Panasonic ET-PKR100P User manual

TQZJ495-2
Model No. ET-PKR100P
Installation Instructions
Ceiling Mount Bracket (for portrait)
Thank you for purchasing this Panasonic product.
■To customers
The “Installation Instructions” is intended for use by installation personnel. Be sure to employ certified personnel to perform
the installation.
After installation, have the installation personnel return these “Installation Instructions” to you, and save it for future use.
When moving or removing the projector, give this manual to the certified personnel and have them perform the procedure.
■To installation personnel
Read the “Installation Instructions” thoroughly and then perform the operation correctly and safely.
Be sure to read through the section entitled “Read this first!” (page 3) before proceeding with the installation.
After installation, return these “Installation Instructions” to the customer.

2 - ENGLISH
Contents
Read this rst! ................................................................................................... 3
Product description........................................................................................... 4
Standard installation dimensions.................................................................... 6
Installation.......................................................................................................... 9
Setting up the screen.......................................................................................................... 9
Screws tightening torques .................................................................................................. 9
Preparing the attachment plate .......................................................................................... 9
Installing the attachment plate to the ceiling......................................................................11
Installing the bracket to the projector................................................................................ 14
Suspending the projector.................................................................................................. 14
Attaching the projector drop prevention kit ....................................................................... 16
Installing the ceiling mount bracket drop prevention kit.................................................... 17
Adjusting the installation angle ..................................................................... 18
Specications .................................................................................................. 19

ENGLISH - 3
Read this rst!
WARNING:
Installation work should only be carried out by the certied personnel.
zIf this product is not installed correctly, serious accidents may result.
zFollow the instructions specied in “Installation” of this manual, and perform secure installation.
Do not install in a place which is not strong enough.
zIf the installation location is not strong enough, the ceiling bracket may fall down and an injury may result.
Make sure that your footing is safe and secure during installation.
zIf your footing is not secure, you may fall down or drop the bracket, and an injury may result.
Make sure that the ceiling bracket is installed correctly in accordance with the structure and materials
used at the installation location.
zIf a mistake is made in the installation procedure, the ceiling bracket may fall down and an injury may result.
Do not loosen or remove the ceiling mount bracket screws or bolts unnecessarily.
zThe projector may fall down and injury may result.
Do not set up the projector in humid or dusty places or in places where the projector may come into
contact with oily smoke or steam.
zUsing the projector under such conditions may result in re, electric shocks or plastic deterioration. The
plastic deterioration may cause the falling down of the projector which is mounted in the ceiling.
Do not allow children to reach the attached metal ttings and screws.
zThe attached metal ttings and screws can cause personal injury if swallowed.
zIf swallowed, seek medical advice immediately.
Mounting and installation must be carried out by two or more persons.
zIncluding the projector, this xture weighs approximately 25 kg (55.1 lbs.). Be sure that mounting and
installation are carried out by two or more persons.
Do not disassemble or modify the ceiling mount bracket.
zThe projector may be damaged or fall, causing injury.
CAUTION:
Install only the designated projector.
Install only using the designated method.
zOtherwise, the projector may fall and become damaged, and cause injury.
Do not install the ceiling bracket in a place which may impede projector ventilation.
zIf this is not observed, re may result.
Do not hang from or hang objects on the projector or ceiling mount bracket.
zThe projector may fall and cause injury.
When installing, always use the supplied components.
zOtherwise, this may cause damaged projector to fall and cause injury.
Install the mounting screws and power cable in such a way that they will not make contact with the
inside parts of the ceiling.
zElectric shocks may result from contact with any metal objects inside the ceiling.
■Panasonic disclaims all liability for any accidents or any damage caused by the installation of the
ceiling mount bracket using methods that are not described in these Installation Instructions or
methods that do not use the parts specied in these Instructions.
■ If products are no longer being used, they should be dismantled and removed by the certied
personnel as soon as possible.
Always follow these precautions

