Panasonic KX-PRXA10 User manual

PanasoniC
Installation Manual
Additional Digital Cordless Handset
Model No. KX-PRXA10
m
lcrorM
s~
Thank you for purchasing a Panasonic product.
This unit is an additional handset compatible with the following series of
Panasonic Digital Cordless Phone:
-KX-PRX120 (KX-PRXA10)
{The corresponding models are subject to change without notice.)
You must register this handset with your base unit before it
·can be used. This
document describes only the steps needed to register and begin using the
handset. Please read the base unit's documentation for further details.
Please read this document before using the unit and save it for future reference.
For assistance, visit our Web site:
http://www.panasonic.com/help
for customers in the U.S.A. or Puerto Rico.
~rinted in China PNQX6195ZA CC1213YK1014 (E)

Installation
Supplied accessories
Accessory
item/Order
number
Charger/PNLC1049ZW
AC adaptor/PNLV226-KZ
Rechargeable battery/KX-PRA1
OEX
Handset cover*1/M81101016740
*1
The handset cover comes attached to the handset.
Note:
Quantity
1
1
1
1
• Please read the base unit's documentation for additional/replacement
accessories.
Preparing the
charger
• KX-PRXA10
G)
Insert the AC adaptor plug to the unit until you
hear a click.
® Connect the AC adaptor to the power outlet.
Note:
• Use only the supplied Panasonic AC adaptor PNLV226K.
• The AC adaptor must remain connected at all times. (It is normal for the adaptor
to feel warm during use.)
Preparing the handset
Inserting microSD card and the battery
A microSD card (not supplied) allows you to expand the handset's storage
capabilities.
Important:
• Use only the supplied battery. For replacement, use only the Panasonic
rechargeable battery noted on page 2.
2 Forassistance, please
visit
http://www.panasonic.com/help

Installation
• When removing the battery, make sure you turn offthe handset first.
• To avoid loss
of data or malfunction, do not damage, carelessly handle, or
short-circuit the gold-colored contacts of the microSD card.
1 Remove the handset's cover.
2 Open the microSD card cover by
sliding it toward the nearest side
of the handset ((D) and then lifting
up(@).
3 Insert the microSD card with the
gold-colored contacts facing
down, close the microSD cover
((D), and then gently slide the
cover toward the opposite side
of
the handset(@).
4 Insert the battery (CD) and lower it
into the handset(@).
5 Attach the cover.
Note:
• Ifthe battery is fully charged, but the operating time seems to be shorter, clean
the charge contacts
of the handset and charger with a dry cloth and charge
again.
For assistance, please visit http://www.panasonic.com/help 3

Installation
Charging the handset
Charge the handset for about 5 hours before initial use. The charge indicator
(G))
lights while the handset is charging and turns offwhen the handset is fully charged.
Important:
• Ifthe handset is placed into the charger while talking on the phone, the call is
not disconnected.
Place the handset into the charger.
Turning on the handset
or
Connect a USB cable (not
supplied) directly to the handset.
To tum the handset on, press and hold the power button on the top
of
the handset.
Setup wizard
The first time you tum on the handset, the setup wizard prompts you to configure
initial settings such as the display language. Follow the on-screen instructions to
configure the handset.
Registration dialog
While using the setup wizard, a dialog may be displayed prompting you to press
the [•l))] on the base unit for 5 seconds. Follow the on-screen instructions to
register the handset to the base unit. When registration is complete, continue to
follow the setup wizard.
_Registering the handset
to
the base
unit
Ifthe handset is not registered, the registration dialog (page
4)
is displayed. Follow
the on-screen instructions to register the handset to the base unit.
If
you cancel this dialog, you can display it again by tapping [Landline] in the home
screen
or
app list, and then tapping [Landline
settings]~
[Initial settings].
4 Forassistance, please
visit
http://www.panasonic.com/help

