
1. Introduction ............................................................................1
1.1 Target Group ............................................................................................. 2
1.2 Safety Instructions ..................................................................................... 3
1.3 Applicable Standards/Regulations............................................................. 6
2. Before Using this Device .......................................................7
2.1 Features..................................................................................................... 8
2.2 Part Description ......................................................................................... 9
2.2.1 Elements of the Controller ST4-C11 ........................................................10
2.2.2 Elements of the Multifunctional Controller ST4-C12EX ........................... 11
2.2.3 Elements of the Sensor ST4-A.................................................................14
2.3 Protection Area........................................................................................ 15
2.3.1 Sensing Range......................................................................................... 15
2.3.2 Safety Distance ........................................................................................ 16
2.3.2.1 Calculation Example for Europe .....................................................17
2.3.2.2 Calculation Example for the US ...................................................... 18
2.3.3 Influence of Reflective Surfaces............................................................... 20
2.3.4 Placement of Emitter and Receiver .........................................................21
2.3.5 Connecting Multiple Sensors Heads........................................................23
2.3.6 Address Allocations of the Sensor ST4-A..............................................25
2.4 Mounting and Removing.......................................................................... 29
2.4.1 Mounting and Removing the Controller ...................................................29
2.4.2 Mounting the Sensor ST4-A...................................................................30
2.4.3 Connecting Controller and Sensor ST4-A.............................................31
2.4.4 Series Connection of the Sensor ST4-A................................................32
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Table of Contents
Panasonic ST4 Instruction Manual
vi
2.5 Wiring .......................................................................................................36
2.5.1 Power Supply Unit....................................................................................36
2.5.2 I/O Circuit Diagrams .................................................................................37
2.5.2.1 Circuit of Controller ST4-C11 ..........................................................37
2.5.2.2 Circuit of Multifunctional Controller ST4-C12EX .............................38
2.5.2.3 Manual and automatic reset............................................................39
2.5.2.4 Emission Halt Input Terminals ........................................................40
2.5.3 Connecting to the Terminal Block ............................................................41
2.5.4 Terminal Arrangement Diagram...............................................................41
2.6 Adjustment and Operation........................................................................44
2.6.1 Beam-Axis Alignment...............................................................................44
2.6.2 Operation Test..........................................................................................46
2.6.3 Operation..................................................................................................47
3. Functions.............................................................................. 49
3.1 Self-Diagnosis Function ...........................................................................50
3.2 Reset Operation .......................................................................................51
3.2.1 Manual Reset ...........................................................................................51
3.2.2 Auto Reset................................................................................................52
3.3 Emission Halt Function.............................................................................53
3.4 Interference Prevention Function .............................................................54
3.4.1 Interference Prevention With One Controller ...........................................54
3.4.2 Interference Prevention Function When Using Two or More Controllers 54
3.5 Auxiliary Output........................................................................................56
3.5.1 Auxiliary Output Operation of Controller ST4-C11...................................56
3.5.2 Auxiliary Output Operation of Controller ST4-C12EX ..............................56
3.5.3 Emission Amount Adjustment Function ...................................................57
3.6 Muting Function (Only for ST4-C12EX)....................................................59
3.6.1 What Is a Muting Sensor..........................................................................60
3.6.2 Installation of the Muting Sensor..............................................................60
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Panasonic ST4 Instruction Manual
Table of Contents
vii
3.7 Override Function (Only ST4-C12EX) ..................................................... 63
3.8 Muting Pattern Selection Function (Only ST4-C12EX)............................ 67
3.8.1 Control Condition of Muting Pattern No. 1 ...............................................68
3.8.2 Control Condition of Muting Pattern No. 2 ...............................................69
3.8.3 Control Condition of Muting Pattern No. 3 ...............................................70
3.9 Sensor Diagnosis Function (Only ST4-C12EX)....................................... 71
