Panasonic AV-HS410 User manual

AV-HS410
Live Switcher
(AV-HS410N, AV-HS410E)
A Rival to High-End Switchers in Performance and Ease of Operation
into a Compact, Integrated Body
picture simulated

High-End Performance and Functions in a Compact Body.
A User Interface Designed for Live Operation,
and Plug-in Compatibility for Easy Expansion.
●Nine Standard Inputs: Eight SDI and One DVI
Six Standard Outputs: Five SDI and One DVI
Optional: Additional Four inputs/Four outputs
maximum
●Built-in 178 mm (7 inches) multi-mode color
LCD monitor displays versatile menus, image
monitor, waveform/vectorscope, etc.
●Featuring High-quality Primatte® chroma
keying and Versatile transitions, including
DVE functions
●Enhanced MultiViewer Display with up to 16
splits enables nine screen variations, clock,
level meter and 4:3 marker display.
●Video Memory function allows playback of
two channels of still or moving images.
●Memory Preview function provides previews
of shot memory and event memory image
effects.
●Supports Plug-in API function for external
control, external camera control, output of
status data, etc.
●Control panel with additional direct button
control, numeric keypad, etc achieves
enhanced ease of operation.
* Primatte® is a registered trademark of IMAGICA DIGIX Inc. The copyrights of Primatte®
belong to IMAGICA DIGIX Inc. The patents for Primatte® belong to IMAGICA DIGIX Inc.
picture simulated

Input/Output Signal Standard
Option Board
AV-HS
04M1
AV-HS
04M2
AV-HS
04M3
AV-HS
04M4
AV-HS
04M5
AV-HS
04M6
AV-HS
04M7
AV-HS
04M8
Video Signal Video Format
SDI
x 8
DVI-D
x 1
SDI
x 5
DVI-D
x 1
SDI
x 2
COMP
x 2
DVI-I
x 2
COMP
x 2
DVI-I/
COMP
VIDEO
x 2
SDI
x 2
DVI-D
x 2
IN IN OUT OUT IN IN IN OUT OUT IN OUT IN
SDI
480/59.94i √ √ √ √
576/50i √ √ √ √
1080/59.94i √ √ √ √
1080/50i √ √ √ √
720/59.94p √ √ √ √
720/50p √ √ √ √
1080/24PsF √ √
1080/23.98PsF √ √
DVI Analog
XGA (1024 x 768) 60 Hz/50 Hz √ √
WXGA (1280 x 768) 60 Hz/50 Hz √ √
SXGA (1280 x 1024) 60 Hz/50 Hz √ √
DVI Digital
(PC)
XGA (1024 x 768) 60 Hz/50 Hz √ √ √ √ √
WXGA (1280 x 768) 60 Hz/50 Hz √ √ √ √ √
SXGA (1280 x 1024) 60 Hz/50 Hz √ √ √ √ √
UXGA (1600 x 1200) 60 Hz/50 Hz √√ √ √
WSXGA+ (1680 x 1050) 60 Hz/50 Hz √√ √ √
WUXGA (1920 x 1200) 60 Hz/50 Hz √√ √ √
DVI Digital
(VIDEO)
1080/59.94i √ √
1080/59.94p √ √ √
1080/50i √ √
1080/50p √ √ √
720/59.94p √ √
720/50p √ √
Analog
Composite
NTSC √
PAL √
Analog
Component
480/59.94i √ √ √
576/50i √ √ √
1080/59.94i √ √ √
1080/50i √ √ √
720/59.94p √ √ √
720/50p √ √ √
Nine Standard Inputs/
Six Standard Outputs
(Max. 13 Inputs/10 Outputs)
The AV-HS410 comes standard with Nine
inputs (Eight SDI (HD/SD) and One DVI-D)
and Six outputs (Five SDI (HD/SD) and
One DVI-D). Two expansion slots
accommodate either input or output
optional boards, providing a maximum of
13 inputs, and 10 outputs.
HD/SD Multi-Format Support
The AV-HS410 supports standard HD/SD
multi-format, including 1080/24PsF.
System frequency is 59.94 Hz/50 Hz/24
Hz switchable. This makes the system
ideal for digital cinema production and
worldwide operation. A wide range of
optional boards also allows the input and
output of analog component and various
other signals. (Please see the table at the
right for more details.)