Installation
For your safety
To prevent severe injury and loss of life/property, read this section carefully before
using the product to ensure proper and safe operation
of your product.
WARNING
Powerconnection
• Completely insert the AC adaptor/power plug into the power outlet. Failure to do
so may cause electric shock and/or excessive heat resulting in a fire.
• Regularly remove any dust, etc. from the AC adaptor/power plug by pulling it
from the power outlet, then wiping with a dry cloth. Accumulated dust may cause.
an insulation defect from moisture, etc. resulting in a fire.
• Unplug the product from power outlets
if it emits smoke, an abnormal smell, or
makes an unusual noise. These conditions can cause fire or electric shock.
Confirm that smoke has stopped emitting and contact us atwww.panasonic.com/
contactinfo
Installation
• This product is not water-resistant. To prevent the risk of fire or electrical shock,
do not expose the product to rain
or any type of moisture.
• Do not place
or use this product near automatically controlled devices such as
automatic doors and fire alarms. Radio waves emitted from this product may
cause such devices to malfunction resulting in an accident.
• Keep all accessories, including the microSD card, out
of the reach of children to
prevent swaflowing.
Operating safeguards
• To prevent possible hearing damage, do not listen at high volume levels for long
periods.
CAUTION
Installation and location
• The AC adaptor is used as the main disconnect device. Ensure that the AC
outlet is installed nearthe product and is easily accessible.
Forassistance, please visit http://www.panasonic.com/help 5

Installation
Battery
• Use only the specified battery
or
additional/replacement battery noted on page 2
for replacement battery information.
• Do not open
or
mutilate the battery. Released electrolyte from the battery is
corrosive and may cause burns
or
injury to the eyes
or
skin. The electrolyte is
toxic and may be harmful ifswallowed.
• Exercise care when handling the battery. Do not allow conductive materials
such as rings, bracelets,
or
keys to touch the battery, otherwise a short circuit
may cause the battery and/orthe conductive material to overheat and cause
burns.
• Charge the battery in accordance with the instructions and limitations specified
in this manual.
• Only use a compatible charger to charge the battery. Do not tamper with the
charger. Failure to follow these instructions may cause the battery to swell
or
explode.
• Do not subject the battery to mechanical shock.
• Keep the battery out
of
the reach
of
children.
• Keep the battery clean and dry.
• Wipe the battery terminals with a clean dry cloth ifthey become dirty.
• Do not continuously charge the battery for a prolonged period
of
time.
• Remove the battery from the product ifthe product will not be used for a
prolonged period
of
time.
Attention:
The lithium ion/polymer battery you
h~ve
purchased is recyclable.
Please call 1-800-8-BATTERY
(1-800-822-8837) for information on how
to recycle this battery.
Important safety instructions
When using your product, basic safety precautions should always be followed to
reduce the risk
of
fire, electric shock, and injury to persons, including the following:
1.
Do not use this product nearwater for example, near a bathtub, washbowl,
kitchen sink,
or
laundry tub, in a wet basement
or
near a swimming pool.
2.
Do not use the telephone to report a gas leak in the vicinity
of
the leak.
3.
Use only the power cord and batteries indicated in this manual. Do not dispose
of
batteries in a fire. They may explode. Check with local codes for possible
special disposal instructions.
SAVE THESE INSTRUCTIONS
6 For assistance, please visit http://www.panasonic.com/help

Installation
Other information
• Operating the product nearelectrical appliances may cause interference. Move
away from the electrical appliances.
CAUTION: Risk
of
explosion ifbattery is replaced by an incorrect type. Dispose
of
used batteries according to the instructions.
Routine care
• Wipe the
outer
surface
of
the
product
with a
soft
moist
cloth.
• Do not use benzine, thinner,
or
any abrasive powder.
Notice
for
downloading software
or
upgrading the operating system
• Product functions and operating procedures may change and certain
applications may not function any longer ifthe product's operating system is
upgraded.
• Confirm the safety and security
of
software before downloading
or
installing it on
this product. Installing malware
or
viruses can cause malfunction and the
disclosure
of
any private information stored in this product,
or
may cause
excessive sound volume.
Notice
for
product
disposal, transfer,
or
return
• This product can store your private/confidential information. To protect your
privacy/confidentiality, we recommend that you erase information such as
phonebook
or
caller list entries from the memory before you dispose of, transfer,
or
return the product.
Trademarks
• The Android robot is reproduced
or
modified from work created and shared by ·
Google and used according to terms described in the Creative Commons 3.0
Attribution License.
• microSDHC Logo is a trademark
of
SD-3C, LLC.
• All other trademarks identified herein are the property
of
their respective owners.
FCC and other information
This equipment is hearing aid compatible as defined by the FCC in 47 CFR Section
68.316.
When you hold the phone to your ear, noise might be heard in your Hearing Aid.
Some Hearing Aids are not adequately shielded from external RF (radio frequency)
energy.
If
noise occurs, use an optional headset accessory
or
the speakerphone
Forassistance, please
visit
http://www.panasonic.com/help 7