3.10 Muting Lamp Diagnosis Function (Only ST4-C12EX) ............................. 74
4. Maintenance..........................................................................75
4.1 Daily Inspection ....................................................................................... 76
4.2 Periodic Inspection Checklist (Every Six Months) ................................... 77
4.3 Inspection After Maintenance .................................................................. 78
5. Troubleshooting ...................................................................79
5.1 Troubleshooting of Controller ST4-C11................................................... 80
5.2 Troubleshooting of Controller ST4-C12EX .............................................. 83
5.3 Troubleshooting of the Sensor ST4-A................................................... 86
6. Specifications .......................................................................87
6.1 Specifications, Controller ST4-C11.......................................................... 88
6.2 Specifications, Controller ST4-C12EX..................................................... 90
6.3 Specifications, Sensor ST4-A................................................................ 92
6.4 Options .................................................................................................... 93
6.4.1 Extension Cable .......................................................................................93
6.4.2 Branch Cable............................................................................................93
6.4.3 Foot Angled Mounting Bracket.................................................................93
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Table of Contents
Panasonic ST4 Instruction Manual
viii
6.4.4 Back Angled Mounting Bracket ................................................................94
6.4.5 Foot Biangled Protective Mounting Bracket.............................................94
6.4.6 Slit Masks .................................................................................................94
7. Dimensions........................................................................... 95
7.1 Controller ST4-C11 ..................................................................................96
7.2 Multifunctional Controller ST4-C12EX......................................................97
7.3 Single-beam Sensor ST4-A...................................................................98
7.4 Branch Cable ST4-CCJ05-WY.................................................................99
7.5 Foot Angled Mounting Bracket MS-CX-1 ...............................................100
7.6 Back Angled Mounting Bracket MS-ST4-3.............................................101
7.7 Foot Biangled Protective Mounting Bracket MS-ST4-6..........................102
8. Glossary of Terms.............................................................. 103
9. Index.................................................................................... 105
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Chapter 1
Introduction
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Introduction
Panasonic ST4 Instruction Manual
2
1.1 Target Group
Thank you for purchasing the PanasonicSafety Beam Sensor ST4 series (hereafter called 'this
device'). Please read this instruction manual carefully and thoroughly for the correct and
optimum use of this product. Kindly keep this manual in a convenient place for quick reference.
This device is a safety beam sensor for protecting a person from dangerous parts of a machine
which can cause injury or accident.
This manual has been written for the personnel who:
•have undergone suitable training and have knowledge of safety beam sensors as well
as safety systems and standards.
•are responsible for this device
•design systems using this device
•install and connect this device
•manage and operate a plant using this device
Machine designer, installer, employer and operator
The machine designer, installer, employer and operator are solely responsible for ensuring that
all applicable legal requirements relating to the installation and the use in any application are
satisfied and all instructions for installation and maintenance contained in the instruction manual
are followed.
Whether this device functions as intended and systems including this device comply with safety
regulations depend on the appropriateness of the application, installation, maintenance and
operation. The machine designer, installer, employer and operator are solely responsible for
these items.
Engineer
The engineer must be a person who is appropriately trained, has widespread knowledge and
experience, and can solve various problems which may arise in his field of work, e.g. as a
machine designer or a person in charge of installation or operation, etc.
Operator
The operator should read this instruction manual thoroughly, understand its contents, and
perform operations following the procedures described in this manual for the correct operation
of this device.
In case this device does not perform properly, the operator should report this to the person in
charge and stop machine operation immediately. The machine must not be used until correct
performance of this device has been confirmed.
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Panasonic ST4 Instruction Manual
1.2 Safety Instructions
3
1.2 Safety Instructions
DANGER!
!
Please adhere to the following safety instructions when
you install and operate this device. Failure to do so can
result in fatal or critical injury during unprotected use of
hazardous machinery.
•Use this device as per its specifications. Do not modify the safety beam
sensor since its functions and capabilities may not be maintained and it may
malfunction.
•The safety beam sensor has been developed/produced for industrial use
only.
•Do not use the safety beam sensor under conditions or in environments not
described in this manual. Please consult us if there is no other choice but to
use this device in such an environment.