AV-HS410*1
HD Component IN
HD Component IN
*Additional application is required for the
operation of the system.
Please contact your Panasonic representative
for more information.
RS-422A
TALLY/GPI
RS-422A
DVI-D Output LAN
DVI-D IN*2
HD SDI OUT
HD SDI OUT
HD SDI IN
HD SDI IN
VTR etc.
HDMI OUT
DVI-D
IN
HD Camera Recorder
HD Camera
Recorder
System Camera
HD Camera Recorder
DVD Player
AUX Panel
AUX Panel
Editing Controller
PC
HD SDI Monitor
PC Monitor, Projector, etc.
HD SDI Monitor
Remote Camera
Switching
Hub
HDMI/DVI-D
Conversion Cable
PC
*Additional application is required for the operation of the system.
Please contact your Panasonic representative for more information.
*1: The photo shows a system example with the optional AV-HS04M8 and AV-HS04M2 boards mounted.
*2: This connector does not support the HDCP technologies.

Various Switching Functions and High Image Quality
are Achieved with an Intuitive User Interface.
Built-in Frame Synchronizer
for All Input Channels
All input channels feature a built-in frame synchronizer for use in
switching unsynchronized video signals. A gen-lock function also
supports synchronizing systems based on external sync signals
(black burst or tri-level).
Up-Converter, Dot by Dot and Video Processing
The AV-HS410 is equipped with an SD/HD up-converter function for
four inputs, and a dot by dot function for eight inputs. Dot by dot
input can be used for P-in-P display of HD images from SD footage
without degradation. A video processing function with color correction
is also provided for eight inputs.
Four Aux Buses and Two P-in-P
Two P-in-P buses and four Aux buses are provided. Borders and
software effects can be applied to the P-in-P buses. In addition to a
Cut transition, the bus transition function (P-in-P bus and Aux bus
switching effect) also enables a Mix transition (Aux 1 only). Flexible
operation is achieved by combining Aux buses and M/E sections.
Versatile Transitions and Effects
In addition to standard wipe, mix and cut effects, DVE transition
patterns using two channels, such as reduce, slide, squeeze and 3D
wipe are included.
New Video Memory Function for Two Inputs
Two inputs for still (STILL) or moving (CLIP) images can be saved in
Video Memory, and selected as bus footage. Moving pictures can be
recorded and played with key signals (for a maximum of
approximately 20 seconds/600 frames with 59.94i). Moving picture
and still files can also be transferred over a LAN network from an
SDHC/SD Memory Card or PC.
* Uploading of moving picture and still images from an Ethernet LAN will be supported in the
future.
SDHC/SD Memory Card Slot
Video memory, shot memory, event memory and set-up data can be
saved to SDHC/SD Memory Cards.
Primatte® High-Quality Chroma Key
Linear, luminance and chroma keying are provided. Chroma keying
employs the Primatte® algorithm, which is widely used as a plug-in
for nonlinear editors. The same excellent Primatte® image quality that
is used worldwide for movies, TV programs, music videos and
commercials is achieved by the AV-HS410's real time processing.
Superior blue-spill processing naturally combines translucent objects,
such as thin cloth and glass, with background colors. Extremely fine
objects, such as individual strands of hair, are faithfully reproduced.
One DSK channel is also provided to add borders, shadows, and
other edge effects.
* Primatte® is a registered trademark of IMAGICA DIGIX Inc. The copyrights of Primatte®
belong to IMAGICA DIGIX Inc. The patents for Primatte® belong to IMAGICA DIGIX Inc.
Shot Memory
Up to 100 image effects, such as background transition patterns,
P-in-P sizes and border widths, can be registered in shot memory for
instant retrieval. The AV-HS410's Effect Dissolve function enables
smooth switching from a current image to one of the images or
operations registered in the shot memory.
Event Memory
Up to 64 of the image effects that are registered in the shot memory
can be sequentially registered in the event memory for instant
retrieval. This allows highly expressive consecutive effects to be easily
and smoothly executed. Up to 100 event memories can be registered.
picture simulated
Circle wipe Page turn
Primatte®
chroma key
(picture simulated)
Conventional
chroma key
(picture simulated)

New Memory Preview
This new function lets you preview the shot memory and event
memory content. It allows image effects to be easily confirmed while
on-air with this 1 M/E switcher. This is particularly convenient for
live operation.