4 - ENGLISH
Product description
This is a ceiling mount bracket for installing projectors.
■Structural components
Parts name Form (number of parts) Applications
Attachment plate
× 1
The attachment plate is attached
to the ceiling via four ceiling
mount bolts.
Installation methods are different
for concrete and wooden ceilings.
It also allows horizontal swing
adjustment.
Projector mount
bracket
× 1
This is used to install the projector
itself.
It also includes a function for
adjusting the left/right tilt.
Adjustment pole
Adjustment pole 1
× 1
Adjustment pole 2
× 1
This is the adjustment pole
which is installed in between the
attachment plate and the projector
mount bracket.
It also includes a function for
adjusting the distance between
the ceiling and the projector itself.
Angle adjusting
bracket
× 1
This is attached to the projector
mount bracket.
It also allows vertical swing
adjustment.
Pole brace
× 1
This is attached to the attachment
plate to secure adjustment pole 1.
Pole base
× 1
This is attached to the adjustment
pole 2.
Screws and bolts
Hex nut (M6) × 4
Flat washer (M6) × 4
These are used to assemble the
bracket and mount it onto the
projector.
Hex head bolt, captive washer (M6×80) × 4
Screw, captive
washer (M4×10) × 4
Hex head bolt,
captive washer
(M6×16) × 24
Ceiling mount
bracket drop
prevention kit
Prevents the the ceiling mount
bracket from falling.
Flat washer (M8) × 1
Wire rope for ceiling
mount bracket
(2.0 mm (3/32") wire
diameter, 800 mm
(31-1/2") length) × 1

ENGLISH - 5
Parts name Form (number of parts) Applications
Projector drop
prevention kit
Prevents the projector from
falling.
Wire rope for the
projector
(2.0 mm (3/32")
wire diameter,
600 mm (23-5/8")
length) × 1
Screw, captive
washer (M4×10) × 1
■The user must also obtain the following parts. (commercially-available)
Installation work Required parts Page
Installing the
attachment plate to
the ceiling
(Bolt size: M10)
Installing to a
wooden structure
Ceiling mount bolt (× 4), Hex nut (× 16), Flat washer (× 16),
Spring washer (× 8) 12
Installing to a
concrete structure
Ceiling mount bolt (× 4), Hex nut (× 12), Flat washer (× 12),
Spring washer (× 8), Anchoring nut or curled plug (× 4) 13
Installing the ceiling
mount bracket drop
prevention kit
(Bolt size: M8)
Installing to a
wooden structure
Ceiling mount bolt (× 1), Hex nut (× 2), Flat washer (× 1),
Spring washer (× 1) 17
Installing to a
concrete structure
Anchoring nut or curled plug (× 1), Hex head bolt (× 1),
Spring washer (× 1) 17
zStore small parts in an appropriate manner, and keep them away from small children.
zTightening torque for the screws are, M4: 1.25±0.2 N•m, M6: 4±0.5 N•m, M8: 10±1 N•m, and M10: 20±1 N•m.
zWhen tightening up the screws, use a tool such as a torque screwdriver or torque wrench. Do not use electric
screwdrivers or impact screwdrivers.
Attention
zDispose of the packaging materials properly after taking the product out of it.
Product description (continued)

6 - ENGLISH
Standard installation dimensions
The dimensional relationship between the screen and the projector is shown below.
Establish the dimensions after assessing the area possible for installation.
If your projector has a zoom lens, you can use it to adjust the projected image size and the projection distance.
Check the projected image while making ne adjustments.
SH
SW
SD
<Units: mm (")>
L (LW/LT)
949 (37-3/8") -
1 429 (56-1/4")
211
(8-5/16")
Projected image
100 (3-15/16")
100 (3-15/16")
200
(7-7/8")
200
(7-7/8")
Ceiling
SW SH
Screen
H
W
(Note) This drawing is not in exact scale.
Attention
zInstall the projector with at least 500 mm (19-11/16") gap from the surrounding walls or objects in order to
ensure that the air intake/exhaust ports of the projector will not be blocked.
zAvoid setting up in places which are subject to sudden temperature changes, such as near an air conditioner or
lighting equipment.
Note
zDepending on the product, the appearance may differ from the illustrations in these installation instructions.