•Do not use the safety beam sensor in fields such as nuclear power control,
railroad, aircraft, automobiles, combustion facilities, medical systems,
aerospace development, e.g. in applications where failure could result in
large-scale damage to society or people.
•When the safety beam sensor is to be used for enforcing protection of a
person from any danger occurring around an operating machine, the user
must satisfy the regulations established by national or regional security
committees.
•No matter what kind of equipment you use the device with, follow the safety
regulations in regard to appropriate usage, mounting (installation), operation
and maintenance.
•Use the safety beam sensor by installing suitable protective equipment as a
countermeasure for failure, damage, or malfunction of this device.
•Before using this sensor, check whether the device performs properly and
has the functions and capabilities as stated in the design specifications.
•Dispose of the safety beam sensor as industrial waste.
Environment
•Do not use a mobile phone or a radio phone near this device.
•If the sensor is installed in a place where there are reflective surfaces, make
sure to install this device so that reflected light from the reflective surfaces
does not affect the receiver. Alternatively, take countermeasures such as
painting, masking, roughening, or changing the material of the reflective
surfaces, etc. Failure to do so may cause the sensor not to detect properly,
which may result in death or serious injury.
•Do not install the safety beam sensor in the following environments:
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Introduction
Panasonic ST4 Instruction Manual
4
- Areas exposed to intense interference light such as direct sunlight
- Areas with high humidity where condensation is likely to occur
- Areas exposed to corrosive or explosive gases
- Areas exposed to vibration or shock at levels higher than those specified
- Areas exposed to contact with water
- Areas exposed to excessive steam or dust
- Areas where the beam-receiving part of this device is directly exposed to
light from a high-frequency fluorescent lamp (inverter type) or
rapid-starter fluorescent lamp.
Installation
•Always keep the correctly calculated safety distance between the safety
beam sensor and the dangerous parts of the machine.
•Install an extra protective structure around the machine so that the operator
must pass through the sensing area of the safety beam sensor to reach the
dangerous parts of the machine.
•Install the beam sensor in a manner that some part of the operator's body
always remains in the sensing area until the operator has finished working
with the dangerous parts of the machine.
•Do not install the beam sensor at a location where it can be affected by wall
reflection.
•When installing multiple sets of the safety beam sensor, connect the sets
and, if necessary, install some barriers so that mutual interference does not
occur.
•Do not use any reflection type or recursive reflection type arrangement.
Equipment in which this device is installed
•When the safety beam sensor is used in the PSDI mode, an appropriate
control circuit must be configured between this device and the machinery.
For details, be sure to refer to the standards or regulations applicable in each
region or country.
•In Japan, do not use the safety beam sensor as safety equipment for a press
machine.
•Do not install the safety beam sensor with a machine whose operation
cannot be stopped immediately in the middle of an operation cycle by an
emergency stop.
•This sensor provides safety 2 seconds after the power has been switched
ON. Make sure that the control system takes the time delay into
consideration.
Wiring
•Switch off the power before wiring the safety beam sensor.
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Panasonic ST4 Instruction Manual
1.2 Safety Instructions
5
•All electrical wiring should conform to the regional electrical regulations and
laws. The wiring should be done by skilled personnel with the required
electrical knowledge.
•Do not run the sensor cable together with high-voltage lines or power lines
or put them together in the same raceway.
•In case you need to extend the cable of the ST4-A□, you can use the
dedicated extension cable. The cable can be extended up to 50m (emitter and
receiver, respectively).
•Do not control the device at only one control output (OSSD 1, OSSD 2).
•To ensure that the output is not turned ON due to an earth fault of the control
output (OSSD 1, OSSD 2), ground the device on the 0V side (for PNP output)
or +24V side (for NPN output).
Maintenance
•When you need to replace parts, always use only genuine replacement parts
from the supplier. If you use substitute parts from another manufacturer, the
sensor may fail to detect properly, which may result in death or serious body
injury.
•The device must be inspected periodically by an engineer with the required
knowledge.