* The resolution of images output from memory is slightly lower than the usual resolution.
Built-in 178 mm (7 inches) Color LCD Monitor
with Multi-Mode Display
A 178 mm (7 inches) color LCD monitor with WVGA (800 x 480)
resolution is built into the control panel. It can be switched to a wide
variety of display modes, including setting menus, image monitoring
and waveform/vectorscope. (See the table above.) It also supports
the MultiViewer and Memory Preview functions. AV-HS410 provides
comfortable operation eliminating the need to view multiple displays
in different locations.
Enhanced MultiViewer Display
The MultiViewer function lets you split the screen to display PVW,
PGM and all source images on a single screen. It enables
4/5/6/9/10/16 split screens. The input signal name, audio level meter
and 4:3 marker can also be overlaid onto each screen, and a clock
can be displayed. This makes it possible to efficiently operate a multi-
channel system with a single monitor.
Easy-to-Use Panel Layout
Features such as a total of 12 crosspoint buttons in each A bus and B
bus (for a maximum of 22 with the Shift function) allow direct control
with this simple panel layout. Function settings and registrations are
made quickly and intuitively with the LCD monitor's matrix
menu and rotary switches. Various functions can also be
assigned to eight user buttons for one-touch
operation. This level of easy operation supports
speed and accuracy in live-relay operation.
4 Split 5 Split "A" 5 Split "B"
9 Split6 Split "B"
10 Split "B" 16 Split
6 Split "A"
10 Split "A"
1 2
3 4
1 2
345 4 5
123
123
456
789
4
5 6
1 3 42
9 10
1 3 42
5 7 86
1 3 42
5 7 86
9 11 1210
13 15 1614
3 5 6
1
4
2
3 5 64
7 9 108
1 2
Shot Memory
Event Memory
Memory Preview Bus
Access
Program Bus
Program Image
Preview Image
Mode:
PGM
Output:
PGM
Mode:
MEM-PVW Output:
MEM-PVW
Assign of cross point
One line of menu display on a image monitorMenu display/Subscreen/Image display
Menu display in Matrix type
VECTOR displayWFM display

Expanded Functions with Plug-in Software and Optional Boards
Plug-in Software Created with a Software Development Kit*
Plug-ins allow flexible expansion of software-based functions. A Software Development Kit (SDK) is provided
so that third parties or SI enterprises can freely develop the software to add new functions to the AV-HS410.
This will enable the system to meet an even wider range of needs, such as controlling the AV-HS410 with an
external controller or PC, operating cameras and other devices from the AV-HS410, and outputting status
data related to the live switcher or image sources.
* Please ask your dealer for details.
*1: When external synchronization is selected as the reference signal setting, the reference signal is input. When internal synchronization is
selected, the reference signal is output.
*2: When external synchronization is selected as the reference signal setting, the signals are looped through output. When internal synchronization
is selected, the reference signal is output.
*3: Two sets of the same output signals are distributed from SDI OUTPUT 1.
*4: Use a crossover cable when connecting the unit and another device on a 1:1 basis without going through a switching hub.
*5: Use a switching hub.