Installation
option (ifapplicable) when using this phone. Consult with your audiologist
or
Hearing Aid manufacturer about the availability
of
Hearing Aids which provide
adequate shielding to RF energy commonly emitted by digital devices.
WHEN PROGRAMMING EMERGENCY NUMBERS AND(OR) MAKING TEST
CALLS TO EMERGENCY NUMBERS:
1) Remain on the line and briefly explain to the dispatcherthe reason for the call.
2) Perform such activities in the off-peak hours, such as early morning
or
late
evenings.
This device complies with Part 15
of
the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Privacy
of
communications may not be ensured when using this phone.
CAUTION:
Any changes
or
modifications not expressly·approved by the party responsible for
compliance could void the user's authority to operate this device.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15
of
the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in
a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and,
if
not installed and used in accordance with the instructions, may
cause harmfu,l interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. Ifthis
equipment does cause harmful interference to radio
or
television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one
or
more
of
the following measures:
-Reorient
or
relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer
or
an experienced radiofTV technician for help.
FCC RF Exposure Warning:
• This product complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
• This handset may not be collocated
or
operated in conjunction with any other
antenna
or
transmitter.
• For body-worn operation, the handset must be used only with a non-metallic
accessory. Use
of
other accessories may not ensure compliance with FCC RF
exposure requirements.
8 For assistance, please visit http://www.panasonic.com/help

Installation
Notice:
• FCC
10
can be found inside the battery compartment
or
on the bottom
of
the
unit.
Notice:
•This
product is designed for use in the United States
of
America. Sale
or
use
of
this product in other countries may violate local laws.
•Cet
appareil est conyu pour etre utilise aux Etats-Unis d'Amerique. La vente
ou l'emploi de cet appareil dans certains autres pays peut constituer une
infraction
a
Ia legislation locale.
• Este producto esta disenado para usarse en los Estados Unidos de America.
La venta o el empleo de este producto en ciertos paises puede constituir
violaci6n de
Ia
legislaci6n local.
•*~~-a-~§ffl~~ofi~X~~-~~d§ffl'~~-~&~~$~o
•
~(])it~
f~,
B
*lil*
~(J)~m
~§tt-l
c L
"'C~!t
~
n
"'C
13
"J,
B
*lilr1'J~(J)
ilmf~5!tfil&c
~
")
*9
o
~-:)
"'C,
~*±~f~
B*~r1'Jf::(SL
'"'Cfa:JmJliJ
cL
-c•Jm~
~(J)-+f-
t:::
.Af~it
LfJ';b*9
o
End-user license
This is an agreement between you and Panasonic System Networks Co., Ltd.
("Panasonic") with respect to the. software installed
in
this product. Carefully read
the terms
of
this agreement prior to using this product and using indicates your
acceptance
of
these terms.
Copyright:
The software is protected by copyright laws and international treaty provisions, and
all other applicable laws. You are receiving only a limited license to use the
software and related documentation, and that you shall obtain no title, ownership
nor any other rights
in
orto the software and its related documentation, all
of
which
title and rights shall remain with Panasonic or its licensor.
License:
You may:
CD
use the software solely for the purpose
of
recording images from this
product compatible with the software, ® transfer your rights under this agreement
on a permanent basis, provided that you transfer this agreement, all copies
of
the
software, all related documentation and this product, and the recipient agrees to
the terms
of
this agreement.
Restrictions:
You may not:
CD
reverse engineer, decompile or disassemble the software, except
as expressly permitted by applicable
law,®
use, copy, modify, alter, rent, lease or
transfer the software, its related documentation, or any copies thereof,
in
whole
or
For assistance, please visit http://www.panasonic.com/help 9