ENGLISH - 7
Standard installation dimensions (continued)
■Projected image size and projection distance
The dimensions in the table below contain a slight error.
zDistances for the PT-RZ475 series
Projected image size (9:16 aspect ratio) Projection distance (L) Center of lens-
Top edge of image: H
Center of lens-
Right edge of image: W
Screen diagonal (SD) Height (SH) Width (SW)
1.02 m (40") 0.89 m (2'11") 0.50 m (1'8") 0.67 m (2'2") approx. 0.41 m – 0.47 m
(approx. 1'4" – 1'7" )
approx. 0.20 m – 0.30 m
(approx. 0'8" – 0'12")
1.27 m (50") 1.11 m (3'8") 0.62 m (2') 0.85 m (2'9") approx. 0.52 m – 0.59 m
(approx. 1'8" – 1'11")
approx. 0.25 m – 0.37 m
(approx. 0'10" – 1'3" )
1.52 m (60") 1.33 m (4'4") 0.75 m (2'6") 1.03 m (3'5") approx. 0.62 m – 0.71 m
(approx. 2'0" – 2'4" )
approx. 0.30 m – 0.45 m
(approx. 0'12" – 1'6" )
1.78 m (70") 1.55 m (5'1") 0.87 m (2'10") 1.21 m (3'12") approx. 0.72 m – 0.83 m
(approx. 2'4" – 2'9" )
approx. 0.35 m – 0.52 m
(approx. 1'2" – 1'8" )
2.03 m (80") 1.77 m (5'10") 1.00 m (3'3") 1.39 m (4'7") approx. 0.83 m – 0.95 m
(approx. 2'9" – 3'1" )
approx. 0.40 m – 0.60 m
(approx. 1'4" – 1'12")
2.29 m (90") 1.99 m (6'6") 1.12 m (3'8") 1.57 m (5'2") approx. 0.93 m – 1.06 m
(approx. 3'1" – 3'6" )
approx. 0.45 m – 0.67 m
(approx. 1'6" – 2'2" )
2.54 m (100") 2.21 m (7'3") 1.25 m (4'1") 1.75 m (5'9") approx. 1.03 m – 1.18 m
(approx. 3'5" – 3'10")
approx. 0.50 m – 0.75 m
(approx. 1'8" – 2'6" )
3.05 m (120") 2.66 m (8'9") 1.49 m (4'11") 2.11 m (6'11") approx. 1.24 m – 1.42 m
(approx. 4'1" – 4'8" )
approx. 0.60 m – 0.90 m
(approx. 1'12" – 2'11")
3.81 m (150") 3.32 m (10'11") 1.87 m (6'2") 2.65 m (8'8") approx. 1.55 m – 1.77 m
(approx. 5'1" – 5'10")
approx. 0.75 m – 1.12 m
(approx. 2'6" – 3'8" )
5.08 m (200") 4.43 m (14'6") 2.49 m (8'2") 3.55 m (11'8") approx. 2.06 m – 2.36 m
(approx. 6'9" – 7'9" )
approx. 1.00 m – 1.49 m
(approx. 3'3" – 4'11")
zDistances for the PT-RZ470 series
Projected image size (9:16 aspect ratio) Projection distance (L) Center of lens-
Top edge of image: H
Center of lens-
Right edge of image: W
Screen diagonal (SD) Height (SH) Width (SW) Minimum (LW) Maximum (LT)
1.02 m (40") 0.89 m (2'11") 0.50 m (1'8") 1.26 m (4'2") 2.58 m (8'6") approx. 0.13 m – 0.69 m
(approx. 5" – 2'3")
approx. -0.12 m – 0.49 m
(approx. -5" – 1'7")
1.27 m (50") 1.11 m (3'8") 0.62 m (2') 1.59 m (5'3") 3.23 m (10'7") approx. 0.17 m – 0.85 m
(approx. 7" – 2'9")
approx. -0.14 m – 0.61 m
(approx. -6" – 2')
1.52 m (60") 1.32 m (4'4") 0.75 m (2'6") 1.91 m (6'3") 3.89 m (12'9") approx. 0.20 m – 1.02 m
(approx. 8" – 3'4")
approx. -0.17 m – 0.74 m
(approx. -7" – 2'5")
1.78 m (70") 1.55 m (5'1") 0.87 m (2'10") 2.24 m (7'4") 4.54 m (14'11") approx. 0.23 m – 1.19 m
(approx. 9" – 3'11")
approx. -0.20 m – 0.85 m
(approx. -8" – 2'9")
2.03 m (80") 1.77 m (5'10") 1.00 m (3'3") 2.57 m (8'5") 5.20 m (17'1") approx. 0.27 m – 1.36 m
(approx. 11" – 4'6")
approx. -0.23 m – 0.98 m
(approx. -9" – 3'3")
2.29 m (90") 2.00 m (6'7") 1.12 m (3'8") 2.90 m (9'6") 5.85 m (19'2") approx. 0.30 m – 1.54 m
(approx. 12" – 5'1")
approx. -0.26 m – 1.10 m
(approx. -10" – 3'7")
2.54 m (100") 2.21 m (7'3") 1.25 m (4'1") 3.23 m (10'7") 6.51 m (21'4") approx. 0.33 m – 1.70 m
(approx. 1'1" – 5'7")
approx. -0.29 m – 1.23 m
(approx. -11" – 4')
3.05 m (120") 2.66 m (8'9") 1.50 m (4'11") 3.89 m (12'9") 7.82 m (25'8") approx. 0.40 m – 2.05 m
(approx. 1'4" – 6'9")
approx. -0.35 m – 1.47 m
(approx. -1'2" – 4'10")
3.81 m (150") 3.32 m (10'11") 1.87 m (6'2") 4.88 m (16') 9.79 m (32'1") approx. 0.50 m – 2.56 m
(approx. 1'8" – 8'5")
approx. -0.43 m – 1.83 m
(approx. -1'5" – 6')
5.08 m (200") 4.43 m (14'6") 2.49 m (8'2") 6.52 m (21'5") 13.07 m (42'11") approx. 0.66 m – 3.41 m
(approx. 2'2" – 11'2")
approx. -0.57 m – 2.44 m
(approx. -1'10" – 8')
6.35 m (250") 5.53 m (18'2") 3.11 m (10'2") 8.17 m (26'10") 16.34 m (53'7") approx. 0.83 m – 4.26 m
(approx. 2'9" – 13'12")
approx. -0.72 m – 3.05 m
(approx. -2'4" – 10')
7.62 m (300") 6.64 m (21'9") 3.74 m (12'3") 9.81 m (32'2") 19.62 m (64'4") approx. 1.00 m – 5.11 m
(approx. 3'3" – 16'9")
approx. -0.86 m – 3.67 m
(approx. -2'10" – 12')