Input Option Boards
(As of December, 2011)
Output Option Boards
(As of December, 2011)
AV-HS04M2
Analog Component Input Board
HD/SD Analog Component x 2 (Y/PB/PR)
(Built-in Up-converter)
AV-HS04M3
DVI Input Board
DVI-I x 2 (Built-in Scaler)
AV-HS04M4
Analog Output Board
HD/SD Analog Component x 2 (Y/PB/PR)
AV-HS04M5
DVI/Analog Output Board
DVI-I×1, HD/SD Analog Component x 1
(Y/PB/PR)
AV-HS04M6
Analog Composite Input Board
Analog Composite x 2 (Built-in Up-converter)
AV-HS04M7
SDI Output Board
SDI (HD/SD) x 2 (Each one has 2 outputs)
(BNC) (Built-in Down-converter)
AV-HS04M1
SDI Input Board
SDI (HD/SD) x 2 (BNC)
(Built-in Up-converter)
AV-HS04M8
Full HD DVI Input Board
DVI-D x 2 (compatible with WUXGA)
SDI Input
1 to 8
Memory card
Input
A1, A2
Input
B1, B2
Output
A1, A2
Output
B1, B2
Black
STILL1, 2
CLIP1, 2
Input
matrix
ColorBar
Color
BKGD1, 2
Output
matrix
SDI Output
1-1, 1-2 ( 3)
SDI Output
2 to 5
DVI-D Output
~ AC IN PowerAC/DC
SDI OUTPUT
1-1, 1-2
SDI OUTPUT
2 to 5
DVI-D OUT
Scaler
DVI-D Input
SDI IN
5 to 8
FS
UC
VPrc
DbyD
SDI IN
1 to 4
FS
VPrc
DbyD
DVI-D IN
Scaler
BKGD
CUT, MIX, WIPE, DVE
KEY
CUT, MIX, WIPE, DVE
AUX 1 to 4
WFM
MEM PVW
FTB
Multi View
DSK
CUT, MIX
PinP1, 2
CUT, MIX
Option slot A
Option slot B
REF IN/OUT ( 1)
REF OUT ( 2)
Reference signal
TALLY/GPI 1
Dsub 15
GPI-IN: 8
GPI-OUT: 19
ALARM OUT: 1
GND: 2
TALLY/GPI 2
Dsub 15
Editing controller
Aux panel
VTR, etc.
Switching
hub
COM
Dsub 9
EDITOR
Dsub 9
LAN
RJ45
Remote cameraAux panelComputer
( 4)
(5)
Block Diagram

Specifications (As of December, 2011)
Power Requirement: AC 100 V to 240 V, 50 Hz/60 Hz, 88 W
Operating Temperature : 0 °C to 40 °C (32 °F to 104 °F)
Operating Humidity: 10 % to 90 % (no condensation)
Dimensions: 440 mm x 158 mm x 361 mm
(W x H x D) (17-5/16 inches x 6-7/32 inches x 14-7/32 inches) excluding protrusions
Weight: Approx. 6.2 kg (13.669 lb)
excluding accessory parts when no options have been installed
Approx. 6.6 kg (14.550 lb)
excluding accessory parts when all the possible options have been installed
Video Inputs (13 signal lines maximum):
Standard SDI: 8 signal lines, BNC x 8 (SDI INPUT 1 to SDI INPUT 8)
(The up-converter function can be used for the SDI INPUT 5 to
SDI INPUT 8 connectors.)
Standard DVI-D: 1 signal line, DVI-D x 1
Optional: Up to 4 additional signal lines (IN A1, IN A2, IN B1, IN B2)
(
Up to two option boards can be installed in the two input/output slots.)
Video Outputs (10 signal lines, maximum):
Standard SDI: 5 signal lines, BNC x 6
(SDI OUTPUT 1 to SDI OUTPUT 5 x 1 line each, 2 distributed outputs for
SDI OUTPUT 1 only)
Standard DVI-D: 1 signal line, DVI-D x 1
Optional: Up to 4 additional lines (OUT A1, OUT A2, OUT B1, OUT B2)
  •PGM,PVW,AUX1toAUX4,MV(MULTI_VIEW),CLN,KEYOUTand
MEM PVW can be assigned to SDI OUTPUT 1 to SDI OUTPUT 5,
DVI-D OUT, OUT A1, OUT A2, OUT B1 and OUT B2.
  •CLNcanbepre-selectedfromKEYorDSKusingamenu.(Upto
two option boards can be installed in the two input/output slots.)