Installation
in part, except as expressly provided in this agreement, @ export the software in
contravention
of
any applicable U.S.
or
foreign export laws and regulations.
Open source software notice
Parts
of
this product use open source software supplied based on the relevant
conditions
of
the Free Software Foundation's GPL and/or LGPL and other
conditions. Please read all license information and copyright notices related to the
open source software used by this product. This information is available at the
following web page:
www.
panasonic.netlpcc/support/tel/sdect
At
least three (3) years from delivery
of
this product, Panasonic System Networks
Co., Ltd. will give to any third party who contacts us at the contact information
provided below, for a charge
of
no more than the cost
of
physically distributing
source code, a complete machine-readable copy
of
the corresponding source code
and the copyright notices covered underthe
GPL
and the LGPL. Please note that
software licensed underthe GPL and the LGPL is not underwarranty.
www.
panasonic.netlpcc/support/tel/sdect
Disclaimer
Panasonic shall not be liable for loss
of
data
or
other incidental
or
consequential
damages resulting from the use
of
this product. The use
of
downloaded content
may be restricted
or
prohibited bythe rights
of
third parties, including but not limited
to restriction under applicable copyright laws. You are entirely responsible for.
additional content that you download to
or
forward from this product; Panasonic is
not responsible for such content
or
its use. Panasonic does not warrant
or
guarantee the accuracy, integrity
or
quality
of
any additional content
or
any other
third-party content. Under no circumstances will Panasonic be liable in any way for
the improper use
of
additional content
or
otherthird-party content by this product
or
.
its operator. This document and any related documentation may refer to services
and applications that are provided bythird parties. The use
of
such services
or
programs may require separate registration with the third-party provider and may
be subject to additional terms
of
use. Forapplications accessed on
or
through a
third-party web site, please review the web site's terms
of
use and applicable
privacy policy in advance.
10 For assistance, please visit http://www.panasonic.com/help

Appendix
Customer
services
Customer
Services
Directory
(United
States
and
Puerto
Rico
Obtain Product Information and Operating Assistance; locate
your
nearest
Dealer
or
Service Center; purchase Parts and Accessories;
or
make Customer
Service and Literature·requests by visiting
our
Web Site at:
http://www.panasonic.com/help
or, contact us via the web at: _
http://www.panasonic.com/contactinfo
For
hearing
or
speech
impaired
TTY
users,
TTY: 1-877-833-8855
Accessory
Purchases
(United
States
and
Puerto
Rico
Purchase Parts, Accessories and Owner's Manual online
for
all Panasonic
Products
by
visiting
our
Web Site at:
http://www.pstc.panasonic.com
or, send
your
request by E-mail to:
[email protected]
You may also contact us directly at: 1-800-237-9080 (Fax Only)
(Monday- Friday 9
am
to
9 pm,
EST.)
Panasonic National Parts Center
20421
84th AvenueS., Kent, WA 98032
(We
accept Visa, MasterCard, Discover Card, American Express.)
For
hearing
or
speech
impaired
TTY
users,
TTY: 1-866-605-1277
For
assistance, please
visit
http://www.panasonic.com/help
11

Appendix
Warranty
(For United States
and
Puerto
Rico)
Panasonic Telephone
Products
Limited
Warranty
Limited Warranty Coverage
Ifyour product does not work properly because
of
a defect
in
materials
or
workmanship,
Panasonic Corporation
of
North America (referred to as "the warrantor") will, for the length
of
the period indicated on the chart below, which starts with the date
of
original purchase
("Limited Warranty period"),
at
its option either (a) repair your product with new
or
refurbished
parts, or (b) replace it with a new
or
a refurbished equivalent value product,
or
(c) refund your
purchase price. The decision to repair, replace
or
refund will be made by the warrantor.
Parts
Labor
One (1)
Year
One (1)
Year
During the "Labor" Limited Warranty period there will be no charge for labor. During the
"Parts" Limited Warranty period, there will be no charge for parts. You must mail-in your
product prepaid during the Limited Warranty period. This Limited Warranty excludes both
parts and labor for batteries, antennas, and cosmetic parts (cabinet). This Limited Warranty
only applies to products purchased and serviced in the United States
or
Puerto Rico. This
Limited Warranty is extended only to the original purchaser and only covers products
purchased as new.
Mail-In
Service--Online
Online
Repair
Request
To submit a new repair request and for quick repair status visit our Web Site at
http://www.panasonic.com/repair
When shipping the unit carefully pack in a padded shipping carton, include all accessories,
and send it prepaid. Include a
Jetter
detailing the complaint, a return address and provide a
day
time phone number where you can be reached. P.O. Boxes are not acceptable. Keep
the tracking number for your records. A copy
of
valid registered receipt is required under
the 1 year parts and labor Limited Warranty.
For Limited Warranty service for headsets ifa headset is included with this product please
follow instructions above.
IF REPAIR IS NEEDED PURING THE LIMITED WARRANTY PERIOD THE PURCHASER
WILL
.BE REQUIRED TO FURNISH A
SALES
RECEIPT/PROOF OF PURCHASE
INDICATING DATE OF PURCHASE, AMOUNT PAID AND PLACE OF PURCHASE.
CUSTOMER
WILL
BE
CHARGED FOR THE REPAIR OF
ANY
UNIT RECEIVED WITHOUT
SUCH PROOF OF PURCHASE.
12
Forassistance, please
visit
http://www.panasonic.com/help