8 - ENGLISH
zDistances for the PT-RW430 series
Projected image size (10:16 aspect ratio) Projection distance (L) Center of lens-
Top edge of image: H
Center of lens-
Right edge of image: W
Screen diagonal (SD) Height (SH) Width (SW) Minimum (LW) Maximum (LT)
1.02 m (40") 0.86 m (2'10") 0.54 m (1'9") 1.29 m (4'3") 2.63 m (8'8") approx. 0.11 m – 0.67 m
(approx. 4" – 2'2")
approx. -0.10 m – 0.52 m
(approx. -4" – 1'8")
1.27 m (50") 1.08 m (3'7") 0.67 m (2'2") 1.62 m (5'4") 3.30 m (10'10") approx. 0.14 m – 0.84 m
(approx. 6" – 2'9")
approx. -0.13 m – 0.64 m
(approx. -5" – 2'1")
1.52 m (60") 1.29 m (4'3") 0.81 m (2'8") 1.96 m (6'5") 3.97 m (13') approx. 0.17 m – 1.01 m
(approx. 7" – 3'4")
approx. -0.15 m – 0.78 m
(approx. -6" – 2'7")
1.78 m (70") 1.51 m (4'11") 0.94 m (3'1") 2.29 m (7'6") 4.64 m (15'3") approx. 0.20 m – 1.18 m
(approx. 8" – 3'10")
approx. -0.18 m – 0.90 m
(approx. -7" – 2'11")
2.03 m (80") 1.72 m (5'8") 1.08 m (3'7") 2.63 m (8'8") 5.31 m (17'5") approx. 0.22 m – 1.34 m
(approx. 9" – 4'5")
approx. -0.21 m – 1.04 m
(approx. -8" – 3'5")
2.29 m (90") 1.94 m (6'4") 1.21 m (3'12") 2.97 m (9'9") 5.98 m (19'7") approx. 0.25 m – 1.51 m
(approx. 10" – 4'11")
approx. -0.23 m – 1.16 m
(approx. -9" – 3'10")
2.54 m (100") 2.15 m (7'1") 1.35 m (4'5") 3.30 m (10'10") 6.65 m (21'10") approx. 0.28 m – 1.68 m
(approx. 11" – 5'6")
approx. -0.26 m – 1.30 m
(approx. -10" – 4'3")
3.05 m (120") 2.59 m (8'6") 1.62 m (5'4") 3.98 m (13'1") 7.99 m (26'3") approx. 0.34 m – 2.02 m
(approx. 1'1" – 6'8")
approx. -0.31 m – 1.56 m
(approx. -1' – 5'1")
3.81 m (150") 3.23 m (10'7") 2.02 m (6'8") 4.98 m (16'4") 10.00 m (32'10") approx. 0.42 m – 2.52 m
(approx. 1'5" – 8'3")
approx. -0.38 m – 1.94 m
(approx. -1'3" – 6'4")
5.08 m (200") 4.31 m (14'2") 2.69 m (8'10") 6.66 m (21'10") 13.35 m (43'10") approx. 0.56 m – 3.36 m
(approx. 1'10" – 11')
approx. -0.51 m – 2.58 m
(approx. -1'8" – 8'6")
6.35 m (250") 5.38 m (17'8") 3.37 m (11'1") 8.35 m (27'5") 16.70 m (54'9") approx. 0.70 m – 4.20 m
(approx. 2'4" – 13'9")
approx. -0.64 m – 3.24 m
(approx. -2'1" – 10'8")
7.62 m (300") 6.46 m (21'2") 4.04 m (13'3") 10.03 m (32'11") 20.05 m (65'9") approx. 0.84 m – 5.04 m
(approx. 2'9" – 16'6")
approx. -0.77 m – 3.88 m
(approx. -2'6" – 12'9")
Setting-up dimensions which are not given in the above table can be calculated using the formulas below.
■Formula for projection distance
Dimensions such as projection distances can be calculated from the diagonal length of the projected image
SD (m). Units for calculations: m
Values obtained with the formulas below contain a slight error.
zDistances for the PT-RZ475 series
9:16 aspect ratio 10:16 aspect ratio 3:4 aspect ratio
Projected image size Height (SH) = SD × 0.872 = SD × 0.848 = SD × 0.8
Projected image size Width (SW) = SD × 0.490 = SD × 0.530 = SD × 0.6
Projection distance (L) = 0.7084 × SD - 0.0476 = 0.7659 × SD - 0.0476 = 0.8670 × SD - 0.0476
zDistances for the PT-RZ470 series
9:16 aspect ratio 10:16 aspect ratio 3:4 aspect ratio
Projected image size Height (SH) = SD × 0.872 = SD × 0.848 = SD × 0.8
Projected image size Width (SW) = SD × 0.490 = SD × 0.530 = SD × 0.6
Minimum projection distance (LW) = 1.2955 × SD - 0.0544 = 1.4004 × SD - 0.0544 = 1.5854 × SD - 0.0544
Maximum projection distance (LT) = 2.5812 × SD - 0.0408 = 2.7904 × SD - 0.0408 = 3.1589 × SD - 0.0408
zDistances for the PT-RW430 series
10:16 aspect ratio 9:16 aspect ratio 3:4 aspect ratio
Projected image size Height (SH) = SD × 0.848 = SD × 0.872 = SD × 0.8
Projected image size Width (SW) = SD × 0.530 = SD × 0.490 = SD × 0.6
Minimum projection distance (LW) = 1.3236 × SD - 0.0542 = 1.3604 × SD - 0.0542 = 1.4984 × SD - 0.0542
Maximum projection distance (LT) = 2.6369 × SD - 0.0407 = 2.7102 × SD - 0.0407 = 2.9851 × SD - 0.0407
Standard installation dimensions (continued)