Signal Formats: SD: 480/59.94i, 576/50i
HD: 1080/59.94i, 1080/50i, 720/59.94p, 720/50p, 1080/24PsF*,
1080/23.98PsF*
*The following option boards are not supported: AV-HS04M1, AV-HS04M2,
AV-HS04M3, AV-HS04M4, AV-HS04M5, AV-HS04M6, AV-HS04M7
Signal Processing: Y: PB: PR4: 2: 2, 10 bit (8 bit for video memory), RGB 4:4:4, 8 bit
ME Number: 1 ME
SDI Inputs: HD-SDI: HD Serial digital (SMPTE 292M)
SD-SDI: SD Serial digital (SMPTE 259M)
8 signal lines, standard: IN1 to IN8
12 signal lines, maximum: IN A1, IN A2, IN B1, IN B2
(When two AV-HS04M1 boards are used; with active through)
HD: SMPTE 292M (BTA S-004B) standard complied with
  •0.8V[p-p]±10%(75Ω)
  •AutomaticequalizerMorethan100m(328ft)
(when 1.5 Gbps/5C-FB cable is used)
SD: SMPTE 259M standard complied with
  •0.8V[p-p]±10%(75Ω)
  •Automaticequalizer200m(656ft)(when5C-2Vcableisused)
SDI Outputs: HD-SDI: HD Serial digital (SMPTE 292M)
SD-SDI: SD Serial digital (SMPTE 259M)
5 signal lines, standard: OUT1 x 2; OUT2 to OUT5 x 1 each
9 signal lines, maximum: OUT A1, OUT A2, OUT B1, OUT B2
(When two AV-HS04M7 boards are used)
HD: SMPTE 292M (BTA S-004B) standard complied with
  •Outputlevel 0.8V[p-p]±10%
  •Risetime HD:Lessthan270ps
  •Falltime HD:Lessthan270ps
  •Differencebetweenrisetimeandfalltime
HD: Less than 100 ps
  •Alignmentjitter HD:Lessthan0.2UI(130ps)
  •Timingjitter HD:Lessthan1.0UI
  •Eyeapertureratio Morethan90%
  •DCoffset 0±0.5V
SD: SMPTE 259M standard complied with
  •Outputlevel 0.8V[p-p]±10%
  •Risetime Lessthan1.5ns
  •Falltime Lessthan1.5ns
  •Differencebetweenrisetimeandfalltime
Less than 0.5 ns
  •Jitter Lessthan0.2UI
CompositeInput: Analogcompositesignal(NTSC/PAL)(1.0V[p-p],75Ω)
(Option board) 4 signal lines, maximum: IN A1, IN A2, IN B1, IN B2
(When two AV-HS04M6 boards are used; with loop-through)
Analog Input: SD/HD analog component Y/PB/PR(1.0V[p-p],75Ω)
(Option board) 4 signal lines, maximum: IN A1, IN A2, IN B1, IN B2
(When two AV-HS04M2 boards are used)
Analog Output: SD/HD analog component Y/PB/PR(1.0V[p-p],75Ω)
(Option board) 4 signal lines, maximum: OUT A1, OUT A2, OUT B1, OUT B2
(When two AV-HS04M4 boards are used)
  •
2 signal lines (OUT A1, OUT B1) when two AV-HS04M5 boards are used.
DVI-I Input: Analog/digital RGB:
(Option board) XGA (1024 x 768), WXGA (1280 x 768), SXGA (1280 x 1024)
Vertical frequency: 60 Hz
  •ThisconnectordoesnotsupporttheHDCPtechnologies.
4 signal lines, maximum: IN A1, IN A2, IN B1, IN B2
(When two AV-HS04M3 boards are used)
DVI-I Output: Analog/digital RGB:
(Option board) XGA (1024 x 768), WXGA (1280 x 768), SXGA (1280 x 1024),
WSXGA+* (1680 x 1050), UXGA* (1600 x 1200), WUXGA* (1920 x 1200)
* Selectable only when digital signals are output.
Vertical frequency: 60 Hz
  •ThisconnectordoesnotsupporttheHDCPtechnologies.
2 signal lines, maximum: OUT A2, OUT B2
(When two AV-HS04M5 boards are used)
DVI-D Input: Digital RGB:
(Option board) XGA (1024 x 768), WXGA (1280 x 768), SXGA (1280 x 1024),
WSXGA+ (1680 x 1050), UXGA (1600 x 1200), WUXGA (1920 x 1200)
Vertical frequency: 60 Hz
Digital RGB: 1080/50p, 1080/59.94p
  •Analoginputsignalsarenotsupported.
  •ThisconnectordoesnotsupporttheHDCPtechnologies.
4 signal lines, maximum: IN A1, IN A2, IN B1, IN B2
(When two AV-HS04M8 boards are used)
  •TheDVI-Iconnectorcablecannotbeused.
  •FortheDVI-Dconnectorcable,useacablewithalengthofupto
5 m (16.4 ft).