•When you have adjusted or maintained the device, test the device following
the procedure specified in the maintenance chapter before you switch the
system back on.
•Clean this device with a clean cloth. Do not use thinner-based cleaners.
Others
•Never modify this device. If you modify the device, the sensor may fail to
detect properly, which may result in death or serious injury.
•Do not use this device to detect objects flying over the sensing area.
•Do not use this device to detect transparent objects, translucent objects or
objects smaller than the specified minimum sensing size.
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Introduction
Panasonic ST4 Instruction Manual
6
1.3 Applicable Standards/Regulations
This device complies with the following standards and regulations.
•EU Machinery Directive 98/37/EC, EMC Directive 2004/108/EC
•EN 61496-1 (Type 4), EN 55011, EN 50178,
EN ISO 13849 (Category 4, PLe), EN 61508-1 to 7 (SIL3)
•IEC 61496-1/2 (Type 4), ISO 13849-1 (Category 4, PLe),
IEC 61508-1 to 7 (SIL3), IEC 62061 (SIL3)
•JIS B 9704-1/2 (Type 4), JIS B 9705-1 (ISO 13849-1) (Category 4), JIS C 0508-1 to 7
(SIL3)
•UL 61496-1/2 (Type 4), UL 1998, CSA C22.2 No.14, CSA C22.2 No.0.8
•OSHA 1910.212, OSHA 19 10.217(C), ANSI B11.1 to B11.19, ANSI/RIA 15.06,
ANSI/ISA S84.01 (SIL3)

NOTE
•Conformity to JIS, OSHA and ANSI for this device has been evaluated by us.
•: This device conforms to the EMC directive and the Machinery
directive. The CE-mark indicates that this product conforms to the EMC
directive.
•: This device is certified by TÜV Süd.
•: The C-CL US Listing Mark indicates compliance with both
Canadian and U.S. requirements.
•If you want to use this device in a location other than already described (see
page 3), confirm first that the intended use complies with the standards or
regulations applicable in your region or country.
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Chapter 2
Before Using this Device
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Before Using this Device
Panasonic ST4 Instruction Manual
8
2.1 Features
This device is a safety beam sensor with the following features.
•The controller ST4-C11 or the multifunctional controller ST4-C12EX is used in
combination with the single-beam sensor ST4-A.
•The type ST4-AV comes with an emission amount adjuster to reduce the emission
amount.
•Up to six units of the ST4-Acan be connected per controller. The controller has an
automatic interference prevention function.
•Wiring can be easily done by using the extension cable ST4-CCJ(optional) and the
branch cable ST4-CCJ05-WY (optional), since the cables are connector types.
•The control output (OSSD 1/2) is a PNP/NPN output switching type. The output type
can be switched with the output polarity selection switch on the controller.
•Replacing the relay is not necessary since a semiconductor output is used.
•The muting function complying with ISO 12643 (safety requirements for graphic
technology equipment and systems) is available on the ST4-C12EX. For details, refer to
the Muting Function (see page 59).
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Panasonic ST4 Instruction Manual
2.2 Part Description
9
2.2 Part Description
The ST4 system can be built up from the following parts. Which controller type you choose
depends on your requirements and applications.
Part name Part
Controller ST4-C11
Multifunctional Controller
ST4-C12EX
Emitter Receiver
Emitter ST4-A and
Receiver ST4-A
Back angled mounting
bracket (optional)
Foot angled mounting
bracket (optional)
Foot biangled protective
mounting bracket
(optional)
Extension cable ST4-CCJ
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Before Using this Device
Panasonic ST4 Instruction Manual
10
Part name Part
(optional)
Branch cable
ST4-CCJ-WY (optional)
Slit mask (optional)
2.2.1 Elements of the Controller ST4-C11
1
2
3
4567 8
9
Identifier Function
1Emitter connector Connects the emitter of the ST4-A.
2
Receiver connector Connects the receiver of the ST4-A.
3Output polarity selection switch Switches the control output to PNP output or NPN output.
4
Power indicator (Green) Lights up while power is ON.