ENGLISH - 9
After checking the height, width, and structure of the installation location while referring to “Standard installation
dimensions” on pages 6 to 8, determine the appropriate positions for setting up the screen and installing
the projector.
Setting up the screen
Set up the screen according to the specied method in a position which takes into account the projection distance
and angle and the type of screen being used.
Screws tightening torques
M4 ......... 1.25±0.2 N•m
M6 ......... 4±0.5 N•m
M8 ......... 10±1 N•m
M10 ....... 20±1 N•m
zUse a torque screwdriver or torque wrench to tighten screws and bolts to their specied tightening torques. Do
not use electric screwdrivers or impact screwdrivers.
Preparing the attachment plate
Before installing the attachment plate on the ceiling, attach the pole brace, adjustment poles, and the pole base
to the attachment plate with the following procedures.
■Attaching the pole brace and the adjustment pole 1 to the attachment plate
Circular hole
Pole brace
(M6 × 80)(M6 × 16)
M6 Flat washers
M6 Hex nuts
“FRONT”
inscription
Attachment plate
Adjustment pole 1
To the screen
(Front)
1) Insert the pole brace into the center of the attachment
plate, and secure the pole brace with the supplied
six captive washer hex head bolts (M6 × 16). (Refer
to the gure on the left for the directions of the
attachment plate and the pole brace.)
2) Insert the adjustment pole 1 into the pole brace,
aligning them so that the “FRONT” inscription faces
the front.
3) Insert the supplied two captive washer hex head
bolts (M6×80) through the side of the pole brace, and
secure them with M6 at washers and M6 hex head
nuts. Attach the supplied two captive washer hex
head bolts (M6 × 16) from the screen side of the pole
brace, and secure the pole brace and the adjustment
pole 1.
Attention
zBe sure to tighten the screws to a value within their
specied torque range. If the screws are tightened
with insufcient torque the projected image may tilt.
Installation