DVI-D Input/Output: Digital RGB:
XGA (1024 x 768), WXGA (1280 x 768), SXGA (1280 x 1024),
WSXGA+ (1680 x 1050), UXGA (1600 x 1200), WUXGA (1920 x 1200)
Vertical frequency: 60 Hz
Video format inputs:
Digital RGB: 1080/50p, 1080/59.94p
Vertical frequency: Same as system formats
Video format outputs:
Digital RGB: 1080/50p, 1080/59.94p, 1080/50i, 1080/59.94i,
720/50p, 720/59.94p
  •Theinputandoutputofanalogsignalsarenotsupported.
  •Outputsupportthehigh-resolutionmultiviewmode:
Signals are output with a high resolution even when SD is set as the
system mode. (When high-resolution multi view mode has been
enabled, MV is selected as the DVI-D OUT output, and it is not
possible to select MV with SDI OUT.)
  •ThisconnectordoesnotsupporttheHDCPtechnologies.
Standard input/output: 1 line each (DVI-D IN, DVI-D OUT)
  •TheDVI-Iconnectorcablecannotbeused.
  •FortheDVI-Dconnectorcable,useacablewithalengthofupto
5 m (16.4 ft).
Reference In GENLOCK mode: Black burst or Tri-level Sync input signals
Input/Output: (with loop-through)
In internal sync mode: Black burst output signals x 2
  •Samefieldfrequenciesasthoseofthesystemformatssupported.
  •Withthe1080/24PsFformat,onlyGENLOCKmodesupported.
  •Withthe1080/23.98PsFformat,blackburstwith10F-ID
(SMPTE318M standard met) or TRI signals supported.
Video Delay Time: 1 line (H), When the frame synchronizer setting is “Off” and the
up-converter setting is “Off”.
1 frame (F), When the frame synchronizer setting is “On” or the
up-converter setting is “On”.
  •WhenthesignalshavepassedthroughPinP,DVE,multiview,
down-converter, DVI-IN or DVI-OUT, a maximum delay of 1 frame is
applied in each case.
ControlI/O(LAN): RJ-45
LAN 10BASE-T/100BASE-TX (For IP control)
Connecting cable: LAN cable (category 5 or above), max. 100 m
  [328ft],STP(ShieldedTwistedPair)cablerecommended
  •Whenconnectingtoahub(switchinghub),useastraightcable.
Use a crossover cable when connecting the unit and computer on a
1:1 basis without going through a hub.
  •Usewiththesamesegmentisrecommendedfortheequipment
which is connected to the unit. If the unit is connected to
equipment whose segments are different, events dependent upon
the settings inherent to the network equipment, for instance, may
occur so thoroughly check the connections with the equipment to
which the unit will be connected prior to the start of operation.
Control I/O (EDITOR): D-sub, 9-pin, female
EDITOR Used to control an editor
RS-422 control connector
Communication format
Baud rate: 38400 bps, Character length: 8 bit, Parity: Odd
Stop bit: 1 bit, Flow control: None
Control I/O (COM): D-sub, 9-pin, female
COM Used to control an external device RS-422 control connector
Communication format (selected using a menu)
 • Mode:1(defaultsetting),Baudrate:9600bps,Characterlength:8bit
Parity: None, Stop bit: 1 bit, Flow control: None
 • Mode:2,Baudrate:38400bps,Characterlength:8bit,Parity:Odd
Stop bit: 1 bit, Flow control: None
 • Mode:3,Baudrate:38400bps,Characterlength:8bit,Parity:None
Stop bit: 1 bit, Flow control: None
Control I/O: D-sub, 15-pin, female ( x 2)
(TALLY/GPI 1 Input: 8 inputs, general-purpose, photocoupler sensing
TALLY/GPI 2) Output: 19 outputs; selected from R/G tally, general-purpose
Alarm: 1 output, open collector output (negative logic)
Other: BOOTswitch[SV/NM(service/normal)](formaintenancepurposes)
Normally, this switch is used as the “NM” position.

