Panduit FRME1 User manual

For Technical Support: www.panduit.com/resources/install_maintain.asp
Page 1 of 2
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2011 FS024
Opticom Fiber Optic Rack Mount Enclosure
Part Number: FRME1
Contents:
(1) FRME Enclosure
(1) Port I.D. Label
(2) EIA Enclosure Brackets
(1) FRME Kit
FRME Kit Contents:
(1) Grounding Lug
(2) Cable Ties
(1) #10-32 x 3/8" Screw
(1) #10-32 x 1/4" Screw
(4) #12-24 x 1/2" Screws
(4) M6 x 1.0 x 15MM Screws
(1) Fiber Caution Label
(1) Fiber Laser Warning Label
(2) Grommets
(2) #10-32 Hex Nuts
(1) Strain Relief Clip
Fiber Caution
Label
Fiber Laser
Warning Label
Grommet
GROMMET CUTTING DIAGRAM
Cut the small
circle for 1"
diameter
innerduct
Cut the large
circle for 1-1/2"
diameter
innerduct
Cut the straight
lines when not
using any
innerduct
Assembly Instructions
Determine the cable entry location on the enclosure.
Remove the knockout by inserting a screwdriver into the slot
located in the center of the knockout and apply a twisting
downward motion then lift out. Insert grommet following proper
cutting diagram. Grounding Lug attaches to a stud at the rear,
inside the enclosure on the top or bottom with a #10-32 nut.
Apply Laser Warning Label and Caution Label in a clearly visible
location. Apply Port I.D. Label(s) on the inside of the tray.
Port I.D. Label
Spool
Grounding Lug
Bracket
FRME1

E-mail:
[email protected]m
Phone:
866-405-6654
For Instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp
Page 2 of 2
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2011 FS024
www.panduit.com
Locate rack bracket on the mid
enclosure mounting holes for
projection mounting
Attach the short leg of the bracket
to the enclosure.
To remove the rear door, deflect the
release tab and slide the door off its
hinge.
Attach Strain Relief Clip with the
#10-32 screw and nut provided.
Bracket orientation for 23 inch
rack
Bracket orientation for projection
mount on a 19 inch rack