10 - ENGLISH
■Attaching the pole base to the adjustment pole 2
“FRONT”
inscription
(M6 × 16)
(M6 × 80)
Pole base
Adjustment pole 2
Arrow
1) Place a pole base over the adjustment pole 2 as
shown on the left and align the “FRONT” inscription
with the arrow.
2) Insert 2 supplied captive washer hex head bolts
(M6 × 80) from the side with the arrow on the pole
base, and x both using an M6 hex head bolt and an
M6 at washer. Also attach 2 supplied captive washer
hex head bolts (M6 × 16) to the pole base and rmly
x the adjustment pole 2.
■Attaching the angle adjusting bracket to the pole base
Arrow
Pole base
Angle adjusting bracket
Attach the angle adjusting bracket to the pole base,
aligning the arrow mark as illustrated on the left, and
secure them with the four supplied captive washer hex
head bolts (M6 × 16).
zFirst secure the circular holes on the arrow mark side.
Attention
zAfter adjusting the installation angle on pages 18 to
19, securely tighten the captive washer hex head
bolt of the angle adjusting bracket in four places at the
front and rear.
■Joining the adjustment poles 1 and 2
Adjustment pole 2
Adjustment pole 1
Arrow
“FRONT”
inscription
Insert the adjustment pole 1 into the adjustment pole 2,
align the holes, and secure them with the supplied six
captive washer hex head bolts (M6 × 16).
zAlign the “FRONT” inscription on the adjustment pole
1 with the arrow on the pole base.
zAfter inserting all 6 bolts into the holes, rmly tighten
each one.
Note
zAdjustable screw holes are provided on adjustment
pole 1 at 60 mm (2-3/8") intervals and adjustment pole
2 at 120 mm (4-3/4") intervals. Join the poles to each
other by tting the adjustable screw holes based on
the projection distance (949 - 1 429 mm (37-3/8" - 56-
1/4")) on page 6.
Installation (continued)

ENGLISH - 11
Installing the attachment plate to the ceiling
After checking the height, width, and structure of the installation location while referring to “Standard installation
dimensions” on pages 6 to 8, determine the appropriate positions for setting up the screen and installing
the projector.
■Attachment plate mounting hole sizes and preparation
Make mounting holes while referring to the attachment plate diagram.
To the screen
Center of
screen
Attachment plate diagram Bolt mounting hole size
<Units: mm (")>
Four holes drilled to fit ceiling
mount bolts (M10)
Install the attachment
plate with the circular
hole corner facing the
screen.
200 (7-7/8")
344 (13-17/32")
200 (7-7/8")
200 (7-7/8")
200 (7-7/8")
300 (11-13/16")
72 (2-27/32")
50
(1-31/32")
100 (3-15/16")
Attention
zIf attaching to a concrete ceiling, the sizes of the holes for the anchoring nuts or curled plugs should match the
sizes specied by the manufacturer.
zUse commercially available M10 ceiling mount bolts, hex nuts, at washers, spring washers, and anchoring
nuts or curled plugs.
Installation (continued)

12 - ENGLISH
■Installing the attachment plate
Depending on whether it is installed on a concrete or wooden ceiling structure, there are two different
installation methods. Carry out by the appropriate installation method which is suited to each ceiling.
Attention
zMake sure to use the ceiling mount bolts, hex nuts, at washers, spring
washers, anchoring nuts or curled plugs for M10.
zAll bolts and nuts should be securely tightened, and sufcient measures such
as using two nuts or a nut lock should be employed as necessary to prevent
loosening.
Two nuts
Installing to a wooden structure
Hex nut
Hex nut
Approx. 5 mm (3/16")
Ceiling mount
bolt
Flat washer
Flat washer
Attachment plate
Spring washer
Spring washer
Hex nut Hex nut
To the
screen
Ceiling beam
1) Drill four penetration holes in the ceiling beam for
the ceiling mount bolts.
zDrill the penetration holes with same size as
the ceiling mount bolt mounting holes. (Refer to
page 11 for hole locations and dimensions.)
2) Securely x the four ceiling mount bolts to the
ceiling beam.
zConrm that the location to retain the ceiling
mount bolts has enough strength to retain the
weight of the projector and the ceiling mount
bracket. If there is not enough strength, perform
sufcient reinforcement considering the safety
factor.
3) Temporarily secure the attachment plate to the
ceiling mount bolts
(It will be permanently secured after adjusting the
installation angle in horizontal directions on page
18.)
zThe threaded end of ceiling mount bolt at
the attachment plate side should protrude by
approx. 5 mm (3/16") from the hex nut. Be sure
to use commercially available at and spring
washers to install the attachment plate.
Note
zThe signal cable of the projector can also be run
inside the adjustment poles. In such a case, be
sure not to damage the cord or the cable. (The
inside diameter of the adjustment pole is 47 mm
(1-27/32").)
Installation (continued)