Appendix
Limited Warranty
Limits
And
Exclusions
This Limited Warranty ONLY COVERS failures due to defects in materials
or
workmanship,
and DOES NOT COVER normal wear and tear
or
cosmetic damage. The Limited Warranty
ALSO DOES NOT COVER damages which occurred in shipment,
or
failures which are
caused by products not supplied by the warrantor, or failures which result from accidents,
misuse, abuse, neglect, bug infestation, mishandling, misapplication, alteration, faulty
installation, set-up adjustments, misadjustment
of
consumer controls, improper maintenance,
power line surge, lightning damage, modification, introduction
of
sand, humidity or liquids,
commercial use such as hotel, office, restaurant,
or
other business
or
rental use
of
the
product, or service by anyone other than a Factory Service Center
or
otherAuthorized
Servicer,
or
damage that is attributable to acts
of
God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT
AS
LISTED UNDER "LIMITED
WARRANTY COVERAGE". THE WARRANTOR IS NOT
LIABLE
FOR
INCIDENTAL
OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT,
OR
ARISING
OUT
OF
ANY
BREACH OF THIS LIMITED WARRANTY. (As examples, this
excludes damages for lost time, lost calls
or
messages, cost
of
having someone remove
or
re-install an installed unit
if
applicable, travel to and from the servicer. The items listed are not
exclusive, but are for illustration only.)
ALL
EXPRESS
AND
IMPLIED WARRANTIES,
INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD
OF THE LIMITED WARRANTY.
Some states do not allow the exclusion or limitation
of
incidental
_or
consequential damages,
or limitations on how long an implied warranty lasts, so the exclusions may not apply to you.
This Limited Warranty gives you specific legal rights and you may also have other rights
which vary from state to state. Ifa problem with this product develops during
or
after the
Limited Warranty period, you may contact your dealer or Service Center. Ifthe problem is not
handled to your satisfaction, then write to the warrantor's ConsumerAffairs Department at the
addresses listed for the warrantor.
PARTS
AND
SERVICE, WHICH ARE NOT COVERED
BY
THIS LIMITED WARRANTY, ARE
YOUR RESPONSIBILITY.
When
you
ship
the
product
• Carefully pack your unit, preferably in the original carton.
• Attach a letter, detailing the symptom.
• Send the unit to Panasonic Exchange Center, prepaid and adequately insured.
• Do not send your unit to Panasonic Corporation
of
North America listed on the back
cover
or
to executive
or
regional sales offices. These locations do not repair consumer
products.
For
assistance, please
visit
http://www.panasonic.com/help 13

Appendix
IMPORTANT!
If
your
product
is
not
working
properly
...
<D
ReconnectAC
adaptor
to
the
base unit.
® Check
if
telephone line
cord
is
connected.
@ Reinsert
the
battery
and restart
the
handset.
@
Read
troubleshooting
page
in
the base unit's
Operating
Instructions.
Visit
our
Web
site:
http://www.panasonic.com/help
• FAQ
and
troubleshooting
hints
are available.
Panasoriic Corporation
of
North America
Two Riverfront Plaza, Newark, NJ 07102-5490
© Panasonic System Networks Co., Ltd. 2013
14 Forassistance, please
visit
http://www.panasonic.com/help
