Panduit FMT1J User manual

For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2014 FS066
Page 1 of 4
Fiber Optic Connector Enclosures for Japan
Part Numbers: FMT1J, FMT1J4HWBUDSC, FMT1J6HWBUDSC, FMT1J8HWBUDSC,
FMT1J12HWBUDSC, FMT2J, FMT2J24HWBUDSC, FMT2J16HWBUDSC,
FMT2J18HWBUDSC, FMT2J20HWBUDSC
FMT1J
Contents:
4 - #12-24 Screws
1- Splice Tray with Cover
(FMT1J, FMT1J6HWBUDSC
and FMT1J12HWBUDSC)
Bracket
Enclosure
Cover
Splice tray
Splice tray
cover
Strain relief
Fiber laser beam
warning label
Fiber Caution Label
1RU grommet
Fiber optic cable is sensitive to excessive pulling, bending and crushing forces. Consult the manufacturer’s cable specification sheet for
the specific cable in use.
Follow TIA/EIA 568-A, 569, 606, and 607 installation guidelines where applicable.
DANGER: UNMATED CONNECTORS MAY EMIT INVISIBLE LASER RADIATION. DO NOT LOOK DIRECTLY INTO THE END OF THE
CONNECTOR, DO NOT INSPECT WITH MAGNIFYING DEVICES. MAINTAIN CAP ON UNMATED CONNECTORS.
CAUTION:
Grounding lug
Adapter panel
(FAP3HWBUDSC shown)
1 - Enclosure
4 - Strain Relief
2 - Brackets
2 - Short Grommets (FMT1J)
2 - Long Grommets (FMT2J)
FMT1J6HWBUDSC FMT1J12HWBUDSC
M5 black oxide nut
and flat washer
Wire retainer
Cable Tie
M5 screw
with flat washer
M6 screw
#12-24 screw
FMT1J4HWBUDSC FMT1J8HWBUDSC
FMT2J FMT2J24HWBUDSC
ASSEMBLY
(FMT1J shown)
FMT2J20HWBUDSCFMT2J18HWBUDSCFMT2J16HWBUDSC
4 - Grounding Lug
4 - M6 Screws
4 - M5 Screws with Flat Washers
4 - M5 Black Oxide Nut & Flat Washer
8- PLT2S Cable Tie
1 - Splice Tray without Cover
(FMT1J12HWBUDSC)
1 - Fiber Caution Label
1 - Fiber Laser Beam Warning Label
5 - Wire Retainers

For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2014 FS066
Page 2 of 4
DISCARD
DISCARD
Cut the small
circle for 1"
diameter
innerduct
Cut the large
circle for the
1-1/2" diameter
innerduct
Cut the straight
lines when not
using any
innerduct
Determine which grommet(s) will be used to bring the cable
into the enclosure. Follow the diagram for cutting locations.
If you utilize cable entry through a grommet knockout location,
use pliers to grip the knockout and twist to remove.
To remove strain relief knockout, strike the knockout disk with a
screwdriver and remove disk. Install strain relief.
Note: Enclosure comes with the brackets installed in the
recessed position.
Flush enclosure bracket installation on 19" rack Recessed enclosure bracket installation on 19" rack
Grommet knockout
Strain Relief knockout
Plunger
Part Number
FMT2J16
FMT2J18
FMT2J20
FMT2J24
FMT1J4
FMT1J6
FMT1J8
FMT1J12
FAP*HWBUDSC
23
2
0
4
0
0
2
0
4
8
0
1
0
0
6
6
8

For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2014 FS066
Page 3 of 4
Enclosure mounts to rack with the M5 screws
and flat washers, M6 screws, or #12-24 screws
provided.
Insert cable through appropriate entry location.
Strip one meter of jacket from the end of the cable.
Secure the jacketed cable to the grounding lug.
Tighten strain relief to seal cable.
Strain Relief
Grounding Lug

INSTALLATION INSTRUCTIONS
© Panduit Corp. 2014 FS066
E-mail:
[email protected]m
Phone:
866-405-6654
For Instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp www.panduit.com
Page 4 of 4
Slide cover forward and secure with M5
screw. Affix fiber caution label and fiber
laser beam warning label where they are
clearly visible.
Splice cables per manufacturers instructions.
Gently route excess fiber through the
splice tray following the bend radius
control staying under the guide tabs.
Wire retainers and cable ties are
provided to secure the cable within
the enclosure.
Guide Tab
Bend Radius Control
Splice Connection