ENGLISH - 13
Installing to a concrete structure
Approx. 5 mm
(3/16")
Anchoring nut or curled
plug
Concrete ceiling
Ceiling mount
bolt
Flat washer
Flat washer
Attachment plate
Spring washer
Spring washer
Hex nut Hex nut
Hex nutHex nut
To the
screen
1) Attach the anchoring nuts or curled plugs to a
concrete ceiling and securely x the four ceiling
mount bolts. (Refer to page 11 for attachment
positions.)
zWhen installing anchoring nuts or curled plugs,
strictly adhere to the installation instructions
supplied by the manufacturer of the nuts so that
they will not loosen in the concrete structure or
be dislodged from the intended positions.
zCheck to make sure that the concrete ceiling
structure can easily bear the weight of the
projector and the ceiling mount bracket. If it is
found to be fragile or degraded, use steel or
wooden reinforcements.
2) Temporarily secure the attachment plate to the
ceiling mount bolts.
(It will be permanently secured after adjusting the
installation angle in horizontal directions on page
18.)
zThe threaded end of ceiling mount bolt at
the attachment plate side should protrude by
approx. 5 mm (3/16") from the hex nut. Be sure
to use commercially available at and spring
washers to install the attachment plate.
Note
zThe signal cable of the projector can also be run
inside the adjustment poles. In such a case, be
sure not to damage the cord or the cable. (The
inside diameter of the adjustment pole is 47 mm
(1-27/32").)
Installation (continued)

14 - ENGLISH
Installing the bracket to the projector
Attach the projector mount bracket to the projector (sold separately).
*PT-RZ470 is used as an example in the illustrations throughout this manual.
Projector mount bracket
Arrow
Secure in four places
1) Place the projector upside-down onto a piece of
soft material.
2) Secure the projector mount bracket to the bottom
of the projector using the four supplied captive
washer screws (M4 × 10) as illustrated on the left.
Suspending the projector
Angle adjusting bracket Thread
1) Screw the supplied two captive washer hex head
bolts (M6 × 16) half way into the screw holes at the
top of the angle adjusting bracket.
Attention
zCheck that the thread ridges of the temporarily
fastened captive washer hex head bolts are
correctly and rmly afxed to the thread of the
angle adjusting bracket.
Installation (continued)

ENGLISH - 15
Hook
2) Insert the temporarily fastened captive washer hex
head bolts on either side into the hook section of
the projector mount bracket.
Attention
zHold the projector rmly until the captive washer
hex head bolts are securely in place in the hook
part of the projector mount bracket.
WARNING:
Mounting and installation must be carried out
by two or more persons.
Secure with the supplied captive washer hex head bolts
3) As illustrated on the left, use two supplied hex
head bolts (M6 x 16) to secure the projector mount
bracket to the angle adjusting bracket.
Attention
zAfter adjusting the installation angle on pages 18
to 19, securely tighten the captive washer hex
head bolt of the angle adjusting bracket in four
places at the front and rear.
Installation (continued)

16 - ENGLISH
Attaching the projector drop prevention kit
Attach the drop prevention wire rope for the projector.
a
Put through a loop.
Wire rope for the projector
1) Turn the wire rope for the projector around the
adjustment pole.
zMinimize the slack of the wire rope.
2) Secure the bracket at the front end of the wire
rope for the projector to “a” on the projector
using a supplied captive washer screw (M4 ×
10).
Installation (continued)

ENGLISH - 17
Installing the ceiling mount bracket drop prevention kit
Attach the wire rope for the ceiling mount bracket to the ceiling mount bracket before performing installation work
to prevent falling.
Wire rope for the ceiling
mount bracket
Put through a loop.
<Attaching the wire rope for the ceiling mount
bracket>
As illustrated on the left, pass one end of the wire
rope for the ceiling mount bracket through the ring on
the other end and wind it around the adjustment pole.
Max. 1 m (3'3") Max. 1 m (3'3")
Anchoring nut or
curled plug*1
(M8)
<Installation procedure>
This procedure uses the example of attachment to a
concrete surface.
1) Mount the anchoring nut or curled plug (M8) in the
concrete ceiling (at a single point within the area
shown in the diagram on the left).
zIf it is to be attached to a wooden surface, make
holes in the ceiling beam and use commercially
available ceiling mount bolts as described in the
procedure for attaching the attachment plate on
page 12.
Attention
zWhen mounting the anchoring nut or curled plug
(M8) to the ceiling, be careful that there is no
slack of the wire rope for the ceiling mount bracket
between the projector and the ceiling.
zIf the wire rope for the ceiling mount bracket is
too long, increase the number of times it is wound
around the adjustment pole to adjust the length.
Wire rope for the ceiling
mount bracket*2
Flat washer*2
Spring washer*1
Hex head bolt*1 (M8)
*1: Commercially available product
*2: Supplied with this product
2) Tighten the commercially available hex head
bolt (M8) to the anchor, passing through the
commercially available spring washer (M8), the
supplied at washer (M8), and the ring of the end
of the wire rope for the ceiling mount bracket.
zIf it is to be attached to a wooden surface, pass
the loop at the end of the wire rope for the ceiling
mount bracket, a supplied at washer (M8), and
a commercially available spring washer (M8)
through the attached ceiling bolt and x with a
commercially available hex nut (M8).
Attention
zBe sure to use the wire rope for the ceiling mount bracket
and at washer that are supplied with this product.
zPurchase the commercially available anchoring nut
or curled plug, hex head bolt, and spring washer.
Note
zFor attaching the drop prevention kit to the
projector, refer to page 16.
Installation (continued)

