panthera Armrest S3/U3 User manual

Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, 08-761 50 40, www.panthera.se
Manual / Assembly instruction
art.nr.mont-vardarbroms-eng
Rev.2018-01
Assistant brake
With this brake, the assistant will get a good control over the wheelchair when traveling upphills and downhills and in
situations where you need the chair to stand still, the assistant can lock the brake and use them as a park brake.
NOTE! The user must not be left alone unattended in a slope with the park brake activated.
If you wish to combine the assistance brakes with armrest for wheelchairs in the S3-series, you´ll need Armrest S3 26”.
This is to avoid conict between the tyres and the sideguard of the armrest:
Armrest S3/U3 26” pair cpl (incl. attachments) art.no. 4401300 piar.
Armrest S3/U3 26” left art.no. 4401301 1pcs
Armrest S3/U3 26” right art.no. 4401302 1pcs
To brake the wheelchair during motion you
clutch the brake handles easily, equally on
both sides to keep the chair in a straight
course. Release the handles to disengage
the brakes.The S3 series uses the pushbar instead
of the push handles. The function of the brake handle is
however the same.
To activate the park brake when standing still,
you clutch the handles hard and keep them
activated while you poke the red levers with
your nger to make them snap into one of the
slots.
To release the park brake you clutch the hand-
les until the red levers spring out and releases
the brakes and the wheelchair is possible roll.
Assembly
The assistant brake-kit contains 2 rearwheels with drum brakes and 2 brake handles.with wires and attachments for mounting the rearwheels on the
old standard rear axle and attachments for mounting the brake handles on height adjustable push handles / pushbar.
If the chair is not equipped with the old std rear axle and height adjustable push handles / pushbar the order needs to be completed with those.
Mount the old std rear axle,(if not already
done) and switch the inner wheel bracket,
on both sides, with brackets included (art.no.
3300010). Tighten the nut (1) slightly.
The brake lining should be mounted in the
wheel bracket on the rear axle. Apply the
shim, 8 mm (12 mm for S3 series) (3). The
stop arm (2) should be place around the nut
(1, g 1).
Fig. 1 Fig. 2 Fig. 3
Mount the threaded tube in the wheel
bracket. Apply the stop arm (2) around the
nut (1, Fig. 1). Mount shim 8 mm (12 mm for
S3 series) (4) and tighten the nut (5) slightly.
NOTE! The maximum user weight of the wheelchair will be reduced to 100
kg for models with 150 kg user weight.
For S3 series the pushbar is used instead av push
handles.
QR link to video

Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, 08-761 50 40, www.panthera.se
Tighten the nuts rmly with spanners 23 and
24 mm.
Adjust the rear axle to get the right balance of
the chair.
Fig. 6
Fig. 5
Fig. 7
Loosen nut (7) and screw (6) to make the stop arm
(2) come loose from the nut (8). Tighten nut (8) rmly
with spanner 15 mm on both sides to x the rear
axle. Place the stop arm (2) back around the nut (8)
and tighten screw (6) and nut (7).
You may need to ream the axle hole with
reamer 12,7 mm. Test with the rearwheel axle
if it runs smothly in the hole.
Mount height adjustable push handles on
the backrest (if not already done). Remove
the black push handle grip.
Fig. 9-12 shows how to adapt the push handles for
the brake handles. Ready-made push handles has art.
no. 4250047.
Fig. 8 Fig. 9
Fig. 10
Mount the included push handle extensions on
the push handles. Put the push handle in a jaw
vice and drill a 3 mm hole straight through, 5 mm
from the edge.
Enter the included pin in the 3 mm hole with
a hammer.
Use a sharp object to make a small hole on
the back of the push handle grips. This to
help air to escape when mounting the grips.
Put a small amount of contact adhesive in
each of the grips and mount them on the
push handles.
Fig. 11 Fig. 12
NOTE! On Bambino you need to shorten the
pin for the ani-tip lock to app.32 mm to make
space for the stop arm (2).
You may use a punch to knock the pin side ways a little
bit to be able to use an angle grinder to shorten the pin.
Must not be shorter than 31.8 mm to secure the function
of the locking of the anti.tip.
Fig. 4

Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, 08-761 50 40, www.panthera.se
Mount the brake handles on the push hand-
les.
Adjust the brakes with the screws by the brake handles and
by the brake linings.
Fig. 14
Fig. 15
Fig. 13
Mount the push handles on the brackets at the
back rest and pull the wires through the back rest
upholstery.
Fig. 16
Justera bromsarna med skruvarna vid bromshandtaget resp.
bromsbackarna.
Fig. 17
Remove the push bar from the wheelchair Loosen the screw on one side with allenkey
4 mm.
Make sure not to loose the little locking
plate whn the pushbar is taken apart.
Fig. 18 Fig. 19
Mounting of brake handles on push handle for the S3 series

Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, 08-761 50 40, www.panthera.se
Fig. 20
Pull o󰀨 the foam from the pushbar. Cut approx. 12cm on both sides of the foam. Remount the two foam parts on the push-
handle.
Fig. 21 Fig. 22
Fig. 20
Mount the plastic sockets that comes with brake kit,
on both sides of the push handle. Mount the brake handles and tighten the
screws.
Both brake handles mounted on the push-
bar.
Fig. 21 Fig. 22
Fig. 23
If the brake handle is short, 33 cm or below, you
might need to mount the handles as shown in the
image to make room.
Fig. 24