5Control output indicator (Green) Lights up while the control output (OSSD 1/2) is ON.
6
Interlock indicator (Yellow) Lights up while the interlock is ON.
Turns OFF when an error occurs or the control output (OSSD
1/2) is ON.
7
Emission halt indicator (Orange) Lights up while the emission halt function is valid.
8Fault indicator Lights up or blinks when an error occurs.
For details, refer to "Troubleshooting (see page 79)".
9
Terminal block See the following table.
Terminal block
Terminal name Description
IL+
IL-
Interference prevention terminals (downstream)
For details, refer to "Interference Prevention Function see "Interference Prevention
Function" on page 54".
IU+
IU-
Interference prevention terminals (upstream)
For details, refer to Interference Prevention Function see "Interference Prevention
Function" on page 54.
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Panasonic ST4 Instruction Manual
2.2 Part Description
11
Terminal name Description
X1
X2
X3
Reset input terminals (When X1 and X2 are connected: manual reset, and when X1 and
X3 are connected: auto reset)
T1
T2
AUX
Emission halt input terminals
(Open: emission halt, Short-circuit: emission)
OSSD 1
OSSD 2
A1
Control output (OSSD 1/2)
A2 0V
2.2.2 Elements of the Multifunctional Controller ST4-C12EX
7
0
2
3
4
5
6
8
9
1
{
}
q
w
e
r
ty
u
Identifier Function
1
Emitter connector Connects the emitter of the ST4-A.
2Receiver connector Connects the receiver of the ST4-A.
3
Power indicator (Green) Lights up while power is ON.
4Fault display (Red) 7-segment lights up when an error occurs.
For details, refer to Troubleshooting (see page 79).
5
Interlock indicator (Yellow) Lights up while the interlock is ON.
Turns OFF when an error occurs or the control output (OSSD 1/2) is ON.
6
Emission halt indicator
(Orange) Lights up while the emission halt function is valid.
7
Control output indicator Lights up while the control output (OSSD 1/2) is ON.
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG

Before Using this Device
Panasonic ST4 Instruction Manual
12
Identifier Function
(Green)
8Auxiliary output 1 indicator
(Orange)
Turns OFF while the muting function is valid.
Lights up while the muting function is invalid.
9Auxiliary output 2 indicator
(Orange)
Turns OFF while the override function is valid.
Lights up while the override function is invalid.
10
Auxiliary output 3 indicator
(Orange)
Lights up when the muting lamp is in normal operation.
Turns OFF when the muting lamp is in error.
11
Muting input S-A indicator
(Orange)
Lights up when the sensor input connected to the muting input terminal
(S-A) is ON.
12
Muting input S-B indicator
(Orange)
Lights up when the sensor input connected to the muting input terminal
(S-B) is ON.
13 Muting input S-C indicator
(Orange)
Lights up when the sensor input connected to the muting input terminal
(S-C) is ON.
14 Muting input S-D indicator
(Orange)
Lights up when the sensor connected to the muting input terminal (S-D)
is input ON.
15
Muting input S-E indicator
(Orange)
Lights up when the sensor input connected to the muting input terminal
(S-E) is ON.
16 Muting input S-F indicator
(Orange)
Lights up when the sensor input connected to the muting input terminal
(S-F) is ON.
17 Output polarity selection
switch Switches the control output to PNP output or NPN output.
18 DIP switches
1ON 23456 87
See the table "DIP switches".
19 Terminal block See table "Terminal block".
DIP Switches
No. Description
1 to 4 Sets the ST4-Ainto the muting state.
Sets effective time for muting/override (see page 59).
5 Checks the states "beam received" and "beam interrupted" of the connected ST4-A, or a sensor
error (see "Sensor Diagnosis Function (Only ST4-C12EX)" on page 71).
6
7 Unused
8 Deactivates the muting lamp diagnosis function (see page 74).
Rugghölzli 2
CH - 5453 Busslingen
Tel. [phone]
Fax [phone]
[e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONIC AG