18 - ENGLISH
The ceiling mount bracket has functions to adjust the horizontal swing and the horizontal and vertical tilt.
zAfter conrming that the projector lens is on the standard position*1, adjustments should be carried out in order
to make the center of the projector lens perpendicularly to the surface of the projection screen.
zWithout performing keystone correction from the [POSITION] menu of the projector, make adjustments to
ensure that the lens center is perpendicular to the screen surface. If it is not installed perpendicularly, keystone
distortions will occur. While making sure that the screen and projector are aligned opposite each other, adjust
the installation angle. If your projector has a lens shift function, make sure the lens is in standard position*1
before starting to make adjustments.
*1 The standard position is the state where shift lever of the projector lens is set to the center of the lens.
■If the picture is too far to the left or right of the screen
Adjustable span
Hex nut retaining
ceiling mount bolt
Range of
adjustment
± 1.2°
zLoosen the four hex nuts retaining the attachment
plate to the top ceiling mount bolts, then swivel
the projector head horizontally until the picture is
centered on the screen.
zOnce the picture position has been set, be sure to
retighten the nuts securely.
Attention
zIf the center of the screen and center of the
projector do not align, the installation position
may be incorrect. Refer to “Standard installation
dimensions” on pages 6 and 8 and check
the installation dimensions. If your projector has
a lens shift function, you can make adjustments
using this function.
■If the picture is too far to the top or bottom of the screen
Loosen the captive
washer hex head bolts on
each side.
Range of
adjustment
± 3°
Adjustable span
zLoosen the four captive washer hex head bolts that
attach the angle adjusting bracket to the pole base,
then tilt the back of the projector vertically until the
picture is centered on the screen.
zOnce the picture position has been set, be sure to
retighten the bolts securely.
Attention
zDo not over-loosen the captive washer hex head
bolts, which are used to secure the adjustable
bracket to the pole base. Otherwise, the projector
may fall off.
Note
zWhen setting up in portrait, vertical misalignment
cannot be corrected using keystone correction on
the projector so adjust the projected image so that
the left and right edges are parallel.
Adjusting the installation angle

ENGLISH - 19
■If the picture is tilted to the left or right
Adjustable span
Loosen two captive
washer hex head bolts
each at the front and rear.
Range of
adjustment
± 5°
zAdjust to the position where the picture is not tilted
by loosening the captive washer hex bolts xing the
projector mounting bracket and the angle adjusting
bracket (two locations in front and rear), and
rotating the projector.
zOnce the picture position has been set, be sure to
retighten the bolts securely.
Attention
zDo not over-loosen the captive washer hex head
bolts, which are used to secure the adjustable
bracket to the projector mounting bracket.
Otherwise, the projector may fall off.
Attention
zAfter checking the position adjustments, check that the screws have been tightened to the torques specied on
page 9.
Note
zIf there is a keystone effect in the image even after adjusting the installation angle in the [POSITION] menu
of the projector without applying keystone correction, the positional relationship between the screen and the
projector is out of alignment. Check that the screen and projector are aligned opposite each other. Alternatively,
perform the keystone correction at the projector.
Specications
Range of
adjustment
Height (from center of projector
lens to ceiling) 949 mm - 1 429 mm (37-3/8" - 56-1/4")
Horizontal swing angle ±1.2°
Vertical tilt angle ±3°
Horizontal tilt angle ±5°
External dimensions
Width: 344 mm (13-17/32"),
Height: 1 054 mm - 1 534 mm (41-1/2" - 60-13/32"),
Depth: 303 mm (11-15/16")
Weight Approx. 13.5 kg(29.8 lbs.)
Adjusting the installation angle (continued)

20 - ENGLISH
MEMO