25K201205ZP-1 Printed in Japan
SP-HS410PE2
Panasonic Corporation
Business Solutions Business Group
2-15 Matsuba-cho, Kadoma, Osaka 571-8503
Japan
http://pro-av.panasonic.net/
Argentina [phone]
Australia [phone]
Bahrain [phone]
Belgium [phone]
Brazil [phone]
Canada [phone]
China [phone]
Hong Kong [phone]
Czech Republic [phone]/511
Denmark [phone]
Egypt [phone]
Finland, Latvia, Lithuania, Estonia
[phone]
France [phone]
Germany, Austria, Switzerland
[phone]
Greece [phone]
Hungary [phone]
India [phone]
Indonesia [phone]
Iran
(Vida) [phone]
(Panasonic Office) [phone]
Italy [phone]
Jordan [phone]
Kazakhstan [phone]
Korea [phone]
Kuwait [phone]
Lebanon [phone]
Malaysia [phone]
Mexico [phone]
Netherlands [phone]
New Zealand [phone]
Norway [phone]
Pakistan [phone] (SNT)
Palestine [phone]
Panama [phone]
Peru [phone]
Philippines [phone]
Poland [phone]
Portugal [phone]
Puerto Rico [phone]
Romania [phone]
Russia & CIS [phone]
Saudi Arabia [phone]
Singapore [phone]
Slovak Republic [phone]
Slovenia, Albania, Bulgaria, Serbia,
Croatia, Bosnia, Macedonia, Montenegro
[phone]
South Africa [phone]
Spain [phone]
Sweden [phone]
Syria [phone]/4
Taiwan [phone]
Thailand [phone]
Turkey [phone]
U.A.E. (for All Middle East)
[phone]
Ukraine [phone]
U.K. [phone]
U.S.A. [phone]
Vietnam [phone]
[Countries and Regions]
Factories of Business Solutions Business Group have
received ISO14001:2004-the Environmental Management
System certification. (Except for 3rd party’s peripherals.)
4
INS
POWER
ALARM
LINK
LiveSwitcherAV-HS410
U1 U2 U3 U4 U5 U6 U7 U8
USERBUTTON
MENU
MODE PICT DSK TIME
PLUGIN
BKGD
CBGD
KEY
CHRKEY
PinP1
PinP2
MENU
HOLD
XPT
MV
IN
OUT
CONFIG
SYS
MENU
OFF
WFM
VECT
VMEM
SDCard
SHOT
EVENT
DISPLAY MENUSELECT
POSITIO NER
X/Y
Z
MENU
INPUT
VMEM
BKGD
PATT
KEY
PATT
TAKE
ENTER

/+
PAGE
PLAY
REC
STOP
XPT
DSBL
＜
CLIP1
STILL1
MEMORY/WIPEPATTERN/10KEY
＜＜ TRIMOFF ＞＞
CLIP2
STILL2
REV
TRIMOUT
TRIMIN
9
PASTE
6
MOD
3
REV
C
UNDO
8
COPY
5
DEL
2
＞
.
＞＞
7
NEW
1
＜
0/10
＜＜
STORE
RE
CALL
EDIT
DEL
SHOT
MEM
EVENT
MEM
PLUGIN
MEM1
PLUGIN
MEM2
＞
F1 F2 F3 F4 F5
AMBER:FILL/GREEN:SOURCE
KEY PinP1 PinP2 DSK AUX1 AUX2 AUX3 AUX4 DISP MV
AUXBUSDELEGATION
PGM
A
PST
B
AUX
1/13 2/14 3/15 4/16 5/17 6/18 7/19 8/20 9/21 10/22 11/23 12/24
AUX/DISPSOURCE
SHIFT
SHIFT
SHIFT
PGMPVW
CUT AUTO
MIX
MIX WIPE
N/R R
BKGD KEY KEY
ON
FTB
ON
PinP1
ON
PinP2
ON
DSK
ON
WIPEDIRECTION
WIPE
MIX
WIPE
ON
OFF
POWER
〜ACIN
GND
SIGNAL
LAN
SLOTA
IN/OUTA1IN/OUTA2IN/OUTB1IN/OUTB2
SLOTB
DVI-DINDVI-DOUT
SVNM
4 3
SDIOUTPUTS
1
25 8 7 6 5 4 3 2 1
SDIINPUTS
EDITOR COM TALLY/GPI2 TALLY/GPI1 REFBOOT
440 mm (17-5/16 inches)
158 mm (6-7/32 inches)
31 mm (1-7/32 inches)
361 mm (14-7/32 inches)
120 mm (4-23/32 inches)
Dimensions
http://pro-av.panasonic.net/
Please refer to the latest information, etc. at the following Panasonic web site.
